ON Semiconductor NB3N5573DTGEVB User manual

©Semiconductor Components Industries, LLC, 2012
February, 2012 −Rev. 1
1Publication Order Number:
EVBUM2065/D
NB3N5573DTGEVB
NB3N5573DTGEVB
Evaluation Board User's
Manual
Device Name: NB3N5573DTG (TSSOP−16)
Board Name: NB35573DTGEVB
Description
The NB3N5573 is a high precision, low phase noise clock
generator that supports PCI Express and Ethernet
requirements. The device takes a 25 MHz fundamental
mode parallel resonant crystal and generates differential
HCSL output at 25 MHz, 100 MHz, 125 MHz or 200 MHz
clock frequencies.
See datasheet NB3N5573/D (www.onsemi.com).The
NB3N5573DTGEVB Evaluation board is designed to
provide a flexible and convenient platform to quickly
program, evaluate and verify the performance and operation
of the NB3N5573DTG TSSOP−16 (Package Case 948F)
device under test: With the device removed, this
NB3N5573DTGEVB Evaluation board is designed to
accept a 16 Lead TSSOP Socket (M&M Specialties, Inc.,
1−800−892−8760, www.mmspec.com, M&M
#50−000−00809) to permit use as an insertion test fixture.
Board Features
•Crystal mount source, or input external clock source
(SMA)
•A TSSOP−16 NB3N5573DTG device is solder
mounted or the board may be adapted for insertion
testing by adding a TSSOP−16 socket.
•Separate supply connectors for VDD (banana jack and
Anvil Clip) and GND (banana jack)
Contents
Description
Board Features
Board Layout Maps
Test and Measurement Setup Procedures
Appendix 1: Pin to Board Connection Information
Appendix 2: Schematic
Appendix 3: Bill of Materials, Lamination Stackup
FRONT BACK
Figure 1. NB3N5573DTGEVB Evaluation Board
http://onsemi.com
EVAL BOARD USER’S MANUAL

NB3N5573DTGEVB
http://onsemi.com
2
BOARD LAYOUT
X1/CLK
X2
PIN8
OE
CLK
GND Jack Connector
VDD ANVIL Connector
CLK
VDD Jack Connector
CLK1
CLK1
SEL0
SEL1
PIN3
Figure 2. FRONT Board Layout
Figure 3. FRONT Layer Design

NB3N5573DTGEVB
http://onsemi.com
3
GND Jack Connector
VDD Jack Connector
Crystal
SEL0
PIN8
SEL1
X1/CLK
X2
OE
PIN3
CLK
CLK
CLK1
CLK1
Figure 4. BACK Board Layout
Figure 5. BACK Layer Design

NB3N5573DTGEVB
http://onsemi.com
4
TEST AND MEASUREMENT SET−UP AND PROCEDURE
Step 1: Equipment
1. Signal Generator: Agilent #33250A or HP8133 (or
equivalent)
2. Tektronix TDS8000 Oscilloscope
3. Power Supply: Agilent #6624A or AG6626A DC
(or equivalent)
4. Digital Voltmeter: Agilent 34410A or 34401 (or
equivalent)
5. Matched Cables (> 20 GHz, SMA connectors):
Storm or Semflex (or equivalent)
6. Time Transition Convertor: Agilent 14534 250 ps
(or equivalent)
7. Phase noise Analyzer: Agilent E5052B (or
equivalent)
Step 2: Lab Set−Up Procedure
1. Test Supply Setup:
Board and Device Power Supply Connections are
shown in Table 1. VDD (Banana Jack or Anvil
Clip test point) and GND (Banana Jack) and may
be connected by.
Table 1. POWER SUPPLY CONNECTIONS
Device Board Banana Jack
Anvil Clip
Test Point Comments
VDD VDD BJ1 J11
GND GND BJ2 J7 DUTGND and SMA GND
SUPPLY (VDD = 3.3 V; GND = 0.0 V’ VEE = 0.0 V)
Single supply operation may be accomplished by
connecting VDD and GND. HCSL CLK, CLKb, CLK1, and
CLK1b outputs are directly connected to a LOW impedance
(50 W) module, scope, or probe per Figure 6. Both lines in
an HCSL pair must be terminated.
Figure 6. Typical Termination for Output Driver and Device Evaluation
2. Inputs: (see Appendix 1, Device Pin to Board
Connection Information)
For a Single Ended input to X1/CLK operation, install a
zero ohm jumper resistor at R14. Do not install R16. Do not
drive X2. Use a LVCMOS Clock amplitude signal at 25
MHz which satisfies datasheet VIH and VIL to drive
X1/CLK. Input tr/tf transition edges should be about 250 ps.
Use a TTC (Time transition Convertor) such as Agilent
14534 (250 ps) or equivalent, if needed to slow faster edges.
Termination of a signal generator may be accomplished by
placing a 50 Wresistor (to GND) at location C42. The
mounted crystal does not need to be removed for Single
Ended input operation.
For Crystal operation use a fundamental Parallel
Resonant crystal (see Datasheet section on “Recommended
Crystal Parameters”) of 25 MHz. The board is supplied with
a thru–hole 25 MHz crystal installed, but alternatively has
the tabs for a surface mount crystal. The Crystal mount is

NB3N5573DTGEVB
http://onsemi.com
5
located on the back (underside) of the board and is
permanently connected to the device inputs by traces.
Crystal load caps should be mounted from each crystal pin
to GND (16 74−20 pF) to fine tune frequency.
Device frequency is selected by LVTTL/LVCMOS level
inputs SEL0 and SEL1 per datasheet Table 2. Jumpers J12
(SEL0), J13 (SEL1) may be set to either VDD (HI) or GND
(LO), or floated open (HI) to program the output frequency
of operation. Jumpers may be removed to drive SEL0/1b
directly with spec VIH or VIL levels. Note SEL0/1 inputs
will default to VDD when left floating open. High
Impedance probes must be used to sense the
LVTTL/LVCMOS input signal levels. Load cap may be
added to fine tune frequency such as 15 pF to GND on both
crystal pins.
Output current reference pin, IREF (Pin9) has a precision
475 Wresistor (R5) installed from the output pin to GND to
set the output current.
Inputs OE1 and OE2 may be jumpered to VEE (GND) for
a LOW level (DISABLED) using J15 (OE1) or J12 (OE2).
If floated open (jumper removed), pin will default to a HIGH
level (ENABLED). High Impedance probes must be used to
sense the signal levels.
APPENDIX 1: DEVICE PIN TO BOARD CONNECTION INFORMATION (see current Datasheet)
Table 2. DEVICE PINS TO BOARD CONNECTION
Device
Pin
Device Pin
Name
Board
Connection I/O Description
1 S0 SEL0 LVTTL/LVCMOS
Input
Frequency select input 0. Internal pullup resistor to VDD. See
datasheet Table 2
2 S1 SEL1 LVTTL/LVCMOS
Input
Frequency select input 1. Internal pullup resistor to VDD. See
datasheet Table 2
3 NC PIN3 No Connect No Connect
4 X1/CLK X1/CLK Crystal Interface Oscillator Input from Crystal. Single ended 25 Mhz
LVTTL/LVCMOS Clock Input.
5 X2 X2 Crystal Interface Oscillator Output to drive Crystal
6 OE OE LVTTL/LVCMOS
Input
Output Enable Input pin to control CLKx (tri−states CLKx when
LOW, open pin defaults to HIGH)
7 GND GND Ground Supply DUT and SMA GND Supply. All Supply pins must be
connected for proper operation
8 NC PIN3 No Connect No Connect
9 IREF ( −) (connects Pin 9 through 475 Wto GND)
10 CLK1b CLK1b HCSL Output HCSL Invert Output
11 CLK1 CLK1 HCSL Output HCSL True Output
12 VDD VDD Positive Supply Positive Supply pin. All Supply pins must be connected for
proper operation.
13 GND GND Ground Supply DUT and SMA GND Supply. All Supply pins must be
connected for proper operation
14 CLK0b CLK0b HCSL Output HCSL Invert Output
15 CLK0 CLK0 HCSL Output HCSL True Output
16 GND GND Ground Supply DUT and SMA GND Supply. All Supply pins must be
connected for proper operation

NB3N5573DTGEVB
http://onsemi.com
6
APPENDIX 2: SCHEMATIC
Figure 7. Schematic

NB3N5573DTGEVB
http://onsemi.com
7
APPENDIX 3: BILL OF MATERIALS, LAMINATION STACKUP, AND ASSEMBLY NOTES
Table 3. BILL OF MATERIAL
Item Qty Schematic Value Size MFG P/N Description
1 2 BJ1−BJ2 ITT POMONA
ELECTRONICS
B−JACK 1/4−32 THREAD BANANAJACK
2 2 C1,C2 0.1 mF0402 Panasonic −ECG ECJ−DEB1A104K CAP CERM .1UF 10% 10V X5R
3 2 C3,C4 0.01 mF0402 AVX Corporation 04023C103KAT2A CAP CERM .01UF 10% 25V X7R
4 1 C9 10 mF7343 Kemet T491C106K016AT CAP TANT 10UF 16V 10% SMD
5 5 J10,J12,J13,J15,J16 2pin Sullins Electronics
Corp
PEC36SACN CONN HEADER .100 SINGL STR 36 POS
6 5 J10,J12,J13,J15,J16 Sullins Electronics
Corp
STC02SYAN CONN JUMPER SHORTING TIN
7 4 R1,R2,R7,R8 33.2 0402 Panasonic −ECG ERJ−2RKF33R2X RES 33.2 W1/16W 1% 0805 SMD
8 4 R3,R4,R9,R10 49.9 0402 YAGEO AMERICA 9C04021A49R8FLHF3 RES 49.9 W1/16W 1% 0805 SMD
9 1 R5 475 0402 Panasonic −ECG ERJ−2RKF49R9X RES 475 W1/16W 1% 0805 SMD
10 11 J1−6,J8,J9,J14,J17,J18 Emerson Network
Power Connectivity
Solutions
142−0701−801 CONN JACK END LAUNCH PCB .187” G
11 1 J11 SMT KEYSTONE
ELECTRONICS
5016 PC TEST POINT COMPACT SMT
12 2 Y1 Socket Pins Ampere 2−330808−8CONN SOCKET RCPT .013−0.21 30AU
13 U1 On Semiconductor NB3N5573DT 16 lead Tssop Dut
14 4 Standoff Nylon Standoff
15 4 Screw Nylon Screw
16 1 Xtal ECLIPTEK ECX−6150−25.000M XTAL (Do Not Solder)
17 1 SOCKET M&M 50−000−00809 NOT INSTALLED, Not Provided
Figure 8. Lamination Stack

NB3N5573DTGEVB
http://onsemi.com
8

www.onsemi.com
1
ADDITIONAL INFORMATION
TECHNICAL PUBLICATIONS:
Technical Library: www.onsemi.com/design/resources/technical−documentation
onsemi Website: www.onsemi.com
ONLINE SUPPORT: www.onsemi.com/support
For additional information, please contact your local Sales Representative at
www.onsemi.com/support/sales
onsemi, , and other names, marks, and brands are registered and/or common law trademarks of Semiconductor Components Industries, LLC dba “onsemi” or its affiliates
and/or subsidiaries in the United States and/or other countries. onsemi owns the rights to a number of patents, trademarks, copyrights, trade secrets, and other intellectual property. A
listing of onsemi’s product/patent coverage may be accessed at www.onsemi.com/site/pdf/Patent−Marking.pdf. onsemi is an Equal Opportunity/Affirmative Action Employer. This
literature is subject to all applicable copyright laws and is not for resale in any manner.
The evaluation board/kit (research and development board/kit) (hereinafter the “board”) is not a finished product and is not available for sale to consumers. The board is only intended
for research, development, demonstration and evaluation purposes and will only be used in laboratory/development areas by persons with an engineering/technical training and familiar
with the risks associated with handling electrical/mechanical components, systems and subsystems. This person assumes full responsibility/liability for proper and safe handling. Any
other use, resale or redistribution for any other purpose is strictly prohibited.
THE BOARD IS PROVIDED BY ONSEMI TO YOU “AS IS” AND WITHOUT ANY REPRESENTATIONS OR WARRANTIES WHATSOEVER. WITHOUT LIMITING THE FOREGOING,
ONSEMI (AND ITS LICENSORS/SUPPLIERS) HEREBY DISCLAIMS ANY AND ALL REPRESENTATIONS AND WARRANTIES IN RELATION TO THE BOARD, ANY
MODIFICATIONS, OR THIS AGREEMENT, WHETHER EXPRESS, IMPLIED, STATUTORY OR OTHERWISE, INCLUDING WITHOUT LIMITATION ANY AND ALL
REPRESENTATIONS AND WARRANTIES OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE, TITLE, NON−INFRINGEMENT, AND THOSE ARISING FROM A
COURSE OF DEALING, TRADE USAGE, TRADE CUSTOM OR TRADE PRACTICE.
onsemi reserves the right to make changes without further notice to any board.
You are responsible for determining whether the board will be suitable for your intended use or application or will achieve your intended results. Prior to using or distributing any systems
that have been evaluated, designed or tested using the board, you agree to test and validate your design to confirm the functionality for your application. Any technical, applications or
design information or advice, quality characterization, reliability data or other services provided by onsemi shall not constitute any representation or warranty by onsemi, and no additional
obligations or liabilities shall arise from onsemi having provided such information or services.
onsemi products including the boards are not designed, intended, or authorized for use in life support systems, or any FDA Class 3 medical devices or medical devices with a similar
or equivalent classification in a foreign jurisdiction, or any devices intended for implantation in the human body. You agree to indemnify, defend and hold harmless onsemi, its directors,
officers, employees, representatives, agents, subsidiaries, affiliates, distributors, and assigns, against any and all liabilities, losses, costs, damages, judgments, and expenses, arising
out of any claim, demand, investigation, lawsuit, regulatory action or cause of action arising out of or associated with any unauthorized use, even if such claim alleges that onsemi was
negligent regarding the design or manufacture of any products and/or the board.
This evaluation board/kit does not fall within the scope of the European Union directives regarding electromagnetic compatibility, restricted substances (RoHS), recycling (WEEE), FCC,
CE or UL, and may not meet the technical requirements of these or other related directives.
FCC WARNING – This evaluation board/kit is intended for use for engineering development, demonstration, or evaluation purposes only and is not considered by onsemi to be a finished
end product fit for general consumer use. It may generate, use, or radiate radio frequency energy and has not been tested for compliance with the limits of computing devices pursuant
to part 15 of FCC rules, which are designed to provide reasonable protection against radio frequency interference. Operation of this equipment may cause interference with radio
communications, in which case the user shall be responsible, at its expense, to take whatever measures may be required to correct this interference.
onsemi does not convey any license under its patent rights nor the rights of others.
LIMITATIONS OF LIABILITY: onsemi shall not be liable for any special, consequential, incidental, indirect or punitive damages, including, but not limited to the costs of requalification,
delay, loss of profits or goodwill, arising out of or in connection with the board, even if onsemi is advised of the possibility of such damages. In no event shall onsemi’s aggregate liability
from any obligation arising out of or in connection with the board, under any theory of liability, exceed the purchase price paid for the board, if any.
The board is provided to you subject to the license and other terms per onsemi’s standard terms and conditions of sale. For more information and documentation, please visit
www.onsemi.com.

