NX Smart Home NX-GL4 User manual

NX-GL4
Smart RGBW LED Garden Lights
USER MANUAL
ENGINEERED FOR THE NEXT GENERATION™

1
CONTENTS
1.0 WARNINGS....................................................................................... 2
2.0 INTRODUCTION .............................................................................. 2
2.1 Pre-Installation.................................................................................. 2
3.0 NX SMART APP SETUP.................................................................. 3
3.1 App Download...................................................................................3
3.2 App Registration ...............................................................................4
3.3 Home Management ........................................................................ 5
3.4 Add your Garden Lights to the App.............................................7
4.0 OPERATION ....................................................................................10
4.1 Garden Light Colour Options ......................................................10
4.2 Smart Controller............................................................................... 11
4.3 Google Home Integration.............................................................. 11
4.4 Amazon Alexa Integration ............................................................ 14
4.5 Automation .......................................................................................16
4.6 Additional App Functions ............................................................. 17
5.0 SPECIFICATIONS............................................................................17
6.0 WARRANTY TERMS & CONDITIONS...........................................18
8.0 NOTES.............................................................................................22

2
1.0 WARNINGS
• Consult a licensed electrician if you are unsure of the AC
connection or do not have a power point within connection
range.
• Do not disassemble the Adaptor, Smart Controller or Lights.
• There are no user serviceable parts within this kit.
• Do not stare directly at the LED lights.
2.0 INTRODUCTION
Thank you for purchasing the NX-GL4 Smart RGBW LED Garden
Lights. These lights can be controlled directly by the Smart
Controller, via our free smartphone app and by your voice, using
Amazon Alexa or Google Assistant.
2.1 PRE-INSTALLATION
1. This system works with 2.4GHz WiFi networks only.
Depending on your router model, you may need to disable
5HGz networks while connecting the Garden Lights to your
WiFi network. Please see 'Quick Explainer' on page 7.
2. Insert the NX-GL4 Garden Lights power cable in to the AC
adaptor and firmly tighten the locking nut.
3. Please install your NX-GL4 Garden Lights within the range of
your WiFi router. To test this, pair the lights with the NX Smart
App at a location close to the router. Once paired, you can test
dierent installation locations within your WiFi range.
PLEASE NOTE:
• It may take 1-2 minutes for the lights to re-connect with the
WiFi network once you have relocated them.

3
4. Before installing the lights in your garden, lay the cable along
the ground to ensure they will reach your desired installation
location. This kit includes extra-long cable lengths to ensure
maximum installation flexibility.
3.0 NX SMART APP SETUP
3.1 APP DOWNLOAD
Download the NX Smart app from the Apple or Google Play
stores by searching ‘NX Smart’ or scan the QR code below.
0.3m
2m
2m
3m
2m
Smart
Controller Adaptor
Quick Scan QR Code
for NX Smart App.

4
3.2 APP REGISTRATION
To register, select ‘Sign Up.’ Please read and agree to the
privacy policy, then enter your email address.
Select ‘Get Registration Code’ then retrieve the code sent to
your email. Please enter the code into the app to create your
account and set your password.
You will be asked to authorise access to several services
including ‘Bluetooth,’ ‘Notifications’ and ‘Location Services.’
All of these functions enhance the operation of the app.
To activate Music Mode, you’ll be asked for access to your
smartphone’s microphone.

5
3.3 HOME MANAGEMENT
To enable extra NX-GL4 Garden Lights control options, like
adding other users and organising your garden lights into
dierent areas, follow the steps below (you can also set up
Home Management later).

6
CONFIGURATION STEPS:
1. Select ‘Me’ on the menu at the bottom of the screen.
2. Select ‘Home Management.’
Then select ‘My Home’ to configure your default home
setting.
3. Add a home name, then set ‘Location’ (optional). After this
step, you can add and name garden areas (the app refers to
this as a 'room').
For example, ‘Side Garden.’ Always select ‘Save’ when you
have finished making changes.

7
3.4 ADD YOUR GARDEN LIGHTS TO THE APP
1. Ensure your smartphone is connected to your 2.4GHz WiFi
network (this is a specific home network, if you are unsure of
the dierence, please read the quick explainer below).
2. Power up your NX-GL4 Garden Lights. Within 3 seconds, they
should start flashing red. If they don't, press and hold the
button on the smart controller (figure below) for 5 seconds
until they start flashing.
QUICK EXPLAINER:
• Modern home routers typically provide two WiFi networks
(5GHz and 2.4GHz). These separate networks won’t always
be named clearly, especially if you have re-named your
home WiFi network.
• For your NX-GL4 Garden Lights to work, you will need to pair
them to the 2.4GHz WiFi network, which has a greater range
and a stronger and more reliable signal. If you are unsure
which of your WiFi networks is 2.4GHz, please clarify with
your network provider.
3. The NX-GL4 Garden Lights have the latest pairing technology
to ensure quick and easy setup. To pair the lights to your app,
please ensure that Bluetooth is enabled on your smartphone.
Reset/Control
Button

8
4. Select ‘Add Device.’
‘Garden Lights’ will show on the screen as the device
to be added.
Select ‘Go to Add’ to confirm this selection.
5. On the next screen, select the ‘+’ icon (as circled in below
image) to confirm this selection.

9
6. Your WiFi network name will be displayed. If your 2.4HGz WiFi
network name is not displayed, please leave the app, connect
your Smartphone to the 2.4GHz network then return to the
app and enter the WiFi password and select confirm. You can
also enter the network name manually if it is not displayed.
Please refer to our 'Quick Explainer' on page 7 if this
is not clear. If you still cannot find your 2.4GHz WiFi, please
contact your internet provider.
NOTE:
• Bluetooth is only used to enable easy connection to the
lights. After they are connected to WiFi, Bluetooth is not
required.
7. The pairing process will start. A confirmation screen will be
shown when complete. At this stage you can rename your NX-
GL4 Garden Lights if you choose to. This name will be used to
trigger your lights if you are using Amazon Alexa and Google
Assistant. You can change the name by selecting the pen icon
(circled in the image below).
You can allocate the lights to a specified living area if you
have set up Home Management and easily control multiple
devices and/or create smart automations.

10
4.0 OPERATION
There are four operation modes available for the NX-GL4 Garden
Lights. The ON/OFF switch for the LED’s is located at the bottom
centre of the operation mode screen.
4.1 GARDEN LIGHT COLOUR OPTIONS
1. White: The NX Smart LED Garden Lights are supplied with
discreet cool white LED’s to provide natural white light. As the
LED’s are cool white only, the white menu only allows you to
adjust the brightness of the LED’s.
2. Colour: Slide your finger around the colour wheel to select
your desired colour. Brightness is adjusted by the slider.
There is also a contrast slider that when adjusted to 50%
and lower, allows you to select pastel colours.
3. Scene: There are four fixed ambient light scenes and four
flash scenes available for selection. The four ambient scene
settings (Warm, Cool, Sunset and Ocean) need to be set by
the user first using the circled edit control.
The four flash scenes: Relax, Party, RGBFlash and Chill are
preprogrammed but can also be adjusted using the edit
control.

11
4. Music Mode: Uses your smartphone microphone to trigger
the NX-GL4 Garden Lights. The app needs to be left open and
the smartphone unlocked for this function to work.
4.2 SMART CONTROLLER
If a smartphone is unavailable, you can use the button on the
smart controller to operate the lights. With each button press,
the lights will turn on, then cycle through all 8 scenes and the
last press will turn the lights o.
4.3 GOOGLE HOME INTEGRATION
1. The NX Smart app features Verification Code linking for quick
and easy integration with Google Assistant. Simply select ‘Me’
from the NX Smart Home screen, select ‘Google Assistant’,
select ‘Get’ to load your Verification Code, then select ‘Copy’.
Reset/Control
Button

12
2. Open the Google Home app, select ‘+,’ then select ‘Set up
device’ on the next menu, then ‘Works with Google’ on the
following menu. Then tap the search icon at the top right
corner of the screen and search for ‘NX Smart’ and select it.
3. Finally, paste the Verification Code then select ‘Authorise’ on
the next screen
Google Assistant will find your device(s) then select the ones
you want to link. Confirm the home location for the device(s) and
select the room where the device(s) are located.

13
Now you can control the Garden Lights with Google Assistant.
Just start with ‘hey Google’ to use your voice to control your NX
Smart Home Garden Lights.
Some example commands follow - or try your own variations!
Remember whatever you named the NX-GL4 Garden Lights as in
the NX Smart App will also be their Google Assistant name.
• Ok Google, turn on Garden Lights.
• Ok Google, turn o Garden Lights.
• Ok Google, set Garden Lights brightness to 20%.
• Ok Google, set Garden Lights to blue.

14
4.4 AMAZON ALEXA INTEGRATION
1. The NX Smart app features Verification Code linking for quick
and easy integration with Amazon Alexa. Simply select ‘Me’
from the NX Smart Home screen, select ‘Alexa’, select ‘Get’ to
load your Verification Code, then select ‘Copy’.
2. Open your Amazon Alexa app and from the home menu,
select ‘More.’ Then select ‘Skills & Games’ then using the
search tool at the top right corner of the screen, enter 'NX
Smart' to search for the NX Smart App.

15
After you select 'NX Smart', select ‘Enable to Use’ on the next
screen.
3. Paste the Verification Code then select ‘Authorise’ on the next
screen. Once your NX Smart account is linked to Alexa, select
‘CLOSE’ on the following page then ‘DISCOVER DEVICES.’
Some example commands follow - or try your own variations!
Remember what you named NX-GL4 Garden Lights in the NX
App, will be their Alexa name.
Remember whatever you named the NX-GL4 Garden Lights as in
the NX App will also be their Alexa name.
• Alexa, turn on Garden Lights.
• Alexa, turn o Garden Lights.
• Alexa, make Garden Lights brightness 20%.
• Alexa, make Garden Lights to blue.

16
4.5 AUTOMATION
There are various ways you can enhance your smart product
experience. Automation lets you control your NX-GL4 Garden
Lights based on other conditions such as:
• Time
• Temperature
• The operation of another smart device
To activate the Automation function, follow these steps:
From the home screen, perform the following actions:
1. Select ‘Smart’
2. Add an Automation routine, select ‘+’ (circled at the top of the
screen)
3. Select an Automation action. In this example we will select
‘When Weather Changes’
4. Select a specific weather condition, so we will select
‘Temperature Conditions’
5. Select the trigger temperature then ‘Next’
6. Select the action to be performed, We will select ‘run the
device’ for this example
7. Select the device you want to control

17
8. Select the device operation. In this example we will select
‘Switch’ then ‘ON’ to turn the lights on
9. Select ‘Save’ and select ‘Next’
You are finally presented with a summary screen of the
automation actions created. To finish, select ‘Save.’
4.6 ADDITIONAL APP FUNCTIONS
Additional app functions are described in the ‘FAQ & Feedback’
section, and via the ‘Me’ menu in the app.
5.0 SPECIFICATIONS
Model: NX-GL4
WiFi: 2.4GHz only, IEEE802.11b/g/n
Water Resistance: Lights IP65; Adaptor IP44
App Requirements: IOS 10.0 or Android 5 and above.
Operating Voltage: 12VDC 1A
Google Play and the Google Play logo are trademarks of Google Inc. Industries.
Amazon, Alexa and all related logos are trademarks of Amazon.com, Inc. or its aliates.

18
6.0 WARRANTY TERMS & CONDITIONS
Our goods come with guarantees that cannot be excluded under
the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and for compensation for any other
reasonably foreseeable loss or damage. You are also entitled
to have the goods repaired or replaced if the goods fail to be of
acceptable quality and the failure does not amount to a major
failure.
This warranty is provided in addition to your rights under the
Australian Consumer Law. Directed Electronics Australia Pty
Ltd (Directed Electronics) warrants that this product is free from
defects in material and workmanship for a period of 12 months
from the date of purchase or for the period stated on the
packaging. This warranty is only valid where you have used the
product in accordance with any recommendations or instructions
provided by Directed Electronics.
This warranty excludes defects resulting from alterations of the
product, accident, misuse, abuse or neglect. In order to claim the
warranty, you must return the product to the retailer from which
it was purchased or if that retailer is part of a National network, a
store within that chain, along with satisfactory proof of purchase.
The retailer will then return the goods to Directed Electronics.
Directed Electronics will repair, replace or refurbish the product
at its discretion. The retailer will contact you when the product is
ready for collection. All costs involved in claiming this warranty,
including the cost of the retailer sending the product to Directed
Electronics, will be borne by you.
Email: [email protected]
