O.K.I. usa 6 HIGH-LIGHT SIR6H-8S43 Quick start guide

SIR6H-8S43_SIR6H-8S60_rev03102008
Operational Manual
6 HIGH-LIGHT® IR LED Color Waterproof
6 HIGH-LIGHT
®
IR LED 850nm Camera
IR LED Distance up to 65ft / 20m
z1/3” Sony Super HAD CCD
z420 TV Lines
z4.3mm or 6.0mm Special IR Lens
z0.05 Lux (0 Lux @ IR “on”)
zIP67 Rating - Waterproof
z100mA LED “off” / 280mA LED “on”
z12V DC
Mounting Bracket
Model SIR6H-8S43
SIR6H-8S60 SIR6H-8S43P SIR6H-8S60P
TV System NTSC PAL
Image Sensor 1/3" Sony Super HAD CCD
Resolution 420 TV Lines
Scanning
Frequency 15.734 KHz 15.625 KHz
Picture Elements 537(H) x 505(V) 537(H) x 597(V)
Synchronization Internal
Minimum
Illumination 0.05 Lux (0 Lux @ IR “on”)
S/N Ratio More than 50dB (AGC "Off")
Gain Control AGC
White Balance Auto ATW 2500~9500°K
Gamma 0.45
Back Light
Compensation Auto
Electronic
Shutter Speed 1/60~100,000s 1/50~100,000s
Infrared LED
Quantity
6 HIGH-LIGHT®LED
IR LED Distance Up to 65ft / 20m
Video Output Composite 1.0 Vp-p at 75Ω
Lens 4.3mm or 6.0mm Special IR Lens
Power Supply 12V DC
Power
Consumption IR “on”: 280mA IR “off”: 100mA
IP Rating IP67 Waterproof
Operation
Temperature
Working: -20~50°C
Storage: -30~60°C
Humidity:0~95%RH
Dimensions 85mm(W) x 110mm(L)
Weight 500g
* Specifications subject to change without notice
SIR6H-8S43 4.3mm Lens
SIR6H-8S60 6.0mm Lens
SIR6H-8S43P
SIR6H-8S60P
FEATURES
SPECIFICATIONS
Please read the Operational Manual
before attempting to use this product.
DIMENSIONS
(
Unit: mm
)

SIR6H-8S43_SIR6H-8S60_rev03102008
zOne (1) SIR6H-8S43/SIR6H-8S43P or
SIR6H-8S60/SIR6H-8S60P camera with power/video
cable
zOne (1) Detachable Sun Shield
zOne (1) Mounting Bracket
zThree (3) Screws
zThree (3) Wall Anchors
zOne (1) Operational Manual
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light
as this may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper
handling could damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The
allowable temperature range for operation of this camera
is between -20°C ~ 50°C and the allowable humidity is
85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be
cleaned before lens installation or whenever the lens is
changed. Cleaning should be done by using a chamois, a
very fine soft cloth, lens tissue, or cotton tipped applicator
and ethanol to carefully remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified
range. (Camera must meet the specifications). Camera
must be connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this
may touch dangerous voltage points of short out parts
that could result in a fire or electric shock. Never spill any
kind of liquid on the video product.
7. Servicing
Do not attempt to service this video product by yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all service to qualified
servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer
service to qualified servicing personnel under the
following conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen
into the video product.
c. If the video product has been dropped or the
cabinet has been damaged.
d. When the video product exhibits a distinct change
in performance.
9. Installation
Installation should conform to all local codes.
OKIUSA Products are covered under warranty for one year
from the date of purchase. The warranty will
automatically be voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to
confirm any information regarding when and where the
product was purchased. We have no other way to verify
the purchase record without the serial number on the
camera sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a
manner not described in this manual, the warranty will
be voided immediately. It is the customer’s
responsibility to keep the camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be
tampered with. Cutting or modifying of the cables will
result in termination of the warranty.
CAUTION
WARRANTY
LIST OF COMPONENTS
