NR Electric PCS-9785 User manual

PCS-9785
Satellite-Synchronized Clock
Instruction Manual
NR Electric Co., Ltd.
08020 08020 08020
08020 08020 08020
08020 08020 08020

08020 08020 08020
08020 08020 08020
08020 08020 08020

Preface
PCS-9785 Satellite-Synchronized Clock
i
Date: 2019-07-05
Preface
Introduction
This guide and the relevant operating or service manual documentation for the equipment provide
full information on safe handling, commissioning and testing of this equipment.
Documentation for equipment ordered from NR is dispatched separately from manufactured goods
and may not be received at the same time. Therefore, this guide is provided to ensure that printed
information normally present on equipment is fully understood by the recipient.
Before carrying out any work on the equipment, the user should be familiar with the contents of
this manual, and read relevant chapter carefully.
This chapter describes the safety precautions recommended when using the equipment. Before
installing and using the equipment, this chapter must be thoroughly read and understood.
Health and Safety
The information in this chapter of the equipment documentation is intended to ensure that
equipment is properly installed and handled in order to be maintained in a safe condition.
When electrical equipment is in operation, dangerous voltages will be present in certain parts of
the equipment. Failure to observe warning notices, incorrect use, or improper use may endanger
personnel and equipment and cause personal injury or physical damage.
Before working in the terminal strip area, the equipment must be isolated.
Proper and safe operation of the equipment depends on appropriate shipping and handling,
proper storage, installation and commissioning, and on careful operation, maintenance and
servicing. For this reason, only qualified personnel may work on or operate the equipment.
Qualified personnel are individuals who:
 Are familiar with the installation, commissioning, and operation of the equipment and of the
system to which it is being connected;
 Are able to safely perform switching operations in accordance with accepted safety
engineering practices and are authorized to energize and de-energize equipment and to
isolate, ground, and label it;
 Are trained in the care and use of safety apparatus in accordance with safety engineering
practices;
 Are trained in emergency procedures (first aid).
Instructions and Warnings
The following indicators and standard definitions are used:
08020 08020 08020
08020 08020 08020
08020 08020 08020

Preface
PCS-9785 Satellite-Synchronized Clock
ii
Date: 2019-07-05
DANGER! means that death, severe personal injury and considerable equipment damage
will occur if safety precautions are disregarded.
WARNING! means that death, severe personal and considerable equipment damage
could occur if safety precautions are disregarded.
CAUTION! means that light personal injury or equipment damage may occur if safety
precautions are disregarded.
NOTICE! is particularly applied to device damage and resulting damage of equipment.
DANGER!
NEVER allow an open current transformer (CT) secondary circuit connected to this
device while the primary system is live. Open CT circuit will produce a dangerously high
voltage that causes death.
WARNING!
ONLY qualified personnel should work on or near this device. This personnel MUST be
familiar with all safety regulations and service procedures described in this manual.
During operating of electrical device, certain part of the device is under high voltage.
Severe personal injury and significant device damage could result from improper
behavior.
WARNING!
Do NOT touch the exposed terminals of this device while the power supply is on. The
generated high voltage causes death, injury, and device damage.
WARNING!
Thirty seconds is NECESSARY for discharging the voltage. Hazardous voltage can be
present in the DC circuit just after switching off the DC power supply.
CAUTION!
 Earthing
Securely earth the device earthing terminal.
 Operating environment
ONLY use the device within the range of ambient environment and in an
environment free of abnormal vibration.
08020 08020 08020
08020 08020 08020
08020 08020 08020

Preface
PCS-9785 Satellite-Synchronized Clock
iii
Date: 2019-07-05
 Ratings
Check the input ratings BEFORE applying AC voltage/current and power supply to
the device.
 Printed circuit board
Do NOT attach or remove printed circuit board if the device is powered on.
 External circuit
Check the supply voltage used when connecting the device output contacts to
external circuits, in order to prevent overheating.
 Connection cable
Carefully handle connection cables without applying excessive force.
NOTICE!
The firmware may be upgraded to add new features or enhance/modify existing
features, please MAKE SURE that the version of this manual is compatible with the
product in your hand.
Documentation Structure
The manual provides a functional and technical description of this device and a comprehensive
set of instructions for the device’s use and application.
1 Introduction
Brief introduction of the application, functions and features.
2 Technical Data
Lists of the technical data such as electrical specifications, mechanical specifications, ambient
temperature, humidity range, communication port parameters, type tests and accuracy limits.
3 Operation Theory
Comprehensive and detailed functional description.
4 Supervision
Automatic self-supervision function of device.
5 Hardware
Description of plug-in modules and definition of pins.
6 Settings
Setting lists including system settings, communication settings and etc.
08020 08020 08020
08020 08020 08020
08020 08020 08020

Preface
PCS-9785 Satellite-Synchronized Clock
iv
Date: 2019-07-05
7 Human Machine Interface
Description of the HMI panel, LCD display, menu tree and a detailed operating guide
8 Installation
Recommendation for unpacking, handling, inspection and storage with a guide to the
mechanical and electrical installation.
9 Commissioning
Commissioning recommendation for comprising checks on the calibration and functionality of
device.
10 Maintenance
General maintenance policy.
11 Decommissioning and Disposal
General decommissioning and disposal policy.
12 Appendix
The demonstration of IRIG-B time code format.
13 Revisions History
List of document modification and update history records.
Copyright © 2019 NR. All rights reserved.
We reserve all rights to this document and to the information contained herein. Improper use in particular reproduction and dissemination
to third parties is strictly forbidden except where expressly authorized.
The information in this manual is carefully checked periodically, and necessary corrections will be included in future editions. If
nevertheless any errors are detected, suggestions for correction or improvement are greatly appreciated.
We reserve the rights to make technical improvements without notice.
NR ELECTRIC CO., LTD.
Headquarters: 69, Suyuan Avenue, Jiangning, Nanjing 211102, China
Manufactory: 18, Xinfeng Road, Jiangning, Nanjing 211111, China
Tel: [phone]
Fax: [phone]
Website: www.nrelect.com, www.nrec.com
P/N: ZL_PCS-9785_X_Instruction Manual_EN_Overseas General_X Version: R1.20
08020 08020 08020
08020 08020 08020
08020 08020 08020

1 Introduction
PCS-9785 Satellite-Synchronized Clock
1-a
Date: 2019-07-05
1 Introduction
Table of Contents
1 Introduction ..................................................................................... 1-a
1.1 Overview ........................................................................................................... 1-1
1.2 Features ............................................................................................................ 1-1
08020 08020 08020
08020 08020 08020
08020 08020 08020

1 Introduction
PCS-9785 Satellite-Synchronized Clock
1-b
Date: 2019-07-05
08020 08020 08020
08020 08020 08020
08020 08020 08020

1 Introduction
PCS-9785 Satellite-Synchronized Clock
1-1
Date: 2019-07-05
1.1 Overview
The PCS-9785 satellite-synchronized clock is usually used in Substation Automation System (SAS)
to satisfy the time unifying requirements of protection relay, disturbance fault recorder and other
IEDs. Two kinds of PCS-9785 can be adopted to build a higher reliable and accuracy clock
synchronization system in substation. The source clock can receive timing signals from its own
GPS/BDS antenna (Master Mode), while the extension clock receives IRIG-B signals from another
clock source (Slave Mode).
PCS Serial
Protection Relay & BCU
PCS-9785
Satellite-Synchronized
Clock (Source)
Other IEDs
PCS-9794
Protocol Converter
Data transmission bus (Network)
Satellite Timing Signal
Clock Synchronization bus
Coaxial cab le
PCS Serial
Protection Relay & BCU
Other IEDs
PCS-9794
Protocol Converter
Clock Synchronization bus
IRIG-B Signal
PCS-9785
Satellite-Synchronized
Clock (Extension)
1.2 Features
 Remote supervision
This device supports local SCADA and remote control centre communication in using of
protocols such as IEC 61850 Ed1.0 & Ed2.0 to realize the device running status supervision.
 Time service
This device supports GPS (Global Positioning System) and BDS (BeiDou Navigation Satellite
System). In addition, it supports antenna transmission time delay compensation.
 Signal reception
This device provides several reception channels for IRIG-B signal via its optical port or
RS-485/422 port. In addition, it supports link-based reception time delay compensation.
 High accuracy
The device accuracy is high in long term. The punctual error is less than 1μs per hour.
08020 08020 08020
08020 08020 08020
08020 08020 08020

1 Introduction
PCS-9785 Satellite-Synchronized Clock
1-2
Date: 2019-07-05
 IEEE 1588 protocol
This device supports the IEEE 1588 protocol (BC mode and OC mode) for clock
synchronization in SNTP or PRP network.
 SNTP/NTP protocol
This device supports the SNTP/NTP protocol and can work as a network time server.
 PRP/HSR
This device supports the Parallel Redundancy Protocol (PRP) and High-availability Seamless
Redundancy (HSR) protocol.
 Recording
Automatically, this device stores all the self-diagnostic record, binary status change and
service log in its internal storage.
 Output clock synchronization signal
The kinds of output clock synchronization signal is rich, including PPS (Pulse Per Second),
PPM (Pulse Per Minute), PPH (Pulse Per Hour), IRIG-B signal, timing message (serial),
SNTP/NTP timing message (network), IEEE 1588 signal, etc.
 Output interface
Various kinds of output interfaces are provided, including RS-484, RS-232, TTL, dry contact,
AC modulation, optic fiber, RJ45, etc.
 Dual power supplies redundancy
Dual power supply module is an option. The extra power supply module will be placed at the
other side of the device rack and works independently.
 Double devices redundancy strategy
With a interconnection in using of IRIG-B signal, a set of two PCS-9785 can form the "dual
device dual network" redundancy strategy to provide a higher reliable and accuracy clock
synchronization system.
 Output interface extension
The output interface extension is very flexible. In addition, the enormous interfaces are
isolated to each other.
 Easy synchronization bus extension
It is simple to extend the time synchronization bus by adding a new PCS-9785 extension
device.
 Human machine interface
The friendly HMI provides large scale LCD and navigation keypad for the display of real time,
satellite tracking status, IRIG-B inputting status, current clock source, etc.
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-a
Date: 2019-07-05
2 Technical Data
Table of Contents
2 Technical Data ................................................................................. 2-a
2.1 Electrical Specification ................................................................................... 2-1
2.1.1 Power Supply ....................................................................................................................... 2-1
2.1.2 Binary Output for Block/Alarm .............................................................................................. 2-1
2.2 Mechanical Specification ................................................................................ 2-1
2.3 Ambient Temperature and Humidity Range .................................................. 2-1
2.4 Communication Port ....................................................................................... 2-2
2.4.1 Ethernet Port ........................................................................................................................ 2-2
2.4.2 SFP Interface ........................................................................................................................ 2-2
2.5 Clock Synchronization Port ............................................................................ 2-2
2.5.1 Input ...................................................................................................................................... 2-2
2.5.1.1 EIA-485 Port ..............................................................................................................................................2-2
2.5.1.2 Optical Port ................................................................................................................................................2-2
2.5.2 Output ................................................................................................................................... 2-3
2.5.2.1 RS-485/232 Port ........................................................................................................................................2-3
2.5.2.2 Optical-coupled Contact ............................................................................................................................2-3
2.5.2.3 TTL ............................................................................................................................................................2-3
2.5.2.4 AC Modulation ...........................................................................................................................................2-3
2.5.2.5 Optical Port ................................................................................................................................................2-3
2.6 Type Test .......................................................................................................... 2-4
2.6.1 Environmental Test ............................................................................................................... 2-4
2.6.2 Mechanical Test .................................................................................................................... 2-4
2.6.3 Insulation Test....................................................................................................................... 2-4
2.6.4 Electromagnetic Compatibility .............................................................................................. 2-4
2.7 Clock Synchronization Specifications ........................................................... 2-5
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-b
Date: 2019-07-05
2.7.1 PPS/PPM/PPH ..................................................................................................................... 2-5
2.7.2 IRIG-B DC Code ................................................................................................................... 2-5
2.7.3 IRIG-B AC Code ................................................................................................................... 2-5
2.7.4 Serial Port Timing Message ................................................................................................. 2-5
2.7.5 Network ................................................................................................................................ 2-6
2.7.6 GPS Receiver ....................................................................................................................... 2-6
2.7.7 BDS Receiver ....................................................................................................................... 2-6
2.7.8 Time Frequency Measurement ............................................................................................ 2-6
2.7.9 Internal Clock ....................................................................................................................... 2-6
2.8 Certifications .................................................................................................... 2-6
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-1
Date: 2019-07-05
2.1 Electrical Specification
2.1.1 Power Supply
Standard IEC 60255-26:2013
Rated voltage 110Vdc/125Vdc, 220Vdc/250Vdc 110Vac/220Vac
Operating range 88~300Vdc 88~264Vac
Permissible AC ripple voltage Max. 15% of the nominal auxiliary voltage
Burden
Quiescent condition
Operating condition
28W
30W
2.1.2 Binary Output for Block/Alarm
Output mode Potential free contact
Maximal system voltage 380Vac, 250Vdc
Voltage withstand 1000V RMS in 1min
Continuous carry 8A
Short duration current 12A@3s, 15A@1s, 20A@0.5s, 3[email protected]
Breaking capacity (L/R=40ms)
0.70A@48Vdc
0.40A@110Vdc
0.30A@125Vdc
0.20A@220Vdc
0.15A@250Vdc
Pickup time 10ms
Drop off time 6ms
Durability Min.10,000 operations
2.2 Mechanical Specification
Mounting Way Flush mounted
Chassis color Silver grey
Weight per device Approx. 8kg
Chassis material Aluminum alloy
Location of terminal Rear panel of the device
Device structure Plug-in modular type @ rear side, integrated front plate
Protection class
Standard IEC 60255-1:2009
HMI side IP51
Terminal side IP30
Other sides IP50
2.3 Ambient Temperature and Humidity Range
Standard IEC 60255-1:2009
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-2
Date: 2019-07-05
Operating temperature -25°C to +55°C (Readability of display may be impaired below -20°C)
Transport and storage
temperature range -40°C to +70°C
Permissible humidity 5%-95%, without condensation
Pollution degree Class 2
Altitude Max. 3000m
2.4 Communication Port
2.4.1 Ethernet Port
Connecter type RJ-45
Transmission rate 100Mbits/s
Transmission standard 10Base-T/100Base-TX
Transmission distance Max. 100m
Protocol IEC 60870-5-103:1997 or IEC 61850
Safety level Isolation to ELV level
2.4.2 SFP Interface
Characteristic Glass optical fiber
Connector type LC
Fiber type Multi-mode (62.5/125μm)
Transmission distance Max. 2km
Wave length 1310nm
Transmission power Min. -23.0dBm (Avago)
Min. -19.0dBm (Yuguang)
Receiving power Min. -30.0dBm
Margin Min. +3.0dB
2.5 Clock Synchronization Port
2.5.1 Input
2.5.1.1 EIA-485 Port
Baud rate 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps,
115200bps
Protocol IEC 60870-5-103:1997
Maximal capacity 32
Transmission distance Max. 500m
Safety level Isolation to ELV level
Twisted pair Screened twisted pair cable
2.5.1.2 Optical Port
Characteristic Glass optical fiber
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-3
Date: 2019-07-05
Connector type ST
Fiber type Multi-mode (62.5/125μm)
Transmission distance Max. 2km
Wave length 850nm
Transmission power Min. -20.0dBm
Receiving power Min. -24.0dBm
Margin Min. +3.0dB
2.5.2 Output
2.5.2.1 RS-485/232 Port
Type Differential
Transmission distance Max. 500m
Maximal capacity 32
Timing standard IRIG-B
Safety level Isolation to ELV level
2.5.2.2 Optical-coupled Contact
Operating voltage Max. 300Vdc
Operating current Max. 125mA
Transmission distance Max. 200m
Safety level Isolation to ELV level
2.5.2.3 TTL
Output voltage 0~5V
Impedance 50Ω
Transmission distance Max. 100m
Safety level Isolation to ELV level
2.5.2.4 AC Modulation
Connector type BNC-3
Impedance 600Ω
Transmission distance Max. 2000m
Safety level Isolation to ELV level
2.5.2.5 Optical Port
Characteristic Glass optical fiber
Connector type ST
Fibre type Multi-mode (62.5/125μm)
Wave length 850nm
Receiving power Min. -25.0dBm
Margin Min +3.0dB
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-4
Date: 2019-07-05
2.6 Type Test
2.6.1 Environmental Test
Dry cold test IEC 60068-2-1: 2007
Dry heat test IEC 60068-2-2: 2007
Damp heat test, cyclic IEC 60068-2-30: 2005
Seady heat test IEC 60068-2-78: 2001
2.6.2 Mechanical Test
Vibration test IEC 60255-21-1: 1988 Class I
Shock test IEC 60255-21-2: 1988 Class I
Bump test IEC 60255-21-2: 1988 Class I
Earthquake test IEC 60255-21-3: 1993 Class I
2.6.3 Insulation Test
Standard IEC 60255-27-2013
Dielectric withstand 2.8kV, DC, 1min
2.0kV, AC, 1min
Impulse voltage 5kV
Overvoltage category Class III
Insulation resistance Min.100MΩ @500Vdc
2.6.4 Electromagnetic Compatibility
1MHz burst disturbance test
IEC 60255-26-2013, Class III
Common mode: 2.5kV
Differential mode: 1.0kV
Electrostatic discharge test
IEC 60255-26-2013, Class IV
For contact discharge: ±8kV
For air discharge: ±15kV
Radio frequency interference
tests
IEC 60255-26-2013, Class III
Frequency sweep
Radiated amplitude-modulated
10V/m (rms), f=80~1000MHz
Fast transient disturbance
tests
IEC 60255-26-2013, Class IV
Power supply, I/O, Earth: ±4kV, 5kHz for 15ms, 100kHz for 0.75ms
Communication terminals: ±2kV, 5kHz for 15ms, 100kHz for 0.75ms
Surge immunity test
IEC 60255-26-2013, Class IV
Power supply, AC input, I/O port: 1.2/50μs
Common mode: ±4kV
Differential mode: ±2kV
Power frequency magnetic
field immunity
IEC 61000-4-8:2009, Class V
100A/m for 1min, 1000A/m for 3s
Pulse magnetic field immunity IEC 61000-4-9:2001, Class V
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-5
Date: 2019-07-05
6.4/16μs, 1000A/m
Conducted RF
electromagnetic disturbance
IEC 60255-26-2013, Class III
Power supply, AC, I/O, Comm. Terminal: 10Vrms, 150kHz~80MHz
Spot frequency, f=27MHz/68MHz
Power frequency immunity
IEC 60255-26-2013, Class A
Common mode: 300V
Differential mode: 150V
Conducted emission IEC 60255-26-2013, Class A
f=0.15MHz~0.5MHz/0.5kHz~30MHz
Radiated emission IEC 60255-26-2013, Class A
f=30MHz~230MHz/230MHz~1000MHz
Damped oscillatory magnetic
field immunity
IEC 61000-4-10:2001, Class V
100kHz & 1MHz, 100A/m
Power supply performance
- Voltage dip
- Voltage short interruption
IEC 60255-26-2013
Max. 200ms for dip to 40% (then recovery) of rated voltage (Un = 220Vdc)
without reset
Max. 100ms for interruption of rated voltage (Un = 220Vdc) without reboot
2.7 Clock Synchronization Specifications
2.7.1 PPS/PPM/PPH
RS-485 TTL Contact
Rising edge (max.) 50ns 50ns 200ns
Accuracy (max.) 100ns 100ns 3μs
Pulse width 10~200ms 10~200ms 10~200ms
2.7.2 IRIG-B DC Code
RS-485 TTL Contact
Rising edge (max.) 50ns 50ns 200ns
Accuracy (max.) 100ns 100ns 3μs
Format B000 (According to IEEE 1344:1995, add "Year" between P50~P58).
2.7.3 IRIG-B AC Code
Carrier waveform Sinusoidal wave
Carrier frequency 1kHz
Voltage magnitude 0~10V (phase-phase), continuously adjustable
Modulation ratio 3:1
Accuracy Max. 15μs
Time code format B120 (According to IEEE 1344:1995, add "Year" between P50~P58).
2.7.4 Serial Port Timing Message
Baudrate 1200bps, 2400bps, 4800bps, 9600bps, 19200bps, 38400bps, 57600bps,
115200bps
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-6
Date: 2019-07-05
Data format
Data bits 8
Stop bit 1
Parity Odd or Even
Message format Motorola binary format
Transmission period 1s
Accuracy Max. 1ms
2.7.5 Network
SNTP/NTP Max. 100μs
IEEE1588 Max. 100ns
2.7.6 GPS Receiver
Frequency 1575.42MHz
Sensitivity (max.) Tracking -163dBW
Acquisition -160dBW
Satellites quantity Max.12
Acquisition time (max.)
TTFF-hot 25s (with current almanac, position, time and ephemeris)
TTFF-warm 50s (with current almanac, position, and time)
TTFF-cold 200s (no stored information)
Reacquisition 1s
Accuracy Max. 100ns
2.7.7 BDS Receiver
Frequency 1561.098MHz
Sensitivity Max. -133dBmW
Acquisition time (max.)
TTFF-hot 3s
TTFF-cold 33s
Reacquisition 1s
Accuracy Max. 50ns
2.7.8 Time Frequency Measurement
Rated voltage 220Vac (grid voltage)
Operating range 45.000Hz~55.000Hz
Accuracy 0.001Hz
Sampling period 1s
2.7.9 Internal Clock
Inaccuracy Max. 3×10-10(1μs/h)
2.8 Certifications
 ISO9001:2008
 ISO14001:2004
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-7
Date: 2019-07-05
 OHSAS18001:2007
 ISO10012:2003
 CMMI L5
 EMC: 2014/30/EU, EN60255-26:2013
 LVD: 2014/35/EU, EN60255-27:2014
08020 08020 08020
08020 08020 08020
08020 08020 08020

2 Technical Data
PCS-9785 Satellite-Synchronized Clock
2-8
Date: 2019-07-05
08020 08020 08020
08020 08020 08020
08020 08020 08020
