Nuvelon Flare User manual
USER
GUIDE
STOP!
For questions or
tech support call
1-866-652-8064
Please do not
return to
store
®
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions and save them for personal reference in the future.
Follow all directions for operating the product.
Heed all warnings on the product and in the operation instructions.
Clean with a dry cloth only. Always unplug the product from any power
source before cleaning.
Do not use third-party attachments or non-recommended accessories
with this product.
Do not place product on an unstable surface, such as a cart, stand,
tripod, table, etc. Unstable surfaces may cause the product to fall and
cause serious injury to people and serious damage to the product.
Follow all manufacturer instructions for mounting and accessories.
Do not block or cover ventilation slots. Openings in the product cabin
ensure reliable operation and prevent overheating. Avoid placing on
beds, sofas, and rugs, or mounting on racks or bookcases, unless proper
ventilation is provided.
Do not use plug incorrectly. The product may come with a polarized,
alternating-current line plug (one blade is wider/larger than the other).
This is a safety feature: the plug will only go into outlet receptacles one
to replace the outlet.
Prevent power cord hazards. Route cords to avoid walking on them or
pinching them, especially at plug ends and connection points to the
product & power outlets.
Unplug power cord when not in use. The product should not be plugged
into a power source when not in use for long periods of time.
Do not use this product near bodies of water. The product is not
waterproof and cannot be fully submerged in water. Power cords and
electric currents should never be exposed to water.
Do not set up near heat sources. Avoid radiators, stoves, heat registers,
sunlight and high temperatures.
Refersonnel. If the product becomes damaged
personnel. Do not attempt to service yourself.
2
QUICK START GUIDE
OPERATING INSTRUCTIONS
CHARGING
SYNCING SPEAKERS
SYNC TIPS AND HELP
BLUETOOTH PAIRING
AUXILIARY INPUT
LIGHT SHOW GUIDE
TABLE OF CONTENTS
3. WARRANTY & CUSTOMER CARE
4
1
1
3
CARE AND STORAGE
Store
away from direct sunlight.
Always turn speaker off when not
Never
.
U.S. Patents Pending
The Bluetooth® word mark and logos are registered trademarks
owned by the Bluetooth SIG, Inc. and any use of such marks
by Nuvelon and Forever Gifts, Inc. is under license.
MODEL: NF15A1-BTM
SPECIFICATIONS
Speaker -
Total Output: 15 Watts
Range: Class 2, up to 33 ft (10 m)
Li-ion Rechargeable Battery: 6600mAh
Speaker Driver: 3.0 inch (x2)
Passive Bass Radiator: 3.5 inch (x2)
Charging Time: Approx. 3 hours
Battery Life: Approx. 7-10 hours
Bluetooth version : 4.
Compatibility: Bluetooth®2.0 or above
device with A2DP/AVRCP
Auxiliary input: 3.5mm
Operating temperature range:
Operating humidity range:
40 - 90% RH
Storage temperature range:
Water resistance : IPX5 (splash resistant)
OUTDOOR OPERATION
1. Keep away from direct rain.
2. Place on a firm, stable surface.
3. Never submerge the speaker or
place on floating pool accessories.
4. Keep speaker out of direct sunlight.
5. Do not charge speaker near water.
01 QUICK
START GUIDE
Solid light indicates speaker is charged
indicates low charge level
1. Unpack the Box
2. Speaker Control Panel and Ports
3. Charging and remaining charge level indicators
INDICATOR LIGHTS
1 2 8
4 53
6 7
FUNCTION AND DISPLAY PANEL BUTTONS
1. POWER ON/OFF
2. BLUETOOTH Pair/Wake/Disconnect
3. LIGHT SHOW ON/OFF + BRIGHTNESS CONTROL
4. LIGHT SHOW + TIMER SELECTION
5. SYNC (requires additional speakers)
6. VOLUME UP
7. VOLUME DOWN
8. TIMER INTERVAL INDICATOR
AUX IN (A)
BA
CHARGING PORT (B)
RELEASE COVER TO ACCESS PORTS
Speaker
Auxiliary Cable
Charging Cable
NOTE:
CHARGE SPEAKERS FULLY
BEFORE USE
(approx. 3 hours)
4
NOTE:
hold
55
4. Syncing your Speakers
6. Light Show Selections and Timer
See Section B. on page 1 for more details
SOLID COLOR OPTIONS: Red/Blue/Aqua/Amber/Green/P/P/White
COLOR-CHANGING OPTIONS: Color-changing Fade / Color-changing Pulse
TIMER: Press and HOLD the COLOR/TIMER button. When the desired
timer interval lights up, release the button To change, repeat steps 1 2.
2. TURN ON REMAINING SPEAKERS
1. TURN ON FIRST SPEAKER
3. PRESS SYNC BUTTON 4. PRESS SYNC BUTTON ON ALL OTHER
SPEAKERS TO SYNC
NOTE: When speakers are synced transmitter light and receiver light will be solid
Transmitting speaker (first speaker turned on) Receiving speaker
PAIRED
Solid light + chime indicates pairing successful
TO PAIR (enable Bluetooth on your device)
Select “Nuvelon FLARE” from devices lisW
To disconnect user, press BT button 4-5 secs.
(chime will sound when device is disconnected)
BLUETOOTH WAKE-UP
If your device is out of BT ranfor >5 mins,
press BT button to pair again
LIGHT SHOW / BRIGHTNESS BUTTON
Press to turn lantern and cycle through
brightness settings - 20%, 40%, 60%, 80%, 100%
Press and release COLOR/TIMER button to
cycle through light show selections
LIGHT SHOW SELECTIONS (Lantern must be ON)
For detailed sync instructions see Section III on age 7 of this guide
5. Pairing your Device
127(,I\RXV\QFHGVSHDNHUV\RXFDQRQO\SDLU\RXUGHYLFHZLWKWKHILUVWVSHDNHU\RXWXUQHGRQ
02 OPERATING
INSTRUCTIONS
6
I. REVIEW THE FUNCTION PANEL AND PORTS
II. CHARGE YOUR SPEAKERS
NOTE: speakers must be fully charged before use
1. Release port cover and plug power adapter pin (B) into charging port
2. Plug power adapter into power outlet
3. Charge until indicator light turns solid red and remove charging cord
(full charge is reached after approximately 3 hours of charging)
INDICATOR LIGHTS
1 2 8
4 53
6 7
FUNCTION AND DISPLAY PANEL BUTTONS
1. POWER ON/OFF
2. BLUETOOTH Pair/Wake/Disconnect
3. LIGHT SHOW ON/OFF + BRIGHTNESS CONTROL
4. LIGHT SHOW + TIMER SELECTION
5. SYNC (requires additional speakers)
6. VOLUME UP
7. VOLUME DOWN
8. TIMER INTERVAL INDICATOR
AUX IN (A)
BA
CHARGING PORT (B)
RELEASE COVER TO ACCESS PORTS
NOTE:
7
CHARGED
Solid light indicates speaker is charged
CHARGING
indicates speaker is charging
LOW POWER
indicates low charge level
Charging and remaining charge level indicators
III.SYNCING SPEAKERS
NOTE: 2 or more Nuvelon FLAREVSHDNHUV
If you are not syncing any speakers go directly to Ste
Tips and Help” Guide on the next page.
2. TURN ON REMAINING SPEAKERS1. TURN ON FIRST SPEAKER
3. 4.
NOTE: When speakers are synced transmitter light and receiver light will be solid
Transmitting speaker (first speaker turned on) Receiving speaker
1. SPEAKER SYNC SET UP PERIOD IS LIMITED TO 90 SECONDS
AFTER TURNING THE FIRST SPEAKER ON.
Whether you are syncing a small or large number of speakers you may
not be able to sync all your speakers within the 90 second time period.
If this happens, follow these steps to continue syncing:
(i) Press the sync button on the first speaker until sync light goes off
(ii) Follow steps 3 and 4 on Page 7 to continue syncing speakers
(iii) Press the sync button on any synced speakers that became unlinked
2. WHEN SYNCED SPEAKERS ON,
.
When you sync speakers they stay synced - meaning when you
power synced speakers off they will automatically sync with each
other again when powered power all your
.
3. CHOOSING A LOCATION FOR THE TRANSMITTING SPEAKER.
off, it .
position the transmitting speaker in a
location where you can easily turn it on and off.
4. CHANGING A TRANSMITTING SPEAKER TO A RECEIVING
8
SYNC TIPS
Please note the below tips to enhance your multi-sync experience!
SPEAKER.
wish to change to a transmitting speaker:
Turn it on first and follow steps 2 - 4 on Page 7 for syncing speakers,
but continue to hold the sync button on the first speaker while you
press the sync button on the transmitting speaker.
If you cannot establish sync connection, please contact customer care
(SEE PAGE 12)
9
PAIRED
Solid light indicates pairing successful
READY TO PAIR
flash indicates speaker is ready to pair
Enable Bluetooth in your device settings and select “Nuvelon FLARE”
Upon pairing, a chime will sound and the indicator light will remain lit
Press and hold the BLUETOOTH button until the chime sounds
EHJLQVIODVKLQJDERXWVHFRQGV
Follow steps - 3 in section$ (ESTABLISHING A NEW PAIRING
DISCONNECT PAIRED DEVICE
BLUETOOTH WAKE-UP
fast flash indicates wake-up successful
If you cannot pair device, ollow steps in above to ensure no other device is paired.
H[SHULHQFHGLIILFXOW\ZLWKSDLULQJFDUH
. WAKE UP BLUETOOTH FROM SLEEP MODE
To save power, the Bluetooth connection will automatically go into sleep mode if
your device stays out of Bluetooth range for more than 5 minutes.
To reconnect when your device is back within range, press the BLUETOOTH
button to cancel sleep mode and re-establish pairing connection.
%.(67$%/,6+,1*$1(:3$,5,1*RUPRUHV\QFHGVSHDNHUV
3UHVV%/8(7227+EXWWRQRQILUVWVSHDNHUXQWLOLWTXLFNO\DQGIROORZVWHSV
LQVHFWLRQ$(67$%/,6+,1*$1(:3$,5,1*
IV.BLUETOOTH PAIRING
A.ESTABLISHING A NEW *VLQJOHVSHDNHU
&.DISCONNECT '(9,&(AND PAIR WITH A NEW DEVICE
NOTE: BLUETOOTH DEVICE AND SPEAKER SHOULD BE IN CLOSE
PROXIMITY WHEN PAIRING (~3 ft./1m)
chime will sound when device is disconnected
10
AUX IN
RELEASE COVER TO ACCESS PORTS AUXILIARY CABLE
Solid green light indicates auxiliary input
V. AUXILIARY INPUT
If your device has a 3.5mm audio jack, or is not Bluetooth enabled, you may use the
included auxiliary cable to use the speaker without Bluetooth. When used this way,
Bluetooth will be disabled, but speaker sync features remain fully functional.
1. Plug one end of the auxiliary cable into the speaker auxiliary port
2. Plug the other end of the auxiliary cable into your device audio jack
(ensure audio jack is not obstructed by any protective case or accessories)
3. When auxiliary cable is plugged into speaker you will hear an audible chime
and the auxiliary indicator will illuminate.
LIGHT SHOW ON & BRIGHTNESS BUTTON
press to cycle through brightness settings
V,. LIGHT SHOW
NOTE: Color-changing Pulse feature DOES NOT WORK without playing music!
By default, t
lantern to illuminate for longer, please set the timer (see Section )
A. LANTERN ON/OFF AND BRIGHTNESS CONTROL
Press the LIGHT SHOW button to turn the lantern feature 21
3UHVVDJDLQWRWXUQODQWHUQIHDWXUH2))
Each time you press the button again, the brightness of the light increases
Press button a total of 5 times to reach maximum brightness, then press
2))
(Brightness level settings correspond to 20%, 40%, 60%, 80% and 100%)
11
B. LIGHT SHOW COLOR SELECTIONVLQJOHVSHDNHU
Lantern feature must be on to change light show color selections. See A. Above.
1. Press and release the COLOR/TIMER button to select the next light color
Light shows are arranged in the following sequence:
1. Red
2. Blue
3. Aqua
Amber
Green
P
P
White
9. Color-changing Fade
10. Color-changing Pulse*
*NOTE: Only works when audio is playing
%ULJKWQHVVRIFRORUFKDQJLQJSXOVH
HIIHFWYDULHVDFFRUGLQJWRW\SHDQG
YROXPHOHYHORIPXVLFSOD\HG
'. TIMER OPTION
1. Press and HOLD the COLOR/TIMER button
2. When the desired timer interval lights up, release the button
3. To change the timer interval, repeat steps 1. and 2.
(Timer will revert to last selected timer interval when speaker is powered on)
NOTE: Brightness control
can only be adjusted for
these color selections
press and release COLOR/TIMER button
LIGHT SHOW SELECTIONS
You may set the
the lantern after 2,
4, 6 or 8 hours
NOTE: By default,
the lantern will
hours to extend
run time
PRESS AND HOLD COLOR/TIMER BUTTON
release when desired interval illuminates
&. LIGHT SHOW COLOR SELECTIONRUPRUHV\QFHGVSHDNHUV
(;&(37
03 !ȳÁx0«!«0ۭ
á««zÁç³0«àX!0
CUSTOMER CARE
1
CUSTOMER
,I\RXKDYHIROORZHGWKHGLUHFWLRQVLQWKLVJXLGHEXW\RXU1XYHORQ)/$5(
/DQWHUQ6SHD HULVQRWRSHUDWLQJDVH[SHFWHGSOHDVHGRQRWUHWXUQWKH
SURGXFWWRWKHVWRUHZKHUH\RXSXUFKDVHGLW
&
FDUH
To obtain warranty service, please contact Customer
(except holidays), or email customerFDUH@nuvelon.com
Please keep your original receipt as proof of purchase.
Limited Warranty
Model NF15A1-BTM
This Nuvelon-branded product, marketed POMZBTOFX in JUT original carton to the original purchaser (“Product”), is
warranted by Forever Gifts, INC against manufacturing defects in materials and workmanship for a limited warranty
period of Ninety (90) Days for Labor and One (1) year for Parts. This Limited Warranty is conditionBM uponVTFPGUIF
1SPEVDUBTTFUPVUJOUIJT-JNJUFE8BSSBOUZ
This Limited Warranty does not apply to store EFNPOTUSBUJPO productsproductT“marked down” GPSTBMF, in “as is”
condition, “close outs”,“liquidation and clearance sales”, “open box”, products missing accessories, or no fault found.
Proof of purchase in the form of a Bill of Sale, Receipt or Receipted Invoice is SFRVJSFEUPDFSUJGZ the Product is within
the -imited 8arranty period. The Bill of Sale, Receipt or Receipted Invoice must be QSPEVDFEJOPSEFSUPPCUBJO-imited
8arranty service.
This -imited 8arranty DPNNFODFTon the original date of purchase and is valid only on Products purchased through
authorized dealers and used iOUnited StatesUFSSJUPSJFTby the original Purchaser. To receive warranty service, the
Purchaser must first contact 'PSFWFS(JGUT*/$ for problem JEFOUJGJDBUJPO and service procedures. The original dated
#ill of 4ale, 3eceipt or 3eceipted *nvoice must be prPEVDFEupon request as proof of purchase.
We will repair your productor if repairs cannot be made we will replace BUPVSTPMFEJTDSFUJPO withQSPEVDUPG same
or similar WBMVF.If the Product defectT as specified in this -imited 8arranty PDDVSSFEduring the -imited 8arranty
period, we SFTFSWFUIFSJHIUUP use new or remanufactured parts to repair the Product. All replaced parts and
1roducts become our property and must be returned to us. Replacement parts and 1roducts assume the remaining
original -imited 8arranty, or ninety (90) days, whichever is longer.
8IFOSFUVSOJOHZPVSProductfreight must be prepaid by you, the original Purchaserand1SPEVDUNVTUCF shipped in
its original packagingor packagingXIJDI affordTan equal degree of protection. We will not be responsible forOor
obligated to replace damaged ProductsTIJQQFEJOVOTVJUBCMFQBDLBHJOH
If the Product is received damaged, it is your responsibility as the consumer to file a claim against the carrier. We will
only store the damaged Product for 30 days and reserve the right, BU our sole discretion, to dispose of the damaged
Product or ship it back to you at your expense after 30 days.
This -imited 8arranty covers manufacturing defects in materials and workmanship encountered in normal, and
except to the extent otherwise expressly provided for in this statement, noncommercial use of this Product, and shall
not apply to the following, including, but not limited to: Damage which occurs in shipment; delivery and installation;
applications and uses for which this Product was not intended; altered Product or serial numbers; cosmetic damage or
exterior finish; accidents, abuse, neglect, fire, water, lightning or other acts of nature; use of products, equipment,
systems, utilities, services, hardware, supplies, BDDFTTPSJFT, applications, installations, repairs, external wiring or
connectors not supplied or authorized by us or the manufacturer, which damage this Product or result in service
problems; incorrect electrical line voltage, fluctuations and surges; customer adjustments and failure to follow
operating instructions, cleaning, maintenance and environmental instructions that are covered and prescribed in the
instruction book; reception problems and distortion related to noise, echo, interference or other signal transmission
and delivery problems. Uninterrupted or error-free operation of the Product is not warranted.
THERE ARE NO EXPRESS OR IMPLIED WARRANTIES OTHER THAN THOSE LISTED AND DESCRIBED ABOVE,
AND NO WARRANTIES WHETHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, ANY IMPLIED
WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE, SHALL APPLY AFTER THE
EXPRESS WARRANTY PERIODS STATED ABOVE, AND NO OTHER EXPRESS WARRANTY OR GUARANT&&GIVEN
BY ANY PERSON, FIRM OR CORPORATION WITH RESPECT TO THIS PRODUCT SHALL BE BINDING ON US. REPAIR
OR REPLACEMENT AS PROVIDED UNDER THIS LIMITED WARRANTY IS YOUR EXCLUSIVE REMEDY ASTHE
CONSUMER. WE SHALL NOT BE LIABLE FOR ANY INCIDENTAL, OR CONSEQUENTIAL DAMAGES FOR BREACH OF
ANY EXPRESS OR IMPLIED WARRANTY ON THIS PRODUCT; EXCEPT TO THE EXTENT PROHIBITED BY APPLICABLE
LAW, ANY IMPLIED WARRANTY OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE ON THIS
PRODUCT IS LIMITED FOR THE DURATION OF THIS LIMITED WARRANTY. THIS LIMITED WARRANTY SHALL NOT
EXTEND TO ANYONE OTHER THAN THE ORIGINAL PURCHASER OF THIS PRODUCT, IS NONTRANSFERABLE AND
STATES YOUR EXCLUSIVE REMEDY.
Some states do not allow limitations on how long an implied warranty lasts, or the exclusion or limitation of incidental
or consequential damages, so the above limitations or exclusions may not apply to you. This -imited 8arranty gives
you specific legal rights, and you may also have other rights which vary from state to state. Any provision contained
herein which is found contrary to state or local laws shall be deemed null and void and the remaining provisions shall
continue in full force and effect.
5PPCUBJOXBSSBOUZTFSWJDFDBMM1-866-652-8064TFFQSFWJPVTQBHFGPSIPVST
1
FCC WARNING STATEMENT
ations not expressly approved by the party responsible
for compliance could void the user’s authority to operate the equipment. This
equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable protection against harmful
interference in a residential installation. This equipment generates, uses, and can
radiate radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful
interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference
by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and receiver.
- Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
- Consult the dealer or an experienced radio/TV technician for help.
FCC Radiation Exposure Statement
This equipment complies with FCC radiation exposure limits set forth for an
uncontrolled environment. In order to avoid the possibility of exceeding the FCC
radio frequency exposure limits, Human proximity to the antenna shall not be less
than 20cm (8 inches) during normal operation.
the presence of insulated “dangerous voltage” within the product’s
of electric shock to persons who come into contact with it.
An exclamation point within an equilateral triangle denotes the presence
of important operation & maintenance/service instructions.
WARNING
PREVENT FIRE AND SHOCK HAZARDS. DO NOT USE EXTENSION CORDS OR OUTLETS THAT
EXPOSE PLUG BLADES. DO NOT EXPOSE CABLES AND PLUGS TO RAIN OR MOISTURE.
DO NOT ATTEMPT TO PERFORM ANY SERVICING THAT IS NOT INCLUDED IN THE OPERATING
INSTRUCTIONS. DO NOT ATTEMPT TO REPLACE THE BATTERY, AS INCORRECT INSTALLATION
CAN CAUSE FIRE OR EXPLOSION. FOR SERVICE, CONTACT QUALIFIED SERVICE
PERSONNEL.
DO NOT REMOVE COVER OR BACK OF PRODUCT. THERE ARE NO USER-SERVICEABLE
PARTS INSIDE. ATTEMPTING TO MODIFY CONTROLS OR PERFORMANCE BEYOND
MANUFACTURER SPECIFICATIONS MAY RESULT IN HAZARDOUS EXPOSURE TO RADIATION.
1
.
®
Other manuals for Flare
1
Table of contents
Other Nuvelon Speakers manuals
