OM SYSTEM OM-1 User manual

QUICK START GUIDE

OM-1 Quick Guide 2
1. Overview 3
Preface
2. Super Control Panel 6
3. Modes 8
4. Custom Modes 10
5. Autofocus 12
Frontside, Backside Pg. 3
Top View, Side View Right, Side View Left Pg. 4
PASM Pg. 8
B Pg. 9
C1, C2 Pg. 10
C3, C4 Pg. 11
This Quick Guide provides an quick introductory overview of the OM-1. For detail information and instruction
on using your OM SYSTEM equippment, please see the repective user maunuals, which can be found on the
support pages of OM SYSTEM Website. To accompany your adventures in photography OM SYSTEM has
created several access points with a great mix of technical, community and educational content - all for free.
https://shop.olympus.eu/ - Olympus (Europe)
https://learnandsupport.getolympus.com/ - Learning Center (US)
https://www.youtube.com/c/OMSystemGlobal

OM-1 Quick Guide 3
Overview
Front Side
Back Side
Hot shoe
ON/OFF lever (AF/metering mode)
button & (Sequential
shooting/self-timer/
ash) button
(AF/metering mode)
button & (Sequential
shooting/self-timer/
ash) button
External ash terminal
Lens release button
Mode dial
Mode dial
Rear dial
ISO / f(Rating) button
AF-ON button
AEL / 0(Protect) button
Multi selector
Arrow pad / OK button
INFO button
D(Erase) button
q(Playback) button
Shutter button
Self-timer lamp/AF illuminator
(One-touch white balance)
button
(Preview) button
Front dial
Hot Shoe
Diopter adjustment dial
MENU button
Live view button
Viewnder
Eye sensor
Fn lever
Touch screen
monitor
Mode dial lock
Loud Speaker
Battery Charge Lamp

OM-1 Quick Guide 4
Top Side
Left Side Right Side
(AF/metering mode) button
(Sequential shooting
/self-timer/ash) button
External ash terminal
Stereo microphone
ON/OFF lever
Hot shoe Mode dial
Mode dial lock
Microphone jack
(3.5 mm stereo
minijack for third-party
microphones)
UHS-II Card slot
Remote cable terminal
UHS-II Card slot
Headphone jack
(3.5 mm stereo
minijack for third-party
headphones)
HDMI connector
(Type D)
USB connector
(Type C)
Shutter button
Shutter button
R(Movie)/ h(High Res
Shot)/H(selection) button
Front dial
ISO / f(Rating) button
Rear dial

OM-1 Quick Guide 5
Portability
Weathersealed
Portability is essential for all adventurers, who take all efforts to get the image. The OM-1 offers, together with
the M.Zuiko lenses, an unrivaled portability, as it produces the highest image quality in a small and light-
weight body. Compared to 35mm camera the equivalent lenses are much smaller and lighter. This gives you
the possibility of agile handheld shooting even with long tele lenses and allows photographers to take advan-
tage of the mobility of the system
Carrying lighter gear gives you more energy. More shooting exibility. More ways to express yourself. You’re
free to shoot longer so you can nail the best shot and enjoy your photography more.
When you call nature your
home and you are shooting
in the wild it is essential that
your camera can withstand
all natural forces. The
OM-1 is sealed with cast
rings to ensure an IP53
dustproof and splashproof
performance to give you the
condence that you can take
your photos in the roughest
conditions.
600mm equiv.600mm equiv.
IP53
OM SYSTEM OM-1 + M.Zuiko Digital ED 300mm F4.0 IS PRO

OM-1 Quick Guide 6
Interface
p
YF
1023 1:02:03
±
S-IS Auto
±
0.3
Natural
0.0
5.6250P
Small
S-AF
4 : 3
1/ Auto
ISO
YF
60p L
-
8
Off
#
x
G
3
0+
-
200
5400K CWB
0
Battery level
Name of the
currently
selected
option
Shooting mode
Shutter speed
AF Target
AF mode
Drive mode
Storage options
Picture mode
Exposure
compensation
Aperture value
Wi-Fi/Bluetooth
Button function assignment
Manual ash output
Image stabilizer
Image quality,
Available recording
time
ISO sensitivity
White balance
Face &
Eye Detection
Slot 1: Image quality, number of
storable still pictures. Slot 2: Image quality, number of
storable still pictures.
Metering mode
Exposure
compensation value
Color temperature
Flash mode
Aspect ratio
Super Control Panel Photo
All shooting options can be accessed via the Super Control Panel (SCP). It enables a quick and comfortable
way to get an overview of all settings and an easy way to adjust them. You activate the SCP as an overlay by
pressing the OK button. If you shoot with the viewnder, you can display the SCP by pressing the Live View
Button. That allows you to take control over all your camera settings. The touchscreen makes the operation
easy, quick, and comfortable.

OM-1 Quick Guide 7
INTRERFACE
Super Control Panel Video
1:42:22
5400K
Natural
0.0
5.6 800250
n
CWB
Mid
C-AF M-IS 1
1/ FP
Auto
ISO
60p L
-
8
Off
G
3
0
01240-dB
R
+
-
P
±0
8
L
by OM SYSTEM Ambassador Chris Eyer-Walker
by OM SYSTEM Ambassador Michaela Skovranova
nmode
Sound
Recording
Level
Headphone Volume
Recording level meter
Image quality,
Available recording
time
Viewnder Interface Navigation
200200
ISO
Auto
ISO
Auto
WB Auto WB Auto
1
1
[1:02:03][1:02:03]
10231023
PP
100
%
100
%
0.00.0
00
+
-
1 /
250
1 /
F
250
5.65.6
F
Battery level
Shooting mode
Shutter speed
Aperture value
Exposure
compensation
Exposure
compensation value
ISO sensitivity
White balance
Available recording time
Number of storable
still pictures

OM-1 Quick Guide 8
Modes
PASM
The mode dial is the main control of
your camera and denes in which
shooting mode you are working. Here
you can decide how your camera
should work and support your
shooting style. Decide whether you
would like to work in fully automatic
mode or completely manual.
P Mode
S Mode
Use the P mode when you would like
to let the camera decide on aperture
and exposure time. However, you
have always the option to overrule
the settings.
Use S mode when you would like to
control the shutter speed in case you
are shooting fast moving object. You
don’t have to worry about the aperture
as the camera is choosing the one tting
to your shutter speed.
by OM SYSTEM Ambassador Chris Eyer-Walker
by OM SYSTEM Ambassador Ben Knoot

OM-1 Quick Guide 9
Modes
M Mode
B Mode
For total control choose the M Mode.
In this mode you select shutter speed
and aperture as you want. The OM-1
shows in the viewnder and / or monitor
how the exposure of the nal image will
look like, that you are able to control the
result before you take the image.
The B Mode gives a quick and easy
access to the “Live Modes“:The camera
shows you how the images develops
and you can stop exposure as soon as
it is well exposed.
“Live Composite” only adds com-
posites of the sections with changes in
brightness.
“Live Bulb” keeps the shutter open
while the shutter release button is
pressed.
“Live Time” opens the shutter on the
rst push and closes it on the second
push of the shutter release button.
by OM SYSTEM Ambassador Hannu Huhtamo

OM-1 Quick Guide 10
Modes
C1 // Birds in Flight
C2 // Pro Capture
Taking images from birds in ight is
quite challenging. This mode allows
you to revisit the necessary settings on
the spot, that you never miss a shot in
future.
Pro Capture starts shooting the
moment you press the shutter release
button down halfway, with a buffer that
can be set to capture up to 70 frames
in full resolution. This way you get the
exact moment you want to capture
without any lag.
Shooting mode S
Image Quality Mode LSF + RAW
AF Mode C-AF + TR
AF Target ALL
AF Area Pointer On2
Drive Mode SH2 with 25 fps
Frame Rate EVF High
Grid Settings Three-way split composition
Grid color White
Shooting mode P
Image Quality Mode LSF + RAW
AF Mode S-AF
AF Target Cross
AF Area Pointer On1
Drive Mode ProCapSH1 35 pre frames / 120 fps
Frame Rate EVF High
Grid Settings Flexible
Grid Color White
Mode C1-C4 are memory slots which give you quick and easy access to your individual settings.
They can be customized to your needs.
Custom Modes
by OM SYSTEM Ambassador Ben Knoot
by OM SYSTEM Ambassador Ben Knoot
