Novus NVIP-2DPT-8731/30/T User manual

Quick start guide
NVIP-2DPT-8731/30/T

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
2
THE PRODUCT MEETS THE REQUIREMENTS CONTAINED IN THE FOLLOWING DIRECTIVES:
Exclusion of liability in the event of damage to data contained on disks or other devices or media:
The manufacturer is not liable in the event of damage or loss of data contained on disks or other
devices or carriers during the operation of the Product.
Obligation to consult the Manufacturer before performing any action not provided for in the
instruction manual or other documents:
Before performing an action that is not provided for a given Product in the user manual, other
documents attached to the Product or does not result from the normal purpose of the Product, it is
necessary, under pain of exclusion of the Manufacturer's liability for the consequences of such action,
to contact the Manufacturer.
CAUTIONS AND WARNINGS
Pictures in this publication showing camera views can be simulations. Actual camera
images may vary depending on the type, model, settings, observation area, or
environmental conditions.
DIRECTIVE 2014/30/EU OF THE EUROPEAN PARLIMENT AND OF THE
COUNCIL of 26 February 2014 on the harmonization of the laws of the Member States
relating to electromagnetic compatibility (OJ L 96, 29.3.2014, p. 79–106, with changes).
DIRECTIVE 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE
COUNCIL of 4 July 2012 on waste electrical and electronic equipment WEEE)
(OJ L 197, 24.7.2012, p. 38–71, with changes).
DIRECTIVE 2011/65/EU OF THE EUROPEAN PARLIAMENT AND OF THE
COUNCIL of 8 June 2011 on the restriction of the use of certain hazardous substances in
electrical and electronic equipment (OJ L 174, 1.7.2011, p. 88–110, with changes).
COMMISION DELEGATED DIRECTIVE (EU) 2015/863 of 31 March 2015 amending
Annex II to Directive 2011/65/EU of the European Parliament and of the Council as regards
the list of restricted substances.
DIRECTIVE (EU) 2017/2102 OF THE EUROPEAN PARLIAMENT AND OF THE
COUNCIL of 15 November 2017 amending Directive 2011/65/EU on the restriction of the
use of certain hazardous substances in electrical and electronic equipment.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
3
1. Please read this manual carefully before installation and operation;
2. Please keep this manual for the lifespan of the device in case referring to the contents of this
manual is necessary;
3. It is necessary to comply with the safety requirements described in the manual, as they have a
direct impact on the safety of users and the durability and reliability of the device;
4. All activities performed by installers and users must be carried out as described in the manual;
5. The device should be disconnected from power sources during maintenance procedures;
6. It is not allowed to use any additional devices, components or accessories not provided for and not
recommended by the manufacturer;
7. Do not install this device in places where proper ventilation cannot be provided (e.g. closed
cabinets, etc.), as this may cause heat build-up and may result in damage;
8. Do not place the device on unstable surfaces. Installation must be carried out by qualified
personnel with appropriate permissions in accordance with the recommendations provided in this
manual;
9. The device may be powered only from sources with parameters compliant with those indicated by
the manufacturer in the technical data;
SAFETY REQUIREMENTS
Before using the device, read the instruction manual in order to ensure proper and safe operation
of the device. Failure to comply with the instructions may lead to damage to the device and/or
safety violations.
The user may not repair the device himself. Repairs and maintenance of the device may only be
performed by qualified service personnel.
The device, which is an element of a professional CCTV system used for supervision and
control, is not intended for self-assembly in households by persons without specialist
knowledge.
As the product is constantly improved and optimized, some of its parameters and functions may have
changed from those described in this manual. If in doubt, please refer to the user manual at
www.novuscctv.com
The user manual located at www.novuscctv.com is always the most up-to-date version.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
4
FOREWORD INFORMATION
1. TECHNICAL SPECIFICATION
IMAGE - THERMAL MODULE
Image Sensor Uncooled FPA Microbolometer
Number of Eecve Pixels 400 (H) x 300 (V)
Pixel Size 17 µm
Spectral Range 8 - 14 µm
Thermal Sensivity 40 mK
Thermovision Modes
White Hot, Black Hot, Rainbow, Ironbow, HSV, Autumn, Bone,
Cool, Copper, Fire Hot, Pink, Spring, Summer, Winter, Jet, Flame,
Rosebengal
Detecon Temperature -20°C ~ 150°C
Digital Noise Reducon (DNR) 2D, 3D
LENS - THERMAL MODULE
Lens Type f=35 mm/F1.0
Object Detecon Range 1029m - human , 3137m - vehicle , 1029m - re
Object Recognion Range 257m - human , 789m - vehicle
Image Sensor 4 MPX CMOS sensor 1/2.8” SONY
Number of Eecve Pixels 2592 (H) x 1520 (V)
Min. Illuminaon 0.01 lx/F1.2 - color mode,
0.001 lx/F1.2 - B/W mode
Electronic Shuer auto: 1/5 s ~ 1/20000 s
Digital Slow Shuer (DSS) up to 1/5 s
Wide Dynamic Range (WDR) yes (double scan sensor)
Digital Image Stabilizaon (DIS) yes
Digital Noise Reducon (DNR) 3D
Defog Funcon (F-DNR) yes
Highlight Compensaon (HLC) yes
Back Light Compensaon (BLC) yes
LENS
Opcal Zoom 30x
Lens Type motorized, auto-iris funcon, f=5.3 ~ 159 mm/F1.6 ~ F4.3
Auto-focus zoom trigger, manual trigger
DAY/NIGHT
Switching Type mechanical IR cut lter
Switching Mode auto, me
Switching Level Adjustment yes
Switching Delay 0 ~ 180 s

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
5
FOREWORD INFORMATION
NETWORK
Stream Resoluon
2592 x 1520, 2560 x 1440 (QHD), 2304 x 1296, 1920 x 1080
(Full HD), 1280 x 720 (HD), 720 x 576 (D1), 640 x 480 (VGA),
352 x 288 (CIF), 320 x 240 (QVGA)
for thermal module: 352 x 240, 704x576
Frame Rate 30 fps for each resoluon
Mulstreaming Mode 3 streams (main stream, sub stream, third stream)
Video/Audio Compression H.264, H.265, MJPEG/G.711, RAW_PCM
Number of Simultaneous Connecons max. 10
Network Protocols Support HTTP, TCP/IP, IPv4/v6, UDP, DHCP, DNS, RTSP, RTP, IEEE 802.1X,
PPPoE, SMTP, RTCP, HTML5
Camera Conguraon from Firefox, Chrome, Edge browsers
languages: Polish, English, and others
Compable Soware NOVUS MANAGEMENT SYSTEM VSS
PTZ
Preset Commands 400
Tours 12 (up to 32 presets per tour)
Auto-Scans 8
Paerns 6
Tilt/Pan Range -90° ~ 90°/360° (connuous)
Pan/Tilt Speed up to 60°/s (proporonal to zoom)
Preset Speed up to 60°/s
OTHER FUNCTIONS
Temperature Measurement yes - for thermal module
Temperature Alarm yes - for thermal module
Temperature Measurement Zones 20 - for thermal module polygon, line, point
Temperature Measurement Accuracy +-2°C / +-2%
Moon Detecon yes
Region of interest (ROI) 8
Video Content Analysis (VCA)
line cross, zone entrance, zone exit, double line cross, loiter,
converse, objects disnguishing, people counng
for thermal module: re detecon, temperature measurement, re
source detecon, smoke detecon
Image Processing Defecve Pixel Correcon (DPC), mirror eect, vercal ip,
horizontal ip
Restoring default sengs via web browser

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
6
FOREWORD INFORMATION
1.1. Camera dimensions (given in mm)
INTERFACES
Video Output BNC, 1.0 Vp-p, 75 Ohm
Audio Input/Output 2 x Jack (3.5 mm)/2 x Jack (3.5 mm)
Alarm Input/Output 9 (NO/NC)/4
Network Interface 1 x Ethernet - RJ-45 interface, 10/100 Mbit/s
INSTALLATION PARAMETERS
Dimensions (mm) with bracket: 419 (W) x 316 (H) x 282 (L)
Weight 16.5 kg
Degree of Protecon IP 66 (details in the user’s manual on page 10)
Enclosure aluminium, white,
Power Supply 36 VDC (power supply included)
Power Consumpon 80 W
Operang Temperature -40°C ~ 60°C
Humidity max. 90%, relave (non-condensing)
Built-in Heater/Fan yes/yes

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
7
1.2. Package contents
After you open the package make sure that the following elements are inside:
• Thermal IP camera
• Bag with mounting accessories
• Two special screws for adjusting the focus of the thermal imaging module lens
• Connection cables
• Power supply
• Quick Start Guide
If any of this elements has been damaged during transport, pack all the elements back into the original
box and contact your supplier for further assistance.
2. START-UP AND INITIAL CONFIGURATION
Before starting the device familiarize yourself with the description and the role of particular
inputs, outputs and adjusting elements that the device is equipped with.
2.1. Description of the camera's electrical connectors
All electrical connections of the camera are made using two multi-conductor cables with plugs,
plugged into the appropriate sockets in the base of the camera. The socket and plug of the power
supply cable are marked "DC 36V". The second socket and plug are unmarked. Connecting the plug to
the appropriate socket is done by inserting it in the appropriate position and turning the ring on the
plug clockwise until it stops. Proper and careful connection of the plugs is essential to ensure a tight
connection.
START-UP AND INITIAL CONFIGURATION
When connecting the plug, pay attention to the positioning elements. The plug has cutouts in the
housing, and the socket has protrusions enabling these elements to be connected in only one,
precisely defined way.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
8
Each of the cables plugs into a twenty-six-pin socket. The following tables describe the meanings of
the wires in each cable.
2.1.1. Power cable
START-UP AND INITIAL CONFIGURATION
Name Funcon Wire color Pin number
36 VDC - Power ground Black (thick) 1
36VDC + Power Red (thick) 2
36 VDC - Power ground Black (thick) 3
36 VDC - Power ground Black (thick) 4
ALARM OUT 1 Alarm output 1 Red (thin) 5
36VDC + Power Red (thick) 6
36VDC + Power Red (thick) 7
AUDIO IN GND Audio input ground Red mini-jack plug 8
AUDIO IN Audio input Red mini-jack plug 9
ALARM OUT 1 Alarm output 1 Black (thin) 10
ALARM OUT 3 Alarm output 3 Blue 11
ALARM OUT 3 Alarm output 3 Pink 12
ALARM OUT 4 Alarm output 4 White 13
AUDIO OUT GND Audio output ground Green mini-jack plug 14
AUDIO OUT Audio output Green mini-jack plug 15
VIDEO OUT Analog video output BNC plug 16
VIDEO OUT GND Analog video output ground BNC plug 17
ALARM OUT 2 Alarm output 2 White and orange 18
ALARM OUT 4 Alarm output 4 Green 19
RS485 A RS485 port Orange (thick) 20
RS485 B RS485 port Yellow (thick) 21
ETH TX+ RJ45 port RJ45 socket 22
ETH TX- RJ45 port RJ45 socket 23
ALARM OUT 2 Alarm output 2 White and yellow 24
ETH TX+ RJ45 port RJ45 socket 25
ETH TX- RJ45 port RJ45 socket 26

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
9
Each of the cables plugs into a twenty-six-pin socket. The following tables describe the meanings of
the wires in each cable.
2.1.2. Signal Cable
START-UP AND INITIAL CONFIGURATION
Name Funcon Wire color Pin number
- Unused - 1
- Unused - 2
- Unused - 3
- Unused - 4
- Unused - 5
- Unused - 6
- Unused - 7
- Unused - 8
- Unused - 9
- Unused - 10
ALARM IN 1 Alarm input 1 White 11
ALARM IN 2 Alarm input 2 White and orange 12
ALARM IN 3 Alarm input 3 Blue 13
AUDIO IN GND Audio input ground Red mini-jack plug 14
AUDIO IN Audio input Red mini-jack plug 15
VIDEO OUT Analog video output BNC plug 16
VIDEO OUT GND Analog video output ground BNC plug 17
AUDIO OUT Audio output Green mini-jack plug 18
AUDIO OUT GND Audio output ground Green mini-jack plug 19
ALARM IN 4 Alarm input 4 Pink 20
ALARM IN 5 Alarm input 5 Red (thin) 21
ALARM IN 6 Alarm input 6 White and yellow 22
ALARM IN 7 Alarm input 7 Black (thin) 23
ALARM IN 8 Alarm input 8 Yellow (thick) 24
ALARM IN 9 Alarm input 9 Orange (thick) 25
ALARM IN GND Ground of alarm inputs Black (thick) 26

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
10
2.2. Connection of alarm input and output
2.3. Power connection
The camera must be powered from the power supply included in the kit. If you need to use one of the
DC power supplies available on the market, select a model that meets the technical requirements of the
camera. The power supply must provide a stabilized DC voltage of 36V, must allow power
consumption of at least 100W, and must enable connection to the camera using bare wires.
The power supply cables should be connected to the camera cables, maintaining the correct polarity.
2.4 Protection against water ingress
The declared tightness class of the camera applies to its housing, cable connectors on the housing (if
any) and/or the point of entry of the connecting cables into the housing (if any), provided that the
connecting cables are properly connected and properly assembled in accordance with the procedure
given in point 2.5 of the manual. It is the responsibility of the person installing the camera to protect the
elements that require it against moisture.
The manufacturer is not responsible for any damage to the camera resulting from failure to comply
with the above-mentioned obligation, which at the same time means that they are not subject to
warranty repairs.
START-UP AND INITIAL CONFIGURATION
Connecon diagram of an exemplary alarm
input
ALARM IN 1
ALARM IN GND
Connecon diagram of an exemplary alarm
output
ALARM OUT 1
ALARM OUT 1
Illustrative drawing
Water protected area Area that needs to be sealed
during installation

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
11
2.5. Camera mounting
 Mark the holes in the mounting location for screwing the camera base. You can use the drawing
below.
Screw the camera to the base using screws from the mounting kit or your own screws appropriate
to the construction material of the mounting location. In the second case, screws or bolts that
ensure adequate strength should be used.
 Connect the connection cables and route them to a hermetic junction box (not included). Make
electrical connections.
 Adjust the focus of the thermal imaging module (if necessary). Adjustment is made by screwing
special screws included in the accessories into the holes in the ring around the lens. Using the
screws as handles, gently rotate the ring until the desired focus is achieved. After completing the
adjustment, remove the screws.
START-UP AND INITIAL CONFIGURATION
The mounting location must ensure free rotation of the camera heads. For this purpose, free
space must be provided within a radius of at least 50 cm from the vertical axis of the camera.
When removing the camera from the packaging and carrying it, grasp only the body of the
device (middle part). Grabbing the camera modules may damage them.
To ensure safety, the mounting location must be able to support at least four times the weight of
the camera.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
12
2.6. Start-up camera
To start the camera, connect the Ethernet cable to the RJ45 network socket of the IP camera, and the
other end to the network switch.
The recommended method of starting and configuring the IP camera is to connect it to a PC or laptop in
a dedicated network switch to which no other devices are connected. In case of power supply from an
external power supply, it is enough to use any network switch or a cable connected directly to the
computer. For network configuration data (IP address, gateway, netmask etc.), please contact the
administrator of the network in which the device is to work.
• Connection using an external power supply and a network switch
• Connection using the camera's external power supply and direct connection to the computer
Caution!
In order to provide protection against voltage surges/lightning strikes, usage of appropriate surge
protectors is advised. Any damages resulting from surges are not eligible for service repairs.
START-UP AND INITIAL CONFIGURATION
IP camera
Data transmission Data transmission
Switch PC
PCIP camera
Data transmission - Ethernet crossover cable

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
13
2.7. Parameter configuration using a web browser
The default network settings for Novus NVIP-2DPT-8731/30/T camera are:
1. IP address of the video module - 192.168.1.199
2. IP address of the thermal imaging module - 192.168.1.200
3. Network mask - 255.255.255.0
4. Gateway - 192.168.1.1
5. User name - root
6. Password - pass
Knowing the camera’s IP address you need to appropriately set PC IP address, so the two devices can
operate in one network subnet ( e.g. for IP 192.168.1.1, appropriate address for the camera ranges from
192.168.1.2 to 192.168.1.254, for example 192.168.1.60). It is not allowed to set the same addresses for
camera and PC computer
You can either set a network configuration (IP address, gateway, net mask, etc.) of NOVUS IP camera
yourself or select DHCP mode (DHCP server is required in this method in target network) by using
web browser or by NMS software. When you use DHCP server check IP address lease and its linking
with camera MAC address to avoid changing or losing IP address during device operation or network/
DHCP server breakdown. You have to remember to use a new camera IP address after changing
network parameters.
After network setting configuration has been done, the camera can be connected to a target network.
START-UP AND INITIAL CONFIGURATION

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
14
START-UP AND INITIAL CONFIGURATION
2.8. Security recommendations for network architecture and configuration
Caution!
Below are shown security recommendations for network architecture and configuration
of CCTV systems that are connected to the Internet to reduce the risk of unauthorized interference with
the system by a third party.
1. Absolutely change the default passwords and user names (if the device gives this possibility) of
all applied network devices (recorders, cameras, routers, network switches, etc.) to the
severely complexity password. Use lowercase and uppercase letters, numbers, and special
characters if there is such possibility.
2. Depending on the available functionality in the order to restrict access to the used network
devices at the administrator account level, it is recommended to configure the users accounts
accordingly.
3. Do not use DMZ function (Demilitarized zone) in your router. Using that function you open the
access to recorder system from the Internet on all ports, which gives possibility for an
unauthorized interference with the system.
Instead of DMZ use port forwarding redirect only the ports which are necessary for the
performance of the connection (detailed information about ports of communication in
different models of recorders, cameras, etc. can be found in the operating instructions).
4. Use routers with firewall function and make sure it is enabled and properly configured.
5. It is recommended to change the default network communication port numbers of used devices
if there is such possibility.
6. If used network devices has aUPnP feature and it is not used, turn it off.
7. If used network devices has aP2P feature and it is not used, turn it off.
8. If used network devices support HTTPS protocol for connection, it is recommended to use it.
9. If used network devices support IP filtering for authorized connections function, it is
recommended to use it.
10. If used recorder has two network interfaces it is recommended to use both of them to physically
separate network for cameras and network for Internet connection. The only device in the system,
accessible from Internet will be recorder - there will be no physically access directly to any
camera.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
15
3. NETWORK CONNECTION USING WEB BROSWER
3.1. Recommended PC specification for web browser connections
The following requirements apply to the connection with the IP camera assuming smooth video display
at the maximum resolution:
1. CPU Intel Core i3 3GHz or newer
2. RAM Memory min. 4 GB
3. Graphic card (any Nvidia GeForce 512MB Ram or equivalent)
4. OS Windows 10/11
5. Network card 100/1000 Mb/s
3.2. First connection to the camera via a web browser
Enter the IP address of the camera in the address bar of the web browser. If the given address is correct
and the target device is reachable at the moment, the login page will be displayed.
Enter the default login details in the "User Name" and "Password" fields. Above, from the language
selection list, you can select the language in which the camera menu will be displayed. By default it is
English.
After entering your login details, press the arrow button to log in.
NETWORK CONNECTION USING WEB BROWSER

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
16
USING AND CONFIGURING
After logging in, the camera will display the remote viewing window. At this point, the camera is ready
for operation, but it is recommended to install a plug-in that improves image quality, display stability
and supports some functions, e.g. intercom.
To do this, click on the "IPCLocalServer.exe" add-on installation icon located in the upper right corner
of the window, download the plug-in file to your computer and start the installation, and then follow
the installer's instructions.
After restarting the browser, a playback mode selection window may appear.
In the window, you can click on the "Continue to use old plug-in" link to use the "IPC Local Server"
add-on to display the image, or you can click on the "Play without plug-in" link to use HTML5 for
displaying the image. Switching between playback modes is also possible during live view by clicking
on the link below the video window.
4. USING AND CONFIGURING
Due to the weight and size of the camera, it is recommended to launch it and initially configure
it before installing it at the target location. This will allow you to familiarize yourself with its
design, all functions and operating characteristics.

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
17
USING AND CONFIGURING
4.1. The remote preview interface
1. Buttons for selecting the operating mode and configure the cameras:
Live - select stream for live view
Playback - enables the playback panel of recordings from the memory card
People counting - displays the people counting statistics panel
Configuration - displays the configuration panel camera
Since the remote viewing windows of the vision and thermal imaging modules are functionally
almost identical, their description is based on the viewing window of the thermal imaging
module. Any differences are marked in the text.
5
4
3
12
6

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
18
2. Live Preview window.
Double-clicking the left mouse button on the preview window enables and disables the display
of the image on the full screen.
3. Camera access icons:
4. Selection of the stream to display in the remote view window.
5. Icons controlling additional functions:
6. PTZ control panel. It allows to control the camera's PTZ functions and activate the vision module's
wiper.
USING AND CONFIGURING
- information about intercom operation (visible when HTML5 playback is selected)
- option inactive
- downloading the „IPCLocalServer.exe” add-on
- logging out of the camera
- displays the password change window for the logged in user
- information about the logged in user
- enables the ability to control PTZ 3D (visible when plug-in playback is selected)
- enables and disables the live preview
- turns audio monitoring on and off
- enables and disables the audio transmission to the camera
- displays the sensor settings menu
- takes a screenshot and saves it to the user PC
- enables and disables recording of the video stream to the user PC
- enables the display of the object classification window in the live view (available in
the vision module).

NVIP-2DPT-8731/30/T Quick start guide version 1.0
All rights reserved © AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
19
RESTORING FACTORY SETTINGS
5. RESTORING FACTORY SETTINGS
The camera has an option in the menu to reset its settings to factory settings. To restore the camera
settings to the default settings, go to the Settings -> Maintenance tab and press the symbol next to the
"Restore to factory default" option. Once confirmed, the camera settings will be reset.

25.09.2023 TF, MK v1.0
AAT SYSTEMY BEZPIECZEŃSTWA Sp. z o.o.
ul. Puławska 431, 02-801 Warszawa, Polska
tel.: [phone], [email protected]
www.novuscctv.com/pl
