oirole CIR415A User manual
Subject to change without prior notice info@abcircle.com
www.abcircle.com
CIR415A Bluetooth® Contactless Smart Card
Reader
User Manual
Page 2 of 12
Driver installation Procedure
* Driver signed by Microsoft and WHQL, user can install the driver with Window Update. In case that
cannot install via Window Update, please process the below steps to Manual installation
Hardware requires:
❖CIR415A
❖PC with OS windows 7 or above
Software requires:
❖CIR415 Driver Package
Steps:
1. Connect CIR415A to PC
2. On PC, open “Control Panel > System”
3. Open “Device Manager”
4. Select and open “Smart card readers”
if it is shown “Microsoft Usbccid ... (WUDF)”, please continue with step 5)
Page 3 of 12
if it is shown “CIR415 CL & 1S” mean driver install completed
5. Right click then select “Update driver”
6. Select “Browse my computer for driver software…”
7. 選擇 “Let me pick from a list …”
Page 4 of 12
8. Select “Have Disk…”
9. Select “Browse…”
Select “CIR415.inf”, then press “Open” and “OK”
Page 5 of 12
10. Select “CIR415 CL & 1S” then “Next”
11. Waiting until below screen shown, Press “Close” to complete
12. Double click to ensure the device changed to “CIR415 CL & 1S”
Page 6 of 12
13. Done
Operation Example
Hardware requires:
❖CIR415A
❖PC with OS windows 7 or above
❖Mifare 1k Test Card
Software requires:
❖Any PCSC Application (e.g. APDU.exe)
Steps:
1. Plug in the reader into the PC
Page 7 of 12
2. Open “APDU.exe”
3. Click “1. Select reader”, Chose “Circle CIR415 CL & 1S PICC 0”, then click “OK”
Page 8 of 12
4. Tag ISO14443 Test card on CIR415A
Select “T1”, Message = “90 0a 00 00 01 00 00”
5. Press “2. Connect”
Page 9 of 12
6. Press “3. Transmit”
7. Result will be shown on the “Answer from the card:”
Page 10 of 12
Parameter Sheet
Physical Characteristics
Dimensions.........................................................95.0 mm (L) x 61.0 mm (W) x 6.0 mm (H)
Casing................................................................White PC
Universal Serial Bus Interface
Specification.......................................................USB 2.0 Type C
Type ...................................................................Four lines: +5V, GND, D+ and D-
Speed.................................................................USB 2.0 Full Speed Device, 12 Mbps
Supply Voltage...................................................Regulated 5V DC (Range from 4.75V to 5.25V)
Supply Current ...................................................<500mA
Cable Length......................................................1m
Contactless Interface
Standard.............................................................ISO14443, ISO18092, FeliCa®, ISO15693
Protocol..............................................................T=CL for ISO14443-4–compliant cards, T=CL
Emulation for MIFARE Classic, ISO 18092, FeliCa and
NFC tags
Page 11 of 12
Carrier Frequency ..............................................13.56MHz
Operating Baud Rate .........................................106kbps, 212kbps, 424kbps, 848kbps (Default:
424kbps)
Antenna Size......................................................53.0 mm x 32.0 mm
SAM Smart Card Interface
Standard.............................................................ISO 7816 3/4 Class A
Protocol Support ................................................T=0 and T=1
Supply Current ...................................................Max. 50mA
Smart Card Voltage............................................5V
Operating Baud Rat ...........................................9600 –125kbps
Clock Frequency ................................................4.0 MHz
Card Connector Type.........................................Contact
Human Interface
LED ....................................................................3 LED:
1 Red & Green Bi-colour (Power & Charging status)
1 Blue & Green Bi-colour (Bluetooth & USB mode)
1 Blue (PICC operation)
Buzzer................................................................Optional
Operating Conditions
Temperature.......................................................0 –60 ℃(when battery is not charging)
0 –45 ℃(when battery is charging)
Humidity .............................................................<85%
Compliances/Certifications
Systems/ Standards...........................................USB 2.0 Full Speed, CCID, Microsoft® WHQL,
Bluetooth 5.0
Regulatory/ Environmental.................................EN 62368/IEC 62368, CE, FCC, VCCI, RoHS, REACH,
MIC, TELEC
Operational Environment
Compatible Operating System...........................Windows® 7, 8, 8,1, 10, Linux®, Mac OS® 10.11 and
above, Android™ 7.0 and above, IOS 8.0 and above
Page 12 of 12
NOTE: This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device
may not cause harmful interference, and (2) this device must accept any interference received, including interference that may
cause undesired operation.
Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user authority to operate the equipment.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of
the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help
