Olympus MAJ-2301 User manual

INSTRUCTIONS
FOOT SWITCH
MAJ-2301
Labels and Symbols 1
Important Information — Please Read Before
Use 3
Summary of Equipment Functions 8
Chapter 1 Checking the Package Contents 9
Chapter 2 Nomenclature and Functions 11
Chapter 3 Installation and Connection 17
Chapter 4 Inspection 35
Chapter 5 Operation 43
Chapter 6 Care, Storage, and Disposal 49
Chapter 7 Troubleshooting 51
Appendix 57

Contents
i
MAJ-2301 INSTRUCTION MANUAL
Contents
Labels and Symbols .......................................................................................................... 1
Important Information — Please Read Before Use ......................................................... 3
Intended use .......................................................................................................................... 3
Instruction manual ................................................................................................................. 3
User qualifications ................................................................................................................. 3
Instrument compatibility ......................................................................................................... 4
Prohibition of improper repair and modification ..................................................................... 4
Signal words .......................................................................................................................... 4
Precautions ............................................................................................................................ 5
EMC ....................................................................................................................................... 7
Summary of Equipment Functions .................................................................................. 8
Chapter 1 Checking the Package Contents ......................................... 9
1.1 Checking the package contents .............................................................................. 9
Chapter 2 Nomenclature and Functions ............................................ 11
2.1 Symbols and descriptions ..................................................................................... 11
2.2 Foot switch ............................................................................................................. 12
2.3 Wireless unit ........................................................................................................... 14
2.4 Foot switch hanger ................................................................................................ 14
2.5 Foot switch cable ................................................................................................... 15
2.6 Pairing stickers ....................................................................................................... 15
Chapter 3 Installation and Connection ............................................... 17
3.1 Precautions for installation and connection ........................................................ 17
3.2 Installation procedure workflow ........................................................................... 18
3.3 Connection of wireless unit .................................................................................. 19
3.4 Connection of foot switch hanger ........................................................................ 22
3.5 Insertion of batteries into the foot switch ............................................................ 24
3.6 Pairing ..................................................................................................................... 29
3.7 Assign the functions of the switches ................................................................... 33
3.8 Storage of foot switch ............................................................................................ 34

ii
Contents
MAJ-2301 INSTRUCTION MANUAL
Chapter 4 Inspection ............................................................................ 35
4.1 Precautions of workflow ........................................................................................ 35
4.2 Inspection workflow ............................................................................................... 36
4.3 Inspection of remaining battery power (for wireless control) ............................ 36
4.4 Inspection of foot switch cable (for wired control) ............................................. 39
4.5 Inspection of foot switch operation ...................................................................... 41
Chapter 5 Operation ............................................................................. 43
5.1 Operating precautions ........................................................................................... 43
5.2 Wireless control of foot switch ............................................................................. 44
5.3 Wired control of foot switch .................................................................................. 46
Chapter 6 Care, Storage, and Disposal .............................................. 49
6.1 Care .......................................................................................................................... 49
6.2 Storage .................................................................................................................... 50
6.3 Disposal ................................................................................................................... 50
Chapter 7 Troubleshooting .................................................................. 51
7.1 Troubleshooting ..................................................................................................... 51
7.2 Troubleshooting guide ........................................................................................... 52
7.3 Returning this instrument for repair ..................................................................... 55
Appendix ................................................................................................. 57
Combination equipment .................................................................................................. 57
System chart ........................................................................................................................ 57
Specifications ................................................................................................................... 59
Environments ....................................................................................................................... 59
Specifications ....................................................................................................................... 59
EMC information .............................................................................................................. 61
Cautions on 2.4 GHz band radio wave equipment ........................................................ 66

Labels and Symbols
1
MAJ-2301 INSTRUCTION MANUAL
Safety-related labels and symbols are attached on the locations shown below. If labels or symbols are
missing or illegible, contact Olympus.
Foot switch
Labels and Symbols
Product plate details
Inside of battery compartment
Battery compartment
Product plate
Non-ionizing radiation marking
Rechargeable battery
inhibition indication
This marking inhibits the use
of rechargeable batteries.
Battery insertion
orientation indication
The applicable battery
type and the orientation
for inserting the batteries
are indicated.
Product plate
The product name, power rating,
non-ionizing radiation marking, and
Ingress protection rating are indicated.
Ingress protection rating
Crossed-out wheeled
bin’ symbol
CE marking
RCM marking

2
Labels and Symbols
MAJ-2301 INSTRUCTION MANUAL
Wireless unit
Back cover of this instruction manual
Symbol Description Symbol Description
Manufacturer Authorized representative in the
European Community
Product plate details
Non-ionizing radiation marking
Product plate
Wireless unit
Serial number
plate
Product plate
The product name, manufacturer name,
power rating, and non-ionizing radiation
marking are indicated.
Crossed-out wheeled
bin’ symbol
CE marking
RCM
marking

Important Information — Please Read Before Use
3
MAJ-2301 INSTRUCTION MANUAL
Intended use
This instrument has been designed to be used with Olympus Surgical Microscope for use in controlling
it.
Instruction manual
This instruction manual contains essential information on using this instrument safely and effectively.
Before use, thoroughly review this manual and the manuals for ancillary equipment and use the
equipment as instructed.
Keep this and all related instruction manuals in a safe, accessible location. If you have any questions
about any information in this manual, contact Olympus.
Terms used in this manual
User qualifications
The operator of this instrument must be a physician or medical personnel under the supervision of a
physician and must have received sufficient training in clinical procedures of microsurgery using
surgical microscope. This manual, therefore, does not explain or discuss the details of microsurgery
using surgical microscope.
For details of microsurgery using a surgical microscope, the physician and operator are requested to
judge from their viewpoints as specialists.
Important Information — Please Read Before Use
Surgical microscope (OME-V200)
The surgical microscope designated by Olympus to be used in combination with this
instrument.
Pairing
Action of giving one-to-one correspondence between the wireless unit connected to the
surgical microscope and the foot switch for holding wireless communication between
them.
View field movement
Function that moves the positioning of observation using the foot switch.

4
Important Information — Please Read Before Use
MAJ-2301 INSTRUCTION MANUAL
Instrument compatibility
This instrument should be used in combination with the ancillary equipment shown in “System chart”
on page 57. Using incompatible equipment can result in patient or operator injury and/or equipment
damage as well as malfunction.
This instrument complies with EMC standard for medical electrical equipment edition 4
(IEC 60601-1-2: 2014).
Prohibition of improper repair and modification
Never allow a person other than Olympus-qualified personnel to disassemble or modify the instrument,
as this may result in injury of the patient or operator as well as damage to the equipment. Olympus will
not assume any liability for human accident or equipment damage occurred due to repair by a person
other than Olympus-qualified personnel.
Signal words
The following signal words are used throughout this manual:
Indicates a potentially hazardous situation which, if not avoided, could result in
death or serious injury.
Indicates a potentially hazardous situation which, if not avoided, may result in minor
or moderate injury. It may also be used to alert against unsafe practices or potential
equipment damage.
Indicates additional helpful information.
WARNING
CAUTION
NOTE

Important Information — Please Read Before Use
5
MAJ-2301 INSTRUCTION MANUAL
Precautions
Follow the warnings and cautions given below when handling this instrument. This information is to be
supplemented by the warnings and cautions given in each chapter.
WARNING
• Strictly observe the following precautions. Failure to do so may place the patient
and medical personnel in danger of an electric shock.
Do not souse or spill a liquid such as water over the wireless unit. If a liquid is
spilt on it, immediately wipe it. Should a liquid penetrate the wireless unit,
immediately stop using it and contact Olympus.
Do not prepare, inspect, or use the foot switch with wet hands.
Should a liquid enter the foot switch during the battery replacement, for
example, immediately remove the batteries to prevent a fire or electric shock
hazard. Once a liquid has entered the foot switch, do not use it because the
equipment may have been damaged.
• Never install and operate the foot switch in locations where:
The concentration of oxygen is high;
Oxidizing agents (such as nitrous oxide (N2O)) are present in the atmosphere;
Flammable gases are present in the atmosphere;
Flammable liquids are near.
Otherwise, explosion or a fire may result because the foot switch is not
explosion-proof.
• Do not use for purposes other than those described in “Intended use” on page 3,
as this may result in injury of the patient or operator as well as damage to the
equipment.
• This instrument should be used under the conditions specified in “Environments”
on page 59. Otherwise, imperilment of safety or failure of equipment may result as
well as malfunction.

6
Important Information — Please Read Before Use
MAJ-2301 INSTRUCTION MANUAL
CAUTION
• Since this instrument has a wireless function, it may affect peripherals to be used at
the same time.
• Handle batteries by strictly observing the following. Incorrect use of batteries may
cause fluid leak, heat generation, which would lead to equipment damage.
Use batteries specified for this instrument.
Do not use charged or rechargeable batteries.
Insert batteries by observing the (+) and (–) polarity.
All batteries of the same brand name have to be used.
Do not use a battery with a broken coating.
Do not use a battery deformed by dropping or other impact.
Do not use a battery if any irregularity, including fluid leak, discoloration, and
deformation, is observed.
• Do not use this instrument in any place where it may be subject to strong
electromagnetic radiation (for example, in the vicinity of a microwave therapeutic
equipment, MRI, wireless set, short-wave therapeutic equipment, cellular/portable
phone, etc.). This may impair the performance of this instrument.
• Do not use this instrument in any place with strong magnetic force, or bring
magnetized equipment or magnets closer. This may impair the performance of this
instrument.
• Do not apply excessive force to a switch of this instrument or press it with a sharp
or hard object. Otherwise, the switch damage may result.
• Connect various connectors in a dry state without contamination of electrical
contacts. Also, do not touch the electrical contacts inside the connector directly. If
the electrical contacts are dirty or used under wet conditions, the equipment may
cause malfunction.
• Do not apply excessive force or strong impact to this instrument, ancillary
equipment, and cables. Otherwise, equipment damage or failure may result.
• Remove batteries when they are exhausted or not to be used for a long period. If
batteries are left inside the instrument, over-discharge may cause fluid leak, which
may eventually lead to a failure of this instrument.
• Remove dust and dirt from batteries before use. If the (+) or (–) pole is dirty or
dusty, a contact failure may result.

Important Information — Please Read Before Use
7
MAJ-2301 INSTRUCTION MANUAL
NOTE
Startup display icons are displayed on four corners of the observation monitor
screen for ten to twenty seconds after the power is turned ON on the surgical
microscope. Afterwards the icons will disappear. These icons are displayed until
the setup of the surgical microscope has completed and does not mean
malfunction.
Figure 1
EMC
• For safety, always use this instrument in combination with equipment compliant to the EMC
standard. Otherwise, interference from or to other equipment may result.
• The foot switch and wireless unit radiate RF energy to achieve their intended use (control of
the surgical microscope). This means that they could produce electromagnetic interferences
when they are placed in the proximity of equipment carrying the symbol marking below or
mobile and portable RF communications equipment such as a cellphone. If an
electromagnetic interference occurs, a relief measure such as displacement of interfered
equipment will be required.
• The foot switch and wireless unit incorporate the radio communication function as shown in
the following table. Consequently, they may be affected by electromagnetic interference from
nearby equipment that uses the same frequency band as them. Before using them, make
sure that there is no risk of electromagnetic interference from nearby equipment.
Table 1
Frequency band with potential risk of
extraneous interference
2400 – 2483.5 MHz
Modulation method Primary modulation: FSK
Secondary modulation: FHSS
Antenna power 1.0 mW

8
Summary of Equipment Functions
MAJ-2301 INSTRUCTION MANUAL
This instrument is designed to be connected to the Olympus-designated surgical microscope. By
pairing between the foot switch and wireless unit, the control signals of the surgical microscope can be
transmitted with either wireless or wired connection. The function incorporated in this instrument is
outlined below.
Note that only one foot switch can be pairing with a wireless unit.
Pairing of foot switch and wireless unit
Pairing of the foot switch and wireless unit enables wireless communication between them.
Pairing can be set using the foot switch cable provided with this instrument. Wireless control of
the functions of the surgical microscope is possible by controlling the foot switch.
Refer to Section 3.6, “Pairing”.
Wired connection of foot switch
In case the wireless signal is weak or the batteries are exhausted, the foot switch can be
connected directly to the Olympus-designated surgical microscope using the provided foot
switch cable. When the foot switch is connected through the foot switch cable, the functions of
the surgical microscope can be controlled from the foot switch even when it contains no
batteries in it.
Refer to Section 5.3, “Wired control of foot switch”.
NOTE
• The foot switch cannot control the microscope functions unless the provided
wireless unit is connected to the microscope. Be sure to connect the wireless unit
to the surgical microscope even before the wired control operation.
• Wireless communication is not performed when wired connection.
Summary of Equipment Functions

1.1 Checking the package contents
9
MAJ-2301 INSTRUCTION MANUAL
Ch.1
Chapter 1 Checking the Package
Contents
Match all items in the package, such as the foot switch, wireless unit, and accessories, with the
components shown below. Inspect each item for damage. If the instrument is damaged, a component
is missing, or you have any questions, do not use the instrument; immediately contact Olympus.
1.1 Checking the package contents
Foot switch and Wireless unit
Foot switch (MAJ-2301) Wireless unit
Accessories
Foot switch hanger Foot switch cable Pairing stickers (No.1 – No.10)
Retaining screws (M4 × 5 mm) (× 4) Retaining screws (M4 × 12 mm) (× 2) Allen screwdriver
(3 mm width across flats)

10
1.1 Checking the package contents
MAJ-2301 INSTRUCTION MANUAL
Ch.1
NOTE
This instrument does not come with batteries. Before use, prepare three “C”-size
1.5 V alkaline batteries separately.
Instruction manual (This book) EU DECLARATION OF
CONFORMITY

2.1 Symbols and descriptions
11
MAJ-2301 INSTRUCTION MANUAL
Ch.2
Chapter 2 Nomenclature and
Functions
This chapter is intended to explain the names and functions of the parts of the foot switch.
Foot switch
Wireless unit
2.1 Symbols and descriptions
Symbol Description Symbol Description
Communication status marking Battery power marking
Battery insertion orientation
indication
Rechargeable battery inhibition
indication
Foot switch1 Foot switch2
Foot switch3 Foot switch4
Foot switch5 Foot switch6
Symbol Description Symbol Description
Foot switch marking Serial number

12
2.2 Foot switch
MAJ-2301 INSTRUCTION MANUAL
Ch.2
Upper surface
NOTE
For the function assignment of the switches, refer to the instruction manual for the
surgical microscope.
2.2 Foot switch
No. Name Description
1 Handle To be held when carrying the foot switch. It can also be hooked on the foot switch
hanger when storing the foot switch.
2 Pairing indicator Indicates pairing with the combined wireless unit.
Refer to Section 3.6, “Pairing”.
3 Joystick Used to control the movement by the joystick on the foot switch of the surgical
microscope.
4 Communication status
indicator
The green LED lights when the communication status is good and flashes when it
deteriorates.
Refer to Section 5.2, “Wireless control of foot switch”.
5 Battery power indicator The amber LED lights or flashes according to the remaining battery power level.
Refer to Section 3.5, “Insertion of batteries into the foot switch”.
6 Foot switches 1 – 6 The functions of the surgical microscope can be assigned to these switches. The
function assignment is performed from the surgical microscope.
7 Foot switches A – D Used to control the focusing and zooming functions of the surgical microscope. The
functions of the four switches are assigned from the surgical microscope.
23
7 (A)
6 (6)
1
6 (4)
6 (2)
6 (5)
6 (3)
7 (B)
6 (1)
7 (C) 7 (D)
4 5

2.2 Foot switch
13
MAJ-2301 INSTRUCTION MANUAL
Ch.2
Rear and front surface
No. Name Description
1 Battery compartment
cover
Opened or closed for inserting or removing batteries.
2 Finger hook Insert your fingertip for opening the battery compartment cover.
3 Lock Used to lock or unlock the battery compartment cover.
4 Battery compartment Insert three “C”-size 1.5 V alkaline batteries.
5 Packing Prevents water penetration inside the battery compartment.
6 Ribbon To be pulled for removing batteries from the foot switch.
7 Connection terminal Connect the FOOTSWITCH connector (on the side marked “FOOTSWITCH”) of the
foot switch cable.
8 Terminal cover Lid for protecting the connection terminal.
To be opened when connecting the foot switch cable to the terminal.
1
3
4
5
6
7
View when battery
compartment cover is opened
Terminal surface
Rear surface
Close-up view
of connection
terminal
8
7
2

14
2.3 Wireless unit
MAJ-2301 INSTRUCTION MANUAL
Ch.2
2.3 Wireless unit
No. Name Description
1 Connection terminal Means of electrical connection to the surgical microscope.
2 Attaching holes Used to attach the wireless unit to the surgical microscope using the provided
retaining screws (M4 × 5 mm).
3 Pairing sticker
attaching part
Attach the pairing sticker.
2.4 Foot switch hanger
No. Name Description
1 Attaching section Used when attaching to the movement handle of the surgical microscope.
2 Attaching holes Used to attach the foot switch hanger to the surgical microscope using the provided
retaining screws (M4 × 12 mm).
3 Hook Used to hook the foot switch.
4 Cable hook Used to hook the cable when storing it.
2
1
2
3
2
1
3
4

2.5 Foot switch cable
15
MAJ-2301 INSTRUCTION MANUAL
Ch.2
2.5 Foot switch cable
No. Name Description
1FOOTSWITCH
connector
Connect this connector to the connector on the foot switch when using it with wired
connection.
2 Index Connect the cable to the terminal on the foot switch so that this marking is visible on
the top.
3FOOTSWITCH
marking
Indicates that the FOOTSWITCH connector is to be connected to the foot switch on
this side.
4 MICROSCOPE
marking
Indicates that the MICROSCOPE connector is to be connected to the surgical
microscope on this side.
5 Index Connect the cable to the footswitch terminal on the surgical microscope so that this
marking is visible on the top.
6 MICROSCOPE
connector
Connect this connector to the foot switch terminal on the surgical microscope.
7 Lock Used for removing from a foot switch or surgical microscope.
2.6 Pairing stickers
No. Name Description
1 Pairing stickers
No.1 – No.10
Attach the sticker matching the pairing indication on the paired foot switch onto the
wireless unit.
Refer to Section 3.6, “Pairing”.
123 4 65
7
1

16
2.6 Pairing stickers
MAJ-2301 INSTRUCTION MANUAL
Ch.2
