Novitek LUMISPA 603 User manual

SISÄLLYSLUETTELO
SISÄLLYSLUETTELO
OUTDOOR HOT TUB INSTALLATION- AND OPERATION MANUAL
LUMISPA
EXCLUSIVE
SELECT BASIC / PREMIUM
STANDARD
SELECT PREMIUM
SELECT BASIC
• HALTI
• OLOS
• SALLA
EXCLUSIVE
• KIILO
• MALLA
• YLLÄS
• LEVI
• PALLAS
STANDARD
• LUOSTO
• RUKA
• HELMI
• ROPI
LUMISPA
• 603
• 602
• 601
• 402
• 401

2
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN TABLE OF CONTENTS
The manufacturer or vendor do not account for improper installation, changes made, misuse or insufcient maintenance of the outdoor
hot tub. Changes cover any system that may cause error to a component or unit, or cause activity that is unsafe. Misuse and insufcient
maintenance cover any use of the outdoor hot tub that is not stated in this user manual, or failing to use the outdoor hot tub for its
intended purpose, especially use of the hot tub incoherent of housing, damage that is caused by using water temperatures outside of the
set guidelines, damage that is caused by an unclean, clogged or calcied bre lter, damage of the coating of the hot tub which is caused
by the use of acidic or otherwise unt cleaning solutions, damage that is caused to the components or coating of the hot tub by incorrect
maintenance of the chemical state of the water, as well as damage that is caused by failing to cover the drained outdoor hot tub from
direct sunlight. The supplier or vendor do not cover for any potential loss of use.
DEAR CUSTOMER
SAFETY GUIDE ...................................3
INSTALLATION AND STARTUP
INSTALLATION SITE...............................4
INSTALLATION ON THE GROUND...................4
INSTALLATION ON A TERRACE.....................4
INSTALLATION SUNKEN INTO A TERRACE...........4
INSTALLATION INDOORS ..........................4
STARTUP ........................................5
ELECTRICAL INSTALLATION .......................5
ELECTRICAL CONNECTION ........................5
INSTRUCTIONS FOR CLEARING AN AIR LOCK. . . . . . . .5
POOL MAINTENANCE
GENERAL ........................................6
FILLING THE POOL................................6
EMPTYING THE POOL .............................6
CLEANING THE POOL .............................7
BATH PILLOWS ...................................7
INSULATION COVER ..............................7
POWER OUTAGE. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
USING THE POOL IN WINTER ......................7
EMPTYING FOR WINTER...........................7
WATER TREATMENT
FIBER FILTER.....................................8
OZONIZATION SYSTEM. . . . . . . . . . . . . . . . . . . . . . . . . . . .8
CLEANING CHEMICALS ...........................8
WATER CARE TROUBLESHOOTING GUIDE ...........9
SELECT PREMIUM, EXCLUSIVE AND
LUMISPA
MAIN VIEW .................................... 10
SYMBOLS ...................................... 10
NAVIGATION ................................... 10
SETTING THE TIME...............................11
SETTING THE TEMPERATURE .....................11
JET PUMPS .....................................11
AIR CONTROLS..................................11
LED LIGHTS .....................................11
KEYLOCK .......................................11
LANGUAGE .....................................11
MODES .........................................12
SERVICE MODE..................................12
LOWER AND UPPER TEMPERATURE RANGES.......12
FILTRATION CYCLES .............................12
CLEANING CYCLE................................12
M8 EFFICIENT SMARTNESS.......................13
TURNING THE DISPLAY...........................13
TIMED MESSAGES ...............................13
UNITS ..........................................13
TECHNICAL SETTINGS ...........................13
SCREEN ERROR MESSAGES ......................14
SELECT BASIC
MAIN VIEW .....................................15
NAVIGATION ....................................15
SETTING THE TIME...............................16
SETTING THE TEMPERATURE .....................16
JET PUMPS .....................................16
AIR CONTROLS..................................16
LED LIGHTS .....................................16
KEYLOCK .......................................16
MODES .........................................17
SERVICE MODE..................................17
LOWER AND UPPER TEMPERATURE RANGES.......17
FILTRATION CYCLES .............................17
CLEANING CYCLE................................18
TURNING THE DISPLAY...........................18
TECHNICAL SETTINGS ...........................18
ADDITIOONAL SETTINGS .........................18
SYSTEM INFORMATION ..........................18
SPA MENU ......................................19
SHORTCUT MENU ...............................19
TIMED MESSAGES ...............................19
SCREEN ERROR MESSAGES ......................20
STANDARD
MAIN VIEW .....................................21
SCREEN SYMBOLS...............................21
JET PUMPS .....................................21
SETTING THE TEMPERATURE .....................21
SETTING THE TIME...............................22
TURNING THE DISPLAY...........................22
LED LIGHTS .....................................22
KEYLOCK .......................................22
MODES .........................................22
SERVICE MODE..................................22
LOWER AND UPPER TEMPERATURE RANGES.......23
FILTRATION CYCLES .............................23
CLEANING CYCLE................................23
TIMED MESSAGES ...............................24
SCREEN ERROR MESSAGES ......................25
FACTORY INSTALLED ACCESSORIES
SINK PANELING .................................26
MICROSILK .....................................26
SUPPLEMENTARY HEATER .......................26
CONTROLMYSPA™ REMOTE CONTROL ............27
GENERAL WARRANTY TERMS
CONDITIONS FOR THE WARRANTY’S VALIDITY .....28
COMMERCIAL USE...............................28
LIMITATIONS....................................28
WARRANTY FOR DISPLAY PRODUCTS .............28
WARRANTY MEASURE ...........................29
REFUNDING/INVOICING WARRANTY-COVERED PARTS
................................................29

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
3
EN
DEAR CUSTOMER
These instructions contain important information on the installation, operation, and servicing of the
pool. Please read through the instructions carefully before installing and starting up a new pool. Keep
the instructions for future reference.
Ensure that the delivery contains the following products:
• Outdoor hot tub
• Insulation cover
• Fibre lter
The manufacturer retains the right to change the product’s assembly or structure without separate
notice and without any obligation arising from this.
SAFETY GUIDE
PLEASE NOTE! Read the safety guide with care and follow these instructions!
• Children may not use the pool without adult supervision.
• When using the pool with small children, check the suitability of the water temperature.
• Do not let children climb onto the insulation cover of the pool.
• Diving is not allowed in the pool.
• Keep the pool cover closed and locked when the pool is not in use.
• Do not keep the machine unit exposed.
• Do not remove or plug the suction drains or use the pool without the drains or if the drains are
broken.
• Do not bring electrical devices closer than 2.5 meters from the pool. Neglecting to keep a safe
distance increases the risk of electric shock and may cause a serious injury or even death.
• The surface of the pool may be very slippery. Be careful when entering and exiting the pool.
• Keep loose items of clothing and jewellery away from the rotating jets and other moving parts.
• The use of intoxicating substances, alcohol and medications before or during the use of the pool
may induce drowning. The use of the pool should always be consulted with the doctor prescribing
the medications. The use of the pool under the inuence of abovementioned substances is at your
own risk.
• If you have an articial joint replacement or pacemaker, consult the use of the pool with a doctor.
• Use of the pool during pregnancy must always be consulted with a doctor.
• We recommend that a continuous bathing session be no longer than 30 minutes in length, after
which you should cool down for 5–10 minutes.
• Ensure adequate hydration during the bathing experience.
• Water over 40°C warm may be harmful for your health.

4
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN INSTALLATION AND STARTUP
The pool should be lifted off the pallet onto its nal site turned to its side or turning it horizontally.
Cargo straps can be used as a help, for example. The pool should not be slid across the ground,
therefore make sure to have enough helpers on hand. The pool can be lifted onto its nal site with a
loading crane as well.
PLEASE NOTE! Check the condition of the delivery package when the pool arrives at your yard.
If any potential transportation damage is present, a damage report must be led immediately
with the carrier as well as the retailer.
INSTALLATION SITE
The pool can be installed directly onto the ground, on a terrace, sunken into a terrace, on a balcony –
or indoors as well. The requirements are that the surface is at, structurally uniform and free of frost
heaving, and withstands the weight of the pool unaltered (2 000 – 3 000 kg). Faulty installation may
lead to structural damage of the product. The manufacturer does not account for potential damage
caused by incorrect installation of the pool.
There must be no less than 50 cm of space around the outdoor spa pool for any required servicing
measures. It must be possible to open the service hatches located on each side of the pool without
impediment.
INSTALLATION DIRECTLY ON THE GROUND
The foundation for the pool must be even, structurally uniform and free of frost heaving. The
foundation can be laid with concrete, paving stones, bricks, gravel or wood. Depending on the model
of the pool, the base must be able to withstand a weight of 2 000 – 3 000 kg, without subsiding or
transforming. The pool comes equipped with an insulating base. Therefore, the foundation does not
require separate insulation. For the base, we recommend using concrete slabs of a minimum thickness
of 10 cm.
INSTALLATION ON A TERRACE
When installing the pool on a terrace, the requirements are the same as when installing directly on the
ground. The base must be uniform and completely even, in addition to this, make sure the terrace is
able to withstand a weight of 2 000 – 3 000 kg, depending on the model of the pool.
INSTALLATION SUNKEN INTO A TERRACE
When installing the pool sunken into a terrace, the requirements are the
same as when installing directly on the ground. If the pool is sunken into
a terrace, separate maintenance hatches must be made to each side of the
pool. The maintenance hatches must be made so that the side panels of
the pool can be opened, and that there is enough space to work around the
pool, when required.
If the pool comes equipped with sink panelling factory-installed, a
separate service hatch does not need to be made. The sinking depth can
be maximum 40 cm from the bottom of the pool to the surface of the
terrace.
INSTALLATION INDOORS
When installing the pool indoors, appropriate drainage as well as wet space regulations required by
law, must be ensured. The oor beneath the pool must be even, and the structure of the house must be
able to withstand a weight of 2 000 – 3 000 kg, depending on the model of the pool. The manufacturer
does not account for potential damage caused by incorrect installation of the pool.
SERVICE HATCH
SERVICE HATCH
SERVICE HATCH
SERVICE HATCH

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
5
EN
3 X 16 A, 400V 1 X 16 A, 230V
EXCLUSIVE STANDARD
SELECT
INSTALLATION AND STARTUP
1. Turn the jets clockwise, until they are open.
2. Before using the pool, check that all the threaded connections of the pumps are  rmly secured.
The threaded connections may come loose during transportation.
3. Fill the pool with water through the  ltration opening (with a garden hose, for example) up until
the LED-lights, so that air locks are not formed in the piping. See the instructions for  lling the
pool.
4. Only turn on power to the pool once it is  lled up.
5. After power is turned on, the pool display will show setup data, after this the text Priming Mode
shows at the bottom of the screen. This initialization will last 4–5 minutes.
6. If the error message The water fl ow is low, shows on the display within the  rst few minutes, it
indicates that there is air in the pump. In this case, see the instructions for clearing an air lock.
7. Turn on the pumps and check that water is coming out of all jets.
STARTUP
PLEASE NOTE! Do not connect power to the pool until it is  lled with water!
The electrical installation may only be carried out by a licensed electrician.
The pool is hooked up to an electrical connection according to the table below. The electrical
connection must be protected with a ground fault circuit interrupter. The electric supply can be drilled
through any corner of the pool’s siding or a moving strap groove in the pool base. The side behind
which the control panel is located is marked on the pool.
ELECTRICAL INSTALLATION
An air lock causes the jets to malfunction. An air lock is often caused by  lling the pool too quickly,
which results in air being trapped in the piping. This prevents the pump from pre lling and the water
from circulating properly.
INSTRUCTIONS FOR CLEARING AN AIR LOCK
1. 1. Open the service hatch and turn the threaded connection on top of
the pump slightly open.
2. When water starts coming out, tighten the connection and turn
on the pump. The pump will pump for a moment, after which the
water will start to  ow properly.
3. Dry any spilled water and close the service hatch. Your outdoor
spa pool is ready for use.
PLEASE NOTE! The wires must be stripped to a length of approx. 20 mm, and the earth
connection must be completed appropriately. The electrical wiring instructions are marked on the
inside of the control panel next to the terminal block.
1. Make sure that the pool is  lled with water up
until the LED-lights.
2. Open the service hatch to access the control
panel.
3. Connect the power cable to the control panel.
4. Close the service hatch.
ELECTRICAL
CONNECTION

6
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN POOL MAINTENANCE
GENERAL
• Do not leave the pool in direct sunlight without the insulation cover. Direct sunlight may damage
the pool’s surface materials. When the pool is not in use, put the cover in place and lock it,
regardless of whether the pool is empty or full.
• Do not roll or slide the pool on its side. This may cause damage to the siding of the pool.
• Do not attempt to open up the control panel of the pool by yourself. The control panel does not
contain any parts that can be serviced by yourself.
• Empty and clean the pool regularly. Always  ll the pool with clean water.
• Clean the  bre  ler at minimum once per month.
• Wash yourself carefully before entering the pool.
• Sand that gets carried into the pool may clog the massage pumps
• Replace the water in the pool 2–3 times per year.
FILLING THE POOL
1. Remove the  bre  lter according to the instructions below.
2. Fill the pool with water through the  lter system (with a garden hose, for example), so that
airlocks are not formed in the piping or in the pumps.
3. We recommend  lling the pool up until the edge of the LED lights. Ensure that there is always
enough water and that the jets are always submerged.
4. After  lling the pool, set the  bre  lter, the  lter sift and the cover of the  lter back to their place.
5. Turn on the power to the pool and ensure that it is in READY mode.
6. Close up the insulation cover of the pool.
EMPTYING THE POOL
1. Turn off power to the pool before emptying it.
2. The pool is emptied into the wastewater drain with a submersible pump. PLEASE NOTE! Do not
use a metal submersible pump.
3. Remove the  bre  lter after emptying the pool according to the instructions below.
4. Clean the inner surface thoroughly with a mild disinfectant. Use a soft and lint-free cloth or
sponge.
5. After cleaning the pool, we recommend waxing the coating. The wax effectively protects the
naturally shiny surface of the pool.
1. 2. 3.

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
7
EN
POOL MAINTENANCE
CLEANING THE POOL
For cleaning the pool, use a mild disinfectant, as well as a soft and lint-free cloth or sponge. After
cleaning the pool, we recommend waxing the coating. The wax effectively protects the naturally shiny
coating of the pool. The cabinet can be wiped with a wet cloth or sponge.
BATH PILLOWS
INSULATION COVER
The bath pillows have to be removed when the pool is not in use. If the pillows discolour through the
pool chemicals, they can be treated with conditioner and nished with silicone spray.
The insulation cover is fabricated to withstand weight well, however, for instance, snow should be
removed from top of the insulation cover. Do not use sharp objects for removing the excess weight, so
that the leather of the insulation cover is not damaged. For cleaning the insulation cover, only use the
conditioner intended for it, so that the leather of the cover stays exible. PLEASE NOTE! The outdoor
spa pool’s insulation cover is not made to withstand human weight.
USE IN WINTER
EMPTYING FOR WINTER
We recommend keeping the pool in use year-round. Emptying the pool for winter may cause damage
caused by freezing. If you do not intend to use the pool during winter, we recommend setting the pool
into the REST state and using a pool protection hood. PLEASE NOTE! The warranty does not cover
damage caused by freezing.
The pool is designed for year-round outdoor use. If the pool is emptied for winter, the warranty does not
cover potential damage caused by freezing.
The pool has an automatic frost protection, which turns on the pumps when the water temperature
drops below 6,7 °C. Though the frost protection does not protect the pool during a power outage.
We recommend using a protection hood for the cover or a bigger one for the entire pool. A pool
protection hood will protect the pool from wind, rain and sunlight, and make the pool longer lasting as
well as more energy efcient.
In the event of a power outage, DO NOT OPEN THE INSULATON COVER! The pool will turn back
on automatically when power is restored. After a power outage, check the functions and water
temperature of the pool.
Short power outages ranging from a few minutes to a few hours do not affect the functionality of
the pool. The pool is well-insulated, which prevents it from freezing in this amount of time, even in
freezing temperatures. It takes a power outage of longer than a few days for the pool to freeze. In the
event of a longer power outage, please contact the seller or your service agent.
POWER OUTAGE

8
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN WATER CARE
The water of the pool is maintained in three different ways. The water stays clean and clear by means
of the bre lter, the ozonisation system and cleaning chemicals.
FIBER FILTER
OZONIZATION SYSTEM
CLEANING CHEMICALS
The bre lter collects small debris from the water. The bre lter should be replaced for a new one
always in conjunction with a water change. The bre lter can get clogged up with calcium particles
found in hard water, as a result of which, the water ow weakens. The operating time of the bre lter
can be lengthened, and the ltration effectiveness improved, by rinsing the bre lter under owing
water 2 – 4 times a month. The ltration system of the pool is completely automatic.
Before switching the bre lter, make sure that a ltration period is not in action. If needed, turn off the
power to the pool, or switch the pool into the HOLD-mode. The instructions on how to remove the Fibre
lter are on the previous opening.
The ozonisation system removes bacteria, particles and musty odour. The system is functioning, when
air bubbles are rising out of the grey ozone jet.
The ozonisation system is completely maintenance free and does not cause any measures to be taken
by its owner. However, to ensure adequate cleaning effectiveness, the appliance should be replaced for
a new one every 3 – 4 years.
The cleaning chemicals (chlorine) keep the water disinfected, clear and clean, as well as removes
bacteria from the water. In addition to chlorine, chlorine-free active oxygen tablets or SpaBalancer
water care solution can be used in the hot tub. For more precise instructions on the dosage of the
cleaning chemicals, view the package of your chosen chemical product.
Chlorine works best, when the pH value of the water is 7,2 – 7,6. Keep track of the pH values of the pool
regularly. The use of the pool, chlorine use and rainwater that potentially winds up in the pool lower
the pH value of the water. The chemical expenditure varies depending on the municipality, since the
water pH value, as well as chalice and iron concentrations uctuate greatly.

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
9
EN
PROBLEM POSSIBLE CAUSE SOLUTION
Cloudy water
• Dirty lter
• The pH value is not within the
recommended range
• Insufcient use of cleaning chemicals
• Excessive use of the same water or the
water is too old
• Clean the lter
• Adjust the water pH level to the
recommended range
• Add a cleaning chemical to the water
• Replace the water in the pool
Smell of water
• The water contains too much organic
matter
• Insufcient use of cleaning chemicals
• Water pH level too low
• Adjust the water pH level to the
recommended range
• Add a cleaning chemical to the water
Smell of chlorine
• Chlorine level too high
• Water pH level too low
• Wait for the chlorine level to decrease
• Adjust the water pH level to the
recommended range
Musty smell • Bacterial or algae growth • Add a cleaning chemical to the water
• Empty, clean and rell the pool
Organic layer • Accumulated oil and dirt • Wipe the dirt away with a clean sponge
Algae growth • Water pH level too high
• Adjust the water pH level to the
recommended range
• Add a cleaning chemical to the water
Irritated skin • Unhygienic water
• Free chlorine levels over 5 mg/l
• Add a cleaning chemical to the water
• Wait that free chlorine levels drop
Patches on the pool surface
• Total alkalinity of water too low
• Water pH level too low
• Adjust the water pH level to the
recommended range
• Adjust the total alkalinity to the correct
value
Calcication
• Too much calcium in the water
• Total alkalinity of water too low
• Water pH level too low
• Adjust the water pH level to the
recommended range
• Empty, clean and rell the pool
WATER CARE
Maintaining and cleaning of the pool is easy and effortless. Chlorine or another water care chemical
is added every time after bathing, or at least once a week, even if the pool was not used. The bre lter
should be rinsed at least once per month and switched out or a new one with every water change. The
pool should be thoroughly cleaned with a mild disinfectant, and a soft and lint-free cloth or sponge.
Showering before entering the pool is highly advisable, so that abundant solutions or grease from, for
instance, deodorants, fragrances, hair shaping products or body lotions, do not get into the pool. The
water of the pool stays clearer for longer as well, and the bre lter does not have to be cleaned as
often.
In the table below are the most common problems, causes as well as solutions regarding water care.
WATER CARE TROUBLESHOOTING GUIDE

10
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN SELECT PREMIUM, EXCLUSIVE AND LUMISPA
The main view shows the most important settings and messages of the pool. The water temperature is
shown in the middle of the display. The status bar at the top shows the symbols regarding the function
modes of the pool. PLEASE NOTE! The screen automatically goes into sleep mode when it is not used
for 30 minutes. The screen starts up again by touching any part of the screen.
MAIN VIEW
The pool comes equipped with a touch screen, which is navigated by pressing the icons. For example,
view settings by pressing the settings icon
SETTINGS
and reminder messages can be viewed by pressing the
-symbol. Depending on the view, you can change settings or move to the next view of the menu with
the arrow brackets. PLEASE NOTE! The look of the screen interface may differ from the instructions.
NAVIGATION
1. Status bar 2. LED lights 3. Music (accessory) 4. Water temperature 5. Jets 6. Settings
SYMBOLS
= Highest temperature setting
= Ready mode
= Rest mode
= Ozonisation running
= Lowest temperature setting
= Filtration period 1 running
= Wi-Fi connected
= Turning the display
= Back
= Filtration period 2 running
= Info message
= Error message
= Heater running
= Screen locked
= Reminder message

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
11
EN
SELECT PREMIUM, EXCLUSIVE AND LUMISPA
The pool temperature is factory set to 38 °C. The water temperature is set in the main view by pressing
the up or down bracket, then the set temperature text changes colour and °C starts to blink. The
set temperature is saved automatically.
SETTING THE TEMPERATURE
The time must be set immediately after the pool’s installation, as the correct time is important for the
functionality of the  ltration cycles. If the time has not been set, there will be a message showing Set
Time. The time is set by choosing Time
TIME
in the Settings
SETTINGS
menu. Time
TIME
. When in the Time view,
 rst press hours or minutes, after this you can modify the time with the arrow brackets. Save the time
by pressing the Select symbol .
SETTING THE TIME
The pool has three massage pumps. The pumps turn on by pressing Jets
JETS
in the menu, after this
you can start up the pump of your choosing by pressing the Jets 1-JETS 1 , Jets 2-JETS 2 or Jets 3 JETS 3 -icons. The
massaging speed turns off automatically after 15 minutes or you can turn them off by pressing again
the Jets 1-, Jets 2- or Jets 3-icon.
If the  ltration pump is running, the JETS-icon is shown in colour
JETS
.The  ltration pump turns on
automatically and cannot be turned off manually.
PLEASE NOTE! If the pool is in READY mode, the  ltration speed turns on automatically when the pool
checks the water temperature.
JET PUMPS
The massage intensity can be adjusted for each seat individually, with
controllers on the side of the pool. The massage intensity increases
when turning the controller counter clockwise, and likewise decreases
when turning it clockwise.
AIR ADJUSTERS
The LED lights of the pool turn on by pressing the LIGHT icon LIGHTS in the main view. To turn off the
lights, press the LIGHT icon again. The pool’s LED lights have different colors and light modes. To
change the light mode, turn off the LED lights and immediately turn them back on. The LED lights turn
off automatically four hours after being turned on.
LED LIGHTS
The screen of the pool is locked by choosing the Lock
LOCK
icon in the Settings SETTINGS menu. In the Lock-view
you can either choose to lock the whole screen Panel, or to only lock the Settings. By only locking the
settings, you can normally use all the basic functions of the pool.
The keyboard is locked and opened by pressing the Panel or Settings icon once, in the Lock view,
then the text ”Lock Panel” or ”Lock setting” appears on screen, depending which one you are locking.
After this, press the text ”LOCK”on the status bar for  ve seconds continuously. The icon changes into
LOCKED mode LOCKED and when opening into UNLOCKED UNLOCKED mode.
KEYLOCK
The display language can be changed by choosing Language LANGUAGE in the Settings SETTINGS menu. Choose your
desired language and save the choice by pressing the Select symbol. .
LANGUAGE

12
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN SELECT PREMIUM, EXCLUSIVE AND LUMISPA
In order to keep the pool water warm, the pump circulates the water through heaters.
In the READY mode, the pool maintains the set temperature and heats up the water as necessary. In the
REST mode, the pool heats up the water only during set  ltration cycles. In the REST mode, the pool
display may not necessarily show the pool temperature. The temperature will appear by starting up
Jets 1
JETS 1
and by returning to the main view.
The mode can be switched by choosing the Heat HEAT icon in the Settings SETTINGS menu. The Ready and Rest
modes can be switched by pressing the HEAT MODE bar, the Ready/Rest modes change. To return to
the main view, press the back symbol . The chosen mode symbol, = READY and = REST, are
shown in the main view at the left side of the status bar.
MODES
The pool has two different settings for temperature ranges. You can set a separate temperature for each
of them. In the upper temperature setting (High) the temperature can be set between 26,5 °C and 40 °C.
This setting is best suited for use when you want to keep the pool always ready for use. In the lower
temperature setting (Low) the temperature can be set between 10 °C and 37 °C. The lower temperature
range is best suited for use when the pool is not used for an extended period of time and you do not
want to maintain a high temperature.
The temperature range setting is changed by selecting the Heat HEAT icon in the Settings SETTINGS menu.
The High and Low settings are selected by pressing the TEMP RANGE bar, then the High/Low mode
changes. To return to the main view, press the back symbol . The selected temperature range
symbol, = HIGH and = LOW, are shown in the main view at the left side of the status bar.
LOWER AND UPPER TEMPERATURE RANGES
Filtration cycle 1 is factory set to run from 8:00 pm to 10:00 pm. The starting point and duration of the
 ltration cycle can be changed by selecting Filter FILTER in the Settings SETTINGS menu. When in the Filter FILTER
view,  rst press the time and then modify it with the arrow keys. Save the changes by pressing the
Select-symbol .
Filtration cycle is factory set to run from 8:00 am to 10:00 am. You can change the second  ltration
cycle’s start time and duration in the same way as the  rst  ltration cycle. Save the changes by
pressing the Select-symbol .
In normal use, we recommend setting two 2-hour  ltration cycles per day. In this case, the interval
between the start times of the  ltration cycles must be 12 hours. For example, the  ltration cycles
can be set the factory set periods 8:00–10:00 pm and 8:00–10:00 am. PLEASE NOTE! If you use the
pool more frequently than three times per week, the length of the  ltration cycles must be
increased.
FILTRATION CYCLES
The service mode (HOLD) can be used to stop the pump when carrying out small-scale servicing work,
for example. The service mode is activated by choosing Hold
HOLD
in the Settings
SETTINGS
menu. The service
mode runs for 60 minutes by default, but it can be interrupted manually by pressing the back symbol .
SERVICE MODE
The pool has an automatic preset cleaning cycle. The cleaning cycle starts when the pump has been
turned off for at least 30 minutes. You can  nd the cleaning cycle settings in the Settings SETTINGS menu, by
pressing the Cleanup
CLEANUP
symbol.
CLEANING CYCLE

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
13
EN
The service mode (HOLD) can be used to stop the pump when carrying out small-scale servicing work,
for example. The service mode is activated by choosing Hold
HOLD
in the Settings
SETTINGS
menu. The service
mode runs for 60 minutes by default, but it can be interrupted manually by pressing the back symbol .
SELECT PREMIUM, EXCLUSIVE AND LUMISPA
The screen view of the pool can be turned for ease of use in the inside and outside of the pool. The
screen view turns by pressing Turning the display symbol at the right side of the status bar.
TURNING THE DISPLAY
From time to time there will appear symbol at the bottom of the screen, which indicates a timed
reminder message. Reminder messages are possible to turn off, by choosing Reminders
REMINDERS
in the
Settings SETTINGS menu. The setting is changed by pressing the REMINDERS bar (Yes/No). The most common
messages and their meaning are shown in the table below.
TIMED MESSAGES
MESSAGE MEANING
Check the pH Check the pH of the water and adjust the chemicals if necessary.
Check the sanitizer Check the amount of chloride and add if necessary.
Clean the lter Clean the lter.
Test the GFCI Check that the ground fault circuit interrupter is functional.
Change the water Replace the water in the outdoor spa pool.
Clean the cover Clean the insulation cover.
Change the lter Change the lter
The temperature and time format can be changed by selecting Units UNITS in the Settings SETTINGS menu.
The temperature unit is changed by pressing the TEMP DISPLAY bar (°C/°F), and the time format by
pressing the TIME DISPLAY bar (24 HR/12 HR). To return to the main view, press the back symbol .
UNITS
To go to the technical settings, select Utilities UTILITIES in the Settings SETTINGS menu. In the technical settings you
can modify the screen time-out settings Panel PANEL as well as see the log information of the last 24 error
codes Faults FAU LTS .
TECHNICAL SETTINGS
M8 – EFFICIENT SMARTNESS
Energy consumption is minimized with the new M8 feature. The M8 feature automatically determines
the activation of the jets, according to the conditions and ambient temperature.
You can nd the M8 setting (On/Off) in the Settings SETTINGS menu by pressing the M8 M8
M8
symbol.

14
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN SELECT PREMIUM, EXCLUSIVE AND LUMISPA
Alla olevasta taulukosta löydät yleisimmät vikakoodit, niiden merkityksen ja vaaditut toimenpiteet.
Noudata aina vaadittua toimenpidettä ja ota tarvittaessa yhteyttä jälleenmyyjääsi tai huoltoon.
The symbol of the error codes is shown at the bottom left side of the screen. The table below shows
the most common error codes, their meanings and the required measures. Always take the required
measures and contact your distributor or service agent if necessary.
NÄYTÖN VIKAKOODIT
ERROR CODES
CODE MEANING REQUIRED MEASURE
DARK SCREEN The pool is not receiving power. Turn on power to the pool / check the
connection.
Possible freezing condition The pool may have frozen
The pumps will turn on automatically,
regardless of the pool’s mode. Contact your
service agent.
Water is too hot
OVERTEMPERATURE – One of the
temperature sensors has detected a
temperature of 43.3 °C or higher.
DO NOT ENTER THE WATER! The pool will
turn off and turn on again once the water
temperature has decreased to 41.7 °C.
Remove the pool cover to cool the water.
The water ow is low
Notable difference in temperatures
measured by sensors A and B. Indicates a
problem with the water ow.
Check that there is enough water, ll if
necessary. Clean the lter and check that
the pumps work. If the problem continues,
contact your service agent.
The water ow has failed
Continuous problems with the water
ow. The heater will turn off if this code
appears ve times in a day.
Check that the lter is clean. Turn the
heater on again by pressing any icon.
If the problem continues, contact your
service agent.
The heater may be dry The water ow in the heater is low, or
there is air in the heater.
Turn the pool off for 15 minutes. Check that
there is enough water and ll if necessary.
If necessary, remove air according to the
instructions for clearing an airlock. Return
the pool to the normal mode by pressing
any icon. If the problem continues, contact
your service agent.
The heater is dry Not enough water in the heater. The pool
will turn itself off.
Check that there is enough water, ll if
necessary. Clean the lter and check that
the pumps work. If the problem continues,
contact your service agent.
The heater is too hot
OVERTEMPERATURE – One of the
temperature sensors has detected a
temperature of 47.8 °C or higher.
DO NOT ENTER THE WATER! Remove
the pool cover to allow the water to cool.
After the water has cooled down, reset the
system by pressing any icon.
Sensors are out of sync Temperature sensors out of balance.
The phenomenon may be temporary. If the
problem continues, contact your service
agent.
Sensors are out of sync -- Call for service-- The temperature sensors have been out of
balance for at least an hour. Contact your service agent.
Sensor A fault, Sensor B fault Temperature sensor A or B does not work.
The pool has turned off.
May occur momentarily when the
temperature rises too high. The message
will disappear once the temperature
decreases. If the problem continues,
contact your service agent.
A pump may be stuck on The pump will not turn off.
DO NOT ENTER THE WATER! The water
may have overheated. Turn off power to
the pool and contact your service agent.

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
15
EN
SELECT BASIC
1. Pumps ON/OFF 2. LED-lights ON/OFF 3. Selection key 4. Navigator key
1
3
2 4
The main view shows current settings and messages of the pool. The water temperature is shown at
the upper left corner, and the set temperature below that. The current set function mode is shown at
the upper right corner of the screen. Settings of the pool can by changed from the menu at the right
side of the screen. The symbol in the middle of the screen shows if the pump or heating are turned on.
PLEASE NOTE! The screen turns off automatically after 30 minutes of not being in use. Start the screen
up again by pressing any button.
The menu of the pool is navigated with the arrow brackets at the right side of the screen 4. When the
text colour changes to white, that function is then selected. The active function is selected by pressing
selection key. 3. You go back to the main view, by navigating on the Back symbol and pressing the
selection key.3.
MAIN VIEW
NAVIGATION
Water temperature Function mode
Set temperature
Menu
Pool mode
Messages

16
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN
The pool temperature is factory set to 38 °C. The water temperature is set in the main view by rst
pressing the arrow key to the left, then the set temperature text turns white. The temperature setting is
adjusted up or down with the arrow keys. Save the changes by pressing the select key. 3.
SETTING THE TEMPERATURE
The time must be set immediately after the pool’s installation, as the correct time is important for the
functionality of the ltration cycles. If the time has not been set, there will be a message showing Set
Time. The time is set by choosing Time of Day in the Settings menu. Navigate right or left to change
the hours, minutes and the 12h/24h option. The time can be adjusted up or down with the arrow keys.
Save the setting by navigating onto the Save symbol and pressing the select key.3.
SETTING THE TIME
The pool has three jet pumps, of which JETS 1 is a dual-speed pump. JETS 1 pumppu käynnistyy joko
suodatus- tai hierontanopeudelle, riippuen altaan tilasta. JETS 1 pump starts either at ltration or
massaging speed, depending on the pool mode. If the pump starts at ltration speed, you can turn on
massaging speed by pressing the JETS 1 button again. The massaging speed turns off automatically
after 15 minutes and the ltration speed after 30 minutes, or you can turn them off by pressing the
JETS button. The other pumps of the pool always start up at massaging speed.
PLEASE NOTE! If the pool is in READY mode, the ltration speed turns on automatically when
the pool checks the water temperature every 30 minutes. If the ltration speed has turned on
automatically, it cannot be turned off, but you can turn on massaging speed by pressing the
JETS 1 button
The massage intensity can be adjusted for each seat individually, with
controllers on the side of the pool. The massage intensity increases
when turning the controller counterclockwise, and likewise decreases
when turning it clockwise.
JET PUMPS
AIR CONTROLS
The pool’s LED lights can be turned on by pressing the LIGHT button 2. To turn off the lights, press
the LIGHT button 2again. The pool’s LED lights have different colours and light modes. To change
the light mode, turn off the LED lights and immediately turn them back on. The LED lights turn off
automatically four hours after being turned on.
LED LIGHTS
The control panel of the pool is locked by selecting Lock in the Settings menu. In the Lock view, you
can choose between locking the entire key panel (Panel) or only the settings (Settings). By only locking
the settings, the lights and jets of the pool can be used normally.
You can unlock the panel in the same menu by rst pressing the select key twice 3, and then the
down arrow once.
KEYLOCK
SELECT BASIC

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
17
EN
In order to keep the pool water warm, the pump circulates the water through heaters.
In the READY mode, the pool maintains the set temperature and heats up the water as necessary. In
the REST mode, the pool heats up the water only during set ltration cycles. In the REST mode the pool
temperature is not necessarily shown, because the pump has not circulated water through the heater.
The temperature appears by pressing the JETS 1 button and waiting a moment.
The modes can be switched by choosing Heat Mode in the Settings menu. Choose between the READY
and REST modes by pressing the arrow key 3. The chosen mode is shown in the main view at the
bottom left side.
If the JETS 1 button is pressed, the text READY/REST appears on screen, when the REST mode is
chosen. After turning the pump off, it runs at a ltration speed of 60 minutes, after which the pool
returns to the REST mode.
MODES
The pool has two different settings for temperature ranges. You can set a separate temperature for
each of them. The set temperature range is shown at the upper right side of the screen.
In the upper temperature setting (High) the temperature can be set between 26,5 °C and 40 °C. This
setting is best suited for use when you want to keep the pool always ready for use. In the lower
temperature setting (Low) the temperature can be set between 10 °C and 37 °C. The lower temperature
range is best suited for use when the pool is not used for an extended period of time and you do not
want to maintain a high temperature.
The temperature range can be changed by selecting Heat Mode and choosing between High and Low
with the select key, in the Settings menu 3. The selected function mode is shown in the main view at
the upper right side of the screen.
LOWER AND UPPER TEMPERATURE RANGES
The ltration cycle of the pool has been factory set to 8.00 p.m. – 10.00 p.m. The starting point and
duration of the ltration cycle can be changed by selecting Filter Cycles in the Settings menu. Navigate
right and left to modify the starting time and length of the ltration cycle. The starting time and
duration of the ltration cycle can be modied up and down with the arrow keys. The ending time is
set automatically. Save the changes by navigating on the Save symbol and pressing the select key 3.
Filtration cycle 2 is factory set to run from 8:00 am to 10:00 am. The second lter cycle can be found
in the same Filter Cycles menu by navigating to the Filter cycles 2 line. You can change the second
ltration cycle’s start time and duration in the same way as the rst ltration cycle. Save the changes
by navigating on the Save symbol and pressing the select key 3.
In normal use, we recommend setting two 2-hour ltration cycles per day. In this case, the interval
between the start times of the ltration cycles must be 12 hours. For example, the ltration cycles can
be set the factory set periods 8:00–10:00 pm and 8:00–10:00 am. PLEASE NOTE! If you use the pool more
frequently than three times per week, the length of the ltration cycles must be increased.
FILTRATION CYCLES
The service mode (HOLD) can be used to stop the pump when carrying out small-scale servicing work,
for example. The service mode lasts for 60 minutes. The service mode is activated by choosing HOLD
in the Settings menu. The service mode can be interrupted manually, by pressing the EXIT symbol
with the select key.
SERVICE MODE
SELECT BASIC

18
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN
The screen view of the control panel is possible to turn for ease of use in the inside and outside of the
pool. The screen turns by selecting Normal (normal) or Invert Panel (inverted) in the Settings menu,
choose between the modes by pressing the select key 3.
View the technical settings by selecting Utilities in the Settings menu. Use the arrow keys and select
key to navigate in the technical settings menu 3.
TURNING THE DISPLAY
TECHNICAL SETTINGS
To view the additional settings, select Utilities in the Settings menu. Use the arrow keys and select key
to navigate in the additional settings menu 3.
ADDITIONAL SETTINGS
This information is only needed when asked by a service person. The view the system information,
select Information in the Settings menu. Use the arrow keys to navigate in the system information
menu. The information of the selected item is shown at the bottom left side of the screen.
SYSTEM INFORMATION
• A/B Temp: If this is on (ON), the temperatures of temperature sensors A and B are shown separately
at the upper right side of the screen.
• Fault Log: Log information of the last 24 error codes.
• Temp Display: Temperature format °F/°C.
• Time Display: Time format 12 h/24 h.
• Reminders: Messages, such as ”clean the lter” ON/OFF.
• Cleanup: Length of the additional ltration period after each time of use.
• Color: Screen background colour.
• Language: Control panel language.
• Panel: Screen and backlight time-out settings.
• Software ID (SSID): Processor software version.
• System Model: Processor model.
• Current Setup: Number of predened setup program.
• Conguration Signature: Program validation number.
• Heater Wattage: Heater power kW (1—3/3 —6).
• Heater Type: Heater type.
• Dip Switch Settings: Control centre dip switch settings.
• Panel Version: Key panel program version.
The pool has an automatic pre-set cleaning cycle. The cleaning cycle starts when the pump has been
turned off for at least 30 minutes.
CLEANING CYCLE
SELECT BASIC

OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
19
EN
In the spa menu, you can view all the controllable devices in one glance. Within the menu, the pumps
and lights and jets can be easily controlled, and the screen turned. This view is dependent on the
accessories and amount of installed jets, so the view may vary with each pool. Use the arrow keys to
navigate in the Spa menu. The chosen function has a white frame, and the function can be controlled
with the select key 3.
JETS 1 is a dual speed pump. In this menu you can easily check if the pump is on ltration or massage
speed. The JETS 1 symbol shows the status of the pump.
SPA MENU
Pump is turned off Filtration speed Massage speed
There is no need to navigate in the shortcut menu, the pool functions can be easily controlled within
one view. The jets and lights of the pool are controlled with the arrow keys, press the Select key
3to
get back to the main view. Like in the Spa menu, the pump status can be easily viewed in the shortcut
menu.
SHORTCUT MENU
From time to time different timed reminder messages will appear at the bottom left side of the screen.
Messages can be bypassed by pressing the arrow key to the right. The most common messages and
their meaning are shown in the table below.
TIMED MESSAGES
MESSAGE MEANING
Check the pH Check the pH of the water and adjust the chemicals if necessary.
Check the sanitizer Check the amount of chloride and add if necessary.
Clean the lter Clean the lter.
Test the GFCI Check that the ground fault circuit interrupter is functional.
Change the water Replace the water in the outdoor spa pool.
Clean the cover Clean the insulation cover.
Change the lter Change the lter
SELECT BASIC

20
OY NORDIC SPA LTD | Tehdaskatu 7, 24100 Salo | www.novitek.
EN
The error messages are shown at the left lower side. The table below shows the most common error
codes, their meanings and the required measures. Always take the required measures and contact your
distributor or service agent if necessary.
ERROR CODES
CODE MEANING REQUIRED MEASURE
DARK SCREEN The pool is not receiving power. Turn on power to the pool / check the
connection.
Possible freezing condition The pool may have frozen
The pumps will turn on automatically,
regardless of the pool’s mode. Contact your
service agent.
Water is too hot
OVERTEMPERATURE – One of the
temperature sensors has detected a
temperature of 43.3 °C or higher.
DO NOT ENTER THE WATER! The pool will
turn off and turn on again once the water
temperature has decreased to 41.7 °C.
Remove the pool cover to cool the water.
The water ow is low
Notable difference in temperatures
measured by sensors A and B. Indicates a
problem with the water ow.
Check that there is enough water, ll if
necessary. Clean the lter and check that
the pumps work. If the problem continues,
contact your service agent.
The water ow has failed
Continuous problems with the water
ow. The heater will turn off if this code
appears ve times in a day.
Check that the lter is clean. Turn the
heater on again by pressing any icon.
If the problem continues, contact your
service agent.
The heater may be dry The water ow in the heater is low, or
there is air in the heater.
Turn the pool off for 15 minutes. Check that
there is enough water and ll if necessary.
If necessary, remove air according to the
instructions for clearing an airlock. Return
the pool to the normal mode by pressing
any icon. If the problem continues, contact
your service agent.
The heater is dry Not enough water in the heater. The pool
will turn itself off.
Check that there is enough water, ll if
necessary. Clean the lter and check that
the pumps work. If the problem continues,
contact your service agent.
The heater is too hot
OVERTEMPERATURE – One of the
temperature sensors has detected a
temperature of 47.8 °C or higher.
DO NOT ENTER THE WATER! Remove
the pool cover to allow the water to cool.
After the water has cooled down, reset the
system by pressing any icon.
Sensors are out of sync Temperature sensors out of balance.
The phenomenon may be temporary. If the
problem continues, contact your service
agent.
Sensors are out of sync -- Call for service-- The temperature sensors have been out of
balance for at least an hour. Contact your service agent.
Sensor A fault, Sensor B fault Temperature sensor A or B does not work.
The pool has turned off.
May occur momentarily when the
temperature rises too high. The message
will disappear once the temperature
decreases. If the problem continues,
contact your service agent.
A pump may be stuck on The pump will not turn off.
DO NOT ENTER THE WATER! The water
may have overheated. Turn off power to
the pool and contact your service agent.
SELECT BASIC
