Novus NVB-100/4MPG Manual

NVB-100/4MPG
NVB-200/8MPG
NVB-400/16MPG
har d w a r e i n s t a l lati o n
i n s t r u kc ja i n s t al acj i

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 2

NVB-100/4MPG
NVB-200/8MPG
NVB-400/16MPG
har d w a r e i n s t a l lati o n

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 4
TABLE OF CONTENTS
1. IMPORTANT SAFEGUARDS AND WARNINGS……………………….5
2. SPECIFICATION
…………………………. …………………………… . 6
3. MODELS OF CARDS………………...………………...………………….9
4. ACCESSORY……………………………………………………………...1
5. DRIVERS INSTALLATION……………………………………...……….13
6. SOFTWARE INSTALLATION…………………………………...……….16
Technical modification are subject to change without prior notice. Misprints reserved.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 5
1. Important Safeguards and warnings:
1. Read, keep, and follow these instructions.
2. Heed all warnings.
3. There are no user-serviceable parts inside this unit. Only authorized service personnel may open
the unit.
4. Installation and servicing should only be done by qualified service personnel and conform to all
local codes.
5. Unplug the unit from the outlet and refer servicing to qualified service personnel under the
following conditions:
 When the power supply cord or plug is damaged.
 If liquid has been spilled or objects have fallen into the unit.
 If the unit has been submerged under water.
 If the unit does not operate normally by following the operating instructions.
 If the unit has been dropped or the cabinet has been damaged.
 When the unit exhibits a distinct change in performance.
6. Unplug the unit from the power outlet before cleaning. Do not use liquid cleaners or aerosol
cleaners. Use a damp cloth for cleaning purposes.
7. Do not block any ventilation openings. Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat source or near water (any wet area).
9. Only use attachments / accessories specified by the manufacturer.
The product and / or manual may bear the following marks:
This symbol indicates that dangerous voltage constituting a risk of electric shock is present within this
unit.
This symbol indicates that there are important operating and maintenance instructions in the literature
accompanying this unit.
This product is carrying the CE-mark in accordance with the related European
Directives. Responsible for CE-marking is Novus Security sp. z o.o.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 6
2. Spe ifi ations:
Model NVB-100/4MPG
(one board)
NVB-200/8MPG
(one board)
NVB-400/16MPG
(two board)
1 Camera Input 4 8 16
2 Audio In 4 8 16
3 Sensor Input 4 8 16
4 Relay Out 4 4 8
5 Composite Out 1 channel (switching, but selectable) 2 channel (same)
6 Compression Code MPEG-4 Hardware Codec
8 Display Fr. Rate Real Time Live (352 x 288)
9 Fr. Rate at Re ord. Mode
352 x 288 25 fps/ch 25 fps/ch 25 fps/ch
7 4 x 288 6.25 fps/ch 6.25 fps/ch 6.25 fps/ch
7 4 x 576 6.25 fps/ch 6.25 fps/ch 6.25 fps/ch
10 En oded File Size .7 - 5 KB/frame (352 x 288)
11 Image format YUV
12 Sear hing
Main DVR Local Searching (Image and audio)
Remote PC Remote and Local Searching (Image)
Web (over Internet) Remote Search
13 Ba k-Up
Media DAT, CD, DVD, Network Drive
Saving (moving image) AVI (Special) from backup viewer (main), AVI from search (remote),
Saving (static image) JPEG from search, backup viewer
Web (over Internet) AVI Back up
14 Remote Conne tions
Modem PSTN, ISDN
TCP/IP Cable Modem, DSL, Ethernet
15 PTZ Interfa e RS232/RS422/RS485
Availability Main DVR, Remote PC, Web Search over internet
16 Other features
Motion Detection Hardware motion Detection
Image Security WaterMark
Application software POS , Access control , ATM , PDA etc
Protect System Hardware Watchdog
Backup Viewer Viewer of Backup Data stored other place
Quick Viewer Emergency Data Recovery
DB Tool Generating Index for Removed HDD to other machine
17 Compatible system
CPU Equivalent. or more than Pentium IV- 1.8 GHz
Main Board Intel, ASUS, GigaByte Main board equipped with Intel 845PE, 865 Chipset
RAM 512 MB
VGA Later than ATI 75

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 7
Features
1. 4, 8, 16 Camera Inputs / Output
 Normal input condition: 75 Ohm, 1 Volt ( p-p )
2. 1~16 Sensor Inputs
 As default,
 Additional power supply of DC 12 Volts must be provided for sensor operation.
3. 1~16 Digital Outputs (Relay Outputs)
 As default,
 Additional power supply of DC 12 Volts must be provided for relay operation.
4. Sound Re ording and Two Way Communi ations Capabilities
 16 channel sound recording.
 Each channel can have two way of communication, one by one channel.
5. Multi-Viewing
 The multi viewing is applicable to one of 1, 4, 6, 9, 1 , 16 camera views including the
enlarging screen feature.
6. PAN/TILT/ZOOM/FOCUS Capabilities
 You can control the camera by the DiViS program just like manipulating the camera by
controller, if the camera supports PTZ control, of course.
7. Auto Rebooting System
 When DiViS DVR system detects a malfunction in the system and this feature is set to enable,
the system automatically reboots and corrects the malfunctions. This is so called Watch-dog
feature.
8. Motion Dete tion and Sensor Trigger
 It is possible to record images only when movements are detected, which permits you to
exclude storage of unnecessary recording. Consequently, you can optimize the usage of storage
disc space.
9. S heduled re ording
 You can schedule the recording in accordance with program you made.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 8
10. Data Ba kup and Auto Ba kup
 Data Backup can be transferred to different media like DAT, CD, or DVD. User can select
the data backup of the specific camera. Also specific image can be acquired from video clip
of the designated date and time. And just like the scheduled recording, the scheduled
backup program can be preset and utilized.
11. Digitalized Video Sear h
 Recorded data can be played back. One or multiple cameras views of the designated time
can be viewed. By inputting date and time user can ,not only, retrieve single image from the
video, but also save it separately and print it out.
12. Network Support ( TCP/IP , ISDN ,PSTN Support)
 With network software, you can log in DiViS-main remotely to search and save the video
data locally, and even change the settings of the operating programs.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 9
3. Models of ards:
1. NVB-100/4MPG
2. NVB-200/8MPG
3. NVB-400/16MPG

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 1
4. A essory:
1. Video Input
2. Audio Input
3. TV-Out, Sensor, Relay
TV-OUT
↓
1 2 3 4 G G G 8 7 6 5 4 3 2 1

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 11
4. RS-232 to RS-422/RS-485 Converter:
This is the converter for controlling of Pan/Tilt Device.
1. Connect the cable to computer serial Port.
2. You can select one of the three Power connectors.
 1 : Power from Capture Board(+5V) 1
 2 : Power from System Power Supply 2
 3 : Power from System Power Supply 3
3. Connect data line from camera to this port.
4. Set the jumper switch as guidance for RS-422 Pan/Tilt
5. Set the jumper switch as guidance for RS-458 Pan/Tilt

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 12
6. In case of RS232 Pan/tilt port , connect directly to RS232 port of the system.
7. RS-422/485 Pin number port
RS-422/485 Connector
Pin name Pin number
- TxData 2
+ TxData 3
- RxData 4
+ RxData 5
Signal 1.5

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 13
5. Drivers Installation:
INSTALATION NOTES:
1. Intel Chipset mother board are recommended
 Not compatible with mother boards that are specifically designed such us for Small Form
Factor (SFF-Mobile).
2. Intel Pentium 4 2.4 or higher for CPU are recommended
 CPU that is lower than Intel Pentium 4 2.4 can reduce the recording frame rate.
 Recommend Intel Pentium 4 3. or higher for 32 channel.
3. 512MB or more of the system memory is recommended
 Less than 512MB of memory may bring down the overall system performance.
 1GB of memory or more is required for 32 channel board.
4. Recommend ATI Radeon 9 or higher.
 Using video card lower than ATI Radeon 9 may affect the recording data.
 Intel onboard Extreme II VGA is an alternative.
5. 12 GB HDD or larger hard drive is recommended.
 Install the latest Service Pack when using 16 GB or larger hard drive.
 Recommend S-ATA type hard drive for 32 channel.
6. Install Direct X 8. or higher.
 Under Windows 2 , must install Direct X 8. or higher for sound recording. (In
Windows XP, Direct X 8. is installed as default.)
7. Disable screen saver and Standby mode.
 Turn off System Standby mode.
 Turn off Screen saver.
 Turn off all the energy saving feature.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 14
INSTALATION:
When installing board for the first time, the above message will appear. Click “Cancel”.
Open Driver folder in CD-Rom and run “Installer”.
Click “Next”.

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 15
Click „Install”
When the above picture appears, installation is completed. Click “Reboot” to restart the system.
The drivers for each models of cards:
1. NVB-1 /4MPG:
 DVR MPG 4 Capture Card
2. NVB-2 /8MPG:
 DVR MPG 4 Capture Card
 DVR MPG 4 Capture Card
3.NVB-4 /16MPG:
 DVR MPG 4 Capture Card
 DVR MPG 4 Capture Card
 DVR MPG 4 Capture Card
 DVR MPG 4 Capture Card

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 16
6. Software Installation:
Run “Setup.exe”.
(Choose the language in which to install the program.)
Click “Next”.
Choose the proper media format (NTSC or PAL) and continue by clicking “Next.”

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 17
 USER NAME: make top Admin user name;
 PASSWORD: make top Admin user possword;
 Confirm P/W: confirm the password;
Once setup of the software has been complete, the system will need to be restarted to allow the
settings to take effect.
After rebooting system, you will find above icons on the desktop:
DVR MAIN— main software;
DVR Search — search software;
DVR Setting — setting software

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 18

Hardware Installation Guide of MPG Capture Card
© Copyright 2005, Novus Security Sp. z o.o. All rights
Page 19

NOVUS Security Sp. z o.o.
Pulawska Street 431, 02-801 arsaw, Poland
phone.: [phone], fax: [phone]
www.novuscctv.com
2 5- 5-25.
