NORBY Combi One User manual

Combi One/Two - Instructions
Page 1/2
Thank you for purchasing the Combi One/Two Navigation light
The product offer tri-colour Navigation light and anchor light at a very low power consumption. The product is desig-
ned in high quality for many years usage in harsh marine environment.
The installation is easy and the product can be mounted / unmounted easily again with the connector.
Positioning and Operation
•May only be installed on sailing vessels of less than 12 meters length for COMBI ONE and 20 meters for COMBI TWO.
•Carried near the top of the mast, where the light can be seen all round without any obstructions.
•Use only when vessel is driven under sails an no power are used.
Connecting power
• Supply Voltage between 10VDC and 30VDC
• Recommended <2A (slow) fuse or circuit breaker
Specications
Lamp House
Lamp Lens
Mounting bracket
Visible Distance
Light Source
Voltage protection
Power Consumption
Dimensions
Weight
Warranty:
UV/corrosions resistant anodized aluminium or black powdered
UV resistant PMMA
316 stainless steel
1 Nautical Miles (yacht) Navigation light (Combi One)/
2 Nautical Miles (yacht) Navigation light (Combi Two)
2 Nautical Miles (yacht) Anchor light
LED
Reverse polarity protected
Spike protected to +500 volts
Electromagne Ctic ompatibilities (EMC)
Port, Starboard and stern 1 or 2W Allround White / Anchor 1W
75mm (diameter) x 75mm (height)
430g
1years product limited warranty. If you want to claim a warranty for your product,
please write an email to [email protected]
COMBI ONE/TWO

Combi One/Two - Instructions
Page 2/2
Mounting
Step 1
Mount correct bracket to top of mast. Ensure direction arrow is forward. Ensure that the correct bracket (A or B) is
used depending on the slope of the top of the mast. Use fastening materials for your particular mast (not included).
Step 2
Connect cable to vessels lamp circuit. Use Supply Voltage between 10VDC and 30VDC (Typically 12 or 24 Volts systems).
Cabling mounting: Avoid chafe. Route away of electric motors or other items with large inductive elds. Route away
from heat sources such as motor or heater.
Step 3
Connect cable to lamp with the connector.
Service
• Clean ONLY with freshwater or a damp cloth
• DO NOT use alcohol or thinner for cleaning. This could damage the lens.
•Lubricatethe connector pins if needed.
Step 4
Mount lamp to bracket. The install is nished
The lamps must be mounted with the ”zero degrees indication arrow” aligned to the vessel centerline poin-
ting forward.
A
Forward Vessel
Aft Vessel
Forward Vessel
Aft Vessel
Forward Vessel
Aft Vessel
B
Forward Vessel
Aft Vessel
Colour Connect to Power Function
Black Negative ( - )
Yellow Positive ( + ) 1W or 2 W Navigation light
White Positive ( + ) 1W Anchor light
