NXT Power NPT 80 User manual

Model Numbers (120 VAC 60Hz)
NPT 80, 120, 180, 240, 360, 480, 600, 720, 840, 1000, 1200, 1500, 2000
Model Numbers (200-240 VAC 50/60Hz)
NPT 80, 240, 480, 780, 1000, 1200, 1500, 2000
POWER CONDITIONER USER’S MANUAL
For use with Standard, NXT Ground & Medical Power Conditioners

1
TABLE OF CONTENTS
1.0 – INTRODUCTION ………………………………………….......................................... 2
2.0 – SAFETY GUIDELINES …………………………………............................................ 2
3.0 – OPERATION & MAINTENANCE …………………................................................... 3
4.0 – POWER CONDITIONER RATINGS CHART …………………………………………. 5
5.0 – WARRANTY ………………………………………………………………..……………. 6
6.0 – CONTACT US …………………………………………………………………………..... 7

2
1.0 INTRODUCTION
Thank You
Thank you for purchasing an NXT POWER Isolation Transformer-Based Power Conditioner.
This power conditioner provides the highest level of electrical noise and surge filtering against
electrical power disturbances. This power conditioner will protect your sensitive electronic
equipment from the degrading and damaging effects of AC-line based electrical noise and
surges (Between Line and Neutral and Neutral to Ground).
This exclusive NXT POWER product you have purchased protects and provides clean power to
your system. We have prepared this document to help familiarize you with the functions and
controls of the product. If you have any additional questions after reviewing this manual, please
feel free to contact our technical support team by phone [phone]) or email us at
[email protected].
2.0 SAFETY GUIDELINES
Symbol Description
DANGER - High risk hazard that could, if not avoided, can result in serious injury or
death.
WARNING - Medium or low risk hazard that could, if not avoided, can result in moderate
or minor injury.
CAUTION - Potentially hazardous situation that could, if not avoided, result in equipment
damage, data loss, performance deterioration, or unanticipated results.
ANTI-STATIC PROMPTING – Observe precautions for handling.
RISK OF ELECTRIC SHOCK - Direct contact with exposed energized conductors or
circuit parts may result in electric shock.
TIP - Provides useful information that may help you solve a problem or save time.
For indoor use only
Short-circuit proof separating transformer

3
3.0 OPERATION & MAINTENANCE
Before Installation: Inspect the power conditioner for any physical damage. If any damage is
visible do not use the power conditioner and contact the seller immediately.
Environmental Conditions: The NXT POWER Conditioner is designed only for installation
in an indoor, temperature and humidity-controlled environment. Install the power conditioner
away from heat, moisture, and dust sources.
Ensure the unit has a minimum of 3 inches (75mm) of clearance on all sides of the unit. Do not
block any of the air vents or place objects next to or on top of the unit.
Place the NXT POWER Conditioner as close to the load equipment/electronic devices as
possible. Plug in all electrical devices that you would like to protect from electrical noise into the
power conditioner. Ensure the power conditioner is not overloaded. This can be done by
making sure the power conditioner is not loaded above its maximum rating (please see back
panel of the unit for rating information). If you have any questions regarding the rating of the
unit, please contact the seller.
Power Conditioner Voltage and Power Rating: It is important to choose the correct
power conditioner for your application. In this manual you will find the voltage and power rating
information for the model power conditioner you have. Ensure the power conditioner is correctly
rated for your application. If you have any questions in this regard contact the seller.
Installation: Place the power conditioner as close to the load equipment (the equipment you
want to power from the power conditioner) as possible. Plug the load equipment/electronic
devices into the power conditioner. Using the input power cord that is provided with the power
conditioner plug on end into the power inlet of the power conditioner. Then plug the power cord
into a correctly rated and wired outlet.
WARNING
CAUTION
WARNING
TIP

4
Do not use any other input power cord other than the one provided with the unit. If the
input power cord is lost or missing contact the seller to procure a replacement cord.
The outlet must consist of a Line, Neutral and Ground (DO NOT plug the power conditioner into
an ungrounded outlet or use any kind of ground removing plug (commonly called “cheater
plugs”) to power the conditioner. If the power conditioner is equipped with a power on circuit
breaker switch turn the switch to the ON position. The blue power ON indicator (light) on the
front of the unit will illuminate. Once the power conditioner is plugged in and turned on, insure
the “Site Wiring Fault” LED (120 VAC North American models only) on the rear of the unit is not
flashing. If this LED is flashing contact a qualified electrician immediately to insure proper wiring
of the mains outlet. The power conditioner must not be plugged into this outlet until the wiring
problem is corrected. If the “wiring fault” LED is not ON or flashing, you can turn on the load
equipment/electronic devices. If you have any questions in this regard, contact the seller.
Note: If the power conditioner is mounted to a wall the installation can be in the horizontal position
facing left or right. If the power conditioner is mounted vertically the unit must be installed with front
plastic panel facing the ground.
All NXT POWER Conditioners are equipped with overload protection and this protection will turn
off the power conditioner if overloaded. If the power conditioner turns off due to an overload,
remove some of the load equipment/electronic devices from the conditioner and turn the power
conditioner on again. Overload Protection device cannot be replaced.
These power conditioners are not rated or intended for use in the presence of flammable gas or
anesthetics as there will be a risk of a of an explosion.
All power conditioners use a basic type insulation and a grounded power network must
be used.
All power conditioners listed below are considered Class 1.
All power conditioners listed below are considered Type B.
There are no user serviceable parts inside the power conditioner, contact the seller for
service or repair.
All power conditioners use hazardous voltage.
All power conditioners should only be used in ordinary locations.
All Power conditioners can be operated in continuous duty cycle.
All Power conditioners enclosure are IP40 rated.
CAUTION
CAUTION
DANGER

5
Separating transformer is non-inherent short circuit proof
4.0 POWER CONDITIONER RATING CHART
Model Number
Input Voltage
AC
~
Output voltage
AC
~
Maximum Load Rating
Maximum Power VA
Frequency
NPT80
-
XXX
-
N
120
120
0.
70
amps
80 VA
60 Hz
NPT120
-
XXX
-
N
120
120
1.0 amps
120 VA
60 Hz
NPT180
-
XXX
-
N
120
120
1.5 amps
180 VA
60 Hz
NPT2
4
0
-
XXX
-
N
120
120
2.0
amps
24
0 VA
60 Hz
NPT360
-
XXX
-
N
120
120
3.0 amps
360 VA
60 Hz
NPT480
-
XXX
-
N
120
120
4.0 amps
480 VA
60 Hz
NPT600
-
XXX
-
N
120
120
5.0 amps
600 VA
60 Hz
NPT
720
-
XXX
-
N
120
120
6
.0 amps
720
VA
60 Hz
NPT
840
-
XXX
-
N
120
120
7.0
amps
840
VA
60 Hz
NPT
1000
-
XXX
-
N
120
120
8
.
3
amps
1000
VA
60 Hz
NPT
1200
-
XXX
-
N
120
120
10
.0 amps
1200
VA
60 Hz
NPT
1500
-
XXX
-
N
120
120
12.0
amps
1440
VA
60 Hz
NPT2000
-
XXX
-
N
120
120
16.0 amps
1980 VA
60 Hz
Model Number Input Voltage AC ~ Output voltage AC ~ Maximum Load
Rating
Maximum Power VA Frequency ZI %
NPT80-XXX-i 200-240 200-240 0.35 amps 80 VA 50/60 Hz 6.97
NPT240-XXX-i 200-240 200-240 1.0 amps 240 VA 50/60 Hz 6.16
NPT480-XXX-i 200-240 200-240 2.0 amps 480 VA 50/60 Hz 8.23
NPT780-XXX-i 200-240 200-240 3.25 amps 780 VA 50/60 Hz 4.76
NPT1000-XXX-i 200-240 200-240 4.10 amps 1000 VA 50/60 Hz 4.89
NP1200-XXX-i 200-240 200-240 5.4 amps 1200 VA 50/60 Hz 4.12
NPT1500-XXX-i 200-240 200-240 6.5 amps 1500 VA 50/60 Hz 3.07
NPT2000-XXX-i 200-240 200-240 8.5 amps 2000 VA 50/60 Hz 3.75
XXX: F (Floating Ground), G (NXT Ground), H (Hardwired), W (wall mount) or M (medical listed to 60601-1)
Input supply cord for all ”i” models must be type 60227 IEC53 (H05W) rated with the following conductor sizes:
- NPT80-XXX-i, NPT240-XXX-i and NPT480-XXX-i: 0.5mm2 minimum
- NPT480-XXX-i, NPT740-XXX-I, NPT1000-XXX-i and NPT1200-XXX-i: 0.75mm2 minimum
- NPT1200-XXX-i, NPT1500-XXX-i and NPT2000-XXX-i: 1.0mm2 minimum

6
5.0 WARRANTY
General Warranty
NXT POWER Next Level conditioners (hereafter referred to as “Product”) are warranted to be
free from defects in material and workmanship for five (5) years from date of shipment from NXT
POWER on the chassis and electronic components. This warranty is limited to repairing,
replacing, or refurbishing at NXT POWER’s discretion, any defective component, circuit board
or module within the Product. For single phase products located anywhere, this warranty is
limited to NXT POWER depot service. For three phase Products located in the continental
United States and Canada, this warranty will include, at NXT POWER’s sole discretion, on-site
service, or NXT POWER depot service. For locations other than those specified herein, this
warranty is limited to parts only. See the Limitations of Warranty section below for additional
limitations and exclusions.
Limitations of Warranty
This limited warranty does not cover any losses or damage resulting from shipment to or from
the Customer, or from improper installation, improper application, inappropriate environment,
abuse, neglect, unauthorized modifications, adjustments, or repair of the Product. Additionally,
any costs related to installation or de-installation of the Product for the purpose of replacement
or servicing will be the Customers sole responsibility. NXT POWER makes no warranties,
expressed or implied, of merchantability, fitness for a particular purpose, performance,
condition, capacity, or otherwise. NXT POWER is not liable for incidental or consequential
damages, monetary loss, loss of sales, or loss of business resulting from the failure or
malfunction of the Product. Warranty is void on Product where evidence of tampering exists.
See full product warranty statement for complete warranty details.
All warranty services will be performed during NXT POWER normal, non-holiday business hours
(Monday through Friday, 8:00 AM – 5:00 PM CST). Any service required by Customer to be
performed outside of normal business hours will be subject to NXT POWER prevailing labor
rates.

7
7051 W Wilson Ave,
Norridge, IL 60706
(P) 872-310-4050
(F) 708-457-2266
(E) [email protected]
022-00001 2020 REV. C, – User Manual Power conditioner 80 VA to 2000VA 120/230 VAC
