onCare Quartet TA User manual

HARMONY
POWER
Press the POWER button. The STANDBY (amber)
LED will turn off and the ON (green) LED will turn on.
TURN ASSIST
Press and hold one of the TURN ASSIST buttons and
use the SELECT button to toggle between options:



Use the ADJUST SETTINGS buttons to set the
above options. To exit the menu, press the
PAUSE button. Press the same TURN ASSIST
buttons and the surface will begin turning.
PAUSE
Press the PAUSE button to halt mattress rotation.
To set the pause time, hold the pause button
for 2-3 seconds and use the ADJUST SETTINGS
arrows to set the the pause time between
5-120 minutes (default is 15 minutes). To exit
the menu, press the SELECT button.
AUTO IMMERSION
With patient on the mattress, press the AUTO
IMMERSION button and the blue LED will turn on.
The surface will monitor and automatically
adjust immersion settings to match patient
weight and position.
QuartetTM TA
Quick Reference Guide
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
Quartet
Clear Turn
FIRMER
SOFTER
STANDBY ON
LATERAL ROTATIONLOCKALARM SILENCE
PAUSE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
MAX INFLATE
FIRMER
SOFTER
STANDBY ON
LOCKALARM SILENCE
PAUSE
AUTO
IMMERSION
ADJUST
SETTINGS
MAX INFLATE SELECT
FIRMER
SOFTER
STANDBY ON
LOCKALARM SILENCE
PAUSE
AUTO
IMMERSION
ADJUST
SETTINGS
MAX INFLATE SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
LOCK
Press and hold the LOCK button until the LED light turns on,
to prevent tampering of settings. To unlock mattress settings,
press and hold the LOCK button until the LED light turns off.

FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT

HARMONY
QuartetTM TA
Quick Reference Guide
Please read user manual for operating instructions and
www.oncaremedical.com for additional product information.
1.800.847.7368.
ALARM SILENCE
Press the ALARM SILENCE button the control unit “beeps” to mute
audio alarm.
BED EXIT ALARM
To enable the bed exit alarm, press and hold the ALARM SILENCE button
until the control unit “beeps” and follow the instructions on the screen.
POWER STATUS

battery is charging.
BATTERy POWER

are discharging. Displays percentage of battery capacity when
the unit is running on either AC power or battery power.
LOW PRESSURE
The micro-controller will activate an audio/visual signal to alert the


SAFETy AIR PAD


located at the bottom right corner (patient’s right) of the mattress.
CPR FUNCTION

from the control unit.
MAX INFLATE
Press the MAX INFLATE button and the mattress will

(MAX INFLATE automatically deactivates after 15 minutes).



PATIENT COMFORT CONTROL LEVEL
The system is designed for patients weighing
between 35-500 lbs., or up to 1000 lbs. on the
bariatric model. Press the COMFORT CONTROL

patient’s preferred comfort level.
SELECT
The SELECT button cycles between the  and
 therapy modes. To select the desired mode,
press the SELECT button until that mode is shown
on the display. Use the ADJUST SETTINGS arrows to
select pulsation frequency and duration options.



FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT
FIRMER
SOFTER
STANDBY ON
A/P MAX INFLATELOCKALARM SILENCE
AUTO
IMMERSION
ADJUST
SETTINGS
SELECT

