ONE MK-F13 User manual

USER
MANUAL
VERSION 2.0
PRODUCT: FOG MACHINE
MODEL: MK-F13

1USER MANUAL (MK-F13)
Product parameters
Product Name 3500W Dry Ice Fog Machine
Voltage :AC110V/220V,60HZ/50HZ
Power: 220V 3500w(110V 2000w)
Control Manual
Consumable Solid Dry Ice
Water Consumption 8~10L (up to waterline)
Heat-up-time 15min
Maximum Output 5~6Min
Coverage Area 50~100m²
G.W 14.5KG
Product Size 42cm x36cm x40cm
Package Size 49cm x49cm x46.5cm
Transport Weight 23KG
Unpacking Instructions
WARNING
Carefully unpacking the product immediately and check
the container to make sure all the parts in the package
and are in good condition
Claims: If the box or the contents(the product and included accessories)
app-ear damaged from shipping, or show signs of mishandling,notify the carrier
imm-ediately. For others issues,such as missing components or parts, damage
not related to shipping,or concealed damage, file a claim with us within 7 days
of delivery.

AMAZING BOOSTER FOR STAGE
2
Safety Notes:
please read the following Safety Notes carefully before working with the
product.The notes include important safety information about installation,usage
and maintenance
*Always connect the product to a grounder circuit to avoid the risk of
electrocution
*Always disconnect the products from the power source before cleaning
*Make sure the power cord is not crimped or damaged
*Never disconnect the product from power cord by pulling or tugging on the
cord
*Make sure there are no flammable surface(Linoleum, carpet, wood, paper,
carton, plastic,etc)
*The product’s nozzle is very hot during operation and it remains hot for a long
time after operation as stopped
*The CO2 Exits the nozzle at very high temperature. Keep a minimum
distance of the 6.5ft(2m) from the nozzle to the nearest object.
*Do not use the product as a space heater
*Do not handle dry ice with bare hands,Thick gloves must be worn
*Do not swallow dry ice. It may lead to severe internal injuries
*Before breaking the dry ice. It may lead to severe internal injuries
*Before breaking the dry ice, cover it with pieces of cloth or place the block in
a cloth bag. Eye protection must be worn
*Do not use in a confined space. Make sure the room is well ventilated
before beginning usage
NOTED:
-For safety reasons,we don’t not recommend mounting the product in any
capacity. Operate the products while it is on the ground only

3USER MANUAL (MK-F13)
-During warm up and operation, water will be scolding not.
-Do not place your hand into the water
-Do not remove basket when the unit is plugged in or when heaters are hot.
Warning:
-Always make sure that the voltage of the outlet to which you are connecting
the product is within the range stated on the decal or rear panel of the product
-The product is for indoor use only (IP20) to prevent risk of fire or shock, do
not expose the product to rain or moisture
-Always install the product in a location adequate ventilation, at least 20 in
(50cm) from adjacent surface
-Be sure that no ventilation slots on the product’s housing are blocked
-Never connect the product to a dimmer
-Never Carry the product from the cord or any moving part
-The maximum ambient temperature(Ta) is 104°F(40℃). Do not operate the
product at higher temperatures
-In the event of a serious operating problem, stop using the
product immediately
-Never try to repair the product. Repairs become wet during operation.
Make sure not to use near smooth floors as they may become slippery
-Water temperature should be about 175:°F(79℃:) for optimal operation
-Keep this User Manual for future consultation.If you sell the product to
another user, be sure that they also receive this document.
How to work with it :
1.Place the machine on a rm level surface where it will be used. Take off the
lid and ll with water (hot or cold) with about 10liters, the water line subject to

AMAZING BOOSTER FOR STAGE
4
the steel plate’s scale mark of the inner side machine until the red light comes
on, which means the machine is heating up.
2.Plug the cord into a grounded 22-amp receptacle. A ground fault interrupted
receptacle would be preferred. The heater draws 11 amps at 220Volts.
3.While the machine is heating up, the heating time of single electrical heated
tube 3000W is 15 minutes. Raise the basket to its highest level with the black
handle on the side of the machine and lock it in the highest stop.
4.When the water is steaming after approximately 20-35 minutes the
machine is now ready to use
5.Using protective gear load, the basket can hold 10 kilograms (about 20lbs)
of dry ice. The basket size has been designed to give on large “show” from
each bag or block of dry – ice if filled to approximately 1-1 from the basked
rim. It can hold 3kgs dry ice at most each time. The loading of the dry-ice
should be done at the last possible moment when needed, because the steamy
atmosphere in the machine will make the dry ice evaporate if put it in too long
beforehand.
6.Remove any ice chips on the lid seal and place the lid on. Secure the lid by
turning the two arms inward on the lid and push down on the leavers to latch.
7.When the “fog” is required, grasp the basket lever and slowly lower the
handle. A full basket should not be plunged into the hot water. This would
result in dangerous pressure build up due to the violent action of the dry-ice
sublimating. A ratchet stop is provided to allow the basket to be stepped into
the water. As the CO2 is immersed a “fog” will be produced in thick clouds from
the front nozzle. To increase the rate, lower the handle to the next stop. Raising
the handle fully will quickly stop the effect, thus it is possible tor and ON & OFF
type of effect.
8.After your rst effect top up the water and allow the unit to heat up. Take the
CO2 block/pieces from its storage container and load in the basket.

5USER MANUAL (MK-F13)
9.When the machine is to be emptied allow it to cool. Empty the machine into
buckets where it stands rather than carrying it to the drain. Do not move the
machine with hot or boiling water in it.
Set UP
AC POWER:
The machine has a xed voltage power supply and can work with an input
voltage of either 120VAC,60Hz or 230VAC,50Hz,depending on the specific
model
To determine the product’s power requirements(circuit breaker,power
outlet,and wiring),use the current value listed on the label affixed to the
product’s back panel,or refer to the product’s specifications chart. The
listed current rating indicates the product’s average current draw under
normal conditions.
Always connect the product to a protected circuit(circuit breaker or fuse).
Make sure the product has an appropriate electrical ground to avoid the risk
of electrocution or re.
Never connect the product to a rheostat(variable resistor) or dimmer
circuit,even if the rheostat or dimmer channel serves only as a 0 to 100%
switch.
ABOUT DRY ICE and CO2
Dry ice is a solid form of carbon dioxide. The term”dry ice”is used because of
its ability to sublimate –the process of transforming from a solid directly to a
gas without any liquid formation. Dry ice reaches a temperature of -189.5°F:
(-87.5℃ : ) .When immersed in hot or boiling water,dry ice sublimates and
agitates the water. The releases cold CO2 gas causes the water vapor to
form water droplets in the air. This expansion of gas and moisture pushes
its way out of the machine. Because the CO2 is cold and heavy, the moisture
sinks to the

AMAZING BOOSTER FOR STAGE
6
oor.The droplets in the air create the fog effect.
Dry ICE Warnings:
*Do Not cover or plug the output nozzle during operation. Compressing
the dry ice will cause a chemical reaction that may lead to an explosion
*Do Not handle dry ice with bare hands. Thick gloves must be worn
*Do Not swallow dry ice. It will lead to severe internal injuries
Before breaking the dry ice,cover it with a piece of cloth or place the block
in a cloth bag. Eye protection must be worn
*Do Not use in a confined space. Make sure the room is well ventilated
before beginning usage
Dry ice should never be stored in a sealed container that can lead to a
pressure build-up and a risk of an explosion
