NOVAGRATZ 6852096WCOM User manual

B346852096WCOM0
WARNING
ameriwoodhome.com
Follow Ameriwood Home
CHANGING TABLE
6852096WCOM
Keep this Assembly Manual for future reference
Unit can p over causing severe injury or death.
- Anchor unit to stud in wall
- Do Not allow children to climb on unit
- Put heavy items on lower shelves or drawers
- Two people required for assembly

Warning
Helpful Hints
Do NOT return this product!
Contact our friendly customer service team rst for help
Call us!
1-800-489-3351
Monday-Friday
9am - 5pm CST
Visit ameriwoodhome.com
Assembly Tips
2
ameriwoodhome.com
- Open your item in the area you plan to keep it for less heavy liing
- Idenfy, sort and count the parts before aempng assembly
- Compression dowels are tapped in with a hammer
- Slides are labeled with a R (right) and L (le) for proper placement
- Make sure to always face the point on the top of the Cam Lock towards the
outer edge
- Use all the nails provided for the back panel and spread them out equally
- Back Panel must be used to make sure your unit is sturdy
- Do NOT use harsh chemicals or abrasive cleaners on this item
- Never push, pull, or drag your furniture

Board Idencaon
Not actual size
6852096WCOM
CHANGING TABLE
3
ameriwoodhome.com
x1
T6852096W010
TOP PANEL
x1
T6852096W020
SIDE PANEL LEFT
x1
T6852096W030
SIDE PANEL RIGHT
x1
T6852096W040
BOTTOM PANEL
x1
T6852096W050
FIXED SHELF
x1
T6852096W060
PARTITION PANEL
x1
T6852096W070
SOLID BACK
x1
T6852096W080
FRONT APRON TOP
x1
T6852096W090
STRINGER
x1
T6852096W100
BACK PANEL
x1
T6852096W110
FRONT APRON LOWER
x2
T6852096W120
DRAWER BOTTOM
x1
T6852096W130
LOWER-DRAWER FRONT
x1
T6852096W140
UPPER-DRAWER FRONT
1
5
9
12 13 14
10 11
6 7 8
2 3 4

Board Idencaon
Not actual size
6852096WCOM
CHANGING TABLE
4
ameriwoodhome.com
x2
T6852096W150
DRAWER BACK
x2
T6852096W160
DRAWER SIDE LEFT
x2
T6852096W170
DRAWER SIDE RIGHT
x2
T6852096W180
DRAWER SUPPORT
x2
T6852096W190
SIDE PANEL
x1
T6852096W200
BOTTOM PANEL
x1
T6852096W210
BACK PANEL
x1
T6852096W220
FRONT PANEL
15
19
16
20
17
21
18
22

Part List
Actual Size
6852096WCOM
CHANGING TABLE
5
ameriwoodhome.com
x44
TTA0001
Cam Bolt
x32
TTA0003
Cam Lock
15-11.5
x28
TTA0005
CBS 3.5 x 12
x13
TTA0010
CSK 4 x 32
x4
TTA0014
PH M4 X 20
x61
TTA0016
DOWEL 6 X 30
x24
TTA0018
NAIL
x12
TTA0004
Cam Lock
12-9.5

Part List
Not Actual Size
6852096WCOM
CHANGING TABLE
6
ameriwoodhome.com
x1 SET
TTA0026
ANTI TIPPING KIT
x4
TTA0038
WOODEN KNOB Ø57
PANTONE 691C
x4
TTA0039
WOODEN KNOB Ø57
PANTONE 423C
x4
TTA0040
WOODEN KNOB Ø57
PANTONE 643C
x2 SET
TTA0041
DRAWER SLIDE

Before You Start
Cam Lock Fastening System
6852096WCOM
CHANGING TABLE
7
ameriwoodhome.com
P
P
P
P
P
This Cam Lock Fastening System will be used throughout the assembly process.
Read through each step carefully and follow the proper order
Separate and count all your parts and hardware
Give yourself enough room for the assembly process
Have the following tools: Flat Head Screwdriver, Phillips Head
Screwdriver and Hammer
Cauon: If using a power drill or power screwdriver for screwing,
please be aware to slow down and stop when screw is ght.
Failure to do so may result in stripping the screw.
Quick
Tip
Assembly
1
3
2
4

6852096WCOM
CHANGING TABLE
8
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 1
x2
TTA0003 x2
TTA0016
x7
TTA0001 x8
TTA0005
2
x2
TTA0041
Raw Edges

6852096WCOM
CHANGING TABLE
9
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 2
x2
TTA0003 x2 TTA0016
x7
TTA0001 x8
TTA0005
3
x2
TTA0041
Raw Edges

6852096WCOM
CHANGING TABLE
10
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 3
5
x4
TTA0003 x4
TTA0016
x2
TTA0001
Raw Face
Raw Edges

6852096WCOM
CHANGING TABLE
11
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 4
x10
TTA0003 x12 TTA0016
6
Raw Edges
Step 5
Raw Face
7

6852096WCOM
CHANGING TABLE
12
ameriwoodhome.com
Step 6
7
5
Raw Edges
Raw Face
Step 7
6
5
7
Edging Face
Raw Edges

6852096WCOM
CHANGING TABLE
13
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 8
x2
TTA0010
7
5
Raw Edges
9
Raw Edges
Raw Face
Step 9
x2
TTA0003 x2
TTA0016

6852096WCOM
CHANGING TABLE
14
ameriwoodhome.com
Step 10
3
7
5
Raw Edges

6852096WCOM
CHANGING TABLE
15
ameriwoodhome.com
Step 11
3
9
Raw Edges

6852096WCOM
CHANGING TABLE
16
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 12
x6
TTA0003
x7
TTA0016
4
Raw Edges
Step 13
11
Raw Edges
x4
TTA0016
x2
TTA0001

6852096WCOM
CHANGING TABLE
17
ameriwoodhome.com
Proper orientation of CAM LOCK
Tip
Assembly
Quick
Step 14
11
4
Raw Edges
Step 15
8
Raw Face
x2
TTA0003
x2
TTA0016

6852096WCOM
CHANGING TABLE
18
ameriwoodhome.com
Step 16
4
3
Raw Edges

6852096WCOM
CHANGING TABLE
19
ameriwoodhome.com
Step 17
8
3
Laminated Surface

6852096WCOM
CHANGING TABLE
20
ameriwoodhome.com
Step 18
2
x1 SET
TTA0026
