CHROMATOGRAPHY REFRIGERATOR
Nor-Lake, Inc.
Registered to ISO 9001:2000
File No. A3204
NOR-LAKE SCIENTIFIC
A Division of
NOR-LAKE, INCORPORATED
727 Second Street
P.O. Box 248
Hudson, Wisconsin 54016
800-477-5253
715-386-2323
800-388-5253 PARTS
715-386-4290 FAX
www.norlake.com
NSCR241WWG/ NSCR331WWG/ NSCR522WWG/ NSCR803WWG/
Designed to meet the demanding requirements of
scientific and laboratory applications. Special cabinet
incorporates industrial quality with a heavy duty
refrigeration system to maintain your valuable products.
NSCR331WWG/
Standard Product Features:
■Adjustable control range from 2oC to 10oC. Factory preset to
4oC
■Digital LED microprocessor control with warm and cold audible
and visual alarms with remote alarm contacts
■Exterior front, sides and back are painted white. Exterior top
and bottom are galvanized steel
■Interior is painted white
■The complete cabinet is foamed-in-place with high
density polyurethane foam insulation
■Heavy duty door with pivot hinges and pull handles
■Magnetic door gaskets
■4 casters on one and two door models (2 locking), 6 casters
(3 locking) on three door model
■3 half size cantilevered solid stainless steel shelves per unit
■3 epoxy coated wire shelves per additional door section on
two and three door models
■Two access ports 2” sleeves with covers
■Full size, double pane glass doors with
anit-condensate heater wires
■Key door locks
■Interior light, switch activated
■Internal electrical outlet
■Complete top mounted refrigeration
system, maximizing the storage area
■Forced air flow refrigerating optimizes air
flow and temperature uniformity
■Air-cooled condensing unit
■Automatic defrost
■Warranties: (USA and Canada)
18 months parts and labor. 5 year
compressor. 18 months parts (International)
■UL, C-UL and CE Mark, CEC California Energy Commission
Optional Features:
■Extra shelves
■Reverse hinge doors
■Legs in lieu of casters
■Solid doors
■4-20 ma output
■Stainless steel exterior
■Stainless steel interior
■Temperature recorder
■Chart paper
SCIENTIFIC

SPECIFICATIONS
Models NSCR241WWG/0 NSCR331WWG/0 NSCR522WWG/0 NSCR803WWG/8
Models NSCR241WWG/5 NSCR331WWG/5 NSCR522WWG/5 NSCR803WWG/5
Crated Height 81” (205.7 cm) 91-3/4” (235 cm) 81” (205.7 cm) 81” (205.7 cm)
Crated Width 31” (78.7 cm) 35-1/4” (89.5 cm) 59” (149.9 cm) 86” (218.4 cm)
Crated Depth 38” (96.5 cm) 39” (99.1 cm) 38” (96.5 cm) 38” (96.5 cm)
Crated Weight (lbs) (kg) 365 (165.5 kg) 625 (284 kg) 545 (247.2 kg) 750 (340.1 kg)
Interior Height 59” (149.9 cm) 67” (170.2 cm) 59” (149.9 cm) 59” (149.9 cm)
Interior Width 23-1/2” (59.7 cm) 27-3/4” (70.4 cm) 51” (129.5 cm) 78-1/2” (199.4 cm)
Interior Depth 30” (76.2 cm) 31” (78.7 cm) 30” (76.2 cm) 30” (76.2 cm)
Overall Height 80-3/8” (204.2 cm) 88 3/8” (224.7 cm) 80-3/8” (204.2 cm) 80-3/8” (204.2 cm)
Overall Width 27-1/2” (69.9 cm) 31-3/4” (80.6 cm) 55” (139.7 cm) 82-1/2” (209.6 cm)
Overall Depth 35-1/2” (90.2 cm) 36-1/2” (92.7 cm) 35-1/2” (90.2 cm) 35-1/2” (90.2 cm)
Gross Cubage (ft.3) (m3) 24.0 (0.68) 33 (0.93) 52.0 (1.47) 80.0 (2.26)
Epoxy Coated Shelves Optional Optional 3 6
Number of Solid Stainless
Steel Shelves halfsize
33 3 3
Number of Casters 4 (2 Locking) 4 (2 Locking) 4 (2 Locking) 6 (3 Locking)
Condensing Unit Size 1/4 1/3 1/2 3/4
Refrigerant R134A R134A R134A R134A
Maximum Fuse Size 15 15 15 15
Total Amp Draw /0, /8 8.6 8.6 10.7 8.3
Total Amp Draw /5 3.2 3.2 4.2 8.1
Specifications subject to change without notice.
Voltage Model
Suffix Code Voltage Description NEMA Plug NEMA Receptacle
/0 115V, 1PH, 60HZ 5-15P 5-15R
/5 230V, 1PH, 50HZ
Power Inlet
(IEC 60320) Module
Cord Supplied
Locally
/8 115/208-230V/1PH60HZ L14-20P L-14-20R
