Oregon Scientific RMR329P User manual

Radio-Controlled Projection Clock
with Indoor / Outdoor Temperature
Mod
el: RMR329P
USER MANUAL
RMR329P_M_EN_R1.indd 8 6/21/07 12:45:29 PM

1
EN
Radio-Controlled Projection Clock
with Indoor / Outdoor Temperature
Mod
el: RMR329P
USER MANUAL
CONTENTS
Introduction..............................................................2
Clock overview ........................................................2
Front view..............................................................2
Back view ..............................................................2
Remote sensor......................................................3
Getting started.........................................................3
Power supply.........................................................3
Remote sensor.........................................................3
Sensor data transmission......................................4
Clock.........................................................................4
Clock reception.....................................................4
Manually set clock.................................................4
Alarm ........................................................................5
Temperature .............................................................5
Projector and backlight........................................... 5
Reset.........................................................................6
Precautions..............................................................6
Specifi cations ..........................................................7
About Oregon Scientifi c .........................................7
EU-Declaration of conformity.................................7
RMR329P_M_EN_R1.indd 1 6/21/07 12:45:17 PM

2
EN
4. / : Toggle setting options; activate /
deactivate clock reception
5. Projector (LED Aperture)
6. TEMP: Toggle in / out temperature settings
BACK VIEW
1
2
4
3
5
6
7
8
9
1. FOCUS: Focus the projected image
2. Battery compartment
3. Light sensor
4. PROJECTION: ON / OFF switch
5. LIGHT: Backlight ON / OFF switch
6. °C / °F: Select temperature unit
7. EU / UK: Radio signal switch
8. RESET: Reset settings to default
9. Adapter socket
INTRODUCTION
Thank you for selecting this Oregon
Scientific
™
Radio-Controlled Projection Clock with Indoor / Outdoor
Temperature. Please keep this manual for instructions
and information you should know about.
CLOCK OVERVIEW
FRONT VIEW
1
5
6
2
3
4
1. SNOOZE: Snooze alarm; activate backlight; rotate
dual line projection display by 180°
2. ALARM: View alarm status; set alarm
3. CLOCK: Change display; set clock
RMR329P_M_EN_R1.indd 2 6/21/07 12:45:20 PM

3
EN
REMOTE SENSOR
1
2
3
4
5
1. LED status indicator
2. Wall mount hole
3. Battery compartment
4. RESET hole: Reset unit to default settings
5. CHANNEL button: Select channel 1
GETTING STARTED
POWER SUPPLY
Batteries serve as a back-up power supply. For
continuous use of projector and backlight, install
adapter.
The socket-outlet shall be installed near the
equipment and shall be easily accessible
.
NOTE will appear when power supply is not
connected.
To insert batteries:
1. Remove the battery compartment and insert
batteries, matching polarities.
2. Press RESET after each battery change.
LOCATION MEANING
Clock / alarm area Main unit batteries low
Outdoor / indoor
temperature area Sensor batteries low
REMOTE SENSOR
To set up the sensor:
1. Open the battery compartment, and insert batteries,
matching polarities.
2. Place the sensor within 30 m (98 ft) of the main
unit using the table stand or wall mount.
The transmission range may vary depending on many
factors. You may need to experiment with various
locations to get the best results.
RMR329P_M_EN_R1.indd 3 6/21/07 12:45:23 PM

4
EN
NOTE We recommend that you use alkaline batteries
with this product for longer usage and consumer grade
lithium batteries in temperatures below freezing.
SENSOR DATA TRANSMISSION
Outdoor sensor
:
The main unit will automatically search for the outdoor
sensor. The sensor reception icon in the remote sensor
area shows the status:
ICON DESCRIPTION
Main unit is searching for
sensor(s)
A channel has been found
The sensor cannot be found.
NOTE If the sensor is not found, check the batteries,
obstructions, and remote unit location.
For best results:
• P
lace the sensor
out of direct sunlight and moisture.
• Position the sensor facing main unit, minimizing
obstructions.
• Place the sensor in a location with a clear view to
the sky, away from metallic or electronic objects.
• Position the sensor close to the main unit during
cold winter months.
CLOCK
CLOCK RECEPTION
This product is designed to synchronize its clock
automatically with a clock signal.
S
lide
EU / UK to select the signal received.
• EU: DCF-77 signal: within 1500 km (932 miles) of
Frankfurt, Germany.
• UK: MSF-60 signal: within 1500 km (932 miles) of
Anthorn, England.
To enable / disable signal reception:
Press
and hold to enable, or to disable signal
reception.
NOTE Reception takes 2-10 minutes. If the signal is
weak, it can take up to 24 hours to get a valid signal.
Clock signal reception indicator:
STRONG
SIGNAL
WEAK
SIGNAL
NO
SIGNAL
MANUALLY SET CLOCK
1. Press and hold CLOCK for 2 seconds.
2. Press or to change the settings.
3. Press CLOCK to confi rm.
RMR329P_M_EN_R1.indd 4 6/21/07 12:45:25 PM

5
EN
4. The setting order is: time zone offset, 12/24-hr
format, hour, minute, year, day / month format,
month, day and language.
NOTE Time zone offset sets the clock +/- 23 hours
from the received clock signal time.
NOTE The language options are (E) English, (F) French,
(D) German, (I) Italian, and (S) Spanish.
To select display mode:
Press CLOCK to choose between clock with seconds
and clock with weekday.
ALARM
To set the alarm:
1. Press and hold ALARM for 2 seconds to enter
alarm-setting mode.
2. Press / to set hour / minute.
3. Press ALARM to confi rm. indicates alarm is ON.
To toggle alarms ON / OFF:
1. Press ALARM to display alarm time.
2. Press ALARM again to turn alarm ON / OFF.
To silence the alarms
:
• Press SNOOZE to silence it for 8 minutes
OR
• Press any other key to turn the alarm off and activate
it again after 24 hours.
TEMPERATURE
To toggle temperature unit
:
Press °C / °F.
To toggle between outdoor / indoor sensor readings
:
Press TEMP. / indicates indoor and outdoor
temperature.
To auto-scan between sensors
:
Press and hold TEMP for 2 seconds to display the
sensor’s data for 5 seconds.
To deactivate auto-scan function press TEMP.
PROJECTOR AND BACKLIGHT
To activate Projection function
:
• Slide PROJECTION switch to ON to illuminate
projection continuously.
To activate Backlight function:
• Slide LIGHT switch to ON to illuminate backlight
continuously.
OR
• Press SNOOZE to turn on projector and backlight
for 5 seconds.
• Press repeatedly to fl ip dual line projection image
by 180 degrees.
NOTE
If projection is illuminated, do not look directly
into the projector.
RMR329P_M_EN_R1.indd 5 6/21/07 12:45:27 PM

6
EN
• Do not tamper with the unit’s internal components.
This invalidates the warranty.
• Only use fresh batteries. Do not mix new and old
batteries.
• Images shown in this manual may differ from the
actual display.
• When disposing of this product, ensure it is collected
separately for special treatment.
• Placement of this product on certain types of wood
may result in damage to its fi nish for which Oregon
Scientifi c will not be responsible. Consult the furniture
manufacture’s care instructions for information.
• The contents of this manual may not be reproduced
without the permission of the manufacturer.
• Do not dispose old batteries as unsorted municipal
waste. Collection of such waste separately for
special treatment is necessary.
• Please note that some units are equipped with a
battery safety strip. Remove the strip from the
battery compartment before fi rst use.
NOTE The technical specifi cations for this product and
the contents of the user manual are subject to change
without notice.
NOTE To save battery life, the projector and backlight
will only operate continuously when adapter is installed.
The light sensor will turn off the projector automatically
when it detects external light sources.
RESET
Press RESET to return to the default settings.
PRECAUTIONS
• Do not subject the unit to excessive force, shock,
dust, temperature or humidity.
• Do not cover the ventilation holes with any items
such as newspapers, curtains etc.
• Do not immerse the unit in water. If you spill liquid
over it, dry it immediately with a soft, lint-free cloth.
• Do not clean the unit with abrasive or corrosive
materials.
RMR329P_M_EN_R1.indd 6 6/21/07 12:45:27 PM

7
EN
SPECIFICATIONS
TYPE DESCRIPTION
MAIN UNIT
L x W x H 155 x 50 x 112 mm
(6.1 x 1.97 x 4.41 in)
Weight 240 g (8.5 oz)
without battery
Temperature Unit °C / °F
Temperature range -5°C to 50°C
(23°F to 122°F)
Resolution 0.1°C (0.2°F)
Signal frequency 433 MHz
Power 3 x UM-4 (AAA) 1.5V batteries /
4.5V AC / DC adapter
REMOTE UNIT (THN132N)
L x W x H 92 x 60 x 20 mm
(3.6 x 2.4 x 0.8 in)
Weight 62 g (2.22 ounces)
Transmission range 30 m (98 ft) unobstructed
Temperature range -30°C to 60°C
(-22°F to 140°F)
Power 1 x UM-3 (AA) 1.5V battery
ABOUT OREGON SCIENTIFIC
Visit our website (www.oregonscientifi c.com) to learn
more about Oregon Scientifi c products. If you’re in
the US and would like to contact our Customer Care
department directly, please visit:
www2.oregonscientifi c.com/service/support
OR
Call 1-800-853-8883.
For international inquiries, please visit:
www2.oregonscientifi c.com/about/international.
EU-DECLARATION OF CONFORMITY
Hereby, Oregon Scientifi c, declares that this Radio-
Controlled Projection Clock with Indoor / Outdoor
Temperature (Model: RMR329P) is in compliance with
the essential requirements and other relevant provisions
of Directive 1999/5/EC. A copy of the signed and dated
Declaration of Conformity is available on request via
our Oregon Scientifi c Customer Service.
COUNTRIES RTTE APPROVAL COMPLIED
All EU countries, Switzerland
and Norway
CH
CH
N
RMR329P_M_EN_R1.indd 7 6/21/07 12:45:28 PM

1
ES
Reloj Proyector Radiocontrolado
con Temperatura Interior / Exterior
Modelo: RMR329P
MANUAL DE USUARIO
ÍNDICE
Introducción.............................................................2
Resumen del reloj....................................................2
Vista frontal ..........................................................2
Vista trasera ..........................................................2
Sensor remoto.......................................................3
Para empezar ...........................................................3
Suministro de corriente .........................................3
Sensor remoto .........................................................3
Transmisión de datos del sensor ..........................4
Reloj..........................................................................4
Recepción de la señal radiocontrolada................ 4
Ajuste manual del reloj..........................................5
Alarma ......................................................................5
Previsión meteorológica.........................................5
Temperatura .............................................................6
Reinicio.....................................................................6
Precaución ...............................................................6
Ficha técnica............................................................7
Sobre Oregon Scientifi c.......................................... 8
EU-Declaración de conformidad............................8
RMR329P_M_ES_R1.indd 1 6/21/07 12:46:22 PM

2
ES
3. CLOCK: Cambiar pantalla; confi gurar reloj
4. / : Alternar opciones de configuración;
activar o desactivar la recepción del reloj
5. Proyector
6. TEMP: Alternar mostrar temperatura interior / exterior
VISTA TRASERA
1
2
4
3
5
6
7
8
9
1. FOCUS: Enfoca la imagen proyectada
2. Compartimento para las pilas
3. Sensor de luz
4. PROJECTION: Interruptor ON/OFF
5. LIGHT : Interruptor ON/OFF de la retroiluminación
6. °C / °F: Selección unidad de temperatura
INTRODUCCIÓN
Gracias por elegir el Reloj Proyector Radiocontrolado con
Temperatura Interior / Exterior de Oregon
Scientifi c
™.
Sírvase guardar este manual para disponer de las
instrucciones y la información que debería conocer.
RESUMEN DEL RELOJ
VISTA FRONTAL
1
5
6
2
3
4
1. SNOOZE: Repetición de alarma; activar
la retroiluminación; girar 180° la pantalla de
proyección de doble línea
2. ALARM: Ver estado de la alarma; ajustar la alarma
RMR329P_M_ES_R1.indd 2 6/21/07 12:46:25 PM
