Nvidia MCP73D User manual

USER'S MANUAL
Of
NVIDIA
MCP73D
Platform Processor Chipset
M/B for LGA775 Quad Core Ready
Intel Core Processor Family
NO. G03-IN73DA2-F
Rev: 2.0
Release date: Aug.,2009
Trademark:
* Specifications and information contained in this documentation are furnished for information use only, and are
subject to change at any time without notice, and should not be construed as a commitment by manufacturer.

i
Environmental Protection Announcement
Do not dispose this electronic device into the trash while discarding. To minimize pollution and
ensure environment protection of mother earth, please recycle.

ii
USER’S NOTICE.....................................................................................................................iii
MANUAL REVISION INFORMATION ..............................................................................iii
COOLING SOLUTIONS........................................................................................................iii
CHAPTER 1 INTRODUCTION OF NVIDIA MOTHERBOARD SERIES
1-1 FEATURE OF MOTHERBOARD ...................................................................................... 1
1-1.1 SPECIAL FEATURES OF MOTHERBOARD.................................................... 2
1-2 SPECIFICATION.................................................................................................................. 3
1-3 PERFORMANCE LIST........................................................................................................ 4
1-4 LAYOUT DIAGRAM & JUMPER SETTING................................................................... 5
CHAPTER 2 HARDWARE INSTALLATION
2-1 HARDWARE INSTALLATION STEPS............................................................................. 7
2-2 CHECKING MOTHERBOARD'S JUMPER SETTING.................................................. 7
2-3 INSTALL CPU....................................................................................................................... 8
2-3-1 GLOSSARY............................................................................................................. 8
2-3-2 About Intel LGA775 CPU ...................................................................................... 9
2-4 INSTALL MEMORY............................................................................................................ 10
2-5 EXPANSION CARD ............................................................................................................. 11
2-5-1 PROCEDURE FOR EXPANSION CARD INSTALLATION............................ 11
2-5-2 ASSIGNING IRQ FOR EXPANSION CARD...................................................... 11
2-5-3 INTERRUPT REQUEST TABLE FOR THIS MOTHERBOARD.................... 11
2-5-4 PCI-Express SLOT ................................................................................................. 12
2-5-5 SLI BRIDGE FOR NVIDIA SLI TECH. SUPPORTED VGA CARDS............. 12
2-6 CONNECTORS, HEADERS................................................................................................ 14
2-6-1 CONNECTORS....................................................................................................... 14
2-6-2 HEADERS ............................................................................................................... 14
2-7 STARTING UP YOUR COMPUTER ................................................................................. 14
CHAPTER 3 INTRODUCING BIOS
3-1 ENTERING SETUP.............................................................................................................. 18
3-2 GETTING HELP................................................................................................................... 19
3-3 THE MAIN MENU................................................................................................................ 19
3-4 STANDARD CMOS FEATURES........................................................................................ 20
3-5 ADVANCED BIOS FEATURES.......................................................................................... 22
3-6 ADVANCED CHIPSET FEATURES.................................................................................. 24
3-6-1 DRAM CONFIGURATIONS............................................................................... 24
3-7 INTEGRATED PERIPHERALS......................................................................................... 25
3-7-1 IDE FUNCTION SETUP ...................................................................................... 25
3-7-2 ONBOARD DEVICE............................................................................................. 26
3-7-3 SUPER IO FUNCTION SETUP........................................................................... 27
3-8 POWER MANAGEMENT SETUP ..................................................................................... 27
3-9 MISCELLANEOUS CONTROL........................................................................................ 29
3-9-1 IRQ RESOURCES.................................................................................................. 29
3-10 PC HEALTH STATUS........................................................................................................ 30
3-11 THERMAL THROTTLING OPTIONS ............................................................................ 30
3-12 POWER USER OVERCLOCK SETTINGS ..................................................................... 31
3-13 PASSWORD SETTINGS .................................................................................................... 32
3-14 LOAD OPTIMIZED DEFAULTS...................................................................................... 32
CHAPTER 4 DRIVER & FREE PROGRAM INSTALLATION
MAGIC INSTALL SUPPORTS WINDOWS 9X/ME/NT4.0/2000/XP ....................................... 33
4-1 NFORCE INSTALL NFORCE INTEGRATED DRIVER.......................................... 34
4-2 SOUND INSTALL ALC880E 8-CHANNEL HD AUDIO DRIVER ........................ 35
4-3 LAN INSTALL REALTEK GIGABIT ETHERNET NIC DRIVER.................. 36
4-4 USB2.0 INSTALL INTEL USB2.0 DRIVER............................................................. 37
4-5 PC-CILLIN INSTALL PC-CILLIN 2006 ANTI-VIRUS PROGRAM........................... 37
4-6 PC-HEALTH INSTALL MYGUARD HARDWARE MONITOR UTILITY .............. 38
4-7 RAIDDISk INSTALL MCP55 WINXP RAID DRIVER DISK................................... 39
4-8 HOW TO UPDATE BIOS..................................................................................................... 39
4-9 NFORCE 550 MCP PLATFORM RAID FUNCTION INSTALLATION........................ 41
4-10 PRO MAGIC PLUS FUNCTION INTRODUCTION........................................................ 42
TABLE OF CONTENT

iii
USER’S NOTICE
COPYRIGHT OF THIS MANUAL BELONGS TO THE MANUFACTURER. NO PART OF THIS
MANUAL, INCLUDING THE PRODUCTS AND SOFTWARE DESCRIBED IN IT MAY BE
REPRODUCED, TRANSMITTED OR TRANSLATED INTO ANY LANGUAGE IN ANY FORM OR
BY ANY MEANS WITHOUT WRITTEN PERMISSION OF THE MANUFACTURER.
THIS MANUAL CONTAINS ALL INFORMATION REQUIRED TO USE IN73DA2
MOTHER-BOARD AND WE DO ASSURE THIS MANUAL MEETS USER’S REQUIREMENT BUT
WILL CHANGE, CORRECT ANY TIME WITHOUT NOTICE. MANUFACTURER PROVIDES THIS
MANUAL “AS IS” WITHOUT WARRANTY OF ANY KIND, AND WILL NOT BE LIABLE FOR ANY
INDIRECT, SPECIAL, INCIDENTIAL OR CONSEQUENTIAL DAMAGES (INCLUDING DAMAGES
FOR LOSS OF PROFIT, LOSS OF BUSINESS, LOSS OF USE OF DATA, INTERRUPTION OF
BUSINESS AND THE LIKE).
PRODUCTS AND CORPORATE NAMES APPEARING IN THIS MANUAL MAY OR MAY NOT BE
REGISTERED TRADEMARKS OR COPYRIGHTS OF THEIR RESPECTIVE COMPANIES, AND
THEY ARE USED ONLY FOR IDENTIFICATION OR EXPLANATION AND TO THE OWNER’S
BENEFIT, WITHOUT INTENT TO INFRINGE.
Manual Revision Information
Reversion Revision History Date
2.0 Second Edition Aug., 2009
Item Checklist
;NVIDIA MC73D Chipset motherboard
;Cable for IDE
;CD for motherboard utilities
;Cable for Serial ATA IDE Port
;NVIDIA MCP73D Chipset User’s Manual
;Back panel

1
Chapter 1
Introduction of NVIDIA MCP73D Motherboard Series
1-1 Features of motherboard
The NVIDIA MCP73D chipset motherboard series are based on MCP73D (Media and
Communication Processor) chipset technology which supports the innovative 65nm Quad-Core,
Dual-Core Intel® Core 2 Quad, Core 2 Duo (Code Name: Conroe) processors, 90nm
Dual-Core Intel® Pentium® D Processor 8 and 9 Series processors , Pentium 4 and Celeron D
with Intel® Hyper-Threading Technology.
The motherboard supports the stunning video playback in all formats and with superb picture
clarity that brings the best visual experience and ultra-realistic effects to the users. NVIDIA
MCP73D Platform Processor Chipset motherboard series are the real cost-effective and powerful
integrated multimedia platform solutions and meet the demanding usage of computing now and
future.
The motherboard series support new generation Intel LGA 775 processors which provides
with 200MHz / 266MHz / 333MHz memory clock frequency for DDRII400 / DDRII533 /
DDRII667 /DDRII800 Module up to 4 GB. And it also accommodates ULTRA ATA 133
connectors and Serial ATA2 with RAID 0, 1, 5 functions which support up to one IDE and
four Serial ATA2 devices to accelerate hard disk drives and guarantee the data security
without failure in advanced computing performance.
The motherboards provide Gigabit LAN function with Realtek RTL8111C-VC Gigabit LAN
which supports 10 / 100 / 1000Mbps data transfer rate. Embedded 6-channel Azalia High
Definition Audio CODEC is fully compatible with Sound Blaster Pro®standard that provides
you with the home cinema quality and absolutely software compatibility.
The NVIDIA MCP73D motherboard series offer one 16-LANE PCI-Express x16 graphics
slot of 4Gbyte/sec data transfer rate at each relative direction which get 3.5 times of
bandwidth more than AGP8X and it’s up to a peak concurrent bandwidth of 8Gbyte/sec at full
speed to guarantee the performance and compatibility of GPU graphics add-in cards. The
whole series carry three 32-bit PCI slots guarantee the rich connectivity for the I/O peripheral
devices. One PCI Express x1 I/O slot offers 512Mbyte/sec concurrently, over 3.5 times more
bandwidth than PCI at 133Mbye/sec.
Embedded USB controller as well as capability of expanding to 8 USB2.0 functional ports
delivering 480Mb/s bandwidth and rich connectivity, these motherboards meet the future
USB demands which are also equipped with hardware monitor function on system to monitor
and protect your system and maintain you non-stop business computing.
Some special features---CPU Thermal Throttling/ CPU Vcore 7-shift in this motherboard are
designed for power user to use the over-clocking function in more flexible ways. But please
be caution that the over-clocking maybe causes the fails in system reliabilities. This
motherboard provides the guaranteed performance and meets the demands of the next
generation computing. But if you insist to gain more system performance with variety
possibilities of the components you choose, please be careful and make sure to read the

2
detailed descriptions of these value added product features, please get them in the coming
section.
1-1.1 Special Features of Motherboard
CPU Thermal Throttling Technology--- (The CPU Overheat Protection Technology)
To prevent the increasing heat from damage of CPU or accidental shutdown while at high
workload, the CPU Thermal Throttling Technology will force CPU to enter partially idle
mode from 87.5% to 12.5% according to preset CPU operating temperature in BIOS (from 40
℃to 90℃). When the system senses the CPU operating temperature reaching the preset
value, the CPU operating bandwidth will be decreased to the preset idle percentage to cool
down the processor. When at throttling mode the beeper sound can be optionally selected to
indicate it is in working.
CPU Vcore 7-Shift--- (Shift to Higher Performance)
The CPU voltage can be adjusted up by 14 steps for the precisely over-clocking of extra
demanding computing performance.
OC-CON capacitors
The working temperature is from 55 degrees centigrade below zero to 125 degrees centigrade,
OC-CON capacitors possess superior physical characteristics that can be while reducing the
working temperature between 20 degrees centigrade each time, intact extension 10 times of
effective product operation lives, at not rising degrees centigrade of working temperatures
each time a relative one, life of product decline 10% only too.

3
1-2 Specification
Spec Description
Design ∗ATX form factor 4 layers PCB size: 29.5cm*18.0cm
Chipset ∗NVIDIA MCP73D
CPU LGA775
∗Support Intel Pentium 4, Celeron D, Pentium D, Core 2 Duo and Core 2 Quad
775-Land LGA Package utilizes Flip-Chip Land Grid Array package processor
∗Support FSB Frequency 533 / 667/ 800 / 1066/1333MHz
Memory Socket
∗240-pin DDR2 Module socket x 2
∗Support 2pcs DDR2 533 / 667 / 800 Modules
∗Expandable to 4GB
Expansion Slot
∗PCI-Express x16 slot 1pcs
∗PCI-Express x1slot 1pcs
∗32-bit PCI slot x 3pcs
Integrate IDE and
Serial ATA2 RAID
∗One IDE controllers support PCI Bus Mastering, ATA PIO/DMA and the ULTRA
DMA 33/66/100/133 functions that deliver the data transfer rate up to 133 MB/s.
∗Four Serial ATA2 ports provide 300 MB/sec data transfer rate with RAID 0, 1, 5
functions
LAN ∗Integrated Realtek RTL8111C-VC 10/100/Gigabit LAN
∗Supports Fast Ethernet LAN function provide 10 / 100 / 1000 Mb p/s
HD Audio ∗Integrated Realtek ALC662 HD Azalia 6-channel
∗6-channel 3D surround& Positioning Audio
∗Audio driver and utility included
BIOS ∗Award 8MB SPI Flash ROM
Multi I/O
∗PS/2 keyboard and PS/2 mouse connectors
∗Floppy disk drive connector x1
∗Serial port header x1
∗HDMI SPDIF Out header x1
∗USB2.0 port x 4 and headers x2
∗Audio connector

4
1-3 Performance List
The following performance data list is the testing result of some popular benchmark testing
programs. These data are just referred by users, and there is no responsibility for different
testing data values gotten by users (the different Hardware & Software configuration will
result in different benchmark testing results.)
Performance Test Report
CPU: core 2 E4400 2.0
DRAM: GEIL 800Hz 2.00
VGA Card : 8.411.0.0
Hard Disk Driver: Seagate SATA 80GB
BIOS: IN73DT01
OS: Windows XP Professional (SERVICE PACK 2)
IN73DA2
3D Mark 2001SE 27599
3D Mark 2003 15484
3D Mark 2005 9402
AQUAMRK3 N/A
PCMark2004
System / CPU / Memory 5841/5115/4157
Graph / HDD 6576/5111
Content Creation Winstone 2004 34
Business Winstone 2004 24
Winbench 99 V2.0:
Business/Hi-end Disk Winmark99 5510/28800
Business/Hi-end Graphic N/A
SISMark 2004: SISMark Rating(Internet Content Creation / Office Productivity )
SISMark 2004 321/209
3D Creation / 2D Creation 285/395
/ Web publication 295
Communication / Document 158/262
/ Data Analysis 221
SISOFT Sandra 2004 : 1.CPU Arithmetic Benchmark 2.Memory bandwidth Benchmark 3.CPU
Multi-Media Benchmar
k
1.Dhrystone ALU MIPS 18369
Whetstone FPU iSSE2 FLOPS 12750
2.Int/Float Buffered MB/S 3889/3870
3.Integer/Floating-Point IT/S 110202/59614
UT2003 Benchmark 340.858826/113.565048
Quake3 DEMO1 / FPS 478.2/468.2
Return to Castle FPS n/a
Super Pi (1M) Second 28.07S
CPUZ System / CPU Clock 2.0GB/800

5
1-4 Layout Diagram & Jumper Setting
8MBit Flash
ROM BIOS
Front Panel Connector
ATA 133 IDE
Conn.(IDE1)
Clear CMOS (JBAT)
ATX Power Conn.
Serial-ATAII Connector
(SATAII1, 2, 3, 4)
PCI Slots
PS2 KB/Mouse Port CPU FAN
RJ45 Over
USB Conn.
PCI Express x16
DDR2 Socket x 2
SYSFAN1
ATX 12V Power Conn.
KBMS/USB Power On
Jumper (JP1)
CD Audio In
Realtek RTL8111C-VC
NVIDIA MCP73D
USB Port
(USB2, USB3)
Floppy Connector
Audio Conn.
Com connector
USB Port
SFAN2
PCI Express x1
IR
Realtek ALC662
Audio Codec
SPDIF Out
HDMI SPDIF
Audio
Power LED Connector
Speaker Connector
LGA 775 Socket.
COM
PS/2 Keyboard
PS/2 Mouse LAN
USB Port
MIC IN
Line IN
Line OUT
SPDIF OUT
USB

6
Jumpers
Jumper Name Description Page
JBAT CMOS RAM Clear 3-pin Block P.7
JP1 Keyboard/USB Power On Enabled/Disabled 3-pin Block P.8
Connectors
Connector Name Description Page
ATXPWR ATX Power Connector 24-pin Block P.12
ATX12V1 ATX 12V Power Connector 8-pin Block P.12
KB PS/2 Mouse & PS/2 Keyboard Connector 6-pin Female P.12
USB1 USB Port Connector 4-pin Connector P.13
UL1 Gigabit-LAN Port Connector RJ-45 Connector P.13
CN1 6-CH Audio Connector 6 phone jack Connector P.13
FDD Floppy Driver Connector 34-pin Block P.13
IDE1 Primary/Secondary IDE Connector 40-pin Block P.14
SATAII1~4 Serial ATAII IDE Connector 7-pin Connector P.14
Headers
Header Name Description Page
AUDIO SPEAKER, MIC header 9-pin Block P.14
USB1, USB2, USB Port Headers 9-pin Block P.15
SPEAK PC Speaker connector 4-pin Block P.15
PWR LED Power LED 3-pin Block P.15
JW_FP
(Power LED/Reset/
IDE LED/Power Button)
Front Panel Header(including Power LED/ IDE
activity LED/Reset switch / Power On Button
lead)
9-pin Block P.15
SYSFAN1, SYSFAN2
CPUFAN,CHAFAN FAN Headers 3-pin Block P.16
CDIN CD Audio-In Header 4-pin Block P.16
HDMI-SPDIF HDMI-SPDIF 5-Pin block P.17
Expansion Sockets
Socket/Slot Name Description Page
ZIFLGA775 Socket CPU Socket LGA775 CORE2 FAMILY P.9
DIMM1~2 DDRII Module Socket 240-pin DDRII Module Socket P.9
PCI1∼PCI3 PCI Slot 32-bit PCI Local Bus Expansion slots P.10
PE1 PCI-Express x16 Slot PCI-Express x16 Expansion Slot P.11
PE2 PCI-Express x1 Slot PCI-Express x1 Expansion Slot P.11

7
Chapter 2
Hardware Installation
2-1 Hardware installation Steps
Before using your computer, you had better complete the following steps:
1. Check motherboard jumper setting
2. Install CPU and Fan
3. Install System Memory (DIMM)
4. Install Expansion cards
5. Connect IDE, Front Panel /Back Panel cable
6. Connect ATX Power cable
7. Power-On and Load Standard Default
8. Reboot
9. Install Operating System
10. Install Driver and Utility
2-2 Checking Motherboard’s Jumper Setting
(1) CMOS RAM Clear (3-pin): JBAT
A battery must be used to retain the motherboard configuration in CMOS RAM short 1-2
pins of JBAT to store the CMOS data.
To clear the CMOS, follow the procedure below:
1. Turn off the system and unplug the AC power
2. Remove ATX power cable from ATX power connector
3. Locate JBAT and short pins 2-3 for a few seconds
4. Return JBAT to its normal setting by shorting pins 1-2
5. Connect ATX power cable back to ATX power connector
Note: When should clear CMOS
1. Troubleshooting
2. Forget password
3. After over clocking system boot fail
CMOS RAM Clear Setting
2-3 Closed Clear CMOS
JBATJBAT
1-2 Closed Normal

8
(2) Keyboard function Enabled/Disabled: JP1
2-3 Install CPU
2-3-1 Glossary
Chipset (or core logic) - two or more integrated circuits which control the interfaces between
the system processor, RAM, I/O devises, and adapter cards.
Processor slot/socket - the slot or socket used to mount the system processor on the
motherboard.
Slot (PCI-E, PCI, RAM) - the slots used to mount adapter cards and system RAM.
AGP - Accelerated Graphics Port - a high speed interface for video cards; runs at 1X
(66MHz), 2X (133MHz), or 4X (266MHz), or 8X (533MHz).
PCI - Peripheral Component Interconnect - a high speed interface for video cards, sound
cards, network interface cards, and modems; runs at 33MHz.
PCI Express- Peripheral Component Interconnect Express- a high speed interface for video
cards, sound cards, network interface cards, and modems.
Serial Port - a low speed interface typically used for mouse and external modems.
Parallel Port - a low speed interface typically used for printers.
PS/2 - a low speed interface used for mouse and keyboards.
USB - Universal Serial Bus - a medium speed interface typically used for mouse, keyboards,
scanners, and some digital cameras.
Sound (interface) - the interface between the sound card or integrated sound connectors and
speakers, MIC, game controllers, and MIDI sound devices.
LAN (interface) - Local Area Network - the interface to your local area network.
BIOS (Basic Input/Output System) - the program logic used to boot up a computer and
establish the relationship between the various components.
Driver - software, which defines the characteristics of a device for use by another device or
other software.
Processor - the "central processing unit" (CPU); the principal integrated circuit used for
doing the "computing" in "personal computer"
Front Side Bus Frequency - the working frequency of the motherboard, which is generated
by the clock generator for CPU, DRAM and PCI BUS.
CPU L2 Cache - the flash memory inside the CPU, normal it depend on CPU type.

9
2-3-2 About Intel LGA775 CPU
This motherboard provides a 775-pin surface mount, LGA775 Land Grid Array socket,
referred to as the LGA775 socket supports Intel Core family processor in the 775 Pin package
utilizes Flip-Chip Land Grid Array (FC-LGA) package technology.
The CPU that comes with the motherboard should have a cooling FAN attached to prevent
overheating. If this is not the case, then purchase a correct cooling FAN before you turn on
your system.
WARNING! Be sure that there is sufficient air circulation across the processor’s heat
sink and CPU cooling FAN is working correctly, otherwise it may cause
the processor and motherboard overheat and damage, you may install an
auxiliary cooling FAN, if necessary.
To install a CPU, first turn off your system and remove its cover. Locate the LGA775
socket and open it by first pulling the level sideways away from the socket then upward to a
90-degree angle. Insert the CPU with the correct orientation as shown below. The notched
corner should point toward the end of the level. Because the CPU has a corner pin for two
of the four corners, the CPU will only fit in the orientation as shown.
When you install the CPU into the LGA775 socket, there’s no force required CPU insertion;
then presses the level to locate position slightly without any extra force.
2-4 Install Memory
This motherboard provides two 240-pin DDR DUAL INLINE MEMORY MODULES
(DIMM) sides for DDR memory expansion available from minimum memory size of 128MB
to maximum memory size of 4GB DDR SDRAM.
Valid Memory Configurations
Bank 240-pin DDR DIMM PCS Total Memory
Bank 0, 1 (DIMM1) DDRII 800/667/ 533 DDR DRAM Module X1 128MB∼2GB
Bank 2, 3 (DIMM2) DDRII 800/667/553 DDR DRAM Module X1 128MB∼2GB
Total System Memory (Max. 4GB) X2 128MB∼4GB
Generally, installing DDR SDRAM modules to your motherboard is very easy, you can refer
to figure 2-4 to see what a 240-pin DDR SDRAM module looks like.
CPU LGA775 Socket
Colden Arrow
LGA775

10
DIMM2 (BANK2+ BANK3) DIMM1 (BANK0+ BANK1)
NOTE! When you install DIMM module fully into the DIMM socket the eject tab should
be locked into the DIMM module very firmly and fit into its indention on both
sides.
2-5 Expansion Cards
WARNING! Turn off your power when adding or removing expansion cards or other
system components. Failure to do so may cause severe damage to both
your motherboard and expansion cards.
2-5-1 Procedure For Expansion Card Installation
1. Read the documentation for your expansion card and make any necessary hardware or
software setting for your expansion card such as jumpers.
2. Remove your computer’s cover and the bracket plate on the slot you intend to use.
3. Align the card’s connectors and press firmly.
4. Secure the card on the slot with the screen you remove above.
5. Replace the computer system’s cover.
6. Set up the BIOS if necessary.
7. Install the necessary software driver for your expansion card.
2-5-2 Assigning IRQs For Expansion Card
Some expansion cards need an IRQ to operate. Generally, an IRQ must exclusively assign
to one use. In a standard design, there are 16 IRQs available but most of them are already in
use.
Standard Interrupt Assignments
IRQ Priority Standard function
0 N/A System Timer
1 N/A Keyboard Controller
2 N/A Programmable Interrupt
3 * 8 Communications Port (COM2)
4 * 9 Communications Port (COM1)
5 * 6 Sound Card (sometimes LPT2)
6 * 11 Floppy Disk Controller
7 * 7 Printer Port (LPT1)
8 N/A System CMOS/Real Time Clock
9 * 10 ACPI Mode when enabled
10 * 3 IRQ Holder for PCI Steering
11 * 2 IRQ Holder for PCI Steering
12 * 4 PS/2 Compatible Mouse Port

11
13 N/A Numeric Data Processor
14 * 5 Primary IDE Channel
15 * 1 Secondary IDE Channel
* These IRQs are usually available for ISA or PCI devices.
2-5-3 Interrupt Request Table For This Motherboard
Interrupt request are shared as shown the table below:
INT A INT B INT C INT D INT E INT F INT G INT H
Slot 1 √
Slot 2 √
Onboard USB 1 √
Onboard USB 2 √
IMPORTANT! If using PCI cards on shared slots, make sure that the drivers support
“Shared IRQ” or that the cards don’t need IRQ assignments. Conflicts will
arise between the two PCI groups that will make the system unstable or
cards inoperable.
2-5-4 Expansion Card
The NVIDIA MCP73D motherboard series offer one 16-LANE PCI-Express x16 graphics
slot of 4Gbyte/sec data transfer rate at each relative direction which get 3.5 times of
bandwidth more than AGP8X and it’s up to a peak concurrent bandwidth of 8Gbyte/sec at full
speed to guarantee the performance and compatibility of GPU graphics add-in cards. The
whole series carry three 32-bit PCI slots guarantee the rich connectivity for the I/O peripheral
devices. One PCI Express x1 I/O slot offers 512Mbyte/sec concurrently, over 3.5 times more
bandwidth than PCI at 133Mbye/sec.
PCI-E x16 Slot
32-bit PCI Slots
PCI-E x1 Slot

12
2-6 Connectors
(1) Power Connector (24-pin block): ATXPWR1
ATX Power Supply connector: This is a new defined 24-pins connector that usually
comes with ATX case. The ATX Power Supply allows using soft power on momentary
switch that connect from the front panel switch to 2-pins Power On jumper pole on the
motherboard. When the power switch on the back of the ATX power supply turned on,
the full power will not come into the system board until the front panel switch is
momentarily pressed. Press this switch again will turn off the power to the system
board.
** We recommend that you use an ATX 12V Specification 2.0-compliant power supply
unit (PSU) with a minimum of 350W power rating. This type has 24-pin and 4-pin
power plugs.
** If you intend to use a PSU with 20-pin and 4-pin power plugs, make sure that the 20-pin
power plug can provide at least 15A on +12V and the power supply unit has a minimum
power rating of 350W. The system may become unstable or may not boot up if the
power is inadequate.
(2) ATX 12V Power Connector (8-pin block) : ATX12V1
This is a new defined 8-pins connector that usually comes
with ATX Power Supply. The ATX Power Supply which fully
supports AM2 processor must including this connector for
support extra 12V voltage to maintain system power
consumption. Without this connector might cause system unstable because the power
supply can not provide sufficient current for system.
(3) PS/2 Mouse & PS/2 Keyboard Connector: KB1
The connectors are for PS/2 keyboard and PS/2 Mouse.
(4) USB Port connector:
The connectors are 4-pin connector that connects USB devices to the system board.
(5) LAN Port connector: UL1
Pin 1
ROW1 ROW2
24-Pin
ROW1 ROW2
Pin 1
20-Pin
PIN ROW1 ROW2
1 3.3V 3.3V
2 3.3V -12V
3 GND GND
4 5V Soft Power On
5 GND GND
6 5V GND
7 GND GND
8 Power OK -5V
9 +5V (for Soft Logic) +5V
10 +12V +5V
11 +12V +5V
12 +3V GND

13
This connector is standard RJ45 connector for Network
The USBLAN1 support 10Mb/100Mb/1000Mb p/ s data transfer rate
(6)
Audio Line-In, Lin-Out, MIC Connector: SURROUND1 / CN1
This Connector are three phone Jack for LINE-OUT, LINE-IN, MIC
Line-in: (BLUE) Audio input to sound chip
Line-out: (GREEN) Audio output to speaker
MIC: (PINK) Microphone Connector
(7)Floppy drive Connector (34-pin block): FDD1
This connector supports the provided floppy drive ribbon cable. After connecting the
single plug end to motherboard, connect the two plugs at other end to the floppy drives.
(8) Secondary IDE Connector (40-pin block): IDE1
This connector connects to the next set of Master and Slave hard disks. Follow the
same procedure described for the primary IDE connector. You may also configure two
hard disks to be both Masters using one ribbon cable on the primary IDE connector and
another ribbon cable on the secondary IDE connector.
•Two hard disks can be connected to each connector. The first HDD is referred to as the
“Master” and the second HDD is referred to as the “Slave”.
•For performance issues, we strongly suggest you don’t install a CD-ROM or DVD-ROM
drive on the same IDE channel as a hard disk. Otherwise, the system performance on this
channel may drop.
PS/2 Keyboard
PS/2 Mouse
USB1
LAN
USB Port
MIC IN
Line IN
Line OUT
SPDIF OUT COM1
Floppy Drive Connector
Pin 1
FDD

14
(9) Serial-ATA Port connector:
SATA1 / SATA2 / SATA3 / SATA4
This connector supports the provided Serial ATA and Serial ATA2 hard disk cable to
connect the motherboard and serial ATA hard disk.
2-7 Headers
(1) Line-Out/MIC Header for Front Panel (9-pin): AUDIO1
This header connects to Front Panel Line-out, MIC connector with cable.
(2)Speaker connector: SPEAK1
This 4-pin connector connects to the case-mounted speaker. See the figure below.
(3) Power LED: PWR LED1
The Power LED is light on while the system power is on. Connect the Power LED
from the system case to this pin.
Primary IDE Connector
Pin 1
IDE1
IDE1
Serial
-
ATA1, 2, 3, 4 Com
p
atible Connector
s
SATA2
SATA1
SATA3
SATA4
Line-Out, MIC Headers
AUDIO
Pin 1
AUD-Lineout2-L
AUD-MIC-R
AUD-Lineout2-R
SENSE-SEND
GND
SENSE2-RETUR
PRESENCE
2
9
10
KEY
AUD-MIC-L
SENSE1-RETURN

15
(4) IDE Activity LED: HD LED
This connector connects to the hard disk activity indicator light on the case.
(5) Reset switch lead: RESET
This 2-pin connector connects to the case-mounted reset switch for rebooting your
computer without having to turn off your power switch. This is a preferred method of
rebooting in order to prolong the lift of the system’s power supply. See the figure
below.
(6) Power switch: PWR BTN
This 2-pin connector connects to the case-mounted power switch to power ON/OFF the
system.
(7)USB Port Headers (9-pin) :
USB2/USB3 (Optional)
These headers are used for connecting the additional USB port plug. By attaching an
option USB cable, your can be provided with two additional USB plugs affixed to the
back panel.
(8) FAN Power Headers: SYSFAN1, SYSFAN2 (3-pin), CPUFAN1 (4-pin)
These connectors support cooling fans of 350mA (4.2 Watts) or less, depending on the
fan manufacturer, the wire and plug may be different. The red wire should be positive,
while the black should be ground. Connect the fan’s plug to the board taking into
consideration the polarity of connector.
System Case Connections
HDLED
RESET
VCC5
GND
VCC5 PWR LED
PWRBTN
PWRBTN
PWRLED
HDDLE
RSTSW
NC GND
JW FP
Pin 1
SPEAK
SPKR
GND
NC
VCC5
Pin 1
PWRLED
Pin 1
USB Port Headers
Pin 1
USB3
VCC
-DAT
A
GND
+DATA
VCC
OC
-DAT
A
GND
+DATA
Pin 1
USB2
VCC
-DATA
GND
+DATA
VCC
OC
-DATA
GND
+DATA

16
(9) CD Audio-In Headers (4-pin): CDIN
CDIN are the connectors for CD-Audio Input signal. Please connect it to CD-ROM
CD-Audio output connector.
(11) HDMI SPDIF:
The SPDIF output is capable of providing digital audio to external speakers or compressed
AC3 data to an external Dolby digital decoder. Use this feature only when your stereo system
has digital input function.
CD Audio-In Headers
CDIN 4 1
12
HDMI_SPDIF_OUT GND
SPDIF
FAN Power Headers
CPUFAN
14
GND
+12V
CPUFAN IN
CPUFAN OUT
SYSFAN1
1
3SYSFAN2
1
3
