CURIOPlayer Z8
Music Player Installation Guide

The process of switching-out the music player should take approximately 20
minutes. It is recommended that you perform the conversion before the store
opens since the music will be off during the process.
2
Welcome to PlayNetwork! This guide
has been produced in order to assist
you in replacing your existing media
player with the new CURIOPlayer Z8.

CURIOPlayer Z8 Installation Guide
Please read through this entire guide prior to beginning the player conversion
3

CURIOPlayer Z8 Installation Guide
System Electronics
Your store will already have an amplifier installed as part of your current music system.
This amplifier will continue to be used as part of your store’s new music system.
In most stores, the player and amplifier will be located in the managers office on a shelf
or in a network cabinet.
Locate your current player and amplifier. Turn volume knob down to
zero.
Utilize the slack in cables on the back of the player to slide it out and
rotate it around. Move the equipment very slowly, and carefully so that
cables don’t disconnect by mistake.
Please DO NOT remove any cables from the amplifier.
Disconnect the audio cable(s) from your existing media player but leave it connected to the back of the
amplifier.
Disconnect the network cable but leave it connected to your network switch or ethernet wall jack.
Disconnect and remove the power cable from your existing media player.
IMPORTANT NOTE: The CURIOPlayer X5 power supply is not compatible with the CURIOPlayer Z8.
Ensure you use the new power supply included with the CURIOPlayer Z8.
Installation (1/4)
4
STEP
1
STEP
2
Amplifier
Z8

CURIOPlayer Z8 Installation Guide
Connect the RCAAdapter cable to the CURIOPlayer Z8 into the
into the headphone jack. Next connect the existing audio cables
from the amplifier to RCAAdapter cable. Match the white RCA
cable to the existing white RCA cable, repeat if there’s an
existing red RCA cable.
Next, place the network cable into the CURIOPlayer Z8 network
port. The other end of the network cable should still be connected
into the switch or ethernet wall jack.
White
Overhead
Music
Installation (2/4)
5
STEP
3
STEP
4
Red Zone 2
when applicable

CURIOPlayer Z8 Installation Guide
Plug the power cable into the new CURIOPlayer Z8.
Plug the other end of the power cable into the existing surge protector
or power outlet.A blue light on the front panel will light up when the
player is on.
The player will automatically power up and start playing music; this
usually takes a couple of minutes.
If music doesn’t begin playing within 2 minutes, power down the
player using the power button for 10 secs. The player will power
off and then press once again to turn the player back on.
Do not remove power from the player without powering down the player first.
Attach the player rubber feet shipped with the player. Rubber feet
stabilizes the player on a surface.
Installation (3/4)
6
STEP
5
STEP
6

CURIOPlayer Z8 Installation Guide
Installation (4/4)
STEP
7
STEP
8Contact the Installation Hotline at 1.866.477.0132 to leave a voicemail and confirm installation.
Include your store name, store number, and the date of installation.
Congratulations and thank you! You have successfully completed your music installation!
Need further assistance with your install?
Contact PlayNetwork Customer Service:
1.888.567.7529 or [e-mail]
Confirm network connectivity at http://connectivity.apps.playnetwork.com
MAC address is located on the bottom of the player. To check connectivity,
enter the MAC address and then click the magnifying glass button to
search.
7
If player is Not Connected, please contact
PlayNetwork customer service at [phone].
