ONE A User manual



I
Introduction (English)
This Concise User’s Guide introduces the main features
of your computer. The English version of this guide be-
gins on page 1. The expanded User’s Manual is on the
Device Drivers & Utilities + User’s Manual disc.
Einführung (Deutsch)
Dieses Ausführliche Benutzerhandbuch führt Sie in die
Hauptfunktionen des Computers ein. Die deutsche Ver-
sion des Handbuchs beginnt auf Seite 41. Das erweiterte
Benutzerhandbuch finden Sie auf der Disc für die Gerä-
tetreiber und Hilfsprogramme (Disc Device Drivers &
Utilities + User's Manual).
Présentation (Français)
Ce Guide Utilisateur Concis présente les fonctionnalités
principales de votre ordinateur. La version française de
ce guide commence à la page 81. Le Manuel de l'Utilisa-
teur étendu se trouve sur le disque de Pilotes & Utili-
taires + Manuel de l'Utilisateur (disque Device Drivers
& Utilities + User's Manual).
Introducción (Español)
Esta Guía del Usuario Concisa le presenta las caracterís-
ticas principales de su ordenador. La versión española de
esta guía comienza en la página 129. El Manual del usua-
rio completo se encuentra en el disco de Controladores
del dispositivo y Utilidades + Manual del usuario (disco
Device Drivers & Utilities + User's Manual).
Introduzione (Italiano)
La presente Guida Rapida per l'Utente introduce le carat-
teristiche principali del computer. La versione italiana di
questa guida inizia da pagina 169. Il Manuale utente
completo si trova nel disco contenente driver e utilità +
Manuale utente (disco Device Drivers & Utilities +
User's Manual).

II
Contents
About this Concise User Guide .........................................................1
Instructions for Care and Operation ..................................................2
System Startup ..................................................................................4
RAID Setup (Models C & D Only) ..................................................6
System Map: Front View with LCD Panel Open .............................8
Keyboard & Function Keys ..............................................................9
LED Indicators ................................................................................10
System Map: Front, Left, Right & Rear Views (Models A & B) ...11
System Map: Front, Left, Right & Rear Views (Models C & D) ...12
System Map: Bottom Views ...........................................................13
Video Features ................................................................................14
Audio Features ................................................................................18
Power Options .................................................................................21
Driver Installation ...........................................................................22
PC Camera ......................................................................................25
WLAN Module (Option) ................................................................27
Fingerprint Reader (Option) ...........................................................28
Bluetooth & WLAN Combo Module (Option) ...............................29
3.75G/HSPA Module (Option) .......................................................31
TV Tuner Module (Option) ............................................................33
Troubleshooting ..............................................................................34
Specifications ..................................................................................35
Inhalt
Über das Ausführliche Benutzerhandbuch ......................................41
Hinweise zu Pflege und Betrieb ......................................................42
Schnellstart ......................................................................................44
RAID Setup (Nur Modelle C & D) .................................................46
Systemübersicht: Ansicht von vorne mit geöffnetem
LCD-Bildschirm ..............................................................................48
Tastatur & Funktionstasten .............................................................49
LED-Anzeigen ................................................................................50
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modelle A & B) .............................................................................51
Systemübersicht: Ansicht von vorne, links, rechts und hinten
(Modelle C & D) .............................................................................52
Systemübersicht: Ansicht von unten ...............................................53
Grafikfunktionen .............................................................................54
Audiofunktionen ..............................................................................58
Energieoptionen ..............................................................................61
Installation der Treiber ....................................................................62
PC-Kamera ......................................................................................65
Wireless-LAN-Modul (Option) .......................................................67
Fingerabdruckleser (Option) ...........................................................68
Kombinierte Bluetooth- und WLAN-Modul (Option) ....................69
3.75G/HSPA-Modul (Option) .........................................................71
TV-Tuner-Modul (Option) ..............................................................73
Fehlerbehebung ...............................................................................74
Technische Daten ............................................................................75

III
Sommaire
A propos de ce Guide Utilisateur Concis ........................................81
Instructions d’entretien et d’utilisation ...........................................82
Guide de démarrage rapide .............................................................84
Configuration RAID (Modèles C & D seulement) .......................86
Carte du système: Vue de face avec l’écran LCD ouvert ...............88
Clavier & touches fonction .............................................................89
Indicateurs LED ..............................................................................90
Carte du système: Vues de face, gauche, droite & arrière
(Modèles A & B) ............................................................................92
Carte du système: Vues de face, gauche, droite & arrière
(Modèles C & D) ............................................................................93
Carte du système: Vues du dessous ...............................................94
Caractéristiques vidéo .....................................................................95
Caractéristiques audio .....................................................................99
Options d’alimentation ..................................................................102
Installation du pilote .....................................................................103
Caméra PC ....................................................................................106
Module LAN sans fil (Option) ......................................................108
Lecteur d'empreintes digitales (Option) ........................................109
Module Combo Bluetooth et LAN sans fil (Option) ....................110
Module 3.75G/HSPA (Option) .....................................................112
Module Tuner TV USB (Option) ..................................................114
Dépannage .....................................................................................116
Spécifications ................................................................................118
Contenidos
Acerca de esta Guía del Usuario Concisa .....................................129
Instrucciones para el cuidado y funcionamiento ...........................130
Guía rápida para empezar ..............................................................132
Configuración RAID (sólo Modelos C & D) ................................134
Mapa del sistema: Vista frontal con panel LCD abierto ...............136
Teclado & teclas de función ..........................................................137
Indicadores LED ...........................................................................138
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelos A & B) ...........................................................................139
Mapa del sistema: Vistas frontal, izquierda, derecha, y posterior
(Modelos C & D) ...........................................................................140
Mapa del sistema: Vistas inferior ..................................................141
Parámetros de vídeo ......................................................................142
Características de audio .................................................................146
Opciones de energía ......................................................................149
Instalación de controladores ..........................................................150
Cámara PC .....................................................................................153
Módulo LAN Wireless (Opción) ...................................................155
Lector de huellas digitales (Opción) .............................................156
Módulo Combo Bluetooth y WLAN (Opción) .............................157
Módulo 3.75G/HSPA (Opción) .....................................................159
Módulo sintonizador de TV USB (Opción) ..................................161
Solución de problemas ..................................................................162
Especificaciones ............................................................................163

IV
Sommario
Informazioni sulla Guida Rapida per l'Utente ..............................169
Istruzioni per la custodia e il funzionamento ................................170
Guida di avvio rapido ....................................................................172
Configurazione RAID (solo Modelli C & D) ...............................174
Descrizione del sistema: Vista anteriore con pannello
LCD aperto ....................................................................................176
Tastiera & tasti funzione ...............................................................177
Indicatori LED ..............................................................................178
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modelli A & B) ............................................................................179
Descrizione del sistema: Vista anteriore, sinistra, destra e posteriore
(Modelli C & D) ............................................................................180
Descrizione del sistema: Vista inferiore .......................................181
Funzioni video ..............................................................................182
Funzionalità audio .........................................................................186
Opzioni risparmio energia .............................................................189
Installazione driver ........................................................................190
Camera PC ....................................................................................193
Modulo LAN Wireless (Opzione) ................................................195
Lettore d’impronte digitali (Opzione) ...........................................196
Modulo Combo Bluetooth e Wireless LAN (Opzione) ................197
Modulo 3.75G/HSPA (Opzione) ..................................................199
Modulo sintonizzatore TV USB (Opzione) ..................................201
Risoluzione dei problemi ..............................................................202
Specifiche tecniche .......................................................................203

About this Concise User Guide - 1
Concise User’s Guide
English
About this Concise User Guide
This quick guide is a brief introduction to getting your system started. This is a supplement, and not a substitute for
the expanded English language User’s Manual in Adobe Acrobat format on the Device Drivers & Utilities + User’s
Manual disc supplied with your computer. This disc also contains the drivers and utilities necessary for the proper
operation of the computer (Note: The company reserves the right to revise this publication or to change its contents
without notice).
Some or all of the computer’s features may already have been setup. If they aren’t, or you are planning to re-configure
(or re-install) portions of the system, refer to the expanded User’s Manual. The Device Drivers & Utilities + User’s
Manual disc does not contain an operating system.
Regulatory and Safety Information
Please pay careful attention to the full regulatory notices and safety information
contained in the expanded User’s Manual on the Device Drivers & Utilities + Us-
er’s Manual disc.
© June 2011
Trademarks
Intel and Intel Core are trademarks/registered trademarks of Intel Corporation.
FCC Statement
This device complies with Part
15 of the FCC Rules. Operation
is subject to the following two
conditions:
1.This device may not cause
harmful interference.
2.This device must accept any
interference received, includ-
ing interference that may
cause undesired operation.

Concise User’s Guide
2 - Instructions for Care and Operation
English
Instructions for Care and Op-
eration
The computer is quite rugged, but it can be damaged. To
prevent this, follow these suggestions:
•Don’t drop it, or expose it to shock. If the computer falls, the case
and the components could be damaged.
•Keep it dry, and don’t overheat it. Keep the computer and power
supply away from any kind of heating element. This is an electrical
appliance. If water or any other liquid gets into it, the computer
could be badly damaged.
•Avoid interference. Keep the computer away from high capacity
transformers, electric motors, and other strong magnetic fields.
These can hinder proper performance and damage your data.
•Follow the proper working procedures for the computer. Shut
the computer down properly and don’t forget to save your work.
Remember to periodically save your data as data may be lost.
• Note that in computer’s featuring a raised LCD electro-plated logo,
the logo is covered by a protective adhesive. Due to general wear
and tear, this adhesive may deteriorate over time and the exposed
logo may develop sharp edges. Be careful when handling the com-
puter in this case, and avoid touching the raised LCD electro-plated
logo. Avoid placing any other items in the carrying bag which may
rub against the top of the computer during transport. If any such
wear and tear develops contact your service center.
Power & Battery Safety
• Only use an AC/DC adapter approved for use with this computer.
• Use only the power cord and batteries indicated in this manual.
• Your AC/DC adapter may be designed for international travel but it
still requires a steady, uninterrupted power supply. If you are
unsure of your local power specifications, consult your service rep-
resentative or local power company.
• The AC/DC adapter may have either a 2-prong or a 3-prong
grounded plug. The third prong is an important safety feature; do
not defeat its purpose. If you do not have access to a compatible
outlet, have a qualified electrician install one.
• When you want to unplug the power cord, be sure to disconnect it
by the plug head, not by its wire.
• Make sure the socket and any extension cord(s) you use can sup-
port the total current load of all the connected devices.
• Make sure that your computer is completely powered off before
putting it into a travel bag (or any such container).
• Only use batteries designed for this computer. The wrong battery
type may explode, leak or damage the computer.
• Do not continue to use a battery that has been dropped, or that
appears damaged (e.g. bent or twisted) in any way. Even if the
computer continues to work with a damaged battery in place, it
may cause circuit damage, which may possibly result in fire.
• Recharge the batteries using the computer’s system. Incorrect
recharging may make the battery explode.
• Do not try to repair a battery pack. Refer any battery pack repair or
replacement to your service representative or qualified service personnel.
• Keep children away from, and promptly dispose of a damaged bat-
tery. Always dispose of batteries carefully. Batteries may explode
or leak if exposed to fire, or improperly handled or discarded.
• Keep the battery away from metal appliances.
• Affix tape to the battery contacts before disposing of the battery.
• Do not dispose of batteries in a fire. They may explode. Check with
local codes for possible special disposal instructions.
• Do not touch the battery contacts with your hands or metal objects.

Concise User’s Guide
Instructions for Care and Operation - 3
English
Polymer Battery Precautions
Note the following information which is specific to poly-
mer batteries only, and where applicable, this overrides
the general battery precaution information.
• Polymer batteries may experience a slight expansion or swelling,
however this is part of the battery’s safety mechanism and is not a
cause for concern.
• Use proper handling procedures when using polymer batteries. Do
not use polymer batteries in high ambient temperature environ-
ments, and do not store unused batteries for extended periods.
Cleaning
• Use a soft clean cloth to clean the computer, but do not apply
cleaner directly to the computer.
• Do not use volatile (petroleum distillates) or abrasive cleaners on
any part of the computer.
• Before cleaning the computer remove the battery and make sure the
computer is disconnected from any external power supplies,
peripherals and cables (including telephone lines).
Servicing
Attempting to service the computer yourself may violate
your warranty and expose you and the computer to electric
shock. Refer all servicing to qualified service personnel,
particularly under any of the following conditions:
• When the power cord or AC/DC adapter is damaged or frayed.
• If the computer has been exposed to any liquids.
• If the computer does not work normally when you follow the oper-
ating instructions.
• If the computer has been dropped or damaged (do not touch the
poisonous liquid if the LCD panel breaks).
• If there is an unusual odor, heat or smoke coming from your com-
puter.
Battery Disposal & Caution
The product that you have purchased contains a recharge-
able battery. The battery is recyclable. At the end of its
useful life, under various state and local laws, it may be il-
legal to dispose of this battery into the municipal waste
stream. Check with your local solid waste officials for de-
tails in your area for recycling options or proper disposal.
Danger of explosion if battery is incorrectly replaced. Re-
place only with the same or equivalent type recommended
by the manufacturer. Discard used battery according to the
manufacturer’s instructions.

Concise User’s Guide
4 - System Startup
English
System Startup
1. Remove all packing materials.
2. Place the computer on a stable surface.
3. Insert the battery and tighten the screws.
4. Securely attach any peripherals you want to use with the
computer (e.g. keyboard and mouse) to their ports.
5. Attach the AC/DC adapter to the DC-In jack at the rear of the
computer, then plug the AC power cord into an outlet, and
connect the AC power cord to the AC/DC adapter.
6. Use one hand to raise the lid/LCD to a comfortable viewing
angle (do not to exceed 135 degrees);
use the other hand (as
illustrated in Figure 1) to support the base of the computer
(Note: Never lift the computer by the lid/LCD).
7. Press the power button to turn the computer “on”.
System Software
Your computer may already come with system software
pre-installed. Where this is not the case, or where you are
re-configuring your computer for a different system, you
will find this manual refers to Microsoft Windows 7.
Shut Down
Note that you should always shut your computer down
by choosing Shut Down from the Start Menu.
This will help prevent hard disk or system problems.
135 ゚
Figure 1
Opening the Lid/LCD/
Computer with AC/DC
Adapter Plugged-In

System Startup - 5
Concise User’s Guide
English
Model Differences
This notebook series includes Four different model types that mainly differ as indicated in the table below. Note that
your model may appear slightly different from those pictured in this manual.
Table 1 - Model Differences
Feature Model A Model B Model C Model D
Case Color Rubber Style Paint Standard Paint
Core Logic Intel@ HM65 Chipset Intel@ HM67 Chipset
CPUs & Video
Adapters
Supported See Troubleshooting on page 34 for a full list of CPUs and video adapters supported by each model.
Display Type 15.6" (39.62cm) FHD
(1920 * 1080)
15.6" (39.62cm) HD+
(1600 * 900)
15.6" (39.62cm) FHD
(1920 * 1080)
17.3" (43.94cm) FHD (1920
* 1080)
17.3"(43.94cm) FHD
(1920 * 1080) 120Hz
panel to support 3D solu-
tion with NV 3DVISION
shutter glasses kit (see
page 15)
Mini-Card Slot 2 for 3.75G/HSPA Module for TV Tuner Module
RAID Not Supported RAID Level 0/1/Recovery Supported
AC/DC Adapter DC output 19V, 9.47A
(180W)DC output 19V, 6.3A
(120W)DC output 19V, 11.57A (220W)

Concise User’s Guide
6 - RAID Setup (Models C & D Only)
English
RAID Setup (Models C & D
Only)
You may use your hard disks in combination with Strip-
ing (RAID 0), Mirroring (RAID 1) or Recovery for either
fault tolerance or performance.
Prepare the following before setting up your serial ATA
hard disks in RAID mode:
• The Microsoft Windows OS disc.
• The Device Drivers & Utilities + User’s Manual disc.
Note: All hard disks in a RAID should be identical (the
same size and brand) in order to prevent unexpected sys-
tem behavior.
Table 2 - RAID Description
RAID Level Description
Recovery
(at lease two
hard disks
needed)
Two identical drives copying data between a
master and a recovery disk. This provides more
control over how data is copied between the
master and recovery drives, fast volume updates
and the ability to view the data in Windows
Explorer.
RAID 0
(at lease two
hard disks
needed)
Identical drives reading and writing data in paral-
lel to increase performance. RAID 0 imple-
ments a striped disk array and the data is broken
into blocks and each block is written to a sepa-
rate disk drive.
RAID 0 (a striped array) is not fault-tolerant. The
failure of one drive will result in the loss of all
data in the array.
RAID 1
(at lease two
hard disks
needed)
Identical drives in a mirrored configuration used
to protect data. Should a drive that is part of a
mirrored array fail, the mirrored drive (which con-
tains identical data) will handle all the data.
When a new replacement drive is installed, data
to the new drive is rebuilt from the mirrored drive
to restore fault tolerance.
RAID 1 (mirrored array) provides full data protec-
tion, as data can simply be copied from ahealthy
disk to a replacement for any failed disk.

RAID Setup (Models C & D Only) - 7
Concise User’s Guide
English
RAID Setup Procedure
Part I: BIOS
1. Start-up your computer and press F2 to
enter the BIOS.
2. Go to the Advanced menu, select
SATA Mode and press Enter.
3. Select RAID.
4. Press Esc and go to the Boot menu.
5. Set the CD/DVD-ROM Drive (make
sure the Microsoft Windows OS disc
is inserted) as the first device in the
boot order from the Boot menu.
6. Select Save Changes and Reset from
the Exit menu (or press F4) and press
Enter to exit the BIOS and reboot the
computer.
Part II: Intel Matrix
1. Press Ctrl + i to enter RAID configura-
tion menu.
Figure 2 - Intel(R) Matrix Storage Man-
ager Option ROM
2. Select 1.Create RAID Volume and
press Enter.
3. Type the RAID volume name and then
press Tab or Enter to advance to the
next field.
4. Specify (use the up and down arrow
keys) the RAID level (RAID 0, RAID 1
or Recovery - see Table 2 on page 6)
and then press Tab or Enter to
advance to the next field.
5. Press Enter and the system will select
the physical disks to use.
6. Press Enter and select (if applicable)
the Strip Size (best set to default).
7. Press Enter and select the Capacity
size (best set to default).
8. Press Enter to select Create Volume.
9. Press Enter to create the volume, and
confirm the selection by pressing Y.
10. This will now return to the main menu.
Figure 3 - RAID Created
11. Select 6.Exit and press Enter, then
press Y to exit the RAID configuration
menu.
12. Press a key when you see the message
"Press any key to boot from CD".
13. Press Enter to continue installing the
operating system as normal (see your
Windows documentation if you need
help on installing the Windows OS).

8 - System Map: Front View with LCD Panel Open
Concise User’s Guide
English
System Map: Front View with LCD Panel Open
2
1
8
9
7
3
6
5
45
Note that the Touchpad and
Buttons valid operational area
is that indicated within the red
dotted lines above.
8
Figure 4
Front View with LCD
Panel Open
1. PC Camera
2. LCD
3. LED Indicators
4. Power Button
5. Speakers
6. Keyboard
7. Built-In Microphone
8. Touchpad and Buttons
9. Fingerprint Reader
(Optional)
10. 3D Emitter (Model D
Only)
3
2
1
8
9
7
6
54
5
3
Models A & B
15.6” (39.62cm)
17.3” (43.94cm)
Models C & D
10

Keyboard & Function Keys - 9
Concise User’s Guide
English
Keyboard & Function Keys
The keyboard includes a numeric keypad (on the right side
of the keyboard) for easy numeric data input. Pressing Fn
+ NumLk turns on/off the numeric keypad. It also features
function keys to allow you to change operational features
instantly. The function keys (F1 - F12 etc.) will act as hot
keys when pressed while the Fn key is held down. In addi-
tion to the basic function key combinations, visual indica-
tors are available when the hot key driver is installed.
Keys Function/Visual Indicators Keys Function/Visual Indicators
Fn + ~ Play/Pause (in Audio/Video Programs) Fn + F8/F9 Brightness Decrease/
Increase
Fn + 3.75G/HSPA Module
Power Toggle Fn + F10 PC Camera Power
Toggle
Fn + F1 Touchpad Toggle Fn + F11 WLAN Module Power
Toggle
Fn + F2 Turn LCD Backlight Off
(Press a key to or use Touchpad to turn on) Fn + F12 Bluetooth Module
Power Toggle
Fn + F3 Mute Toggle Fn + NumLk Number Lock (Numeric Keypad) Toggle
Fn + F4 Sleep Toggle Fn + ScrLk Scroll Lock Toggle
Fn + F5/F6 Volume Decrease/
Increase Fn + 5 (Models C & D Only) Audio Toggle - Toggle between
Standard and Enhanced Audio (see page 21)
Fn + F7 Display Toggle Table 3 - Function Keys & Visual Indicators
Function Keys
Numeric
Keypad
Fn Key
Figure 5 - keyboard
NumLk &
ScrLk
Game Control Keys 3.75G/HSPA
Module Power Toggle

Concise User’s Guide
10 - LED Indicators
English
LED Indicators
The LED indicators on the computer display helpful in-
formation about the current status of the computer.
Table 4 - LED Status Indicators
Table 5 - LED Power Indicators
*The powered USB 2.0 port may be toggled on /off by
means of the Fn + Power Button key combination.
When the powered USB port is on it will supply power
when the system is off but still powered by the AC/DC
adapter plugged into a working outlet (this may not work
with certain devices - see
page 34).
Icon Color
(Models
A & B)
Color
(Models
C & D) Description
Blue White Number Lock (Numeric
Keypad) Activated
Blue White Caps Lock Activated
Blue White Scroll Lock Activated
Blue White Hard Disk Activity
Blue White Wireless LAN Module
Power Toggle
Blue Orange Bluetooth Module Power
Toggle
Models A & B
Models C & D
Icon Color Description
Orange The AC/DC Adapter is Plugged In
Blinking
Orange* The AC/DC adapter is plugged in and the
powered USB Port is on*
Green The Computer is On
Blinking
Green The Computer is in Sleep Mode
Orange The Battery is Charging
Green The Battery is Fully Charged
Blinking
Orange The Battery Has Reached Critically Low
Power Status

System Map: Front, Left, Right & Rear Views (Models A & B) - 11
Concise User’s Guide
English
System Map: Front, Left, Right & Rear Views (Models A & B)
4
7
56
1
23
Front
Left
Right
10 11 13
12
USB
The USB 3.0 ports are colored blue. USB 3.0 will transfer data much faster than USB
2.0, and is backwards-compatible with USB 2.0. The powered USB 2.0 port can supply
power when the system is off but still powered by the AC/DC adapter. Toggle power to this
port by using Fn + power button.
3
4
8
3
15 17
14
16 15
Rear
18 19
Figure6-Front,Left,Right&
Rear Views (Models A & B)
1. LED Power Indicators
2. RJ-45 LAN Jack
3. USB 3.0 Ports
4. Powered USB 2.0 Port
(see note below)
5. Mini-IEEE 1394a Port
6. Multi-in-1 Card Reader
7. Optical Device Drive Bay
8. Emergency Eject Hole
9. Headphone Jack
10. Microphone Jack
11. S/PDIF-Out & Surround-Out
Combo Jack
12. Line-In Jack
13. USB 2.0 Port
14. Security Lock Slot
15. Vent
16. eSATA/USB 2.0 Combo
Port
17. HDMI-Out Port
18. DVI-Out Port
19. DC-In Jack
9

12 - System Map: Front, Left, Right & Rear Views (Models C & D)
Concise User’s Guide
English
System Map: Front, Left, Right & Rear Views (Models C & D)
Front
Figure 7 - Front, Left, Right &
Rear Views (Models C & D)
1. Infrared Receiver
2. LED Power Indicators
3. RJ-45 LAN Jack
4. *USB 3.0 Ports
5. *Powered USB 2.0 Port
(*see USB on page 11)
6. Cable (CATV) Antenna Jack
7. Mini-IEEE 1394a Port
8. Multi-in-1 Card Reader
9. Optical Device Drive Bay
10. Emergency Eject Hole
11. Headphone Jack
12. Microphone Jack
13. S/PDIF-Out & Surround-Out
Combo Jack
14. Line-In Jack
15. USB 2.0 Port
16. Security Lock Slot
17. Vent
18. eSATA/USB 2.0 Combo Port
19. HDMI-Out Port
20. DVI-Out Port
21. DC-In Jack
Overheating
To prevent your computer from overheating make sure nothing blocks any vent while the com-
puter is in use.
58
67
2
34
910 12 14
13
4
16 18
15
17 17
19 20 21
1
11
Front
Left
Right
Rear

System Map: Bottom Views - 13
Concise User’s Guide
English
System Map: Bottom Views
3
2
1
4 5
Battery Information
Always completely discharge, then fully charge, a new battery before using it. Completely dis-
charge and charge the battery at least once every 30 days or after about 20 partial discharges
(see the expanded User’s Manual on the Device Drivers & Utilities + User’s Manual disc).
HDMI
Note that the HDMI Port supports video and audio signals to attached external displays (Note
THX Tru Studio Pro will be disabled when you are connecting to an external display through an
HDMI connection -
see
page 20).
1
11
Figure 8
Bottom Views
1. Vent
2. Component Bay
Cover
3. Sub Woofer
4. HDD Bay
5. Battery
6. Secondary HDD Bay
7. Speakers
CPU
The CPU is not a user
serviceable part. Ac-
cessing the CPU in
any way may violate
your warranty.
32
1
45
1
11
6
7
77
Models A & B Models C & D

Concise User’s Guide
14 - Video Features
English
Video Features
This computer features two different (either NVIDIA or
AMD) video options. You can switch display devices,
and configure display options, from the Display control
panel in Windows as long as the video driver is installed.
To access Display control panel:
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click Display (icon) - in the Appearances and
Personalization category.
3. Click Adjust Screen Resolution/Adjust resolution.
OR
4. Alternatively you can right-click the desktop and select Screen
resolution.
5. Use the dropbox to select the screen Resolution .
6. Click Advanced settings .
To access the NVIDIA Control Panel:
1. Click Start, and click Control Panel (or point to Settings and
click Control Panel).
2. Click NVIDIA Control Panel (icon) - in the Appearances and
Personalization category.
OR
3. Right-click the desktop and select NVIDIA Control Panel from
the menu.
To access the Catalyst™ Control Center:
1. Right-click the desktop and select Graphics Properties .
OR
2. Double-click the icon in the Windows taskbar (or right-
click the icon and select Configure Graphics).
Display Devices
Besides the built-in LCD, you can also use an external
monitor/external Flat Panel Display or TV (connected
to the DVI-Out port/HDMI-Out port) as your display de-
vice.
1
2
Figure 9
Display
Control
Panel
12
This manual suits for next models
3
Table of contents
Languages:
Other ONE Laptop manuals
