Dust Deputy Low-Pro™
Lid Separator
DIY / Deluxe
# AXD250099
# AXD259922
Patents: www.oneida-air.com/patents

Oneida Air Systems2

3oneida-air.com
System Start-Up Information
1. DO NOT use to pick up anything that is burning or smoking, such as
cigarettes, matches, or hot ashes.
2. DO NOT collect ammable or combustible liquids, gases, or explosive
dusts, such as gasoline or other fuels, lighter uid, cleaners, oil-based
paints, natural gas, hydrogen, coal dust, magnesium dust, grain dust,
aluminum dust, sugar dust, our dust or gun powder.
3. Can be used for collecting non-ammable liquids.
4. DO NOT use or store near hazardous materials.
5. DO NOT operate the in areas where explosion risks are high. Areas of
high risk include, but are not limited to, areas near pilot lights, open
ames, or other ignition sources.
6. ALWAYS wear a NIOSH approved respirator when emptying dust bins
and during operation. Dust created by machinery operations may cause
cancer, birth defects, or long-term respiratory damage. Be aware of dust
hazards associated with each work piece material.
7. NEVER introduce sparks or sources of ignition.
8. ENSURE all equipment and connections are electrically grounded.
9. ONLY operate in locations that has a re extinguisher available nearby.
10. ALWAYS dispose of waste in a re safe area aer each use. NEVER
leave wood dust in a building or vehicle. Wood dust mixtures are highly
ammable and can be explosive.
READ THE SAFETY PRACTICES, INSTALLATION
AND MAINTENANCE INSTRUCTIONS, AND YOUR
WET/DRY VACUUM’S OWNER’S MANUAL BEFORE
ASSEMBLING AND USING THE DUST DEPUTY.
SOME DUSTS ARE HIGHLY FLAMMABLE OR
EXPLOSIVE. LEARN/ KNOW WHAT YOU ARE
DEALING WITH. FOLLOW ALL LOCAL, STATE,
FEDERAL & NFPA CODES AND GUIDELINES.

Oneida Air Systems4
18-1/2"
470 mm
5-1/16"
129 mm
3-13/16"
98 mm
Nominal dimensions shown. Dimensions subject to slight varia-
tions in manufacturing.
12-3/8"
315 mm
As installed on a
5 Gallons
19 Liters
Bucket
System Dimensions

5oneida-air.com
13-1/2"
343 mm
Tapered Inlet
and Outlet
2-5/16"
59 mm
18-1/2"
470 mm
3-13/16"
98 mm
Nominal dimensions shown. Dimensions subject to slight varia-
tions in manufacturing.
As installed on a
5 Gallons
19 Liters
Bucket
System Dimensions

Oneida Air Systems6
System Contents
ID Part number Part description Qty
A SDL250000 Lid Separator 1
B RGZ582599 5/8 x 40" Gasket 1
C RGZ031640 1/4 x 40" Gasket 1
D AHX000035 Latch Hardware Pack 2
D1 AFL000009 Latch 1
D2 AFS000012 6-32 x 5/8" Pem Stud 1
D3 AFC230213 Wire Spring Clip 1
D4 AFW188075 3/4" Flat Washer 1
D5 AFT000020 6-32 Wing Nut 1
E VFA050015 Metal Grounding Tape 30"
INCLUDED ONLY WITH DELUXE SYSTEMS
F SDS050002 5-Gallon, 100-Mil, Plastic Bucket 1
G RHB000000 Caster Mounts (4 Pack) 1
H AFQ080101 Double Sided Tape 1
I RHC158716 Casters (4 Pack) 1
J RHS000004 Tether Pack 1
J1 AFS080375 #8 x 3/8 Sheet Metal Screw 1
J2 AFB148000 D ring with clip 1
J3 AFC000007 PSA Retainer Clip 1
J4 AFB100000 Split ring 1
J5 AFH343800 Lanyard 1
K AXD200036A 2" x 36" Hose 1
L AXD600103A 2" Elbow 2

7oneida-air.com
System Contents
D1
D1
D2
D2
D3
D3
D3
D3
D4
D4
B CA
D
K L
J1
J2
J3
J4
J5
GF H
I
J
E

Oneida Air Systems8
Assembly Instructions
Secure each Pem Stud (D2) to the Lid Separator (A)
through the holes as shown in [FIG. 1].
1
D2
You will need the following:
• Phillips Head Screwdriver
• Bucket
• Scissors / Razor Blade
• Wet/Dry Vacuum
• Vacuum hose and adapters
(2.5" recommended)
FIG. 1

9oneida-air.com
Assembly Instructions
Apply the 5/8" Gasket (B) onto the Lid Separator (A) along
the underside rim. [FIG. 2]
Apply the 1/4" Gasket (C) perpindicular to the 5/8" Gasket
along the lip of the Lid Separator. e 1/4" Gasket will
follow the inner diameter of the 5/8" Gasket. [FIG. 2]
Note: e Gasket should overlap around the circumference,
rmly pressing against itself to avoid air leaks. Dust collection
systems cannot operate eectively if there isn’t a complete seal.
ere must be NO air leaks.
2
B
B
C
B
C
C
FIG. 2

Oneida Air Systems10
Secure each Latch (D1) to the previously installed Pem Stud
(D2) on the Lid Separator (A) using one Wire Spring Clip
(D3), one Washer (D4), and one Wing Nut (D5) as shown
in [FIG. 3].
Note: Refer to Optional Grounding Instructions prior to
instaling the Latch Hardware Pack (D) if necessary.
3
Assembly Instructions
FIG. 3
D1
D5
D4
D3
D2

11oneida-air.com
Assembly Instructions (Continued)
If you did not purchase the Deluxe Unit, proceed to Step 9.
Insert the Casters (I) into the Caster Mounts (G). Apply
pressure and twisting motion until Wheels snap into place
[FIG. 4].
Ensure that the surfaces on the Bucket (F) and Caster
Mounts (G) are clean and dry. Remove a square from the
Double Sided Tape (H) and apply to the Caster Mount in
the recessed location at each corner [FIG 5].
FIG. 4
FIG. 5
5
I
G
G
4

Oneida Air Systems12
Assembly Instructions (Continued)
Flip the Bucket (F) upside down and arrange the Caster
assemblies evenly around the bottom edge [FIG. 6].
Note: We recommend arranging the Caster Assemblies at 90°
increments from each other for the most stable setup.
6
FIG. 6
90°

13oneida-air.com
Assembly Instructions (Continued)
FIG. 7b
FIG. 7a
e Caster assemblies must be adhered to the Bucket (F)
with a single smooth motion so that the bottom edge of the
Bucket ts within the recessed channel of the Caster Mount
[FIG. 7a].
Remove the backing paper from the Double Sided Tape (H)
on the Caster assembly. Rest the lip of the Caster assembly
against the bottom of the Bucket and then rotate the Caster
assemblies ush against the side of the Bucket. Press rmly
for a secure t [FIG. 7b].
Note: Optional step to more securely attach the Caster
Mounts to the Bucket we recommend a ¼"-20 nut and ¼"-20
x 1/2" bolt (not included).
7
To further Secure
the Caster Mount
Recessed
channel
F
G
G
F

Oneida Air Systems14
Assembly Instructions (Continued)
e Dust Deputy Low Pro Deluxe can be attached to your
wet/dry vacuum to move as one unit. e Tether Pack (J)
includes a variety of components to meet the needs of any
make/model vacuum. Examine your vacuum conguration
rst to review what option works best. You are not limited
to the below options:
a. Attach the Split Ring (J4) to the slot on the Caster
Mount (G) and attach the Retainer Clip (J3) onto
your vacuum's foot caster. en loop the Lanyard (J5)
around your vacuum's foot caster and through itself
and the Retainer Clip. Finally, clip the Lanyard to the
Split Ring. [FIG 8a]
b. Attach the D ring (J2) to the vacuum with the Sheet
Metal Screw. (J1) en loop the Lanyard (J5) around
the slot on the Caster Mount and through itself.
Finally, clip the Lanyard to the D ring [FIG 8b] [FIG
8c].
8
FIG. 8a
J4
J5
J3

15oneida-air.com
FIG. 8c
FIG. 8b
Assembly Instructions (Continued)
J1
J2
J5
J1
J2
J5

Oneida Air Systems16
FIG. 10a FIG. 10b
To Tool
To Tool
If you purchased the Deluxe Unit, connect the Low-Pro's
(A) top outlet port to your vacuum with Hose (K) and both
Elbows (L) as shown in [FIG. 10a].
If you purchased the DIY Unit, connect the Low-Pro's top
outlet port to your vacuum with your hose [FIG 10b].
Connect the Low-Pro's side inlet port to your tool with your
vacuum's hose [FIG. 10a] [FIG. 10b].
Note: Both ports accept standard 2.5" hose cus (OD ≈ 2.25").
10
FIG. 9
Assembly Instructions (Continued)
Snap the Low-Pro assembly onto your bucket – either (F) or
your own – and ensure that the Latches (D1) are fully seated
with the lip of your bucket [FIG. 9]. e Wing Nut (D5) can
be loosened to slide the Latch tighter to the bucket lip.
Note: It's normal for the Low-Pro to t loosely but it will seal
rmly shut under vacuum pressure. To empty your bucket, li
up on the latches and pull up on the Low-Pro.
9
To vacuum
To vacuum
A
A
L
L
K

17oneida-air.com
Assembly Instructions (Continued)
FIG. 11
Make sure there are no air leaks at the connections. Review
[FIG. 11] for common leak points.
Note: Any air leak will aect separation performance. Make
sure to check your dust drum frequently so you do not overll
it. One option to check for air leaks is with a smoke test. Test
kits are found at most hardware stores in the HVAC section.
Introduce smoke around every leak point. If you see the smoke
being drawn into the system, you’ve found an air leak that
needs to be sealed.
11
Leak Point
(Inlet)
Leak Point
(Low-Pro/bucket)
Leak Point
(Outlet)

Oneida Air Systems18
Recommended for fine dust situations or electronically
sensitive applications.
FIG. 12
Install the Metal Tape (K) to the Lid Separator (A) so that
the inlet, outlet, and ange are attached by a continuous,
conductive path. e tape should wrap 1/4" around the edge
of each opening [FIG 12].
1
Optional Grounding Instructions

19oneida-air.com
FIG. 13
Washer
Wire
For added grounding, attach a self-supplied wire with a
ring terminal on one end and a washer tied to the other end
when installing one of the latches in step 3. e wire must be
long enough for the washer to lie on the oor [FIG 13].
2
Optional Grounding Instructions (Continued)

Oneida Air Systems20
Troubleshooting
PROBLEM CAUSE SOLUTION
Not separating well.
(Only a tiny amount of dust
should reach the vacuum)
Air leaks in the
bucket
1. Check for leaks between the Low-Pro Lid Separator and the bucket.
2. Check for holes or leaks in the bucket.
Material not dropping
into the dust container.
Collecting large,
bulky material
1. Large, bulkier material might swirl. Restart or temporarily cut o
airow to drop material down.
Low air volume System clogged 1. Clean vacuum and the vacuum lter per the manufacturer's specs.
2. Check all hose connections for a blockage in the hose.
Drum collapsing Blocked airow 1. Ensure the end of the hose isn't blocked.
Hose pulling o Hose connections
not tight
1. Due to the varied hose diameters, exible couplers can be used.
They are available at local hardware stores in the plumbing section.
2. Use a hose clamp.
3. Wrap the inlet and outlet of the Low-Pro with a layer of electrical
tape to increase the friction t.
4. Secure hose with a sheet metal screw.
