Nordmende DFSN60 User manual

Dishwasher
Instruction
InstructionInstruction
Instruction Manual
Manual Manual
Manual
Geschirrspüler
Gebrauchsanweisung
GebrauchsanweisungGebrauchsanweisung
Gebrauchsanweisung
DFSN60

CONTENTS
Getting familiar with your machine …………………………………………… 4
•Technical specifications …………………………………………………….. 6
•Conformity with the standards and Test data …………………………….. 6
Safety information and Recommendations…………………………………..
6
•Recycling .......………………………......................................................... 6
•Safety information …………………………………………………………… 6
•Recommendations …...……………………………………………………… 8
•Items not suitable for dishwashing ………………………………………… 8
Installing the machine ………………………………………………………….. 8
•Positioning the machine …………………………………………………….. 8
•Water connections …………………............................................................... 8
•Water inlet hose ….………………………………………………………….. 9
•Water outlet hose …..……………….............................................................. 9
•Electrical connection………………………………………………………… 10
•Prior to using the machine …………………………………………………. 11
Preparing the machine for use ………………………………………………… 11
•The importance of water decalcification ………………………………….. 11
•Filling with salt ……………………………………………………………….. 11
•Testing strip…………………………………………………………………… 12
•Adjusting salt consumption…………………………………………………. 12
•Detergent usage ……………………........................................................ 14
•Filling the detergent compartment…………………………………………. 14
•Combined detergent….……………………………………………………… 14
•Filling with rinse aid and making the setting………………………………. 15
1

Loadingyour dishwasher.……………………………………………………. 16
•Top basket…………………………………………………………………... 16
•Lower basket………………………………………………………………... 17
•Alternativebasketloads…………………………………………………...18
•StandardloadingandTestdata…………………………………………..19
Programmedescriptions .……………………………………………………..20
•Programmeitems…………………………………………………………..20
Switching on the machine andselecting aprogramme……………........21
•Switchingonthemachine…………………………………………………. 21
•Programmefollow-up………………………………………………………21
•Changingaprogramme……………………………………………………21
•Changingaprogrammewithresetting…………………………………...22
•Switchingthemachineoff….……………………………………………...22
Maintenanceand Cleaning ........................................................................23
•Filters..………………………………………………………………………23
•Sprayarms…………………………………………………………………. 24
•Hosefilter……………………………………………………………………24
Failure codesand whattodo incaseof failure ………………………… 25
Practicaland useful information…….........................................................27
2

1.
Upper basket with racks
2. Upper spray arm
3. Lower basket
4. Lower spray arm
5. Filters
6. Rating plate
7. Control Panel
8. Detergent and rinse-aid dispenser
9. Cutlery basket
10. Lower basket handle
11. Salt dispenser
12
13.
Upper basket track latch
Top basket handle
14
Active drying unit: This system provides
better drying performance for your dishes.
3

1.) Power On/Off Button
When the Power On/Off button is pressed, end of program
indicator starts lighting.
2.) Program Display
Program display indicates the times of the programs and the
remaining time during the program flow. You can also follow-up
the selected programs by this display.
3.) Program selection button
Withtheprogramselectorbutton,youcanselectasuitable
program for your dishes.
4.) Delay Timer Button
You can delay the start time of a selected program for 1-2 ….19
hours by pressing the delay timer button of your machine. When
you press the delay timer button, delay “1h” appears on the
program display. If you continue pressing the delay timer button,
1-2… 19 will be displayed respectively. You can activate the
delayed start by selecting the delay time and the desired washing
program with the program selection button. It is also possible to
select the program first and the delayed start afterwards. If you
want to change or cancel the delayed start time, you can adjust it
with the delay timer button; it will be activated according to the
last value entered.
5.) Tablet Detergent Button ( 3 in 1 button )
Press tablet detergent button when you use combined detergents
that include salt and rinse aid.
GETTING FAMILIAR WITH YOUR MACHINE
4
