Operating Instructions and Parts Manual 24417
06/16
2016 OEMTOOLS
HEAVY DUTY MINI AIR
SURFACE PREP SANDER KIT
The following safety information is provided as a guideline to help you operate your Mini Air Surface Prep Sander under the safest possible conditions.
Any tool or piece of equipment can be potentially dangerous to use when safety or safe handling instructions are not known or not followed. The
following safety instructions are to provide the user with the information necessary for safe use and operation. Please read and retain these instructions
for the continued safe use of your tool. Failure to follow instructions listed below may result in serious injury. In addition, make certain that anyone that
uses the equipment understands and follows these safety instructions as well.
WARNING
Explanation of Safety Signal Words
Thank you very much for choosing an OEMTOOLS Product!
For future reference, please complete the owner’s record below:
Model: _______________ Purchase Date: _______________
Save the receipt, warranty and these instructions. It is important that you read the entire manual to become familiar with this product before you begin
using it. This tool is designed for certain applications only. OEMTOOLS cannot be responsible for issues arising from modification. We strongly
recommend this tool is not modified and/or used for any application other than that for which it was designed. If you have any questions
relative to a particular application, DO NOT use the tool until you have first contacted customer service to determine if it can or should be performed
on the product.
WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.
CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderate injury.
CAUTION: Used without the safety alert symbol indicates a potentially hazardous situation which, if not avoided, may result in property damage.
NOTES: Provide clarity and helpful information.
UNPACKING
After unpacking unit, inspect carefully for any damage that
may have occurred during transit. Check for loose, missing, or
damaged parts. If any damage is observed, a shipping damage
claim must be filed with carrier. Do not use the OEMTOOLS®
Mini Air Surface Prep Sander if broken, bent, cracked or
damaged parts (including labels) are noted. Any Mini Air Surface
Prep Sander that appears damaged in any way, operates
abnormally or is missing parts should be removed from service
immediately. If you suspect that the Mini Air Surface Prep
Sander was subjected to shock load (a load that was dropped
suddenly, unexpectedly, etc.) immediately discontinue use until
it has been checked by a factory authorized service center.
FOR CUSTOMER SERVICE
Technical Question?
CALL 1-866-458-2472
[email protected]

2
Operating Instructions and Parts Manual 24417
HEAVY DUTY MINI
AIR SURFACE PREP SANDER KIT
06/16
2016 OEMTOOLS
IMPORTANT INSTRUCTIONS
AND SAFETY RULES
1. Know your tool. Read this manual carefully. Learn the tool’s
applications and limitations, as well as, potential hazards specific
to it.
2. Keep work area clean and well lit. Cluttered or dark work areas
invite accidents.
3. Keep children away. All children should be kept away from the work
area. Never let a child handle a tool without strict adult supervision.
4. Do not operate this tool if under the influence of alcohol or drugs.
Read warning labels on prescriptions to determine if your judgment
or reflexes are impaired while taking drugs. If there is any doubt, do
not attempt to operate.
5. Use safety equipment. Eye protection should be worn at all times
when operating this tool. Use ANSI approved safety glasses.
Everyday eyeglasses are NOT safety glasses. Dust mask, non-skid
safety shoes, hard hat or hearing protection should be used in
appropriate conditions.
6. Wear proper apparel. Loose clothing, gloves, neck-ties, rings,
bracelets or other jewelry may present a potential hazard when
operating this tool. Keep all apparel clear of the tool.
7. Don’t overreach. Keep proper footing and balance at all times when
operating this tool.
8. Check for damage. Check your tool regularly. If part of the tool is
damaged it should be carefully inspected to make sure that it can
perform its intended function correctly. If in doubt, the part should
be repaired. Refer all servicing to a qualified technician. Consult
your dealer for advice.
9. Keep away from flammables. Do not attempt to operate this tool
near flammable materials or combustibles. Failure to comply may
cause serious injury or death.
10. Store idle tools out of the reach of children and untrained persons.
Tools may be dangerous in the hands of untrained users.
11. Maintain tools with care.
12. Keep tools dry and clean.
13. Do not use a damaged tool. Tag damaged tools “Do not use” until
repaired.
14. Use only accessories that are recommended by the manufacturer
for your model. Accessories that may be suitable for one tool may
become hazardous when used on another tool.
15. Tool service must be performed only by qualified repair personnel.
Service or maintenance performed by unqualified personnel could
result in a risk of injury.
16. When servicing a tool, use only identical replacement parts. Use of
unauthorized parts or failure to follow maintenance instructions may
create a risk of injury.
17. Maintain a safe working environment. Keep the work area well lit.
Make sure there is adequate surrounding workspace. Keep the work
area free of obstructions, grease, oil, trash, and other debris. Do not
use this product in a damp or wet location.
18. Maintain labels and nameplates on this product. These carry
important information. If unreadable or missing, contact customer
service for a replacement.
19. Before use, read and understand all warnings, safety precautions,
and instructions as outlined in the vehicle manufacturer’s service
manual. It is beyond the scope of this manual to properly describe
the correct procedure and test data for each vehicle.
20. Always perform vehicle service in a properly ventilated area. Never
run an engine without proper ventilation for its exhaust. Stop work
and take necessary steps to improve ventilation in the work area
if you develop momentary eye, nose, or throat irritation as this
indicates inadequate ventilation.
WARNING
• Disconnect from air supply before changing accessories or servicing.
• Check correct air pressure is maintained and not exceeded.
• Due to possible presences of asbestos dust from brake linings, when
working around vehicle brake systems, we recommend you wear
suitable respiratory protection.
NOTES:The manufacturer declines any and all responsibility for damage
to vehicles or components if said damage is the result of unskillful
handling by the operator or of failure to observe the basic safety rules set
forth in the instruction manual.
WARNING
Read Rules for Safe Operation and Instructions Carefully.
IMPORTANT SAFETY INSTRUCTIONS
The warnings, precautions, and instructions discussed in this manual
cannot cover all possible conditions and situations that may occur. The
operator must understand that common sense and caution are factors
which cannot be built into this product, but must be supplied by the
operator.
WARNING
1. Use only attachments recommended or sold by manufacturer.
2. Do not disassemble the Mini Air Surface Prep Sander. Take it to a
qualified professional when service or repair is required.
3. Keep air hose away from heat, oil and sharp edges. Check air
hose for wear before each use and ensure that all connections are
secure.
4. Only use accessories which are specifically designed for use with a
Mini Air Surface Prep Sander.
5. Wear approved safety eye/face shield, ear defenders and hand
protection.
6. When not in use disconnect from air supply and store in a safe dry,
childproof location.
7. DO NOT use the Mini Air Surface Prep Sander for tasks it is not
designed to perform.
8. DO NOT carry the Mini Air Surface Prep Sander by the air hose, or
yank the hose from the air supply.
9. DO NOT operate the Mini Air Surface Prep Sander if you are tired or
under the influence of alcohol, drugs or intoxicating medication.
10. DO NOT direct air from the tool’s exhaust at yourself or others.
11. Operators and maintenance personnel must be physically able to
handle the bulk, weight and power of this tool.

3
Operating Instructions and Parts Manual 24417
HEAVY DUTY MINI
AIR SURFACE PREP SANDER KIT
06/16
2016 OEMTOOLS
12. Tool shaft may continue to rotate briefly after the throttle is released.
Avoid direct contact with accessories during and after use. Gloves
will reduce the risk of cuts or burns.
DISPOSAL
At the end of the useful life of the OEMTOOLS Mini Air Surface Prep
Sander, dispose of the components according to all state, federal, and
local regulations.
PURPOSE
The OEMTOOLS Heavy Duty Mini Air Surface Prep Sander Kit is ideal for
removal of gasket material rust, surface deposits, and welds also works
great for cleaning and polishing engine components and detail sanding.
PRODUCT SPECIFICATIONS
Free Speed: 15,000 RPM
Air Consumption: 2.1 CFM
Weight: 1.15 Lbs.
Inlet (NPT): 1/4"
Recommended
Air Pressure: 90 PSI
WARNING
Ensure the air supply is clean and does not exceed 90 PSI while operating
the Mini Air Surface Prep Sander. Excessive wear will result if air pressure
is too high and/or you use unclean air. This can shorten the product life
and may be dangerous causing damage and/or personal injury.
OPERATING INSTRUCTIONS
WARNING
Ensure you read, understand and apply safety instructions before use.
1. Always inspect, maintain and operate in accordance with ANSI
safety code for portable air tools (ANSI B186.1) and other local
safety codes and regulations.
2. Do not operate this tool over 90 PSI air pressure.
3. Always disconnect this tool from the air supply before installing,
adjusting or removing any accessory in this tool or before
performing maintenance.
4. Do not carry any air tool by the hose. Keep air hose away from heat
and sharp objects.
5. Continuous use of vibrating air tools by susceptible users may cause
damage to hands.
6. Always lubricate and maintain the tool in safe operating conditions.
7. Only use accessories which are specifically designed for use with a
Mini Air Surface Prep Sander.
8. Correct surface prep disc mounting is necessary to prevent injury.
9. DO NOT use chipped, cracked or damaged surface prep discs.
DO NOT allow the Mini Air Surface Prep Sander to free run for an
extended period of time as this will reduce bearing life.
AIR SUPPLY
Ensure the Mini Air Surface Prep Sander air valve (or trigger) is in the
“off” position before connecting to the air supply. Always use clean dry air
as excessive moisture will lower the available torque and rust the interior
moving parts. Make sure all hoses and fittings are of the recommended
size and be sure the units are not used with less than or more than the
recommended pressure of the tool (90 PSI).
LUBRICATION
Proper lubrication of this air tool is critical to the operation and life of the
unit. Units can be severely damaged or have excessive wear placed on
working parts if not lubricated. We recommend the use of air tool oil or
3-in-1 machine oil which is available at most auto parts locations. The
tool should be lubricated each time it is used. During daily prolonged use,
lube heavily 3 or 4 times during the day.
WARNING
Any excess oil in the motor is immediately expelled from the exhaust port.
Always direct exhaust port away from people or objects.
MAINTENANCE
WARNING
Disconnect the Mini Air Surface Prep Sander from air supply before
changing accessories, servicing or performing maintenance.
1. Replace or repair damaged parts. Use genuine parts only.
Unauthorized parts may be dangerous and will invalidate the
warranty.
2. If the air system does not have an oiler then lubricate the Mini Air
Surface Prep Sander daily with a few drops of air tool oil into the air
inlet.
3. Blow out air line to clear it of accumulated dirt and moisture.
4. Connect tool and operate tool to allow oil to be carried to the interior
of the tool.
5. Clean the Mini Air Surface Prep Sander after use.
6. DO NOT use worn or damaged accessories.
TROUBLESHOOTING
Other factors outside the tool may cause loss of power or erratic action.
Reduced compressor output, excessive drain on the air line, moisture or
restrictions in air pipes or the use of hose connections of improper size or
poor conditions, may reduce air supply. If outside conditions are in order,
and the tool still performs erratically, disconnect the tool and remove from
service.

4
Operating Instructions and Parts Manual 24417
HEAVY DUTY MINI
AIR SURFACE PREP SANDER KIT
06/16
2016 OEMTOOLS
Parts List Parts Diagram
Item # Part Name Qty.
1 Air Inlet 1
2 Exhaust Deflector 1
3 O-Ring 1
4 Spring 1
5Throttle Valve
Assembly
1
5A Throttle Valve Pin 1
5B Throttle Valve 1
6Throttle Valve
Seat
1
7 O-Ring 1
8 Muffler Element 1
9 Motor Housing 1
9-1 Muffler Insert 1
10 O-Ring 1
11 Trigger 1
12 Reverse Knob 1
13 Screw 1
14 Reverse Plate 1
15 O-Ring 1
16 O-Ring 1
17 Reverse Valve 1
18 Spring 1
19 Steel Ball 1
20 Ball Bearing 1
21 Rear End Plate 1
22 Rotor Blade 4
23 Rotor 1
24 Spring Pin 2
25 Cylinder 1
26 Rotor Collar 1
27 Spring Pin 1
28 Front End Plate 1
29 Ball Bearing 1
30 Washer 1
31 Felt Seal 1
34 Clamp Nut 1
35 Spindle 1
36 Spanner Wrench 1
37 2” Pad 1
38 3” Pad 1
OEMTOOLS®ONE YEAR WARRANTY
If for up to one year from the date of purchase of this OEMTOOLS product you find any defect in material
or workmanship, through normal usage, return it to the place of purchase, or to OEMTOOLS for repair or
replacement at our discretion. In order to obtain this service send your tool and proof of purchase, transportation
pre-paid, to OEMTOOLS Q.A. Dept., 3580 E. Raines Road #3, Memphis, TN 38118. We will not be responsible for
lost or damaged goods during transportation, please insure your package. If our inspection verifies the defect,
we will either repair or replace the product at our election, or we may elect to refund the purchase price if we
cannot readily and quickly provide you with a replacement. We will return repaired products at our expense, but
if we determine there is no defect, or that the defect resulted from causes not within the scope of our warranty,
then you must bear the cost of returning the product.
OEMTOOLS does not provide warranty for products labeled other than OEM or OEMTOOLS. OEMTOOLS will
not provide any warranty for products subjected to abnormal use. Abnormal use includes, but is not limited to,
abuse, accident, alteration, neglect, and unauthorized or unreasonable use or repairs. This warranty does not
cover bits, blades, files, batteries, or calibration. We recommend that you maintain your tools and sharpen or
replace blades, bits, files, and batteries as necessary. OEMTOOLS reserves the right to makes any changes in
construction or design at any time without any obligation in incorporating such changes to tools or equipment
previously sold.
OEMTOOLS makes every effort to assure that its products meet high quality and durability standards, and
warrants to the original purchaser that this product is free from defects in materials and workmanship for the
period of one year from the date of purchase. This warranty does not apply to damage due directly or indirectly
to misuse, abuse, negligence or accidents, repairs or alterations outside our facilities, criminal activity, improper
installation, normal wear and tear or to lack of maintenance.
We shall in no event be liable for death, injuries to persons or property, or for incidental, contingent, special
or consequential damages arising from the use of our product. Some states do not allow the exclusion or
limitation of incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING THE
WARRANTIES OF MERCHANTABILITY AND FITNESS. This warranty gives you specific legal rights, and you may
also have other rights, which vary from state to state.
NOTE:
Not all components of the Mini Air Surface Prep Sander are replacement items, but are illustrated as a convenient
reference for location and position in the assembly sequence.
CONTACT US
3580 E. Raines Road, Suite 3, Memphis, TN 38118
Tel: [phone]
www.oem-tools.com
