Omegalink OL-AL(MDB)-GM1 User manual

NOTICE: The manufacturer will accept no responsibility for any electrical damage resulting from
improper installation of this product, be that either damage to the vehicle itself or to the installed
device. This device must be installed by a certified technician. This guide has been written for
properly trained technicians; a certain level of skill & knowledge is therefore assumed. Please
reviewtheInstallation Guide carefullybefore beginning any work.
!
Omega R&D Inc.
INSTALL GUIDE
OL-AL(MDB)-GM1
AvAiLABLe fOR: OL-MDB-ALL
GM1
The brand names and logos found in this guide are property of their respective owners. Omega R&D Inc. © 2011
Rev. Date: October 04, 2011
Doc. No.: ##6621##
20111004
Alarms & Remote Start

INSTALL TYPE SELECTION
XX-XX PAGE X-X ADS-AL(DL)-GM1 1-2 PAGE 2-3
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS ARM OEM ALARM DISARM OEM ALARM DOOR LOCK DOOR UNLOCK PRIORITY UNLOCK TRUNK/HATCH RELEASE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) RAP SHUTDOWN CTRL REAR DEFROST CTRL* HEATED SEATS CTRL* TACHOMETER OUTPUT** DOOR STAT OUTPUT FRONT (L) DOOR STAT OUTPUT FRONT (R) DOOR STAT OUTPUT REAR (L) DOOR STAT OUTPUT REAR (R) TRUNK STAT OUTPUT
BUICK
Allure 05-09 3 •†•••••• •
Century 00-05 1 • • • • • •
LaCrosse 05-09 3 •†•••••• •
LeSabre / Ultra 00-05 3 • • • • • • • • • • • • • • • •
Park Avenue 97-05 3 • • • • • • • • • • • • • • • •
Rainier 04-07 3 • • • • • • • • • • • • •
Regal 00-04 1 • • • • • •
Rendez-vous 02-07 1 • • • • • •
Terraza 05-07 3 •†••••• ••• ••• •
CADILLAC
CTS 03-073••••••• • •••••
Deville 00-05 3 • • • • • • • • • • • • • •
Escallade 99-02 1 • •
Escallade 03-06 3 • • • • • • • • • • • • • •
Escallade EXT 03-06 3 • • • • • • • • • • • •
Seville 98-03 3 • • • • • • • • • • • • • •
SLS 98-99 2 • • • • • • • • • • • • • •
SLS 00-04 3 • • • • • • • • • • • • • •
SRX 04-06 3 • • • • • • • • • • • •
STS 98-99 2 • • • • • • • • • • • • • •
STS 00-04 3 • • • • • • • • • • • • • •
CHEVROLET
Astro 98-05 1 • •
Avalanche 02 1 •
Avalanche 03-06 3 • • • • • • • • • • • •
Blazer 98-05 1 • •
Cavalier 00-05 1 • • • • • • •
Express 03-07 1 • • • • • •
Express 98-02 1 • •
Impala 00-05 1 • • • • • • •
Monte Carlo 00-05 1 • • • • • • •
S10 / S15 98-04 1 • •
Silverado 99-02 1 •
Silverado 03-06 3 • • • • • • • • • • • •
SSR 04-06 3 • • • • • • • • • •
Suburban 99-02 1 • •
Suburban 03-06 3 • • • • • • • • • • • • • •
Tahoe 99-02 1 • •
Tahoe 03-06 3 • • • • • • • • • • • • • •
Trailblazer 02-09 3 • • • • • • • • • § • • •
Uplander 05-09 3 •†••••• ••• ••• •
Venture 00-04 1 • •
* See heated accessories notice.
** Tach output is not available on vehicles with
a duramax engine.
† The PK3 indicator will remain ON during
the remote start sequence and will only
turn OFF upon takeover.
§ Tach output is not available on these ve-
hicles if they are equipped with
a V8 engine.
Page 2 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
Doc. No.: ##6621##

INSTALL TYPE SELECTION
XX-XX PAGE X-X ADS-AL(DL)-GM1 2-2
PAGE 3-3
MAKE MODEL YEAR INSTALL TYPE
FEATURES
DATA IMMOBILIZER BYPASS ARM OEM ALARM DISARM OEM ALARM DOOR LOCK DOOR UNLOCK PRIORITY UNLOCK TRUNK/HATCH RELEASE POWER SLIDING DOOR (L) POWER SLIDING DOOR (R) RAP SHUTDOWN CTRL REAR DEFROST CTRL* HEATED SEATS CTRL* TACHOMETER OUTPUT** DOOR STAT OUTPUT FRONT (L) DOOR STAT OUTPUT FRONT (R) DOOR STAT OUTPUT REAR (L) DOOR STAT OUTPUT REAR (R) TRUNK STAT OUTPUT
HUMMER
H2 03-07 3 • • • • • • • • • • • • •
GMC
Envoy 98-01 1 • §
Envoy 02-09 3 • • • • • • • • • § • • •
Jimmy 98-05 1 • •
Safari 98-05 1 • •
Savana 98-02 1 • •
Savana 03-07 1 • • • • • •
Sierra / CK 98-02 1 • •
Sierra / CK 03-06 3 • • • • • • • • • • • •
Sonoma 98-04 1 • •
Yukon / Denali 99-02 1 • •
Yukon / Denali 03-06 3 • • • • • • • • • • • • • •
ISUZU
Ascender 03-08 3 • • • • • • • • • • • • •
Hombre 98-00 1 • •
OLDSMOBILE
Alero 4cyl 99-01 1 •
Alero 4cyl 02-04 1 • • • • •
Alero 6cyl 99-04 1 • • • • • •
Aurora 00-03 3 • • • • • • • • • • • • • • • •
Bravada 98-01 1 • •
Bravada 02-04 3 • • • • • • • • • • • • •
Intrigue 98-99 1 • •
Intrigue 00-02 1 • • • • • •
Silhouette 00-04 1 • •
PONTIAC
Aztek 01-05 1 • • • • • •
Bonneville 00-05 3 • • • • • • • • • • • • • • • •
Grand Am 4cyl 99-02 1 •
Grand Am 4cyl 02-05 1 • • • • •
Grand Am 6cyl 99-05 1 • • • • • •
Grand Prix 04-08 3 •†•••••• • •••••
Montana 00-04 1 • •
Montana SV6 05-09 3 •†••••• ••• •• •
Sunfi re 00-05 1 • • • • • • •
SAAB
97x 06-09 3 • • • • • • • • • • • • •
SATURN
Relay 05-07 3 • • • • • • • • • • • • •
* See heated accessories notice.
** Tach output is not available on vehicles with
a duramax engine.
† The PK3 indicator will remain ON during
the remote start sequence and will only
turn OFF upon takeover.
§ Tach output is not available on these ve-
hicles if they are equipped with
a V8 engine.
Page 3 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
Doc. No.: ##6621##

XX-XX PAGE X-X
NOTICE
ADS-AL(DL)-GM1 PAGE X-X
HEATED ACCESSORIES NOTICE
2To activate applicable heated
accessories upon remote
start regardless of engine
temperature, connect [purple/
black] wire to ground.
MOVE THE FOLLOWING ITEMS IN YOUR
SCHEMATIC WITH ALL LAYERS ON
USE THE FOLLOWING LAYER SPECIFIC ITEMS AS
WIRING AND TEXT TEMPLATES
GREEN/BLACK
BLUE/BLACK
RED/WHITE
BROWN
PURPLE/YELLOW
ENABLE - PURPLE/BLACK
WHITE
BLACK/WHITE
GREEN
PURPLE/WHITE
BLUE/WHITE
WHITE
BLACK
RED
VERT/NOIR
BLEU/NOIR
ROUGE/BLANC
BRUN
MAUVE/JAUNE
ACTIVER - MAUVE/NOIR
BLANC
NOIR/BLANC
VERT
MAUVE/BLANC
BLEU/BLANC
BLANC
NOIR
ROUGE
BLACK
BLUE/RED
BLUE/YELLOW
GREEN/RED - ENABLE
GRAY/RED (NC)
GRAY/YELLOW
ORANGE
ORANGE/WHITE
ORANGE/BLACK
BROWN/YELLOW
BROWN/RED
YELLOW
PINK/BLACK
PINK
WHITE/BLACK
WHITE/RED
WHITE
BLANC/NOIR
BLANC/ROUGE
BLANC
JAUNE
BRUN/ROUGE
BRUN/JAUNE
ORANGE/NOIR
ORANGE/BLANC
ORANGE
ROSE/NOIR
ROSE
BLEU/ROUGE
BLEU/JAUNE
VERT/ROUGE - ACTIVER
GRIS/ROUGE
GRIS/JAUNE
NOIR
1To disable this feature, connect
[purple/yellow] wire to ground.
NOTE
IView compatibility chart for applicable vehicles.
II In all supported vehicle, heated accessories will automatically
be activated 15 seconds after the remote starter is engaged
and this only if the engine temperature is below 0 C (32 F).
MOVE THE FOLLOWING ITEMS IN YOUR
SCHEMATIC WITH ALL LAYERS ON
USE THE FOLLOWING LAYER SPECIFIC ITEMS AS
WIRING AND TEXT TEMPLATES
GREEN/BLACK
BLUE/BLACK
RED/WHITE
BROWN
DISABLE - PURPLE/YELLOW
PURPLE/BLACK
WHITE
BLACK/WHITE
GREEN
PURPLE/WHITE
BLUE/WHITE
WHITE
BLACK
RED
VERT/NOIR
BLEU/NOIR
ROUGE/BLANC
BRUN
DESACTIVER - MAUVE/JAUNE
MAUVE/NOIR
BLANC
NOIR/BLANC
VERT
MAUVE/BLANC
BLEU/BLANC
BLANC
NOIR
ROUGE
BLACK
BLUE/RED
BLUE/YELLOW
GREEN/RED
GRAY/RED - DISABLE
GRAY/YELLOW
ORANGE
ORANGE/WHITE
ORANGE/BLACK
BROWN/YELLOW
BROWN/RED
YELLOW
PINK/BLACK
PINK
WHITE/BLACK
WHITE/RED
WHITE
BLANC/NOIR
BLANC/ROUGE
BLANC
JAUNE
BRUN/ROUGE
BRUN/JAUNE
ORANGE/NOIR
ORANGE/BLANC
ORANGE
ROSE/NOIR
ROSE
BLEU/ROUGE
BLEU/JAUNE
VERT/ROUGE
GRIS/ROUGE - DESACTIVER
GRIS/JAUNE
NOIR
Page 4 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
Doc. No.: ##6621##

TYPE 1 - WIRING DIAGRAM
Page 5 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
10 11 12 13 14 15 16
12345678
9
2
N/A
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
DATA
PINK/BLACK (NC)PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED (NC)
GRAY/RED (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
AUTO-RELOCK (-) INPUT - BROWN
AUTO-RELOCK (-) INPUT - BROWN
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) OUTPUTLEFT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
(NC) GREEN
(NC) GREEN
*TACH (AC) OUTPUT - PURPLE/WHITE
*TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
WHITE/BLACK (NC)
WHITE/BLACK (NC)
WHITE/RED (NC)
WHITE/RED (NC)
WHITE (NC)
WHITE (NC)
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
REMOTE STARTER
OBDII CONNECTOR LOCATED
UNDER DRIVER SIDE DASH
Doc. No.: ##6621##

TYPE 2 - WIRING DIAGRAM
Page 6 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
10 11 12 13 14 15 16
12345678
9
2
PK3
N/A
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
DATA
PINK/BLACK (NC)PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED (NC)
GRAY/RED (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
DISARM ONLY (-) INPUT - BROWN
DISARM ONLY (-) INPUT - BROWN
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
(NC) GREEN
(NC) GREEN
*TACH (AC) OUTPUT - PURPLE/WHITE
*TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
DISARM ONLY (-) OUTPUT
DISARM ONLY (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
YELLOW/BLACK (-)
PINK - IGNITION (+) INPUTPINK - IGNITION (+) INPUT
WHITE/BLACK - GROUND (-)
WHITE/BLACK - GROUND (-)
WHITE/RED (NC)
WHITE/RED (NC)
WHITE - STARTER ENABLE (-) OUTPUT
WHITE - STARTER ENABLE (-) OUTPUT
PASS KEY III THEFT
DETERRENT : MODULE,
BEHIND DRIVER SIDE DASH,
RIGHT OF STEERING COLUMN
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
REMOTE STARTER
OBDII CONNECTOR LOCATED
UNDER DRIVER SIDE DASH
Doc. No.: ##6621##

TYPE 3 - WIRING DIAGRAM
Page 7 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
10 11 12 13 14 15 16
12345678
9
2
N/A
REQUIRED ->
OPTIONAL ->
OPTIONAL ->
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
YELLOW/BLACK - DOOR STATUS (-) OUTPUT*
GWR (-) INPUT - BLUE/WHITE
GWR (-) INPUT - BLUE/WHITE
BROWN/RED (NC)
BROWN/RED (NC)
BLUE/RED (NC)
BLUE/RED (NC)
LOCK/ARM (-) INPUT - GREEN/BLACK
LOCK/ARM (-) INPUT - GREEN/BLACK
IGNITION (+) OUTPUT
IGNITION (+) OUTPUT
TRUNK STATUS (-) INPUT
TRUNK STATUS (-) INPUT
DOOR STATUS (-) INPUT
DOOR STATUS (-) INPUT
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW/RED - TRUNK STATUS (-) OUTPUT*
YELLOW (NC)
YELLOW (NC)
BROWN/YELLOW (NC)
BROWN/YELLOW (NC)
ORANGE/BLACK (NC)
ORANGE/BLACK (NC)
ORANGE/WHITE (NC)
ORANGE/WHITE (NC)
ORANGE - DATA (J1850)
ORANGE - DATA (J1850)
DATA
PINK/BLACK (NC)PINK/BLACK (NC)
BLUE/YELLOW (NC)
BLUE/YELLOW (NC)
GREEN/RED (NC)
GREEN/RED (NC)
GREEN/YELLOW (NC)
GREEN/YELLOW (NC)
GRAY/RED (NC)
GRAY/RED (NC)
GRAY/YELLOW (NC)
GRAY/YELLOW (NC)
(NC) WHITE
(NC) WHITE
GROUND - BLACK
GROUND - BLACK
12V (+) - RED
12V (+) - RED
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
UNLOCK/DISARM (-) INPUT - BLUE/BLACK
TRUNK (-) INPUT - RED/WHITE
TRUNK (-) INPUT - RED/WHITE
DISARM ONLY (-) INPUT - BROWN
DISARM ONLY (-) INPUT - BROWN
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) INPUT - PURPLE/YELLOW
LEFT SLIDING DOOR (-) OUTPUT
LEFT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) INPUT - PURPLE/BLACK
RIGHT SLIDING DOOR (-) OUTPUT
RIGHT SLIDING DOOR (-) OUTPUT
(NC) WHITE
(NC) WHITE
(NC) BLACK/WHITE
(NC) BLACK/WHITE
(NC) GREEN
(NC) GREEN
*TACH (AC) OUTPUT - PURPLE/WHITE
*TACH (AC) OUTPUT - PURPLE/WHITE
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
<- REQUIRED
LOCK (-) OUTPUT
LOCK (-) OUTPUT
UNLOCK (-) OUTPUT
UNLOCK (-) OUTPUT
TACH (AC) INPUT
TACH (AC) INPUT
TRUNK (-) OUTPUT
TRUNK (-) OUTPUT
DISARM ONLY (-) OUTPUT
DISARM ONLY (-) OUTPUT
12V (+)
12V (+)
GROUND (-)
GROUND (-)
GROUND WHEN RUNNING (-) OUTPUT
GROUND WHEN RUNNING (-) OUTPUT
PINK - IGNITION (+) INPUT
PINK - IGNITION (+) INPUT
OBDII CONNECTOR LOCATED
UNDER DRIVER SIDE DASH
WHITE/BLACK (NC)
WHITE/BLACK (NC)
WHITE/RED (NC)
WHITE/RED (NC)
WHITE (NC)
WHITE (NC)
NOT REQUIRED IN DATA MODE (1-WAY)
NOT REQUIRED IN DATA MODE (2-WAY)
LEGEND
USE DATA MODE
OR HARDWIRE MODE
DATA MODE
DATA MODE
REMOTE STARTER
Doc. No.: ##6621##

XX-XX PAGE X-X ADS-AL(DL)-GM1 PAGE X-X
MODULE PROGRAMMING PROCEDURE
5Module Programming
Procedure completed.
4Turn key to OFF position.
OFF
1Insert key into ignition.
2Turn key to START position.
START
3Wait, LED will turn solid GREEN
for 2 seconds.
ADS-AL(DL)-GM1 81 ADS-DL(TB)-PL 81 ADS-DL-GM1 81 ADS-DLSL-GM1 81
INSTALLATION MODE SELECTION
1Press and release
programming button
to select installation mode. 2Press and hold
programming button
until LED turns solid GREEN
to register selection.
!After registration, follow Factory Reset Procedure to
change installation mode and restart this procedure.
LED fl ashes (1X) once = DATA MODE
LED fl ashes (2X) twice = STANDARD HARDWIRE MODE
Page 8 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
Doc. No.: ##6621##

XX-XX PAGE X-X CLASSIC PAGE 1-1
LED STATUS
DIAGNOSTICS
DURING PROGRAMMING DURING REMOTE START WITH IGNITION OFF
Flashing RED Missing/wrong information from
fi rmware or vehicle Incorrectly programmed Incorrectly programmed or connected
Solid RED Waiting for more vehicle information Incorrectly programmed Not programmed waiting for more
vehicle information
Flashing GREEN Additional steps required to complete
programming
Correctly programmed and
operational
False ground when running status
from remote starter
Solid GREEN then OFF Correctly programmed Reset in progress Reset in progress
OFF No activity or already programmed Invalid ground when running status
from remote starter
At rest and ready for a remote start
sequence
MODULE DIAGNOSTICS
FACTORY RESET PROCEDURE
7Repeat programming procedure.
!Failure to follow procedure may result with a DTC or a
CHECK ENGINE error message.
1DISCONNECT all connectors
from module EXCEPT the black
4-PIN standard or optional data
connector.





6RECONNECT all connectors.


 
2DISCONNECT black 4-PIN
standard or optional data
connector.

4When LED fl ashes red,
RELEASE programming button.
5LED will turn solid red for 2
seconds.
RESET COMPLETED.
3PRESS AND HOLD programming
button while connecting either
4-PIN standard or optional data
connector.
IDENTIFY VEHICLE YEAR
1Locate the Vehicle Identifi cation
Number (VIN) and identify the
10th character. 2Match the VIN’s 10th character
to its corresponding year.
L > 1990 S > 1995 Y > 2000 5 > 2005 A > 2010
M > 1991 T > 1996 1 > 2001 6 > 2006 B > 2011
N > 1992 V > 1997 2 > 2002 7 > 2007 C > 2012
P > 1993 W > 1998 3 > 2003 8 > 2008 D > 2013
R > 1994 X > 1999 4 > 2004 9 > 2009 E > 2014
4 Y 1 N53 A 5 T A L 8 D 5 R 0 X

XX-XX PAGE X-X
NOTICE
This product is protected by one or more of the following patents: U.S. LETTERS PATENT NO. 5,719,551; 6,011,460; 6,243,004; 6,249,216; 6,275,147; 6,297,731; 6,346,876; 6,392,534; 6,529,124; 6,696,927; 6,756,885; 6,756,886; 6,771,167; 6,812,829; 6,924,750;
7,010,402; 7,031,826; 7,046,126; 7,061,137; 7,068,153; 7,015,830; 7,205,679; 7,224,083; 7,369,936; 7,378,945; 7,489,233; 7,501,937; CANADIAN PATENT NO. 2,320,248; 2,415,023; 2,426,670; 2,414,991; 2,415,011; 2,415,027; 2,415,038; 2,415,041; 2,502,893; 2,451,490;
2,452,296; 2,451,487; EUROPEAN PATENT NO. 1,053,128; DE 69807-941T2; U.S. 20020145535; 20060129282; 20060129284; 20040017284; 20080030316; 20090079552; EP1500565; 1538038; 1538037;
PATENT PAGE X-X
Page 9 of 9 OL-AL(MDB)-GM1 20111004
INSTALL GUIDE
Omega Research & Development Inc. © 2011
ALL IN ONE
General Motors
Doc. No.: ##6621##
