Omcon Omc-935ipbmega User manual

Page 1 of 87

OMC-900IP

OMC-900IP BMEGA(F)-(WP)

BMEGA(F)-(WP)

BMEGA(F)-(WP) Series

Series

Indoor

Indoor H.264

H.264

H.264 Megapixel

Megapixel

IP Box

Box

Box Camera

Camera

User

User Manual

Manual

For

For following

following

following models:

models:

OMC-935IPBMEGA

OMC-935IPBMEGA :

: Indoor

Indoor

Indoor IP

IP Box

Box

Box Camera

Camera

Camera ,

, two

two

two way

way

way audio

audio

OMC-935IPBMEGAF

OMC-935IPBMEGAF :

: Indoor

Indoor

Indoor IP

IP Box

Box

Box Camera

Camera

Camera ,two

,two

,two way

way

way audio,with

audio,with

audio,with SD

SD card

card

OMC-935IPBMEGA-P

OMC-935IPBMEGA-P :

: Indoor

Indoor

Indoor PoE

PoE

PoE IP

IP Box

Box

Box Camera

Camera

Camera ,

, two

two

two way

way

way audio

audio

OMC-935IPBMEGAF-W

OMC-935IPBMEGAF-W :

: In

In door

door

door Wifi

Wifi

Wifi IP

IP camera,

camera,

camera, two

two

two way

way

way audio,

audio,

audio, with

with

with SD

SD card

card

Page 2 of 87

Contents

Copyright Declaration .............................................................................................................. 5

Omcon Software License Agreement .................................................................................... 5

1 Before you this product ..........................................................................................................6

2 Package Content ...................................................................................................................7

3 Physical characteristic ........................................................................................................... 7

4 Installation ................................................................................................................................8

4.1 Hardware Installation ................................................................................................... 8

4.1.1 Connect the Ethernet ........................................................................................8

4.1.2 Connect the power ........................................................................................... 8

4.1.3 connect the external device ............................................................................8

4.1.4 Connect PoE IP Camera through Power Over Ethernet (PoE) ..................... 8

4.2 Software Installation ..................................................................................................... 9

4.2.1 Using Web Browsers ............................................................................................9

4.2.2 CMS Installation ................................................................................................ 16

4.3 IP Surveillance System Connection .......................................................................... 20

5 IP camera configuration ......................................................................................................21

5.1 video and audio settings (General, OSD display, Audio Setting) ........................ 22

5.1.1 Video setting .....................................................................................................22

Advanced image setting skill ...................................................................................23

5.1.2 Image setting ....................................................................................................25

5.1.3 Video Flip and Mirror ........................................................................................26

5.1.4 Audio setting .....................................................................................................26

5.2 OSD/MASK setting ...................................................................................................... 26

5.3 network settings (General, DHCP,PPPoE,DDNS, FTP, E-mail, Wifi, 3G) .................. 27

5.3.1 General setting .................................................................................................27

5.3.2 PPPOE ................................................................................................................ 29

5.3.3 DDNS .................................................................................................................. 29

5.3.4 E-Mail Setting .....................................................................................................30

5.3.5 FTP setting ..........................................................................................................30

5.3.5 WIFI setting (Only for WIFI IP Camera models) ..............................................31

5.3.6 3G setting (Only for 3G IP Camera models) ................................................. 33

5.4 PTZ setting .................................................................................................................... 36

5.5 System (version, time configuration, system update, user) ................................... 37

5.5.1 Firmware upgrade, restore, reboot ................................................................37

5.5.2 Time setting ....................................................................................................... 38

5.5.3 Device information ...........................................................................................39

5.5.4 user management ........................................................................................... 40

5.6 Alarm (sensor alarm, motion detection) ..................................................................41

5.6.1 sensor alarm ......................................................................................................41

5.6.2 motion detection ............................................................................................. 43

5.7 SD Card Record ..........................................................................................................45

Page 3 of 87

5.7.1 Format SD card .................................................................................................45

5.7.2 Schedule record on SD card .......................................................................... 45

5.7.3 Schedule snapshot on SD card ...................................................................... 46

5.7.4 Overwrite setting .............................................................................................. 47

5.7.4 Play the record file of SD card ........................................................................48

5.7.5 Download the record files or snapshots of SD card .....................................49

5.8 Manual Record over IE .............................................................................................. 50

5.8.1 Local record file path ...................................................................................... 50

5.8.2 Play Local record file ....................................................................................... 50

6 How to use Management software? ................................................................................. 52

6.1 System login and logout ............................................................................................ 52

6.1.1 System Login ..................................................................................................... 52

6.1.2 Log out system ..................................................................................................52

6.1.3 Minimize system ................................................................................................ 52

6.2 System setting ............................................................................................................. 53

6.2.1 Server management (Add IP camera) ......................................................... 53

6.2.2 User management ........................................................................................... 56

6.3 IP Camera live view ....................................................................................................58

6.3.1 Log in and log off IP camera .......................................................................... 58

6.3.2 Live view IP camera .........................................................................................58

6.3.3 Auto log in IP camera and Auto Connect IP camera ................................ 59

6.4 Remote setup IP Camera ..........................................................................................60

6.5 Multi-view IP camera and control ............................................................................ 60

6.5.1 Loop switch ....................................................................................................... 60

6.5.2 Sound play control and two way audio ....................................................... 62

6.5.3 PTZ control ......................................................................................................... 63

6.6 Snapshot ...................................................................................................................... 64

6.6.1 How to Snapshot .............................................................................................. 64

6.6.2 Search snapshot ...............................................................................................64

6.7 Record ......................................................................................................................... 65

6.7.1 General setting (Record path, overwrite, record package) ......................65

6.7.2 Time Schedule record over Management Software ................................... 66

6.7.3 Manual record ..................................................................................................67

6.7.4 Alarm record .....................................................................................................68

6.8 Playback ......................................................................................................................69

6.9 Alarm management .................................................................................................. 71

6.9.1 Sound Alarm ..................................................................................................... 71

6.9.2 Pop up alarm message ................................................................................... 72

6.9.3 Pop up camera video ..................................................................................... 73

6.9.4 Electronic Map alarm ...................................................................................... 74

6.9.5 Email notification ........................................................................................... 78

6.9.6 History event ......................................................................................................81

6.10 Toolbar ....................................................................................................................... 83

6.10.1 Bottom Toolbar ............................................................................................... 83

Page 4 of 87

6.10.2 PTZ Control Toolbar ........................................................................................ 85

6.10.3 Alarm Control Toolbar ....................................................................................85

7 Appendix ............................................................................................................................... 85

7.1 FAQ ...............................................................................................................................85

7.2 factors influencing system capability .......................................................................87

Page 5 of 87

Declaration

This manual is provided by Omcon Technology Co., Ltd (hereinafter referred to as

‘ Omcon ’ ) as the support file for the Omcon Network Video Server, IP camera, etc.

Both the software and this manual are copyrighted and protected by the laws of the

People's R epublic of China.

reproduced or transmitted in any form or by any means, electronic or mechanical,

without prior written permission from Omcon. By using this manual, you agree to the

following

Software License Agreement

Omcon reserves the right to revise this manual without prior note. Please contact

Omcon for the latest version of this manual.

Omcon has made every effort to ensure the accuracy of this manual but does not

guarantee the absence of errors. Moreover, Omcon assumes no responsibility in

obtaining permission and authorization of any third party patent, copyright or product

involved in relation to the use of this manual.

Note: Windows, Windows NT, Windows 2000, Windows XP and etc. mentioned in this

book are registered trademarks of Microsoft Corporation.

Omcon

Omcon Software

Software

Software License

License

License Agreement

Agreement

1. Omcon Technology Co., Ltd (hereinafter referred to as ‘ Omcon ’ ) owns the

(hereinafter referred to as ‘ this product ’ ). No organization, enterprise, agency or

individual may use th is product without our authorization.

2. We authorize those who achieve the following two requirements to use this

product for free:

A. Using this product with hardware products purchased from Omcon through

a legitimate marketing channel;

B. Promising not to transmit the whole or part of this product to any third party

without prior permission from Omcon.

3. Any organization, enterprise, agency or individual, except as otherwise subject to

the second article of this license agreement, must obtain the written permission

from Omcon before using this product.

4. The authorized organizations, enterprises or individuals have no right to transfer the

authorization.

5. The use of this product indicates that you have fully understood and accepted all

terms in this license.

Page 6 of 87

1Before

Before

Before you

you

you this

this

this product

product

Safety Notes

All the safety and operation instructions should be read before the unit is used.

Location

Ensure the unit is ventilated to protect from overheating.

Ensure there is a 3cm gap between on both side of the unit

This unit is stored in low humidity and dust free area. Avoid places like damp

basements or dusty hallways

Ensure the unit is not located where it ’ s likely to be subject to mechanical shock

Servicing

Do not attempt to service this unit yourself as opening or removing the covers may

expose you to dangerous voltage or other hazards

Ventilation

Ensure the unit is ventilated to protect from overheating as detailed above.

Warning: To prevent fire or shock hazard, do not expose this unit to rain or moisture.

The lighting flash with arrowhead symbol within an equilateral triangle is indented to

alert the user of this unit there are dangerous voltages within the enclosure tha t may

be of sufficient magnitude to constitute a risk of electric shock.

Lightning Strike

The unit has some in-built protection for lightning strike, however it is recommended

that isolation transformers be fitted to the system in areas where lightening is a

common occurrence.

Page 7 of 87

2 Package

Package

Package Content

Content

3 Physical

Physical

Physical characteristic

characteristic

Ethernet

Ethernet : The IP camera connects to the LAN or WAN by a standard RJ45 connector.

IP camera can auto detect the speed of local network segment ( 10Base-T/100Base-TX

Ethernet)

Power

Power : DC 12V input. The LED indicator will light up after IP Camera has successfully

completed the boot process.

A out

out

out : audio out

connect the speaker

A in

in : audio line in, connect the sound amplifier.

SD Card

Card

Card : Insert SD card into slot for local storage. Do not support hot swap the SD card.

R eset

eset

eset : Reset the system or restore the factory settings including the network settings

RS485

RS485 : connect pan tilt unit.

GND

GND : ground pin.

ALM

ALM in

in : connect the IR sensor, smoke sensor or other type sensors.

ALM

ALM Out

Out

Out : connect the alarm speaker or alarm lamp.

Antenna

Antenna : OMC-900IPBMEGA-W Series Wireless IP cameras only

Indoor IP Box camera

Software

Compact Disk



User Manual



Tool (DIVX)



CMS

Accessory

12V DC Power adaptor

Antenna (for OMC-900IPBMEGA-W)

Page 8 of 87

4 Installation

Installation

4. 1

1 Hardware

Hardware

Hardware Installation

Installation

4.1.1

4.1.1 Connect

Connect

Connect the

the

the Ethernet

Ethernet

Depending on the user ’ s application, an Ethernet cable is necessary. The Ethernet

cable should meet the specs of UTP Category 5 and not exceed 100 meters in length.

Make sure the Ethernet is firmly connected to a switch hub. The network status LED is

ste ady orange.

4.1.2

4.1.2 Connect

Connect

Connect the

the

the power

power

Plug in the power adapter.

4.1.3

4.1.3 connect

connect

connect the

the

the external

external

external device

device

4.1.3.1

4.1.3.1 connect

connect

connect alarm

alarm

alarm (optional)

(optional)

Pink, pink /white: alarm output

Purple/ white: alarm input

Black: ground

4.1.3.

4.1.3. 2

2 Connect

Connect

Connect Audio

Audio

Aout: Connect sound amplifier to A-in Interface, connect speaker in A-out interface

4.1.3.

4.1.3. 3

3 SD

SD Card

Card

Card (optional)

(optional)

Insert SD card into SD card slot when power off. Don ’ t support hot swap the SD card.

4.1.4

4.1.4 Connect

Connect

Connect PoE

PoE

PoE IP

IP Camera

Camera

Camera through

through

through Power

Power

Power Over

Over

Over Ethernet

Ethernet

Ethernet (PoE)

(PoE)

When

When using

using

using a

a PoE-enable

PoE-enable

PoE-enable switch

switch

The PoE IP camera allows it to be powered by a single Ethernet cable. If your

switch/router supports PoE, refer to the following instructions to connect the Ip camera

to a PoE-enabled switch/router.

Note:

Note: OMCON PoE IP camera use the higher consumption PoE module which can

transmit up to 100Meters which is better than normal PoE module which only transmits

30-60Meters. Please use the midspan PoE switch with 48V output. Network signal is on

the data pairs ’ pins 1,2,3 &6. Power is on data pairs ’ pins 4,5,7 &8. 4,5 for 48V+, 7,8 for

Page 9 of 87

48V-.

When

When using

using

using a

a PoE-

PoE-

PoE- dis

dis

dis able

able

able switch

switch

If you switch/router does not support PoE, use a PoE injector to connect between the

IP camera and non-PoE switch/router.

Make sure the power is off before you do the following steps:

Step1: Insert the Power

Power

Power adaptor(48V

adaptor(48V

adaptor(48V 1A)

1A)

1A) of PoE IP Camera to the “ Power

Power

Power in

in ”

”

”of the

‘ PoE Injector ”

Step2: Connect the “ PoE

PoE

PoE Out

Out

Out ” of the “ PoE Injector ” to the “ PoE

PoE

PoE IP

IP Camera

Camera

Camera ”

Step3: Connect the Yellow

Yellow

Yellow network

network

network cable

cable

cable from “ PoE Injector ” to the “ Router

Router

Router ”

Step4: Then power on the Power

Power

Power Adaptor(48V

Adaptor(48V

Adaptor(48V 1A)

1A)

1A) of

of Poe

Poe

Poe IP

IP Camera

Camera

4.2

4.2 Software

Software

Software Installation

Installation

Our IP camera provides access through Internet Explorer or Management Software.

You need to set up the network settings and the IP address for the IP device. Please

make sure all connections are properly connected, then follow the procedures below.

4.2.1

4.2.1 Using

Using

Using Web

Web

Web Browsers

Browsers

1 Setup

Setup

Setup your

your

your PC

PC network

network

The IP address for your PC must be within the same subnet as the IP camera. You need

to match the TCP/IP Settings between PC and IP Camera before you can access it

The

The Power

Power

Power adaptor

adaptor

adaptor of

of Poe

Poe

IP camera:

camera:

POE

Injector

Page 10 of 87

through IE.

2 Setup

Setup

Setup IP

IP Camera

Camera

Camera ’

’

’ s

s IP

IP address

address

The IP camera ’ s IP address can be assigned manually or acquired automatically by

network service (DHCP). If it acquired the IP address by using the DHCP service, please

use the management software bundled in the CD to find the IP address for all IP

came ras. The factory default setting is assigned manually IP address.

3 Setup

Setup

Setup your

your

your PC

PC network

network

To set up the network of IP camera via a PC, you have to change the TCP/IP settings

of the PC.

The following are the default network settings of IP camera.

IP address:192.168.188.188

Subnet mask:255.255.255.0

To access the IP camera, the IP address of the PC should match the address below.

IP address:192.168.188.XXX

Subnet mask:255.255.255.0

Note:

Note: XXX should be a number from 1 to 254 except 188, which is used by the IP

camera. Please also make sure that no two devices use the same IP address in the

same network.

The procedures below are the setup procedure on Windows XP.

Step 1: Start up your PC

Step 2:Click the “ Start ” and select the “ Control panel ”

Page 11 of 87

Step 3:Double click the “ Network and Internet connections ” icon.

Step 4:Double click the “ Network connection ” icon

Page 12 of 87

Step 5:Click “ Local Area Connections ”

then click “ Change settings of this

connection ” in the network task menu.

Step 6: Click “ Internet Protocol (TCP/IP ) ”

and click the click the “ Properties ” button. If

you have both IPv4 and IPv6, choose IPv4.

Page 13 of 87

Step 7: Click the “ Use the following IP address ” radio button and enter the IP address

and the subnet mask.

Step 8: Click the “ Ok ” button and window dialog box closes.

4 Configure

Configure

Configure the

the

the IP

IP camera

camera

This section describes how to configure the IP camera. The administrator has unlimited

access to all settings.

Following the procedures below to configure the IP camera.

Step 1: Open your web browser (Microsoft Internet Explorer). Check your Internet

Explorer version is 6.0 or above version. If not, please update your IE to the higher

version.

Step 2: Enter the IP address of Ip camera in the address field. Press Enter.

To access the IP camera, the IP

address of the PC should match the

address below.

IP address : 192.168.188.XXX

Subnet mask : 255.255.255.0

Note:

Note: XXX should be a number from 1

to 254 except 188, which is used by

the IP camera. Please also make sure

that no two devices use the same IP

address in the same network.

Page 14 of 87

The default IP address is 192.168.188.188.

Step 3: The login page is now displayed as below

Step 4: Click 『Install 』to install the OCX.

If it does not pop up the OCX install dialog, Click 『File 』to download the OCX.

Then, i t will pop up a new dialog, click 『Run 』or 『Save 』to download OCX .

After download it , double-click the downloaded file “ DVSClientx.exe ” to install

it.

Step 5: Refresh your web browser

Step 6: Enter the IP address.

It will ask for the password and user name.

Enter user name: admin （default setting for administrator ）and password ：

admin （default setting for administrator ）

Step 7: Click the “ Enter ” button to login or click the “ cancel ” button to close the login

Page 15 of 87

page.

Once you log in successfully

the “ video display page ” will be shown.

Skill

Skill :

Test network connection between IP camera and PC successfully or not.

In WINDOWS, click<Start → run → cmd ，you can see the DOS window and input

“ 192.168.188.188 ” . That proves IP camera or NVS is working if the mention is same to

above picture.

4.2.1.1

4.2.1.1 Live

Live

Live view

view

view over

over

over IE

In the Liveview interface, User can do the operations as snapshot, record, talk,

pan tilt zoom control.

Click to start manual record, and re-click to stop manual record.

Click to capture and save still images.

Click to talk to people around the IP camera. Audio will project from the

external speaker connected to the IP camera. Click this button again to end talking

transmission.

Click to turn on/off the volume on the local computer.

Click to control PTZ . Turn up, down, left, right, automatic, call preset, set

preset point.

Page 16 of 87

4.2.1.2

4.2.1.2 Live

Live

Live view

view

view setting

setting

『Live Stream 』Live stream can set to Stream 01 mode or Stream 02 mode.

OMC-900IP Series IP Camera support dual streaming for live view, local storage and

network transmission. As the dual stream setting, you can refer 5.1.1 Video setting

4.2.2

4.2.2 CMS

CMS

CMS Installation

Installation

4.2.2.1

4.2.2.1 PC

PC requirements

requirements

Basic Configuration of Client PC

Motherboard: Pentium IIII 2.8GHz

Memory: 512M

Display Card: TNT2

Recommended Configuration of Client PC

Motherboard: Dual-core 2.6GMhz

Memory: 1G

Display Card: George FX5200 or ATI 7000(9000) Series 256MB

4.2.2

4.2.2 CMS

CMS

CMS Installation

Installation

Run setup on windows, double click your left mouse button, it will be an “ installation

wizard ” dialogue box, as following figure:

Page 17 of 87

Click “ next ”

there will be a dialogue box:

Click “ Yes ”

there will be a dialogue box:

Page 18 of 87

Input user name and company name (optional), click “ Next ”

there will be a dialogue

box:

Choose installation folder, click “ next ”

there will be a dialogue box:

Page 19 of 87

Click “ Next ”

move to the installation process

When the installation is finished, there will be a dialogue box

Click

Click “

“

“ continue

continue

continue ”

”

” and

and

and finish the installation

CMS is installed into the system default directory and there will be a “ CMS ” program

group on the “ Start ” ” Program ” of the windows system

Page 20 of 87

4.2.

4.2. 3

3 How

How

How to

to obtain

obtain

obtain IP

IP address?

address?

After install the CMS, click 『Start

』『

Program

』『

Search 』

Pops up the following figure

Click “ search ”

you can know the IP address of all IP cameras which connected in the

network. Make sure each IP camera has one individual IP address.

4. 3

3 IP

IP Surveillance

Surveillance

Surveillance System

System

System Connection

Connection

Setting

Setting up

up the

the

the IP

IP camera

camera

camera over

over

over the

the

the Internet

Internet

This section explains how to setup the IP camera to an Internet connection.

1 If you have external devices such as sensors, sound pick-up, speaker, Pan tilt unit,

make the connection.

2 Connect the IP camera to a switch by Ethernet cable

3 Connect the power cable from IP camera to a power outlet.

There are several ways to set up the IP camera over the Internet. The first way is to set

up the IP camera behind a router. The second way is to use PPPoE.

Internet

Internet connection

connection

connection by

by a

a router

router

Before setting up the IP camera over the internet, make sure you have a router and

follow the steps below.

1 Connect your IP Camera behind a router, the internet environment is illustrated

below. Regarding how to obtain your IP address, please refer 4.2.3

This manual suits for next models
