Olivetti OLIBOOKM1020 User manual

Code: 383311Z
USER GUIDE

Edited/Published/Produced by:
Olivetti S.p.A.
Gruppo Telecom Italia
Via Jervis, 77
Ivrea (TO)
Italy
www.olivetti.com
Copyright © Olivetti, 2009
All rights reserved
The mark affixed to the product certifies that
Code: 383311Z
Date of publication: August 2009
Trademarks: Microsoft and Windows are registered
trademarks of Microsoft Corporation.
Other trademarks and trade names
may be used in this document to refer to either the entities
claiming the marks and names or their products.
Olivetti disclaims any proprietary interest in trademarks and
trade names other than its own.
the product satisfies the basic quality
Requirements.
Directive 2002/96/CE
DIRECTIVE 2002/96/CE ON THE TREATMENT, COLLECTION,
RECYCLING AND DISPOSAL OF ELECTRIC AND ELECTRONIC
DEVICES AND THEIR COMPONENTS
1. FOR COUNTRIES IN THE EUROPEAN UNION (EU)
The disposal of electric and electronic devices as solid urban waste is
strictly prohibited: it must be collected separately. The dumping of these
devices at unequipped and unauthorized places may have hazardous
effects on health and the environment.
Offenders will be subjected to the penalties and measures laid down by
the law.
The crossed dustbin symbol on the device means that:
- When it to be disposed of, the device is to be taken to
the equipped waste collection centres and is to be
handled separately from urban waste;
- Olivetti guarantees the activation of the treatment,
collection, recycling and disposal procedures in
accordance with Directive 2002/96/CE (and subsequent
amendments).
To dispose of our devices correctly:
a) Contact the Local Authorities, who will give you the practical
information you need and the instructions for handling the waste
correctly, for example: location and times of the waste collection
centres, etc.
b) When you purchase a new device of ours, give a used device similar
to the one purchased to our dealer for disposal.
2. FOR OTHER COUNTRIES (NOT IN THE EU)
The treatment, collection, recycling and disposal of electric and electronic
devices will be carried out in accordance with the laws in force in the
country in question.

I
Preface
Notice
The company reserves the right to revise this publication or to change its contents without notice. Infor-
mation contained herein is for reference only and does not constitute a commitment on the part of the
manufacturer or any subsequent vendor. They assume no responsibility or liability for any errors or inac-
curacies that may appear in this publication nor are they in anyway responsible for any loss or damage
resulting from the use (or misuse) of this publication.
This publication and any accompanying software may not, in whole or in part, be reproduced, translated,
transmitted or reduced to any machine readable form without prior consent from the vendor, manufac-
turer or creators of this publication, except for copies kept by the user for backup purposes.
Brand and product names mentioned in this publication may or may not be copyrights and/or registered
trademarks of their respective companies. They are mentioned for identification purposes only and are
not intended as an endorsement of that product or its manufacturer.
©August 2009
Trademarks
Intel and Atom are trademarks/registered trademarks of Intel Corporation.
Olivetti and Alice a re trademarks/registered trademarks of Telecom Italia S.p.A.

II
Preface
IMPORTANT SAFETY INSTRUCTIONS
Follow basic safety precautions, including those listed below, to reduce the risk of fire, electric shock, and
injury to persons when using any electrical equipment:
1. Do not use this product near water, for example near a bath tub, wash bowl, kitchen sink or laundry tub, in a wet
basement or near a swimming pool.
2. Avoid using this equipment with a telephone line (other than a cordless type) during an electrical storm. There may
be a remote risk of electrical shock from lightning.
3. Use only the power cord and batteries indicated in this manual. Do not dispose of batteries in a fire. They may
explode. Check with local codes for possible special disposal instructions.
4. This product is intended to be supplied by a Listed Power Unit (Full Range AC/DC Adapter – AC Input 100 - 240 V,
50 - 60 Hz, DC Output 19 V, 1.57A / 1.58 A).
This Computer’s Optical Device is a Laser Class 1 Product

III
Preface
Instructions for Care and Operation
The notebook computer is quite rugged, but it can be damaged. To prevent this, follow these suggestions:
1. Don’t drop it, or expose it to shock. If the computer falls, the case and the components could be damaged.
2. Keep it dry, and don’t overheat it. Keep the computer and power supply away from any kind of heating ele-
ment. This is an electrical appliance. If water or any other liquid gets into it, the computer could be badly damaged.
3. Avoid interference. Keep the computer away from high capacity transformers, electric motors, and other strong
magnetic fields. These can hinder proper performance and damage your data.
Do not expose the computer to
any shock or vibration.
Do not place it on an unstable
surface.
Do not place anything heavy on
the computer.
Do not expose it to excessive
heat or direct sunlight.
Do not leave it in a place where
foreign matter or moisture may
affect the system.
Don’t use or store the com-
puter in a humid environment.
Do not place the computer on
any surface that will block the
Vents/Fan Intakes.

IV
Preface
4. Follow the proper working procedures for the computer. Shut the computer down properly and don’t forget
to save your work. Remember to periodically save your data as data may be lost if the battery is depleted.
5. Take care when using peripheral devices.
Do not turn off the power until
you properly shut down all pro-
grams.
Do not turn off any peripheral
devices when the computer is
on.
Do not disassemble the com-
puter by yourself.
Perform routine maintenance
on your computer.
Use only approved brands of
peripherals.
Unplug the power cord before
attaching peripheral devices.

V
Preface
Power Safety
The computer has specific power requirements:
• Only use a power adapter approved for use with this computer.
• Your AC/DC adapter may be designed for international travel but it still requires a
steady, uninterrupted power supply. If you are unsure of your local power specifica-
tions, consult your service representative or local power company.
• The power adapter may have either a 2-prong or a 3-prong grounded plug. The
third prong is an important safety feature; do not defeat its purpose. If you do not
have access to a compatible outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it by the plug
head, not by its wire.
• Make sure the socket and any extension cord(s) you use can support the total cur-
rent load of all the connected devices.
• Before cleaning the computer, make sure it is disconnected from any external
power supplies (i.e. AC/DC adapter or car adapter).
Do not plug in the power cord
if you are wet.
Do not use the power cord if it
is broken.
Do not place heavy objects on
the power cord.

Power Safety
Warning
Before you undertake
any upgrade proce-
dures, make sure that
you have turned off the
power, and disconnect-
ed all peripherals and
cables (including tele-
phone lines). It is advis-
able to also remove
your battery in order to
prevent accidentally
turning the machine
on.

VI
Preface
Battery Precautions
• Only use batteries designed for this computer. The wrong battery type may explode, leak or damage the computer.
• Do not remove any batteries from the computer while it is powered on.
• Do not continue to use a battery that has been dropped, or that appears damaged (e.g. bent or twisted) in any way.
Even if the computer continues to work with a damaged battery in place, it may cause circuit damage, which may
possibly result in fire.
• Recharge the batteries using the notebook’s system. Incorrect recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or replacement to your service representative or
qualified service personnel.
• Keep children away from, and promptly dispose of a damaged battery. Always dispose of batteries carefully. Batteries
may explode or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not touch the battery contacts with your hands or metal objects.

Battery Disposal & Caution
The product that you have purchased contains a rechargeable battery. The battery is recyclable. At the end of its useful life, under
various state and local laws, it may be illegal to dispose of this battery into the municipal waste stream. Check with your local
solid waste officials for details in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent type recommended by the man-
ufacturer. Discard used battery according to the manufacturer’s instructions.

VII
Preface
Cleaning
Do not apply cleaner directly to the computer; use a soft clean cloth.
Do not use volatile (petroleum distillates) or abrasive cleaners on any part of the computer.
Servicing
Do not attempt to service the computer yourself. Doing so may violate your warranty and expose you and
the computer to electric shock. Refer all servicing to authorized service personnel. Unplug the computer
from the power supply. Then refer servicing to qualified service personnel under any of the following con-
ditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to rain or other liquids.
• If the computer does not work normally when you follow the operating instructions.
• If the computer has been dropped or damaged (do not touch the poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your computer.

Removal Warning
When removing any cover(s) and screw(s) for the purposes of device upgrade, remember to replace the cover(s) and screw(s)
before turning the computer on.

VIII
Preface
Travel Considerations
Packing
As you get ready for your trip, run through this list to make sure the system is ready to go:
1. Check that the battery pack and any spares are fully charged.
2. Power off the computer and peripherals.
3. Close the display panel and make sure it’s latched.
4. Disconnect the AC/DC adapter and cables. Stow them in the carrying bag.
5. The AC/DC adapter uses voltages from 100 to 240 volts so you won’t need a second voltage adapter. However,
check with your travel agent to see if you need any socket adapters.
6. Put the notebook in its carrying bag and secure it with the bag’s straps.
7. If you’re taking any peripherals (e.g. a printer, mouse or digital camera), pack them and those devices’ adapters and/
or cables.
8. Anticipate customs - Some jurisdictions may have import restrictions or require proof of ownership for both hard-
ware and software. Make sure your documents are prepared.

Power Off Before Traveling
Make sure that your notebook is completely powered off before putting it into a travel bag (or any such container). Putting a
notebook which is powered on in a travel bag may cause the vent(s)/fan intake(s)/outlet(s) to be blocked. To prevent your com-
puter from overheating make sure nothing blocks the vent(s)/fan intake(s)/outlet(s) while the computer is in use.

IX
Preface
On the Road
In addition to the general safety and maintenance suggestions in this preface, and Chapter 8: Trouble-
shooting, keep these points in mind:
Hand-carry the notebook - For security, don’t let it out of your sight. In some areas, computer theft is
very common. Don’t check it with normal luggage. Baggage handlers may not be sufficiently careful.
Avoid knocking the computer against hard objects.
Beware of Electromagnetic fields - Devices such as metal detectors & X-ray machines can damage the
computer, hard disk, floppy disks, and other media. They may also destroy any stored data - Pass your
computer and disks around the devices. Ask security officials to hand-inspect them (you may be asked to
turn it on). Note: Some airports also scan luggage with these devices.
Fly safely - Most airlines have regulations about the use of computers and other electronic devices in
flight. These restrictions are for your safety, follow them. If you stow the notebook in an overhead com-
partment, make sure it’s secure. Contents may shift and/or fall out when the compartment is opened.
Get power where you can - If an electrical outlet is available, use the AC/DC adapter and keep your
battery(ies) charged.
Keep it dry - If you move quickly from a cold to a warm location, water vapor can condense inside the
computer. Wait a few minutes before turning it on so that any moisture can evaporate.

X
Preface
Developing Good Work Habits
Developing good work habits is important if you need to work in front of the computer for long periods
of time. Improper work habits can result in discomfort or serious injury from repetitive strain to your
hands, wrists or other joints. The following are some tips to reduce the strain:
•Adjust the height of the chair and/or desk so that the keyboard is at or slightly below
the level of your elbow. Keep your forearms, wrists, and hands in a relaxed position.
•Your knees should be slightly higher than your hips. Place your feet flat on the floor or
on a footrest if necessary.
•Use a chair with a back and adjust it to support your lower back comfortably.
•Sit straight so that your knees, hips and elbows form approximately 90-degree angles
when you are working.
• Take periodic breaks if you are using the computer for long periods of time.

XI
Table of Contents
Contents
Notice ........................................................................ I
Instructions for Care and Operation ......................III
Power Safety ........................................................V
Battery Precautions .............................................. VI
Cleaning ............................................................. VII
Servicing ............................................................. VII
Travel Considerations ......................................... VIII
About this Quick Guide
Regulatory and Safety Information .......................1-1
Trademarks ..........................................................1-1
System Startup .......................................................1-1
System Software ..................................................1-2
System Map: Front & Rear Views ............................ 1-3
System Map: Side & Bottom Views .........................1-4
LED Indicators ........................................................1-5
Keyboard & Function Keys ...................................... 1-6
Driver Installation ...................................................1-7
Features & Components
Overview ................................................................2-1
Hard Disk Drive ......................................................2-2
7-in-1 Card Reader .................................................2-3
TouchPad and Buttons/Mouse ................................2-4
Audio Features .......................................................2-5
Power Management
Overview ................................................................3-1
Advanced Configuration and Power Interface .......3-1
The Power Sources .................................................3-2
AC/DC Adapter ....................................................3-2
Battery .................................................................3-2
Turning on the Computer .......................................3-3
Power Schemes ......................................................3-4
System Power Options ............................................3-6
Hibernate Mode vs. Shutdown .............................3-6
Stand by Mode vs. Hibernate Mode ......................3-6
Configuring the Power Button ................................3-8
Battery Information ................................................3-9
Recharging the Battery
with the AC/DC Adapter ....................................3-10
Battery FAQ ........................................................3-12
Drivers
What to Install ........................................................4-1
Module Driver Installation .....................................4-1

XII
Table of Contents
Driver Installation ...................................................4-2
Authorized Driver Message ...................................4-4
New Hardware Found ..........................................4-4
Version Conflict Message .....................................4-4
BIOS Utilities
Overview ................................................................5-1
The Power-On Self Test (POST) ...............................5-2
Failing the POST ...................................................5-3
The Setup Utility .....................................................5-4
Entering Setup .....................................................5-4
Setup Screens .......................................................5-5
Main Menu ............................................................5-6
Advanced Menu .....................................................5-8
Security Menu ......................................................5-10
Boot Menu ...........................................................5-12
Exit Menu .............................................................5-13
Upgrading The Computer
Overview ................................................................6-1
When Not to Upgrade ..........................................6-2
Removing the Battery .............................................6-3
Upgrading the HDD ................................................6-4
Upgrading the System Memory (RAM) ....................6-7
Upgrading the Processor ......................................6-10
Additional Modules
Overview ................................................................7-1
PC Camera Module ................................................7-2
Wireless LAN Module .............................................7-4
Troubleshooting
Overview ................................................................8-1
Basic Hints and Tips ................................................8-2
Backup and General Maintenance ..........................8-3
Viruses ...................................................................8-4
Upgrading and Adding New Hardware/Software ....8-5
Problems and Possible Solutions .............................8-6
Interface (Ports & Jacks)
Notebook Ports and Jacks ...................................... A-2
Intel Video Driver Controls
Intel Video Driver Installation ..................................B-1
Dynamic Video Memory Technology .......................B-1
Intel Graphics Properties .........................................B-2
Scheme Options .....................................................B-4
Display Devices & Options .......................................B-5
Attaching Other Displays ........................................B-6

XIII
Table of Contents
Specifications
Processor ............................................................... C-2
Core Logic ............................................................. C-2
Display .................................................................. C-2
Memory ................................................................ C-2
Video Adapter ....................................................... C-2
BIOS ...................................................................... C-2
Storage ................................................................. C-2
Security ................................................................. C-2
Audio .................................................................... C-2
Pointing Device ..................................................... C-2
Keyboard .............................................................. C-2
Operating System .................................................. C-3
Card Reader .......................................................... C-3
Slot ....................................................................... C-3
Dimensions & Weight ............................................ C-3

XIV
Table of Contents

Quick Start Guide
About this Quick Guide 1 - 1
I
Chapter 1: About this Quick Guide
This quick guide is a brief introduction to getting your
system started. The remainder of the present manual
covers the more advanced features and options , including
troubleshooting , upgrade and driver installation. The
drivers necessary for the proper operation of the computer
are contained in the same Device Drivers & User’s Manual
disc supplied with your computer (Note: The company
reserves the right to revise this publication or to change its
contents without notice).
The computer’s features may already have been setup . If
you are planning to re-configure (or re-install) portions of
the system, refer to the present User’s Manual. The Device
Drivers & User’s Manual disc does not contain an operating
system.
Regulatory and Safety Information
Please pay careful attention to the safety information contained
in the present User’s Manual .
© August 2009
Trademarks
Intel and Atom are trademarks/registered trademarks of Intel
Corporation.
Olivetti and Alice are trademarks/registered trademarks of
Telecom Italia S.p.A.
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Securely attach any peripherals you want to use with the
notebook (e.g. keyboard and mouse) to their ports.
4. Attach the AC/DC adapter to the DC-In jack on the left of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
5. Use one hand to carefully raise the lid/LCD to a comfortable
viewing angle, while using the other hand o support the base of
the computer (Note: Never lift the computer by the lid/LCD).
6. Press the power button to turn the computer “on”.
System Software
Your computer come with system software pre-installed. You will
find this manual refers to the Microsoft Windows XP Home with
Service Pack 3 operating system.
Figure 1-1
Computer with AC/DC
Adapter Plugged-In

1 - 2 System Map: Front & Rear Views
Quick Start Guide
I
System Map: Front & Rear Views
Figure 1-2- Front & Rear Views
1. Built-In PC Camera
2. LCD
3. Speakers
4. Power Button
5. Keyboard
6. Built-In Microphone
7. TouchPad & Buttons
8. LED Indicators
9. 7-in-1 Card Reader
10. Microphone-In Jack
11. Headphone-Out Jack
12. Battery
Front Open
7
8Front
Rear
1
2
5
4
6
3
12

Shutdown
Note that you should always
shut your computer down by
choosing the Turn Off Com-
puter command from the
Start menu in Windows.
This will help prevent hard
disk or system problems.
910 11

1 - 3 System Map: Side & Bottom Views
Quick Start Guide
I
System Map: Side & Bottom Views
Left
Right
Bottom
2345
9
6
71
4
7
7

External Optical Device
Drives
To install applications and driv-
ers etc. you will need to attach
an external optical device ( CD
or DVD ROM ) to the USB ports.
If you are having problems de-
tecting external ODDs, enable
the enhanced detection of
these devices as follows:
1. Press F2 at startup to enter
the Setup Utility and use
the arrow keys to navigate
to the Advanced menu.
2. Use the arrow keys to select
“Enhance USB ODD
detection” and set the item
to “Enabled” using the
spacebar.
3. Press F10 to save and exit (if
you want to start from the
external ODD you will need
to set it as first priority in the
Boot menu after it has been
detected).
Figure 1-3- Side & Bottom
Views
1. Security Lock Slot
2. DC-In Jack
3. RJ-45 LAN Jack
4. 2 * USB 2.0 Ports
5. External Monitor Port
6. Hard Disk Bay
7. Vent
8. Power Button
9. Battery

Overheating
To prevent your computer
from overheating make
sure nothing blocks any
vent while the computer is
in use.

1 - 4 LED Indicators
Quick Start Guide
I
LED Indicators
The LED indicators on the computer display helpful information about the current status of the computer.
Table 1-1 - LED Indicators
Icon Color Description
Orange DC Power is Plugged In
Green The Computer is On
Blinking Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange
The Battery Has Reached Critically
Low Power Status
Green Hard Disk Activity
Green The Wireless LAN Module is Powe-
red On
