O.K.I. usa SIR12L-755AI922 Quick start guide

SIR12L-755AI922_rev04292008
Operational Manual
True Day & Night Weatherproof
High Power Reflection IR Camera
z1/3” Sony Super HAD CCD
z550 TV Lines, HQ-1 DSP
z12 High Power Reflection IR LED
z9.0mm~22.0mm Aspherical Auto Iris Lens
zIR Distance 75~150ft / 20~45m
z0 Lux IR “on” @ 2.0 Lux
zPower Consumption 224mA @ IR “off” /
355mA @ IR “on”
zMechanical IR Cut Filter (ICR)
zIP67 Rating
z12V DC
Day Time Mode Night/IR Mode
(<2 Lux)
(>5 Lux)
1. DC LEVEL: VR for adjusting the iris level of auto iris lens
2. SWITCHES:
2.1 AES / OFF
ON: Linear auto electronic shutter
1/50 (1/60) ~ 1/100,000sec
OFF: 1/50 (1/60) sec
2.2 BLC / OFF
BLC: Backlight Compensation. When the object is
dark by strong light (sun light etc…), please
turn on BLC.
OFF:BLCoff
2.3 AGC / OFF
AGC:AutomaticGaincontrol. The level of gain varies
from 0 ~ 26dB
OFF: AGC off. The level of gain is fixed at 0dB.
2.4 FL / NOM
FL:Flickerless.InFLmode,theshutterspeedis
1/100sec (NTSC system) / 1/120sec (PAL system).
IfchooseFLmode,“AES”(SW.4)shouldbeoff.
NOM:Normalposition
zOne (1) SIR12L-755AI922/SIR12L-755AI922P Camera with
video/power cable
zOne (1) Mounting Bracket
zThree (3) Mounting Screws
zThree (3) Wall Anchors
zOne (1) Back Cover
zOne (1) Operational Manual
*For any returns, please include all components listed above
with original packaging in Resalable Condition. Absolutely
No Returns will be accepted if any component is
missing/damaged or if any cable is cut or tampered with.
SIR12L-755AI922
SIR12L-755AI922P
FEATURES
Please read the Operational Manual
before attempting to use this product.
NOMENCLATURE & FUNCTION
DIMENSIONS (Unit: mm)
LIST OF COMPONENTS

SIR12L-755AI922_rev04292008
Model SIR12L-755AI922 SIR12L-755AI922P
TV System NTSC PAL
Image Sensor 1/3” Sony Super HAD CCD
DSP Sony HQ-1
Total Pixels 811(H) × 508(V) 795(H) × 596(V)
Video Output 1.0Vp-p composite / 75 Ohms
(BNC connector)
Resolution 550 TV Lines
Minimum
Illumination 0 Lux IR LED “on” @ 2.0 Lux Controlled by a CDS sensor
IR Working
Distance 75~150ft / 20~45m
IR LED 12 High Power Reflection IR LED
Water
Resistance IP67
S/N Ratio More than 50dB (AGC OFF)
Synchronizing
System Internal
B.L.C ON/OFF (Switchable)
A.G.C ON/OFF (Switchable)
Flickerless ON/OFF (Switchable)
Auto White
Balance AWB
Lens/Angle of
View 9.0mm~22.0mm / F1.5
Aspherical Auto Iris Lens
29.2°~13.0°
Power Supply 12V DC
Lead Free Yes
Power
Consumption 224mA @ IR “off” / 355mA @ IR “on” 2.7W @ IR “off” / 4.3W @ IR “on”
Operation
Temperature -10°C ~ +50°C
Storage
Temperature -20°C ~ +60°C
Storage
Humidity Maximum: RH85%
Dimensions 185(L) x 73(Ø) mm w/o Bracket
Weight 520g
*Specifications are subject to change without notice
1. Never point the camera toward the sun
Do not expose the lens directly to the sun or to strong light as this
may damage the pick-up device.
2. Handle this camera with care
Avoid any shock or bumping of the camera. Improper handling
could damage the camera.
3. Requires a proper operating environment
This camera is designed for outdoor or indoor use. The allowable
temperature range for operation of this camera is between
-10°C ~ 50°C and the allowable humidity is 85%RH maximum.
4. Clean the front face to the pick-up device
It is recommended that the pick-up device surface be cleaned
before lens installation or whenever the lens is changed. Cleaning
should be done by using a chamois, a very fine soft cloth, lens
tissue, or cotton tipped applicator and ethanol to carefully
remove any fingerprint or dust.
5. Check the power source voltage
The power source voltage should be within the specified
range. (Camera must meet the specifications). Camera must
be connected to a surge protector at all times.
6. Objects and liquid entry
Never push objects of any kind into this camera as this may
touch dangerous voltage points of short out parts that could
result in a fire or electric shock. Never spill any kind of liquid
on the video product.
7. Servicing
Do not attempt to service this video product by yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all service to qualified
servicing personnel.
8. Damage requiring service
Unplug this video product from the wall outlet and refer
service to qualified servicing personnel under the following
conditions:
a. When the power supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been dropped or the cabinet
has been damaged.
d. When the video product exhibits a distinct change in
performance.
O.K.I.USA Products are covered under warranty for one year
from the date of purchase. The warranty will automatically be
voided if any of the following occurs:
1. Camera sticker is removed
If the camera sticker is removed, we will not be able to
confirm any information regarding when and where the
product was purchased. We have no other way to verify the
purchase record without the serial number on the camera
sticker; therefore, it should not be removed.
2.
Camera is modified in any way
If the camera is scratched, damaged, or modified in a manner
not described in this manual, the warranty will be voided
immediately. It is the customer’s responsibility to keep the
camera in good condition.
3. Video or power cable is cut
The video cable and the power cable should not be tampered
with. Cutting or modifying of the cables will result in
termination of the warranty.
CAUTION
WARRANTY
SPECIFICATIONS
