Nova COMET 14DR User manual

127-0919-001
OPERATION MANUA L
COMET 14DR Lathe™
Publication: 127-0919-001
Date: 6 September 2019
Models:
46900 - USA

127-0919-001
Contact
Teknatool International Ltd
Phone: [phone]
Teknatool USA
Phone: [phone]
Customer Solutions
For all worldwide Inquiries, Repairs or Services (issues must be in writing)
Email: [e-mail]
Or you can contact the retailer where you purchased your NOVA COMET 14DR, for the contact details please
see our website www.teknatool.com

127-0919-001
Table of Contents
Contact..............................................................................................................................................................2
Table of Contents..............................................................................................................................................1
General Safety Rules ........................................................................................................................................1
NOVA COMET 14DR Features .........................................................................................................................2
Lathe Features...............................................................................................................................................2
Lathe Specifications.......................................................................................................................................3
Package Contents.............................................................................................................................................4
Connecting to Power .........................................................................................................................................5
Surge Protection (Ground Fault Interrupters (GFI) / Residual Current Detectors (RCD)) ................................5
Setting up your NOVA COMET 14DR lathe.......................................................................................................6
Setting up your workshop environment ..........................................................................................................6
Motor Break-in Operation...............................................................................................................................6
Assembling the NOVA COMET 14DR Lathe .....................................................................................................7
Assembling the Tailstock................................................................................................................................7
Installing the quill lock handle .........................................................................................................................7
Operating the NOVA COMET 14DR Lathe........................................................................................................7
Turning the lathe ON / OFF............................................................................................................................7
Switching between Forward and Reverse Modes...........................................................................................8
Changing the Speed ......................................................................................................................................9
Changing Belt Positions..................................................................................................................................9
Using the spindle index................................................................................................................................11
Locking and Unlocking the Spindle...............................................................................................................11
Mounting a Faceplate or Chuck onto the lathe..............................................................................................11
Operating the Tool slide...............................................................................................................................12
Positioning the tool slide...............................................................................................................................12
Adjusting the tool rest height.........................................................................................................................12
Operating the Tailstock ................................................................................................................................13
Positioning the tailstock................................................................................................................................13
Extending / Contacting the tailstock quill.......................................................................................................13
Locking the tailstock quill in position.............................................................................................................13
Mounting accessories into the tailstock quill .................................................................................................13
Dismounting the accessories from the tailstock quill.....................................................................................13
Maintaining the NOVA Lathe ...........................................................................................................................14
Maintenance after each use.........................................................................................................................14
Monthly maintenance...................................................................................................................................14
6-months Maintenance.................................................................................................................................14
Cleaning the Tool slide.................................................................................................................................14
Cleaning the Tailstock..................................................................................................................................14
Troubleshooting...............................................................................................................................................16
Mechanical Issue.........................................................................................................................................16
Electrical Issue.............................................................................................................................................16
NOVA Teknatool Warranty..............................................................................................................................17
NOVA COMET 14DR –EXPLODED PARTS ..................................................................................................18
NOVA COMET 14DR –PARTS LIST..............................................................................................................19
NOVA COMET 14DR –Subassembly list........................................................................................................20
Appendix .........................................................................................................................................................21
Using the included knockout bar accessory .................................................................................................21
Controller Wiring Diagram............................................................................................................................21

1
127-0919-001
General Safety Rules
WARNING
Failure to follow these rules may result in serious personal injury or death.
❖IMPORTANT: Before switching the lathe on, ALWAYS check the machine for the correct setting and speed
1. BEFORE OPERATING THE TOOL READ THE
MANUAL! Learn the machine’s application and
limitations, plus the specific hazards particular to it.
2. ALWAYS USE SAFETY GLASSES (must be ANSI
approved) Everyday eyeglasses usually are only impact
resistant and safety glasses only protect eyes. A full-face
shield will protect the eyes and face. Also use face or dust
mask if sanding operation is dusty.
3. WEAR PROPER APPAREL. Do not wear loose clothing,
gloves, neckties, rings, bracelets or other jewelry which
may get caught in moving parts. Nonslip footwear is
recommended. Wear protective hair covering to contain
long hair.
4. USE EAR PROTECTORS. Use ear muffs for extended
period of operation. Use muffs rated to 103 DBA LEQ (8
hour).
5. DO NOT USE IN DANGEROUS ENVIRONMENT. Don’t
use power tools in damp or wet locations, or expose them
to rain. Keep work area well lighted. The NOVA COMET
14DR is intended for indoor use only. Failure to do so may
void the warranty.
14. KEEP GUARDS IN PLACE and in working order.
15. USE CORRECT TOOLS. Do not use a tool or attachment to
do a job for which it was not designed.
16. USE RECOMMENDED NOVA ACCESSORIES. The use of
improper accessories may cause hazards.
17. DO NOT FORCE THE TOOL. It will do the job better and be
safer at the rate for which it was designed.
18. MAINTAIN TOOLS IN TOP CONDITION. Keep tools sharp
and clean for best and safest performance. Follow
instructions for lubricating and changing accessories.
19. NEVER STAND ON TOOL. Serious injury could occur if the
tool is tipped or if the cutting tool is accidentally contacted.
20. REMOVE ADJUSTING KEYS AND WRENCHES. Form a
habit of checking to see that keys and adjusting wrenches
are removed from tool before turning it on.
21. DO NOT OVERREACH. Keep proper footing and balance at
all times.
22. DIRECTION OF FEED.Mind the direction of
spindle/chuck/work to ensure a safe environment.
23. PAY ATTENTION TO WORK. Concentrate on your work. If
you become tired or frustrated, leave it for a while and rest.
24. SECURE WORK. Use clamps or a vice to hold work when
practical. Severe injury or death can occur if an object comes
free as it can become a dangerous projectile.
25. CHECK DAMAGED PARTS. Before further use of the tool,
any part that is damaged should be carefully checked to
ensure that it will operate properly and perform its intended
function. Check for alignment of moving parts, binding of
moving parts, mounting, and any other conditions that may
affect its operation. Any damaged part should be properly
repaired or replaced.
26. DRUGS, ALCOHOL, MEDICATION. Do not operate
machine while under the influence of drugs, alcohol, or any
medication.
27. DUST WARNING. The dust generated by certain woods
and wood products can be harmful to your health. Always
operate machinery in well-ventilated areas and provide
means for proper dust removal. Use wood dust collection
systems whenever possible.
28. DO NOT MODIFY OR USE THE LATHE FOR USES
OTHER THAN FOR WHICH IT WAS DESIGNED.
29. CALIFORNIA PROPOSITION 65 –SEE PAGE 22
6. KEEP WORK AREA CLEAN. Cluttered areas/benches
invite accidents. Build-up of sawdust is a fire hazard.
7. KEEP CHILDREN AND VISITORS AWAY. The NOVA
COMET 14DR is not recommended for children and ailing
persons. Such personnel and onlookers should be kept a
safe distance from work area.
8. MAKE WORKSHOP CHILDPROOF with locks, master
switches, or by removing starter keys.
9. GROUND ALL TOOLS. If the tool is equipped with a
three-prong plug, it should be plugged into a three-hole
electrical receptacle. If an adapter is used to
accommodate a two-prong receptacle, the adapter plug
must be attached to a known ground. Never remove the
third prong and add surge protection.
10. MAKE SURE TOOL IS DISCONNECTED FROM POWER
SOURCE whilst in service/maintenance mode.
11. DISCONNECT TOOLS FROM WALL SOCKET before
servicing and when changing accessories such as bits,
cutters, fuses, etc.
12. AVOID ACCIDENTAL STARTING. Make sure switch is in
the “Off” position before plugging in power cord.
13. NEVER LEAVE MACHINE RUNNING UNATTENDED.
Do not leave machine unless it is turned off and has come
to a complete stop.

2
127-0919-001
NOVA COMET 14DR Features
Lathe Features
Icon
Feature
Description
Versatile Variable Speed Range
2-step Electronic Variable Speed range.
Low range: slower speeds from 250 RPM up to 1100 RPM for
larger spindle and bowl work.
Fast range: from 750 RPM up to 3450 RPM for miniature
turning work.
Dial-In easy to use speed adjustment
with speed screen
Quickly dial-in the correct speed for the job, material and
conditions. you’re not limited to potentially dangerous fixed-
speed steps. The NOVA Comet 14DR is the perfect solution
for a wide variety of projects from small pens to larger bowls
and platters. The easy to read screen lets you know at what
speed you are turning.
Forward and reversing function
Quickly and easily change direction between forward and
reverse. This offers you additional flexibility and allows
you to achieve a superior finish, reducing the need for
extensive sanding.
Flexible capacity to match your project
•14"/355mm Capacity Over Bed
•18.5”/469mm Between Centers standard
•44.1”/1120mm between Centers with ONE extra
accessory bed extension (extra purchase) to extend the
beds as long your project demands.
Solid, precision cast iron for durability,
stability and vibration dampening
CAD designed webbing to absorb vibration throughout the
bed length.
Exceptional structural strength, precision machined for
superior fit and finish.
Easy belt/ pulley access
Quick and fast to lift cover and adjust belt.
Strong 2MT spindles
The precision machined 2MT allows for quick and secure
mounting of accessories onto the lathe.
Quick action cam controls
With comfortable rubber grip for fast and secure locking
Large range of NOVA accessories
NOVA Chucks and Jaws, Faceplates, Chisels, Centers all
enhance your use of the NOVA Comet 14DR Midi Lathe.

3
127-0919-001
Lathe Specifications
Metric
Imperial
Swing Over Bed
177.8mm
7”
Distance Between Centres
469.9mm
18.5”
Swing Over Tool Rest Base
285.75mm
11.25”
Maximum distance
Tool rest to spindle centre
217.49mm
8.5625”
Floor to Centre Height
381mm
15”
Overall Size
920mm(l) x 330mm(w) x 510mm(h)
32.7” (l) x 12.99” (w) x 20” (h)
Footprint
822.32mm (l) x 215.9mm(w)
32.375” (l) x 8.5” (w)
Weight
47 Kg
103.61 lb
Headstock
Spindle Thread
1” x 8TPI (Right Hand Thread)
Headstock Spindle Taper
Morse Taper #2 (MT2)
Spindle Bore
10.31mm
13/32” or .40”
Tailstock
Quill Taper
Morse Taper #2 (MT2)
Tool Rest
Width
152.4mm
6”
Shaft Diameter
25.4mm
1”
Post Length
88.9mm
3.5”
Base Height
84.14mm
3.3125”
Construction
Bed
Precision –Ground Cast Iron
Frame
Cast Iron & Steel
Headstock
Cast Iron & Steel
Tailstock
Cast Iron & Steel
Pain Type/ Finish
Enamel/Powder Coat
Other Specification
Bed Width
203.2mm
8”
Faceplate Size
80mm
3 - 9/64”
Electrical Specifications
Input Voltage
120V
Input Frequency
60Hz
Full Load Input
Current Rating
7.3A
Power Input Plug Type
NEMA 5-15P
Motor Specifications
Motor Type
Universal Brush Type
Motor power output
0.75KW (1HP)
Motor speed
1400 RPM
Phase
Single Phase
Input Current
7.3A
IMPORANT NOTE
Due to NOVA’s continuous product improvement and development policy, specifications, features and images contained in this manual may change without
notice. Teknatool is not responsible for omissions or errors herein or for incidental damages in connection with the furnishing of this information.

4
127-0919-001
Package Contents
Package Items
Description
SKU
Quantity
1
COMET 14-DR Lathe
46900
1
2
Faceplate
4718065
1
3
Spanner
4718071
1
4
Heavy Duty Live Centre
4718069
1
5
Live Centre
4718066
1
6
Spur Centre
4718064
1
7
3mm Hex Key
AK03
1
8
5mm Hex Key
AK05
1
9
8mm Hex Key
AK08
1
10
Operating/Knock Out Bar
4718071
1
11
Handwheel
471834
1
12
Handwheel Handle
4718035
1
13
Handwheel Handle Screw
4718036
1
14
Power Cord
4718063
1
15
Tool Holder
4718072
1
16
Tool Rest Post
9095
1
17
Tool Rest Bar
9027
1

5
127-0919-001
Connecting to Power
WARNING
Improper power connection may result in a risk of electrical hazard
Before plugging the NOVA COMET 14DR lathe, shut off the power source
The power cord installed on the NOVA COMET 14DR lathe will have a grounding three-prong plug. The plug
must be connected to a matching outlet that his properly installed and grounded in accordance with local
electrical codes.
For 115V outlet only:
A temporary adapter can be used to plug into a two-pole outlet if a three-prong outlet is unavailable in your
environment. The ground tab on the adapter must be connected to the screw on the outlet for proper grounding.
This adaptor should only be used until a qualified electrician can install a properly grounded outlet.
➢Note: If an extension cable is required, make sure to check the following:
1. Extension cable gauge
2. Is the cable properly insulated?
If in any doubt, please contact your local electrician to inspect the cord according to the local electrical standards
before using it.
Surge Protection (Ground Fault Interrupters (GFI) / Residual Current Detectors (RCD))
It is recommended to use a surge protection device rated to 15A for the best protection of the lathe. GFI and
RCD are the recommended standard type of surge protection device.

6
127-0919-001
Setting up your NOVA COMET 14DR lathe
Setting up your workshop environment
Your workshop should be set up appropriately for you to effectively use the lathe. The workshop should be
setup with the following factors taken into consideration:
1. Lathe location
Position the NOVA COMET 14DR lathe close to a power source, and in an area with enough clearance for
workloads. Other machines in the workshop should not interfere with the movement/power of the lathe.
2. Lighting
The work shop should have adequate lighting, with enough lighting around the lathe not to cast shadows
upon the workpiece. If possible, locate the lathe near a window. A portable spotlight might be helpful.
3. Ventilation
Workshop must have an adequate level of ventilation. The level of required ventilation depends on the size
of the workshop and the amount of work that is done within the workshop. The use of dust collectors and
filters will minimize your health risk.
4. Elements/Environment
Every shop environment is different. The physical environment where the machine is operated is important
for safe operation and longevity of machine components. For best results, operate this machine in a dry
environment that is free from excessive moisture, hazardous chemicals, airborne abrasives, or extreme
conditions. Extreme conditions for this type of machinery are generally those where the ambient temperature
range exceeds 41° –104°F (5° - 40°C); the relative humidity range exceeds 20%–95% (non-condensing).
Failure to do so could result in serious personal injury, damage to equipment, and/or poor work results.
Motor Break-in Operation
Run the lathe motor without any load for approximately 30~45 minutes before start using the lathe to cut
wood/apply significant load. The motor and bearings break-in should be done at the fastest speed possible and
not be unattended.
The NOVA COMET 14DR features a variable speed DC motor that contains brushes that make physical contact
with the motor rotor. For the best motor performance and life, the motor brushes should be slightly worn out to
ensure the brushes are making good contact.
➢Note: A clicking/swishing noise in the motor is normal which will reduce as the brushes wear in.

7
127-0919-001
Assembling the NOVA COMET 14DR Lathe
Assembling the Tailstock
1. Insert the wheel handle screw into the
handwheel handle
2. Use a flat head screw driver to screw on the
handwheel handle onto the quill adjusting
wheel and tighten.
Installing the quill lock handle
1. Turn the tailstock quill so the machined
slot is in line with the quill lock handle
hole.
2. Thread the tailstock quill lock handle into
the tailstock body.
3. Make sure the tailstock quill does not
rotate with the handle rotation.
Operating the NOVA COMET 14DR Lathe
Turning the lathe ON / OFF
The LCD digital speed readout will light
up and display “0” when the lathe is
plugged intothe power source and “FWD”
LED light of the left side of the will begin
to flash.
LED flashing
Tailstock
Handwheel
Handwheel handle
Handwheel Screw
Tailstock Quill Slot
Tailstock Quill
Lock Handle

8
127-0919-001
Press the <FWD/ REV> key once and the
LED light will become solidly lit.
Press the green <ON> button located on
the lower half of the lathe control panel
when the LED light is solid lit to start the
motor.
Press the red <OFF> button to turn the
motor off while running.
➢Note: The lathe motor will not turn on when the <ON> button is pressed while the LED light
is flashing however, the motor will start immediately after the <FWD/ REV> key is pressed.
Switching between Forward and Reverse Modes
The forward and reverse can be switched by
holding down the <FWD/ REV> key until the
LED light startsflashing on the alternative line.
Press the <FWD/ RED> key once before to
make the LED solidly lit before pressing the
<ON> button to start the lathe motor
LED solid lit after
pressing <FWD/ REV> key
Press Once
Press to start the
motor when LED is lit
solid
Long Press
Press to stop the
motor while running.

9
127-0919-001
Changing the Speed
The motor speed can be controlled by turning the control knob.
1. Turn the speed control knob in the clockwise
direction to increase spindle speed.
2. Turn the speed control knob in anti-clockwise
direction to reduce the spindle speed.
NOVA COMET 14DR features 2 speed positions as shown below:
Speed Band
RPM Range
Type of Work
1
(Motor pulley small, Spindle pulley big)
250 ~ 1900
Large faceplate and spindle work
2
(Motor pulley big, Spindle pulley small)
1901 ~ 3850
Small turning and miniature turning
work
This speed range can be selected by changing the belt pulley position.
Changing Belt Positions
Ensure the lathe is powered off and disconnected
from the power source before commencing to
change the belt positions on the lathe to avoid
accidental motion during the belt changing
procedure.
Lift the Motor Place Handle upwards to unlock the
motor relieving tension on the belt
Unscrew the headstock guard lock knob to unlock
the headstock guard.
Increase Speed
Decrease Speed
Headstock Guard
Headstock
Guard
Lock Knob
Motor
Motor Plate
Handle
Motor Lock Knob

10
127-0919-001
Open the bed belt cover by loosening the motor
lock knob to gain access to the motor belt pulley.
Lift the headstock guard to open and gain access
to the spindle pulley + belt.
Remove the drive belt from the motor pulley by
lifting the motor handle plate and making enough
space. There will be approximately ¾” (20mm) of
vertical movement on the motor handle.
1. Place the belt onto the desired spindle pulley
once the belt is removed from the motor pulley.
2. Place the belt on the corresponding step on the
motor pulley.
3. Apply a firm downwards force by a thumb onto
the motor handle plate to tension the belt.
4. Caution: Excessive belt tension may cause the
belt or the pulleys to break.
5. Turn the bed belt cover to close and relock the
cover.
6. Tighten the motor locking knob while applying
correct tension.
Check the belt tension by applying moderate pressure at approximately halfway between the spindle pulley and
the motor pulley. The belt should have a deflection of approximately ½” (13mm) when an appropriate tension is
applied on the belt.
(1) Loosen
motor lock
knob
(2) Take the belt off from the spindle pulley
and place it onto the desired step.
(2) Loosen the cover
locking screw
(3) Lift and turn the cover
(1) Take the belt off from the motor pulley
and place it onto the desired step.
Motor Pulley

11
127-0919-001
Using the spindle index
There are 12 index positions on the NOVA COMET 14DR spindle; 30 degrees apart.
Locking and Unlocking the Spindle
Pull the lock pin away from the headstock and turn the lock pin 180 degrees to switch between the lock and
unlock positions.
Looking from the back side of the lathe, the state that is described on the right-hand side shows the spindle
lock state:
Unlocked Position
Locked Position
Mounting a Faceplate or Chuck onto the lathe
Ensure to lock the spindle using the spindle lock
function before commencing the procedure.
Use the Allen key to loosen/ remove the safety screw
from the faceplate before installing the faceplate.
Thread the faceplate onto the spindle thread all the
way. Ensure the faceplate meets the spindle bearings.
Thread/tighten the safety screw on the face plate to
lock the face plate in place.
Unlock the spindle before turning the machine on.
Spindle
Index Wheel
Spindle Index
Lock
Spindle Pulley
Spindle Lock Pin
Face plate
Safety screw
Spindle locked in
position via spindle
lock

12
127-0919-001
Operating the Tool slide
Positioning the tool slide
1. Turn the cam shaft handle in either clockwise or anti-clockwise direction to loosen the tool slide.
➢Note: The handle should be free to turn around when the tool slide is loose.
2. The tool slide can be positioned anywhere along the lathe bed once the cam shaft handle is loosened
3. Lock the tool slide at the desired position by turning the cam shaft handle in one direction until it becomes
firm.
❖Tip: Do not position the tool slide so most of the tool rest body is hanging off
from the lathe bed, as this will impose a higher chance of the tool rest
breaking when there is a catch during turning.
Adjusting the tool rest height
1. Loosen the tool reset locking handle to free the tool rest.
2. Pull out/ push in the tool rest into the tool slide body to adjust the tool rest to the desired height.
3. Tighten the tool rest locking handle to lock the tool rest height into place.

13
127-0919-001
Operating the Tailstock
Positioning the tailstock
1. Loosen the tailstock locking handle to loosen the tailstock body so it can slide along the lathe bed.
2. Slide the tailstock along the body to the desired location on the lathe bed.
3. Lock the tailstock in position by tightening the tailstock lock handle.
Extending / Contacting the tailstock quill
1. Make sure to loosen the tailstock quill lock before extending/ contracting the tailstock quill to prevent
damage to the quill.
2. (Looking from the tailstock towards the headstock) Turn the tailstock handwheel in the clockwise
direction to extend the tailstock quill.
3. (Looking from the tailstock towards the headstock) Turn the tailstock handwheel in the counter-
clockwise direction to contract the tailstock quill.
Locking the tailstock quill in position
Tighten the tailstock quill lock on the rear of the tailstock to lock the tailstock quill in position.
Mounting accessories into the tailstock quill
1. The tailstock quill has a Morse Taper (MT) #2. Any accessory tool with MT2 can be attached to the
tailstock quill.
2. Slide the tool into the quill taper to attach the MT2 tool to the tailstock quill. Press in firmly to ensure it is
firmly mounted.
Dismounting the accessories from the tailstock quill
1. The NOVA COMET 14DR tailstock features a self-ejecting function allowing for easy tool removal.
2. Retract the tailstock quill all the way to eject the attached tool. The attached tool will fall out once the
tailstock quill is retracted all the way.
Tailstock Locking Handle
Tailstock Handwheel

14
127-0919-001
Maintaining the NOVA Lathe
WARNING
Always isolate the NOVA lathe from its power source
before carrying out any maintenance procedure
Regular maintenances are essential when considering the long-term use of the lathe.
Maintenance after each use
1. Clean the work area and lathe
2. Vacuum shavings and dust from the headstock, table and base
Monthly maintenance
1. Wax coat the exposed cast iron parts with a good quality paste wax. Buff off thoroughly.
2. Check tightness of nuts and bolts
3. Clean all tapers to ensure a secure fit
6-months Maintenance
1. Lubricate the tailstock quill and its inside threads with a light coat of light weight oil.
2. Check for any rusts on underneath the tool rest, tailstock and on the lathe bed. If there is rust on the
surface, remove it by using a rust removal agent with a abrasive sponge.
Note: Some rust removal agents may leave a stain on the metal surface. Please check on an area
where stains are not easily visible before applying on the actual metal surface.
Cleaning the Tool slide
If the tool slide becomes hard to move and adjust, cleaning and lubricating are required.
1. To make the tool slide move more freely along the bed, make sure the bed rails are clean. Apply some
paste wax to the rails.
2. If the tool slide is hard to move towards or away from you, remove the tool slide from the lathe bed.
Clean the tool slide camshaft (round eccentric rod) with a petroleum-based solvent. Lubricate the rod
with lightweight oil or a silicone spray.
3. Slide the base back onto the lathe bed.
Cleaning the Tailstock
If the tailstock quill becomes hard to use or the Handwheel is hard to turn, cleaning and lubricating are
required.
1. Remove the 6mm set screw from the tailstock handwheel. If needed, turn the handwheel to expose the
set screw.
2. Using a screwdriver, remove the keeper plate from the tailstock body.
3. Remove the quill by unscrewing the tailstock quill lock handle off from the tailstock body and extending
the quill out all the way. Remove handwheel from the tailstock body.
4. Wipe clean all parts including the inside of the tailstock slot.
5. Lubricate the quill, quill lead screw and tailstock slot with lightweight oil, apply small amount of oil to the
quill threads.
6. Reassemble.

15
127-0919-001

16
127-0919-001
Troubleshooting
Mechanical Issue
Symptom
Place to check
How to resolve
Excessive Vibration
1. Work attached to the lathe
2. Lathe Mounting
(either on bench or stand)
1. Slow the lathe speed down
2. Add weight to the machine or bolt the machine down
to a solid platform.
3. Check the spindle runout by using a *DTI.
Faceplate/chuck
not running true
1. Back of face plate
2. Threads (Inner threads on
faceplate and spindle
thread on headstock)
1. Check the lathe spindle thread by using a *DTI to
ensure the spindle itself is running true.
2. Ensure the back of the faceplate is making firm
contact with the spindle base.
Turning tools not sliding
smoothly across Tool rest
1. Tool rest surface
1. Ensure the tool rest surface is smooth without any
chips, cracks of burrs.
Spur drive centre/live centre not
holding into the spindle
taper/quill taper when turning
1. Morse Taper surface
1. Clean the Morse Taper surfaces (both tool and
spindle) with a cleaning agent.
Tailstock and Headstock centre
not lining up correctly
1. Headstock alignment
1. Loosen the headstock casing from the bed and make
the required adjustment.
Tailstock Handwheel hard to
turn or will not turn
1. Quill lock
2. Inside the tailstock quill
housing
3. Quill internal threads
Check if the quill lock is not engaged.
1. Remove the tailstock quill from the tailstock body and
inspect both quill surface and quill housing surface.
2. Clean the quill and quill housing to ensure not foreign
materials exist.
3. Lubricate both quill and housing surface and
reassemble the tailstock.
Tailstock binds
1. Lathe bed
2. Tailstock adjustment plate
1. Slide off the entire tailstock from the lathe bed and
inspect the top lathe bed surface and bottom
tailstock surface.
2. Apply light lubricant to the top lathe surface if there
are no defects on both surfaces.
*Dial Test Indicator
Electrical Issue
Symptom
Place to check
How to resolve
Lathe does not turn on
(No lights on the control panel)
1. Power source
2. Fuse/Reset button
3. Controller
1. Check power source is providing power
2. Check the fuse/reset button is not popped out. Press
the reset switch and repower on the lathe
3. If the above 2 solutions did not resolve the problem,
may require replacing the controller. Please contact
our customer services: [e-mail]

17
127-0919-001
NOVA Teknatool Warranty
NOVA Limited Warranty
4499 126th St North, Clearwater, Florida 33762
teknatool.com | 727.954.3433
This NOVA product is backed by a registered warranty from the date of purchase and only to the original purchaser. These limited
warranties are non-transferable. Under no circumstances will Teknatool International Ltd or Teknatool USA Inc. be liable for incidental,
special, indirect, and consequential damages or expenses, including loss of profits or loss of operations.
INSPECTION: Buyer shall inspect all goods within thirty (30) days of receiving product confirming all parts are in good condition and
accounted.
GUARANTEE: Teknatool International Ltd and Teknatool USA Inc. will repair or replace, at its expense and option, a NOVA product which
under normal use and intended operation, has proven to be defective in workmanship or material. Teknatool will be granted a reasonable
opportunity to verify the alleged defect by inspection and testing. Teknatool will not be responsible for any asserted defect, which has
resulted from normal wear, misuse, abuse, power surges or excess voltage fluctuation, or using in a manner or with material not consistent
with proper use, repair or alteration made by anyone other than an authorized service facility or representative.
Under these Limited Warranties, the sole liability of Teknatool is limited to repair, or at its option, replacement the applicable product or
part not in conformity with these Limited Warranties. REFUNDS ARE NOT AVAILABLE. If within the warranty period, identical materials are
unavailable at the time of repair or replacement, IN NO EVENT SHALL NOVA TEKNATOOL’S RESPONSIBILITY EXCEED THE PURCHASE PRICE
OF THE PRODUCT OR ITS REPLACEMENT AND RESERVES THE RIGHT TO USE REFURBISHED PARTS.
CONDITIONS: Prior warranty registration is not required but advised via https://www.teknatool.com/register-your-warranty/; however,
documented proof of purchase (sales receipt/invoice showing date, location, and purchase price paid) must be provided at the time of
claim. *Repairs are charged hourly. In addition, customer pays for shipping to/from and provides own shipping contain; **Warranty
Repairs: customer pays for shipping to/from and provides own shipping container; repairs are covered within warranty.
OVERSEAS CUSTOMERS: Our NOVA Distributors and agents will issue their own warranty to cover this product. Terms may vary from those
stated above; please check with your dealer. In North America, the warranty covers the Continental USA only. For Alaska, Hawaii and other
areas, warranty covers replacement of parts only and excludes transport costs.
Product
Electrical
Mechanical
All Lathes and *Accessories (except COMET)
COMET I & II
Drill Presses and *Accessories
*Excludes belts and consumables
2 years
1 year
2 years
5 years
2 years
5 years
All Chucks & Accessories
Jaws
-
-
6 years
6 years
Chisels:
-Dovetail
-Smart Chisel Handle
-
-
2 years
1 year
TO FILE A CLAIM: Contact CUSTOMER SERVICE via https://www.teknatool.com/contact-us/ or supp[email protected] with a full
description for claim to include pictures/videos. All claims must include the original bill of sale, the product serial number, and be filed
within the applicable warranty period. Teknatool reserves the right to require defective parts be returned upon request. You must make
arrangements with Teknatool to schedule the transportation of the parts from your home to the retailer or from the retailer to your home.
A RETURN GOODS (RG) form will be sent to you via email. Items shipped to Teknatool without a RG form will be refused at shipper’s
expense. If the retailer from which you purchased the product is not able to service your product, contact Teknatool in writing at
service@teknatool.
Our policy is one of continuous improvement. We therefore reserve the right to change specification/design without notice. This warranty
is Teknatool International Ltd and Teknatool USA Inc. sole warranty whether written or verbal, whether expressed or implied by law, trade,
custom, or otherwise, whether of merchantability, fitness for purpose, or otherwise, except for remedies available to customers under
the Consumer Guarantees Act or other legislation
