Norcold DC-490 User manual

M
PARTS LIST
DC490
PART#619743
NORCOLD 10/30/2002
DC490V
DE490

DE490/DC490/DC490V PARTSLIST-PAGE 2
REFRIGERATOR ASSEMBLY - DE490/DC490/DC490V

DE490/DC490/DC490V PARTSLIST -PAGE 3
REFRIGERATOR ASSEMBLY - DE490/DC490/DC490V
(CONTINUED ON PAGE 4)
NS= NOTSHOWN
NO. PART # DESCRIPTION DE490 DC490 DC490V
2 8050050104 SCREW-TAPPING (DE490 ENDED JUNE2000 - SERIAL MNN) X X
501042700 BOLT/SCREW (DE490 BEGANJULY 2000 - SERIAL MON) X X
3 83400500010 WASHER-TEETHLOCK X X X
4 160924300 HOLDER ASSY-TRAVEL LATCH (DE490 ENDED JUNE 2000-MNN) X
NS 304111010 PLATE-TRAVEL PIN/3 HOLE(DE490 BEGAN JULY 2000-SERIAL # MON
)
XX
NS 160207620 TRAVEL PIN ASSY (USE160207630) X
NS 160207630 TRAVEL PIN ASSY-1.73" (DE490 BEGAN JULY 2000- SERIAL# MON) X X
5 505502330 HINGEPIN-0.625" (DE490 ENDED JUNE2000-SERIAL#MNN) X X
6 304111000 PLATE-HINGE(DE490 BEGAN JULY 2000-SERIAL# MON) X X
NS 160932600 HINGE/PINASSY-1.5" ( PIN WELDED INTO HINGE) X X
7 8300087001 WASHER X X X
8 412000800 CUSHION-RUBBER LEG X X
360906500 SPACER-LEG/METAL X
9 322301900 SUPPORT-BOTTOM RAIL X X X
10 8010060401 SCREW (USEWITH 412000800 CUSHION-RUBBER LEG) X X
500013500 SCREW (USEWITH 360906500 SPACER-LEG/METAL) X
11 160924000 INNER CASEASSY X X X
12 80830441220 SCREW-TAPPING X X X
13 160904800 HINGE-EVAPORATOR DOOR X X X
14 422600120 EVAPORATORFRAME X X X
15 160206700 KNOB-THERMOSTAT X X X
16 160203000 ICECUBETRAY X X X
17 433000500 DRAINAGEPAN X X X
18-A 523001210 SHELF-TOP X X X
18-B 523001220 SHELF-BOTTOM X X X
19 645103950 HOLDER-SHELF X X X
20 545074700 MARK-EVAPORATORFRAME X
545020770 MARK-EVAPORATORFRAME X X
21 430307000 PLATE-"I" X X X
22 645100510 FASTENER-PLASTIC RIVET X X X
23 416004200 BUSHING-FORBLIND PLATE X X X
24 160114020 THERMOSTAT X X X
25 160113910 POWER SUPPLY X
160114900 POWER SUPPLY (ALTERNATEPART # 160113920) X X
28 8083044121 SCREW-TRUSS TAPPING/4 X 12 X X X
29 834004000 WASHER-TEETHLOCK X X X
30 8000040121 SCREW X X X
31 8084043081 SCREW-TRUSS TAPPING/4 X 8 X X X
32 322119100 COVER-DC WIRES X
33 546017120 CAUTIONPLATE X
35 601600010 GROMMET-STRAINRELIEF X X X
36 191203410 CORD ASSY-AC X
NS 190261900 COUPLERASSY-DC WIRES X X
38 439010300 HEAT INSULATOR X X X

DE490/DC490/DC490V PARTSLIST -PAGE 4
REFRIGERATOR ASSEMBLY - DE490/DC490/DC490V (CONTINUED FROM PAGE 3)
NO. PART # DESCRIPTION DE490 DC490 DC490V
39 161212700 BLIND PLATE X X
161212720 BLIND PLATE X
40 8083044121 SCREW-TRUSS TAPPING/4 X 12 X X X
41 161008000 COOLING UNIT X
161008040 COOLING UNIT XX
42 416004200 BUSHING-FORBLIND PLATE X X X
43 8073044121 SCREW-TAPPING/WITH TEETH LOCK WASHER X X
44 422305000 HOLDER-THERMISTER/AT EVAPORATOR X X X
45 8080043082 SCREW-TAPPING X X X
46 321105900 HOLDER-COOLING UNIT X X X
47 322005310 HOLDER-CONDENSER WASHER X X X
48 8073044124 SCREW-TAPPING X X X
49 605505400 THERMISTER-EVAPORATOR X X X
53 190264710 COUPLERASSY X X X
54 192116607 CORD WITH TERMINAL X X X
55 8084043081 SCREW-TRUSS TAPPING/4 X 8 * *
56 8071043163 SCREW-TAPPING X X X
57 160027910 DOORASSY-WITHOUT POCKETS X X X
58 422508900 DOOR POCKET-DOORSHELF BIN X X X
59 422508600 PARTITION-DOORPOCKET X X X
60 160923910 DOORFRAMEASSY-FOAMED LINER X X X
61 302311710 DOORPANEL-BLACK X X X
62 412006690 CUSHION-VERTICAL/DOORFRAMEASSY/FOAM X X X
63 412006680 CUSHION-HORIZONTAL/DOOR FRAMEASSY/FOAM X X X
64 427602720 DOORFRAME-BOTTOM/GRAY X X X
65 160003820 EVAPORATORDOOR ASSY-BLACK X X X
66 433101000 EVAPORATORDOOR LINER-EVAPORATORDOOR X X X
67 414800700 DOORGASKET-EVAPORATOR X X X
68 439004800 HEAT INSULATOR-EVAPORATORDOORASSY X X X
69 422500620 EVAPORATORDOOR PANEL-BLACK X X X
70 8260041009 NUT XXX
71 8320042001 WASHER-SPRING X X X
72 8300041009 WASHER X X X
73 520600200 TORSION BAR-EVAPORATORDOOR X X X
74 8000040124 SCREW X X X
75 8083034062 SCREW-TAPPING X X X
76 83400400010 WASHER-TEETHLOCK X X X
77 160930600 FAN ASSY (USE160930600) X
160930640 FAN ASSY (USE160930600) X X
160928900 FAN ONLY-50 CYCLE/40 WATT X X X
NS 601058020 COUPLERASSY-FAN X X X
NS 500013400 SCREW-BOTTOM RAIL & CUSHION X
NS 500013600 SCREW X
NS 16011620000 WARNING DEVICE-AMBIENT TEMPERATURE X
