ON Semiconductor SECO-NCV7685RGB-GEVB User manual

©Semiconductor Components Industries, LLC, 2020
May, 2020 −Rev. 1
1Publication Order Number:
EVBUM2713/D
SECO-NCV7685RGB-GEVB
NCV7685 RGB Lighting
Evaluation Board User's
Manuals
Description
SECO−NCV7685RGB−GEVB is an evaluation board for RGB
LEDs lighting application with BLE in automotive which driven by
NCV7685 and controlled by RSL10. It is also an interior or exterior
lighting reference design for tail or ambient lights to realize general
sequential or high end pixelated LEDs controlling in−vehicle network.
The user can set RGB LED’s color and intensity by mobile APP to
show customized information or animation.
In general, the user prefers to use fixed address in multiple
NCV7685 applications. It leads to additional procedure to
pre−program each chips’ address in mass production stage. In
addition, it is inconvenient for maintenance in the aftermarket. In
firmware of this evaluation board, it uses floating address setting
method, each time when power on the board, NCV7685 will be
assigned an address which is defined by user, but it’s not locked into
OTP registers. The user can realize this function by using either
RSL10’s GPIO or IO expender (PAC9655).
In firmware, the driver APIs are divided into four levels: Peripheral,
Chip, Board and customer application. User can directly include the
chips and board APIs in their own project, and modify the application
APIs according to their applications. This will accelerate developing
period to market.
The board conceived for use as a plug and play environment to
testing.
Nominal supply voltage is 12 V (Supply voltage range 12−24 V). In
switch mode, four fixed animations shown; the RGB LEDs’ color and
intensity setting by user mobile APP in BLE mode.
Features
•Plug and Play; Switch and BLE Mode to Show Animations
•16 RGB LEDs (48 Channels), each Current Programmable Sources
up to 60 mA
•Independent PWM Duty Cycle Control for each Channel
•On−Chip 150, 300, 600 and 1200 Hz PWM
•Logarithmic or linear independent PWM dimming
•Diagnostic and Protection against Open Load and Under−Voltage,
Over Temperature…
•Dynamic Addressing Method for No−Worries in mass production
•Bluetooth®5 Certified with LE 2M PHY Support
•Rx Sensitivity (Bluetooth Low Energy Mode, 1 Mbps): −94 dBm
•Transmitting Power: −17 to +6 dBm
•Arm Cortex−M3 Processor and LPDSP32
•AEC−Q100 Qualified and PPAP Capable
EVAL BOARD USER’S MANUAL
www.onsemi.com

SECO−NCV7685RGB−GEVB
www.onsemi.com
2
Architecture and Key Parts
Figure 1. Board Architecture
KEY PARTS
Chip Part Description
NCV7685 12 Channels 60 mA LED Linear Current Driver I2C Controllable for Automotive
RSL10 SIP System−in−Package, Bluetooth 5 Certified
PCA9655 Remote 16−bit I/O Expander for I2C Bus with Interrupt
NCV8170 Ultra‐Low IQ 150 mA CMOS LDO Regulator
NCV891330 3 A, 2 MHz Low−IQ Dual−Mode Step−Down Regulator for Automotive

SECO−NCV7685RGB−GEVB
www.onsemi.com
3
Figure 2. Top and Bottom Layer and Key Components
Operations of NCV7685 RGB LEDs Board
After power on, the board shows the “Welcome”
animation, then according to the setting of the switch, the
board shows four kinds of fixed animations or turns into
BLE mode. The functions and operations descripted as
below figures:
Figure 3. Sequence after Power On

SECO−NCV7685RGB−GEVB
www.onsemi.com
4
Switch Setting:
Figure 4. Status Indicator Mode
Status Indicator Mode:
Keep all Switches off; the board comes into status
indicator mode. Green means good, orange means warning
and red means error. The color of LEDs changes in gradient
from green to orange, then to red; and goes back from red to
green. This can be used as the status indicator for dashboard.
Switch Setting:
Figure 5. Second Clock Mode
Second Clock
Keep Switch S1 on and S2, S3, S4 off, every second, only
one LED in blue lights up clockwise direction in turn.
Switch Setting:
Figure 6. Flash Mode
Flash Mode
Keep Switch S2 on and S1, S3, S4 off, all LEDs flash in
red.
Switch Setting:
Figure 7. Fading Mode
Fading Mode
Keep Switch S1, S2 on and S3, S4 off, all LEDs fade in
green.
Switch Setting:
Figure 8. BLE Mode
Figure 9. Standby interface in BLE Mode

SECO−NCV7685RGB−GEVB
www.onsemi.com
5
BLE Mode
Keep Switch S4 on and never mind of the setting of S2, S3,
S4, the board turns into BLE mode. User can use general
mobile App to control LED’s color and intensity for
individual or all LEDs. For example, using “Light Blue” in
iOS®; “BLE Scanner” or “nRF Connect” in Android®OS.
It shows a green “smile face” firstly, and then changes the
color and intensity according to the received five bytes data
through BLE. The first three bytes stand for R, G, B values
to mix the color, and the fourth data stands for intensity (4
level brightness For V1). The fifth byte stands for LED
number, if this value is greater than 0x0f, all LEDs response.
Here are several examples:
Examples: (R, G, B, I, LED_No)
(Four level of Intensity, Depends on Firmware)
800080FF00: LED0 in Purple
FF00003F01: LED1 in Red
XXXXXX0010: All LEDs turn off as the he intensity is 0
(Never mind RGB’s values)
00BFFFFF10: All LEDs in deep sky blue
Here is an example using “Light Blue” App to control
RGB lighting board:
1. Find and choose Peripheral of “NCV7685 RGB
Kit”
2. Tap “Send RGB Setting” character
3. Set RGB and Intensity values
4. The board change color, intensity and LED_No
Figure 10. Using ‘Light Blue’ App to Control the Board

SECO−NCV7685RGB−GEVB
www.onsemi.com
6
Firmware Setting
Generally, floating address method is used in firmware;
the configurations can changed in the “ncv7685.h” file. Here
are options:
1. Floating Address method using SOC GPIO:
#define NCV7675_CHIPS_NUM 0x04 /* Chips number */
#define PCA9655_Address 0x22 /* PCA9655 I2C address */
#define BY_SOC 0 /* SOC or PCA9655 */
#define BY_PCA9655 1
#define ADDRESS_SETTING BY_SOC
#define Fix_Address 0
#define Address_Had_Set 0
2. Floating Address method using PCA9655:
#define NCV7675_CHIPS_NUM 0x04 /* Chips number */
#define PCA9655_Address 0x22 /* PCA9655 I2C address */
#define BY_SOC 0 /* SOC or PCA9655 */
#define BY_PCA9655 1
#define ADDRESS_SETTING BY_PCA9655
#define Fix_Address 0
#define Address_Had_Set 0
3. Fix Address method using PCA9655 or SOC GPIO:
#define NCV7675_CHIPS_NUM 0x04 /* Chips number */
#define PCA9655_Address 0x22 /* PCA9655 I2C address */
#define BY_SOC 0
#define BY_PCA9655 1
#define ADDRESS_SETTING BY_PCA9655 /* SOC or PCA9655 */
#define Fix_Address 1
#define Address_Had_Set 0
4. For the board which address had programmed, just set “Address_Had_Set” to 1, So it will skip address setting
function:
#define NCV7675_CHIPS_NUM 0x04 /* Chips number */
#define PCA9655_Address 0x22 /* PCA9655 I2C address */
#define BY_SOC 0
#define BY_PCA9655 1
#define ADDRESS_SETTING BY_PCA9655 /* SOC or PCA9655 */
#define Fix_Address 1
#define Address_Had_Set 1
Files Structure of Project
Figure 11. Files Structure of Project
·app_basc.c: Battery level indication handler
·app_bass.c: Battery Service code
·app_config.c: Application configuration source file
·app_customss.c: Bluetooth custom service
·app_msg_handler.c: Customer defined functions and data
·app_trace.c: Trace functions
·ncv7685.c: APIs of NCV7685 Chip and Board
·app.c: main function

SECO−NCV7685RGB−GEVB
www.onsemi.com
7
Flow Chart of App.c
Figure 12. Flow chart of App.c

SECO−NCV7685RGB−GEVB
www.onsemi.com
8
Schematic
Figure 13. Schematic of Board

SECO−NCV7685RGB−GEVB
www.onsemi.com
9
Assembly
Figure 14. Bottom Side Assembly

SECO−NCV7685RGB−GEVB
www.onsemi.com
10
Table 1. BILL OF MATERIALS
Item Designator Manufacturer Comment Description Quantity
1C1, C4, C5, C8, C9,
C10, C11, C12, C13,
C14, C15
−10 V, 100 nF WCAP−CSGP Ceramic
Capacitors, 0603
11
2 C2 −25 V, 10 mFWCAP−CSGP Ceramic
Capacitors, 1206
1
3 C3 −25 V, 4.7 mFWCAP−CSGP Ceramic
Capacitors, 1206
1
4 C6 −10 V, 10 mFWCAP−CSGP Ceramic
Capacitors, 1206
1
5 C7 −10 V, 100 nF WCAP−CSGP Ceramic
Capacitors, 1206
1
6 D1 ON Semiconductor BAS16H Schottky Barrier Diode, 1
7D3, D4 ON Semiconductor NTS560 Trench Schottky Rectifier,
Low Forward Voltage, 60 V,
5 A
2
8 J1 −694106106102 DC Power Jack Connector,
5 A, 24 V
1
9 J5 −1.27mm_SMD_Vertical_10 pin Pin Header WR−PHD,
pitch 1.27 mm,
1
10 L1 −2.2 mH, 4.7 A SMT Shielded Power
Inductor
1
11 LED11, LED12,
LED13, LED14,
LED21, LED22,
LED23, LED24,
LED31, LED32,
LED33, LED34,
LED41, LED42,
LED43, LED44
−LRTB GVSG −16
12 R1, R4, R5, R12,
R13, R14, R18, R20,
R21
−10 kW(1002) ±1% Chip Resistor 9
13 R2, R3 −0 W(0R0) ±1% ’Chip Resistor 2
14 R6, R7, R8, R9, R23,
R24
−68 W(68R0) ±1% ’Chip Resistor 6
15 R10 −2.7 kW(2701) ±1% ’Chip Resistor 1
16 R11 −10 W(10R0) ±1% ’Chip Resistor 1
17 R15, R22 −100 kW(1003) ±1% ’Chip Resistor 2
18 R16, R17 −1.5 kW(1501) ±1% ’Chip Resistor 2
19 R25, R26, R27, R28 −2 kW(2001) ±1% ’Chip Resistor 4
20 SW1 −434133025816 4.2x3.2 mm J−Bend SMD
Tact Switch
1
21 SW2 −416131160804 SMD Dip Switch 1
22 U1 ON Semiconductor NCV891330PD38R2G −1
23 U2 ON Semiconductor PCA9655EMTTXG −1
24 U3, U4, U5, U6 ON Semiconductor NCV7685G −4
25 U7 ON Semiconductor RSL10−SIP −1
25 U8 ON Semiconductor NCV8170BMX330TCG −1
Android is a registered trademark of Google LLC.
Bluetooth is a registered trademark of Bluetooth SIG.
iOS is a trademark or registered trademark of Cisco in the U.S. and other countries and is used under license by Apple Inc.

www.onsemi.com
1
ON Semiconductor and the ON Semiconductor logo are trademarks of Semiconductor Components Industries, LLC dba ON Semiconductor or its subsidiaries in the United States and/or
other countries. ON Semiconductor owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A listing of ON Semiconductor’s
product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent−Marking.pdf. ON Semiconductor is an Equal Opportunity/Affirmative Action Employer. This literature is
subject to all applicable copyright laws and is not for resale in any manner.
The evaluation board/kit (research and development board/kit) (hereinafter the “board”) is not a finished product and is as such not available for sale to consumers. The board is only intended
for research, development, demonstration and evaluation purposes and should as such only be used in laboratory/development areas by persons with an engineering/technical training
and familiar with the risks associated with handling electrical/mechanical components, systems and subsystems. This person assumes full responsibility/liability for proper and safe handling.
Any other use, resale or redistribution for any other purpose is strictly prohibited.
The board is delivered “AS IS” and without warranty of any kind including, but not limited to, that the board is production−worthy, that the functions contained in the board will meet your
requirements, or that the operation of the board will be uninterrupted or error free. ON Semiconductor expressly disclaims all warranties, express, implied or otherwise, including without
limitation, warranties of fitness for a particular purpose and non−infringement of intellectual property rights.
ON Semiconductor reserves the right to make changes without further notice to any board.
You are responsible for determining whether the board will be suitable for your intended use or application or will achieve your intended results. Prior to using or distributing any systems
that have been evaluated, designed or tested using the board, you agree to test and validate your design to confirm the functionality for your application. Any technical, applications or design
information or advice, quality characterization, reliability data or other services provided by ON Semiconductor shall not constitute any representation or warranty by ON Semiconductor,
and no additional obligations or liabilities shall arise from ON Semiconductor having provided such information or services.
The boards are not designed, intended, or authorized for use in life support systems, or any FDA Class 3 medical devices or medical devices with a similar or equivalent classification in
a foreign jurisdiction, or any devices intended for implantation in the human body. Should you purchase or use the board for any such unintended or unauthorized application, you shall
indemnify and hold ON Semiconductor and its officers, employees, subsidiaries, affiliates, and distributors harmless against all claims, costs, damages, and expenses, and reasonable
attorney fees arising out of, directly or indirectly, any claim of personal injury or death associated with such unintended or unauthorized use, even if such claim alleges that ON Semiconductor
was negligent regarding the design or manufacture of the board.
This evaluation board/kit does not fall within the scope of the European Union directives regarding electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC,
CE or UL, and may not meet the technical requirements of these or other related directives.
FCC WARNING – This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation purposes only and is not considered by ON Semiconductor to
be a finished end product fit for general consumer use. It may generate, use, or radiate radio frequency energy and has not been tested for compliance with the limits of computing devices
pursuant to part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this equipment may cause interference with radio
communications, in which case the user shall be responsible, at its expense, to take whatever measures may be required to correct this interference.
ON Semiconductor does not convey any license under its patent rights nor the rights of others.
LIMITATIONS OF LIABILITY: ON Semiconductor shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of
requalification, delay, loss of profits or goodwill, arising out of or in connection with the board, even if ON Semiconductor is advised of the possibility of such damages. In no event shall
ON Semiconductor’s aggregate liability from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
For more information and documentation, please visit www.onsemi.com.
PUBLICATION ORDERING INFORMATION
TECHNICAL SUPPORT
North American Technical Support:
Voice Mail: 1 800−282−9855 Toll Free USA/Canada
Phone: [phone]
LITERATURE FULFILLMENT:
Email Requests to: [email protected]
ON Semiconductor Website: www.onsemi.com
Europe, Middle East and Africa Technical Support:
Phone: [phone]
For additional information, please contact your local Sales Representative
◊
