OKM Rover UC User manual

INTRODUCTION
TECHNICAL SPECIFICATIONS
CONTROL ELEMENTS
ASSEMBLY & PREPARATION
OPERATING MODES
FILE TRANSFER
OKM ROVER UC
MANUAL

OKM GmbH
Julius-Zinkeisen-Str. 7
04600 Altenburg
Germany
Phone: [phone]
Internet: www.okmdetectors.com
Facebook: www.facebook.com/okmmetaldetectors
Instagram: www.instagram.com/okmdetectors
YouTube: www.youtube.com/OKMDetectors
TikTok: www.tiktok.com/@okmdetectors
Any information contained in these operating instructions may be changed without prior notice.
OKM does not make any warranty for this document. This also applies without limitation to implied assurances of merchantability and fitness for a specific purpose. OKM does not assume any responsability for
errors in this manual or for any incidental or consequential damage or loss associated with the delivery, exploitation or usage of this material.
This documentation is available "as presented" and without any kind of warranty. In no circumstances OKM takes responsibility for lost profits, usage or data losts, interruption of business activities or all kind of
other indirectly damages, which developed because of errors in this documentation. This instruction manual and all other stored media, which are delivered with this package should only be used for this product.
Program copies are allowed only for security- and savety purposes. The resale of these programs, in original or changed form, is absolutely forbidden.
This manual may not be copied, duplicated or translated into another language, neither in part nor completely, over the copyright matters without the prior written consent of OKM.
Copyright © 2022 OKM GmbH. All rights reserved.

TABLE OF CONTENTS
1 INTRODUCTION...........................................................................4
1.1 PREFACE........................................................................................................ 4
1.2 IMPORTANT NOTES ...................................................................................... 5
1.2.1 General Notes ............................................................................................. 5
1.2.2 Possible Health Hazards ............................................................................ 5
1.2.3 Surrounding Area ....................................................................................... 5
1.2.4 Voltage......................................................................................................... 5
1.2.5 Data Safety .................................................................................................. 5
1.3 MAINTENANCE AND SERVICES.................................................................. 5
1.4 DANGER OF EXPLOSION DURING EXCAVATION........................................ 6
1.5 CARE AND USE ............................................................................................. 6
1.6 PROTECTING YOUR INVESTMENT .............................................................. 6
2 TECHNICAL SPECIFICATIONS.................................................7
2.1 TELESCOPIC PROBE .................................................................................... 7
2.2 WIRELESS DATA TRANSFER....................................................................... 7
3 CONTROL ELEMENTS ...............................................................8
3.1 TELESCOPIC PROBE .................................................................................... 9
3.2 ANDROID SMARTWATCH............................................................................10
3.3 ROVER UC APP SCREEN OVERVIEW .........................................................11
3.3 BLUETOOTH HEADPHONES .......................................................................11
4 ASSEMBLY AND PREPARATION...........................................13
5 OPERATING MODES.................................................................14
5.1 ACTIVITY SCREEN........................................................................................14
5.1.1 Pedometer Reset ........................................................................................15
5.1.2 Compass Calibration..................................................................................15
5.2 3D GROUND SCAN.......................................................................................16
5.2.1 Preparing a 3D Ground Scan .....................................................................16
5.2.2 Performing a 3D Ground Scan ..................................................................18
5.3 MAGNETOMETER ....................................................................................... 20
5.3.1 Performing a Magnetometer Scan ........................................................... 20
5.3.2 Performing a Ground Balance ..................................................................21
5.4 PINPOINTER................................................................................................ 22
5.4.1 Performing a Pinpointer Scan .................................................................. 22
5.4.2 Performing a Ground Balance ................................................................. 23
5.4.3 Analyzing a Pinpointer Scan..................................................................... 23
5.5 FILE EXPLORER.......................................................................................... 24
5.6 SETTINGS.....................................................................................................26
5.6.1 Language....................................................................................................26
5.6.2 Sound .........................................................................................................26
5.6.3 Vibration.................................................................................................... 27
5.6.4 GPS............................................................................................................ 27
5.6.5 App Theme ................................................................................................ 27
5.6.6 Length Unit................................................................................................ 27
5.6.7 Activation................................................................................................... 28
5.6.8 Update ....................................................................................................... 29
5.7 INFORMATION............................................................................................. 29
6 FILE TRANSFER .......................................................................30
6.1 PAIRING BLUETOOTH................................................................................. 30
6.2 IMPORTING SCAN DATA............................................................................. 32

1 INTRODUCTION
1.1 PREFACE
Dear customer,
our engineers, sales, training and support staff at OKM GmbH would like to thank you for your
purchase of the Rover UC.
The Rover UC detector works on the principle of Electro-Magnetic Signature Reading (EMSR).
Besides the detection of metallic objects this device is also capable of detecting natural features
of the earth like formations of strata, cavities, voids, faults, ground water and other non-metallic
objects. Then, of course, this equipment is best suited for the detection of sepulchers, treasures,
buried utilities, tanks etc.
The Rover UC is able to locate, document and analyze buried objects within various structures and
vessels non-intrusively without having to excavate the area. Using EMSR is particularly useful in
areas where detection is a must and excavation is not possible. The intuitive and flexible handling
of the Rover UC can easily and quickly provide reproducible results.
With our team of specialists we guarantee that our products are under recurrent control. Our
specialists try to implement new developments in terms of further quality improvements for you.
By purchasing or using our products, we cannot guarantee that you will be successful and have a
find during the course of your research. The recognition of hidden and buried objects depends on
a huge number of factors. As you well may know there are different soil types all over the world
with different levels of natural attenuation. Variable soil properties can and will hamper and alter
ultimate scan measurements. Areas with an extreme amount of ground water, varying clays, sands
and wet soils make scanning more difficult and may reduce the maximum depth capabilities of the
detection equipment, regardless of make or model.
For more information regarding where this equipment has been used and operated, please visit
our website. Our equipment is constantly being tested. Improvements and upgrades are listed on
our website.
It is necessary for our company to protect our developments and all of the information learned
during the “Research and Development” phases in creating our technology. We strive to stay within
the given framework of legislation, patents and trademark registration.
Please take your time to read this User Manual and familiarize yourself with the operation, func-
tionality and how to utilize the Rover UC. We also offer training for OKM equipment in our head-
quarters and on-site. We strive to maintain a worldwide dealer network for assistance and sup-
port. Please visit our website www.okmdetectors.com for more information.
4 / 34
INTRODUCTION

1.2 IMPORTANT NOTES
Prior to using the Rover UC and its accessories, please read these operating instructions carefully.
These instructions give information on how to use the detector and potential sources where pre-
cautions should be taken.
The Rover UC and its accessories serve for the analysis, documentation and detection of sub-
surface anomalies and ground disturbances. The recorded data of the ground structure will be
transmitted to a computer to give a visual representation using our proprietary software program.
Any additional notes to the software should be observed. Please refer to the Visualizer 3D Studio
Documentation!
1.2.1 General Notes
Being an electronic device, the Rover UC has to be treated with caution and treated with care as
with any electronic device. Any failure to observe the safety precautions given or any use for pur-
poses other than the ones it is designed for may result in damage or destruction of the processing
unit and/or its accessories or connected components.
The device has a built in anti-tampering module which will destroy the unit if it is improperly
opened. There are no consumer serviceable parts inside the unit.
1.2.2 Possible Health Hazards
If used properly this device usually does not pose any health hazards. According to current scien-
tific knowledge, the high-frequency signals are not harmful to the human body on account of their
low power.
1.2.3 Surrounding Area
When moving this unit from a cold place to a warmer place, watch out for condensation. Do not
immediately operate the unit until any possible condensation could have evaporated. The unit is
not weather proof and water or condensation can destroy the unit.
Avoid strong magnetic fields, which may occur in places where there are large electric motors or
unshielded loudspeakers. Try to avoid using this equipment within 50 meters (150ft) of this type
of equipment.
Metallic objects on the ground such as cans, tin, nails, screws or debris can influence your scan
data and present negative results regarding your scan data. Also it is a good habit to remove any
metallic objects off of your person like cellular telephones, keys, jewelry, etc. Do not wear steel
toe boots.
1.2.4 Voltage
The power supply can not be outside the indicated range of values. Use only approved chargers
which are included within the delivery scope.
1.2.5 Data Safety
Data errors can occur if:
• the range of the sender module has been exceeded,
• the power supply of the device or the batteries are too low,
• the unit is operating to close to devices which sends out disturbances or
• atmospheric conditions (electrical storms, lightning, etc.).
1.3 MAINTENANCE AND SERVICES
In this section you will learn how to maintain your measuring instrument with all included acces-
sories to keep it in good condition a long time and to get good measuring results.
The following list indicates what you absolutely should avoid:
• penetrating water
• strong dirt and dust deposits
• hard impacts
• strong magnetic fields
• high and long lasting heat effect
To clean your device please use a clean and dry soft rag or cloth. To avoid any damage you should
transport the device and accessories always in an appropriate way.
Prior to using your Rover UC please be sure that all batteries are fully charged.
To charge the internal battery
use only the approved charger which are part of the delivery scope.
5 / 34

1.4 DANGER OF EXPLOSION DURING EXCAVATION
Unfortunately, the last two world wars and other local conflicts made the ground in many places
of the world a potentially explosive scrap heap. A host of those lethal relics are still buried in the
ground. Do not start digging and hacking for an object wildly when you receive a signal of a piece
of metal from your device. Firstly, you might indeed cause irreparable damage to a truly rare find,
and secondly, there is a chance that the object reacts in an insulted way and strikes back.
Note the color of the ground close to the surface. A red or reddish color of the ground is an in-
dicator of rust traces. As regards to the finds themselves, you should definitely pay attention to
their shape. Curved or round objects should be a sign of alarm, especially if buttons, rings or little
pegs can be identified. The same applies to recognizable ammunition or bullets and shells. Leave
ammonition where it is, do not touch it and, most importantly, do not take any of it home with you.
The devices of war made use of rocker fuses, acid fuses and ball fuses. Those components have
been rusting away in the course of time, and the slightest movement may cause parts of them to
break and be Triggered. Even seemingly harmless objects such as cartridges or large ammunition
are anything but that.
Moving such an object may cause those crystals to produce friction, leading to an explosion. If you
come across such relics, mark the place and do not fail to report the find to the police. Such ob-
jects always pose a danger to the life of hikers, walkers, farmers, children and animals.
1.5 CARE AND USE
The Rover UC is a sturdy instrument, but it is not designed to withstand abuse. In caring for your
ground scanner, there are several important DOs and DON‘Ts to remember:
• DO NOT use to get rid of bushes, flatten area by swinging wildly or pry rocks loose.
• DO NOT drop the machine into water or use it while it is raining or wet.
• DO NOT leave it exposed at night where dew could form on it.
• DO NOT store it in places that could get extremely hot.
• DO NOT leave it in the trunk of a car where high temperatures could build up.
• DO NOT spray lubricants, or any type of cleaners, solvents, sealants or other chemicals into
or onto the electronic parts, switches or controls.
• DO NOT attempt to modify or repair the detector‘s electronics as this will void your detector‘s
warranty.
• DO clean your unit with a soft dry or slightly damp cloth to remove dust and residue from the
previous use.
• DO use the device within the proper operating guidelines.
The warranty does not cover damage resulting from an accident, neglect or abuse.
1.6 PROTECTING YOUR INVESTMENT
Often detector users become disappointed when their new detector becomes less and less
responsive and seems to have lost some of its original peak performance. You can help prevent
this from happening to your detector by following these basic care and protection guidelines:
• Operate your detector exactly as recommended in this User Manual.
• Use only approved OKM chargers.
• Avoid hitting the probe against hard, solid objects and surfaces.
• Keep your probe slightly off of the ground, especially when using in gravel or hard, rocky dirt.
• If working in or near water, or if there is a possibility of rain, use a protective weather resistant
pouch or plastic bag to cover the control housing. Make sure it can “breathe” in order to ensure
against condensation buildup inside.
• After each use, clean the detector with a soft cloth to remove dust, moisture or other conta-
minants.
• When transporting the detector in a car during hot weather, store it on the floor of the pass-
enger compartment if possible. Using the Protection case gives additional protection. In any
case, never allow the detector to roll around unprotected in the trunk or back of a pickup truck.
• Protect your detector from dust, moisture, and extreme temperatures during storage.
• When shipping, use the original heavy-duty container (Protection case) and provide sufficient
padding around all parts.
• Treat your detector as you would treat any sensitive electronic instrument. Though it is
designed to withstand the demands of normal treasure hunting, proper care is essential.
6 / 34

2 TECHNICAL SPECIFICATIONS
The technical specifications are medial values. During operation slight variations are possible.
2.1 TELESCOPIC PROBE
Dimensions (L x W x H) 670– 1380 x 65 x 80mm
Weight 0.5 kg
Input Voltage (max) 5V DC, 2 A
Charge time 3h @10 –30 °C
Operating time approx. 48h
CPU Cortex-M0+, 24MHz
Display LCD, 80 x 160 Pixel
Sample rate 240 values/ second
Measurement resolution 15bit
Interconnect Bluetooth 5.2, max. distance 8m
Operating temperature -5 –60 °C
Storage temperature -10– 70°C
Air humidity 5% –75 %
Technology GST, EMSR
Sensor technology SCMI-15-D
Compass Yes
Pedometer Yes
Waterproof No
2.2 WIRELESS DATA TRANSFER
Technology Bluetooth 5.2
Frequency range 2.4– 2.4835GHz
Maximum transfer rate 1Mbps
Receiving sensitivity -85dBm
Maximum range approx. 8m (Line of Sight)
7 / 34
TECHNICAL SPECIFICATIONS

3 CONTROL ELEMENTS
In this section you learn more about the fundamental use of all control elements for this measur-
ing instrument. All connections, inputs and outputs are explained in detail.
Telescopic
Probe Smartwatch
CONTROL ELEMENTS
8 / 34

3.1 TELESCOPIC PROBE
Telescopic
Rod
Minidisplay
USB-C
Charger Socket
Trigger
with LED
Charging
LED
Trigger with LED: The Trigger is used to power the detector on and off and to control the various
operations. Depending on the activated function, this button will control further features which will
be explained in detail in the corresponding chapters.
Push the Trigger to power on the device. The Trigger LED will illuminate in green color. Addition-
ally, the Minidisplay will show indications about battery status, pedometer and compass.
If Smartwatch or Smartphone is not connected via Bluetooth and the detector is switched on, the
Rover UC can be used as trekking pole with pedometer and compass.
Moreover, to enhance the detector's undercover functionality, press the Trigger once to switch off
the Trigger LED ring and to dim the Minidisplay (UnderCover Mode). The detector is still powered
on and ready for scans.
Trigger LED off The Detector is powered off (unless in UnderCover Mode).
Trigger LED green Detector is powered on, but is not connected to any Android device via
Bluetooth.
Trigger LED blue
Detector is powered on and connected to an Android device
(Smartwatch or Smartphone) via Bluetooth. The detector is ready to
perform scans.
To power off the detector, press and hold the Trigger at least 3 seconds until the LED is no longer
illuminated and the Minidisplay switches off, too.
USB-C Charger Socket with Charging LED: When the internal battery is too low, you have to re-
charge it by connecting the appropriate charger and USB-C cable to the USB-C Charger Socket.
As long as charging is in progress, the Charging LED is red. As soon as the Charging LED turns
green, the battery is fully charged.
When the device is powered on while charging, the Minidisplay shows the charging icon but
no additional indication of the charging progress itself.
Telescopic Rod: The Telescopic Rod can be extended or collapsed according to the user's height.
To make it easier to transport the Rover UC, you can completely collapse every single section.
Minidisplay: The Minidisplay shows indications of the battery status and compass at any time
while operating the detector.
Connection
Indication
Pedometer
Battery
Status
Compass
Scan
Progress
9 / 34

3.2 ANDROID SMARTWATCH
The Rover UC must be operated with an Android device by using the OKM Rover UC App. The
standard delivery scope of the Rover UC already includes a pre-configured Android Smartwatch.
Button A
Button B
Long press Button B (min. 2 s) to power on the Smartwatch or, if Smartwatch is switched on, to
enter the Shutdown screen. From here you can choose between Power off, Reboot, Power Save
or Recent Task.
For additional information please read the Smartwatch User Manual.
Button A
or
Swipe right
Swipe left
Button B
Button B
Button A
or
swipe right
Swipe up/down to browse App List
Standby
(Screen off)
Button B
Button B
10 / 34

3.3 ROVER UC APP SCREEN OVERVIEW
Toggle Activity Screen /
Return to Main Menu Selected menu
Selected
language
Smartwatch battery status
Detector battery status
Available
options
View next option
Selectable
option
View previous option
Return to
previous screen
3.3 BLUETOOTH HEADPHONES
The Rover UC can be operated with any Bluetooth headphones available on the market. Your Rover
UC already includes Bluetooth headphones.
To use the headphones with your detector, they must be paired with the Android device that you
use to operate your detector via OKM Rover UC App. Connect your headphones according to the
following steps:
1. Power on your headphones (Baseline HS).
2. From the App List select Settings > Connect > Bluetooth.
3. Enable Bluetooth.
4. Scroll down to section Available devices and click on button Search.
5. The entry Baseline HS will appear in the list. Select it to start pairing.
6. After the headphones are paired, the entry Baseline HS will appear in Paired devices and is
ready to use.
For further information, please refer to the user manuals of your Android device as well as your
headphones!
11 / 34

12 / 34
ASSEMBLY & PREPARATION

4 ASSEMBLY AND PREPARATION
Please follow these instructions to assemble your detector and get ready for your first scan.
1
Make sure to recharge the internal battery of
the detector before going into the field.
Plug charger into detector to check the charge
status:
• Charging LED green = fully charged
• Charging LED red = charging
4
Start the OKM App on the Smartwatch
and select the desired operating mode, see
chapter 5 OPERATING MODES on page 14.
2
Release the lock by turning the grip clockwise.
Fully extend the lower part of the Telescopic
Rod and lock it again.
Then adjust the upper parts of the Telescopic
Rod to your height for maximum comfort.
3
Push the Trigger to power on the detector. The
Trigger LED turns green and the Minidisplay
turns on.
13 / 34

14 / 34
5 OPERATING MODES
The detector is controlled by a Smartwatch (alternatively Smartphone) with pre-installed OKM
Rover UC application. Power on the Smartwatch and select the OKM Rover UC App icon by tapping
on it. The application will start and display the main menu.
The Activity Screen is accessible anywhere at any time:
• Activity Screen: Display the UnderCover Screen with pedometer and compass.
The following functions are started from the main menu:
• 3D Ground Scan: Graphical 3D measurement for detailed analysis on a computer.
• Magnetometer: Acoustic magnetic field measurement to detect ferrous metals.
• Pinpointer: Basic target discrimination and real-time scan to locate potential targets.
• File Explorer: List of all scans that have been stored. The scan files can be viewed and analy-
zed directly on the Smartwatch as well as transferred to a computer.
• Settings: Adjust general settings like language, feedback, design etc.
• Information: View information like serial number and firmware version.
The choice of the operating mode depends on your planned project. Usually, you should use
several operating modes one after another to explore an area. In that way you can obtain as many
information as possible from the underground of the scanned area.
5.1 ACTIVITY SCREEN
If you aroused suspicion with the detector, click on the Smartwatch Button A to open the activity
screen. This screen shows your steps taken (pedometer function), current heart rate and the cur-
rent direction the detector is heading to (compass function). It may take a moment until the heart
rate is displayed.
14 / 34
OPERATING MODES

15 / 34
5.1.1 Pedometer Reset
You can reset the pedometer at any time by clicking the reset icon
After clicking, you will be asked if you really want to reset the counter.
Confirm by clicking or cancel by clicking
After confirming the pedometer will start counting beginning at 0.
5.1.2 Compass Calibration
In order to calibrate the compass, click on the calibrate compass icon
Make sure that the probe is held vertically, avoid pivoting or swinging.
Compass Calibration
Calibrating ...
1
After clicking on the icon, the Rover UC App
will start the calibration.
2
Rotate very slowly around your own axis
(approx. 16s for a complete 360° rotation)
while the Calibrating ... screen is visible.
3
After finishing your 360° rotation, press the
Trigger on the probe to finalize the calibration
process.
Compass Calibration
Calibration successful!
4
As soon as the calibration is completed, the
App will confirm with Calibrating successful!
Press to finish.
If the calibration failed, please try again!
Reasons for failure may be:
• You moved/rotated too fast.
• The probe was pivoted while calibrating.
• There are too many ferromagnetic inter-
ferences in the area (e.g. power lines).
15 / 34

5.2 3D GROUND SCAN
The operating mode 3D Ground Scan provides
a graphical measurement of any area for further
analysis on a computer.
Get general information on performing a geophysical
measurement in the "3D Ground Scan Guide" and find
further information in the infobox on page 33.
5.2.1 Preparing a 3D Ground Scan
1
Start the OKM Rover UC App and select the
operating mode 3D Ground Scan from the
main menu.
2
Select Default to use the preset parameters that we recommend for fast scans:
Field Length: Auto | Impulse Mode: Automatic | Scan Mode: Parallel
2
Select Customized to adjust the parameters
individually.
3
Choose the Field Length.
Auto: Determine the length by pressing the
Trigger at the end of the first scan line. All suc-
ceeding lines will stop automatically.
10m, 20m, ... : The length of the scan lines is
defined before the scan. All lines will stop au-
tomatically.
4
Select the Impulse Mode to determine how the
single impulses (scan values) will be released by
the detector.
Automatic: All scan values will be recorded con-
tinuously line by line without any break.
Manual: Every single scan value will only be re-
corded by pressing the Trigger.
16 / 34

7
The Bluetooth connection to the detector will
be established automatically.
As soon as the Bluetooth connection is
established successfully, the Trigger LED
turns blue.
6
Confirm your settings by pressing Start Scan.
5
Select the Scan Mode to determine how to
walk over the scan field while scanning:
Parallel: Scan all lines in the same direction.
Zigzag: Scan all scan lines in zigzag style.
For further information please continue with
section 5.2.2 Performing a 3D Ground Scan on
page 18
8
As soon as the Bluetooth connection is
established, the App is ready to record the first
scan line.
Continue with section 5.2.2 Performing a 3D
Ground Scan on page 18
17 / 34

18 / 34
5.2.2 Performing a 3D Ground Scan
After all parameters have been adjusted, the Rover UC App is ready to start the first scan line. Go to
your starting point of the first scan line and press the Trigger on the Probe.
Impulse Mode Automatic and Field Length Options
If you have selected the Impulse Mode Automatic, just keep walking until you have reached the end
of the first scan line.
If you have set an individual Field Length, the App will stop automatically after reaching the
selected field length.
If you have selected Field Length Auto, press the Trigger at the end of the first scan line.
Then go to the starting point of the next scan line and press the Trigger again. The device will stop
automatically at the end of all following scan lines of this measurement.
Impulse Mode Manual and Field Length Auto
If you have selected the Impulse Mode Manual, you have to release each single impulse manually
one by one by pushing the Trigger on the Probe. This mode requires Field Length Auto.
First, press the Trigger to start your measurement. Then, take a step forward and press the Trigger
again to measure the next impulse. Continue in this way until you have reached the end of the first
scan line. Press to finish the first scan line.
Go to the starting point of your next scan line and push the Trigger again. Go another step forward
and repeat this in the same way like you recorded the first scan line. The App will signalize automa-
tically the end of the following scan lines.
1
As soon as you press the Trigger on the probe,
the detector will record scan values.
The display will indicate the number of the cur-
rent scan line (left) and the number of mea-
sured impulses per scan line (right).
2
Go to the starting point of the next scan line
and press the Trigger to start measuring.
Walk until you reach the end of the scan line.
3
The scan image will be generated during the
measurement. This will help you to follow your
progress while measuring.
The first scan lines may look rather incorrect.
The inconsistent scan image will stabilize in
the course of the measurement.
4
Perform as many scan lines as you like
by repeating Step 2.
Press Finish Scan to finish your scan.

19 / 34
Scan Modes Parallel and Zigzag
If you have selected the Scan Mode Parallel, all scan lines head into
the same direction.
Scan the first scan line to its end and then go back to the starting point
without further scanning. Take one step to the left and scan the next
line parallel to your first scan line.
Repeat this until you reached the last scan line.
If you have selected the Scan Mode Zigzag, all scan lines must be
scanned in zigzag style.
Scan the first scan line to its end, then take a step to the left and scan
the second line in reverse. Step to the left again and scan the next line.
Repeat this until you reached the last scan line.
Read more about the scanning procedure in the "3D Ground Scan Guide"
(see infobox on page 33).
After finishing and saving your 3D Ground Scan, you can view your scan image directly on the
Android device display (see section 5.5 FILE EXPLORER on page 24) or transfer the scan files to a
computer for in-depth analyses (see chapter 6 FILE TRANSFER on page 30).
5
Press to save the scan.
If you want to finish the scan without saving,
click .
6
Enter the correct field length.
7
Enter the correct field width.
8
Confirm by pressing Save Scan
You can swipe up again (or use the navigation
arrow on the right) to return to the previous
screen to correct your information.

5.3 MAGNETOMETER
The operating mode Magnetometer allows to research the area in regard to ferromagnetic
metals, e.g. iron, cobalt and nickel and other metals or objects which include traces of such metals.
Primarily, this function is an acoustic mode that additionally generates a basic graphical represen-
tation to visualize the peaks.
As soon as you get an acoustic signal, the device has detected a potential metal target right below
the position of the probe. In this way it is possible to find small metal objects near the surface like
nails, screws, wires, seals and similar targets.
A general rule is:
The fewer small metal items in the soil, the deeper you can detect targets with 3D Ground Scan.
5.3.1 Performing a Magnetometer Scan
In this operating mode all measured data will be directly displayed in the OKM Rover UC App.
Thus, we recommend to use the Magnetometer to remove disturbing metal items from the area that
you like to scan in detail. The less metals near to the surface, the better your result in the operating
mode 3D Ground Scan.
Moreover, Magnetometer can be used to pinpoint objects during excavation. If you have already dug
a large hole and do not remember where exactly the detected object was situated, you can relocate
fast and efficiently the target position.
1
Power on the detector and the Smartwatch. Start
the Rover UC App and select the operating mode
Magnetometer.
2
The Bluetooth connection to the detector will
be established automatically.
As soon as the Bluetooth connection is
established successfully, the Trigger LED
turns blue.
3
Move the probe slowly in any direction:
back and forth, to the left and to the right.
Make sure you hold the probe vertically to the
ground, avoid rotating, pivoting and swinging.
The scan results are displayed in real-
time on the Smartwatch screen.
As soon as a strong signal is detected, the
values will reach its peak when the probe is
directly above the detected object.
To pause the scan, tap on and continue
with
To finish the scan and return to the App main
menu, tap on the back arrow
90°
20 / 34
