PARTS LIST
MODELS
DC0040
DC0040K
DC0040S
DC0040V
DC0040 SERIES
PART#622309
NORCOLD 03/24/2008

DC0040SERIESPARTSLIST-PAGE2
REFRIGERATOR ASSEMBLY - DC0040 SERIES

DC0040SERIESPARTSLIST-PAGE3
REFRIGERATOR ASSEMBLY - DC0040 SERIES
NO. PART # DESCRIPTION DC0040 DC0040K DC0040S DC0040V
1 422511100 COVER-CONTROL/BLACK X X X
422511110 COVER-CONTROL/STAINLESS X
2163010700POWERSUPPLY-DC XXXX
3160220100KNOB-THERMOSTAT XXXX
4 422111400 COVER-PLATEFORTRAVEL LATCH X X X
5 300206400 PLATE-FORTRAVEL LATCH X X X
6501042700BOLT/SCREW XXXX
7160932610HINGEASSY XXXX
8416027200BUSHING-RUBBER/CABINET/COOLINGUNITTUBING XXXX
9404006300BUSHING-"I"/PLASTIC/CABINET/COOLINGUNITTUBING XXXX
10645109400HOLDER-SHELF/REAR XXXX
11 422601400 FRAME-CABINET BOTTOM X X X
422601410 FRAME-CABINET BOTTOM/STAINLESS X
12412018700CUSHION-BOTTOMLEG XXXX
1380800432050SCREW-BOTTOMLEG XXXX
14 322376500 FRAME-COVER/CABINET FRONT/4 SIDES/BLACK X X X
15 323009810 FRAME-CABINET SIDE/LH/BLACK X X X
323009850 FRAME-CABINET SIDE/LH/STAINLESS X
16 323009820 FRAME-CABINET SIDE/RH/BLACK X X X
323009860 FRAME-CABINET SIDE/RH/STAINLESS X
17160203000ICECUBETRAY XXXX
18433003800DRAINAGEPAN XXXX
19523003610SHELF-UPPER/HOLDSDRAINAGEPAN XXXX
20523003600SHELF-LOWER XXXX
21160928900FANONLY-50CYCLE/40WATT XXXX
22161011400COOLINGUNIT XXXX
23500013600SCREW XXXX
24605505420THERMISTER-EVAPORATOR XXXX
25422305000HOLDER-THERMISTER/ATEVAPORATOR XXXX
26 16004443008 DOORASSY-WITHOUT DOOR POCKET/BLACK X X X
16004444008 DOOR ASSY-WITHOUT DOORPOCKET/STAINLESS X
27 160934400 DOOR FRAMEASSY-BLACK(FOAMED DOORLINER) X X X
160934420 DOOR FRAME ASSY-STAINLESS (FOAMED DOOR LINER) X
28 302313400 DOOR PANEL-BLACK X X X
302313430 DOORPANEL-STAINLESS X
29 422111300 COVER-HINGE/RH/BLACK X X X
422111310 COVER-HINGE/RH/STAINLESS X
30 422111200 COVER-HINGE/LH X X X
422111210 COVER-HINGE/LH/STAINLESS X
31 160222100 HANDLEASSY-DOOR/BLACK X X X
160222120 HANDLEASSY-DOOR/STAINLESS X
32520004400SPRING-TRAVELLATCH XXXX
33 422602000 DOOR FRAME-BOTTOM/BLACK X X X
422602020 DOORFRAME-BOTTOM/STAINLESS X
34422508710DOORPOCKET-DOORSHELFBIN XXXX
35422508610PARTITION-DOORPOCKET XXXX
NS606901100FERRITECORE XXXX
NS 623009 KIT-GRILL/DC0040K X
NS 621775 WIRING PICTAIL-PACCAR(POWERSUPPLY TO DC SOURCE) X
NS = NOT SHOWN
