Onkyo DV-C600 User manual

DVD Changer
DV-C600
Instruction Manual
Thank you for purchasing the ONKYO DVD Changer.
Please read this manual thoroughly before making
connections and turning on the power.
Following the instructions in this manual will enable
you to obtain optimum performance and listening
enjoyment from your new DVD Changer.
Please retain this manual for future reference.
Contents
6
10
14
32
Getting Started
Connections
Function Setup
Before UsingYour DVD Changer 2
THIS DVD CHANGER IS MANUFACTURED FOR
PLAYBACK OF REGION 2 (EUROPE) ENCODED DVD
SOFTWARE. USE OF SOFTWARE NOT INTENDED FOR
REGION 2 PLAYBACK MAY RESULT IN UNDESIRABLE
PLAYER PERFORMANCE.
OPEN/CLOSE PLAY
POWER
OFF
STOPPAUSE
DISC 1 DISC 2 DISC 3 DISC 4 DISC 5 DISC 6
NEXT SELECTION
REPEAT
DVD CHANGER DV-C600
ON
DIMMER DISPLAY
DISC SKIP
DISC
123456
STANDBY/ON
20
Advanced Playback
40
Others
Basic Playback

2
1. Read Instructions -All the safety and operating instructions should
be read before the appliance is operated.
2. Retain Instructions - The safety and operating instructions should
be retained for future reference.
3. HeedWarnings - All warnings on the appliance and in the operating
instructions should be adhered to.
4. Follow Instructions -All operating and use instructions should be
followed.
5. Water and Moisture - The appliance should not be used near water
- for example, near a bathtub, washbowl, kitchen sink, laundry tub,
in a wet basement, or near a swimming pool, and the like.
6. Carts and Stands - The appliance should
be used only with a cart or stand that is
recommended by the manufacturer.
6A. An appliance and cart combination should
be moved with care. Quick stops,
excessive force, and uneven surfaces may
cause the appliance and cart combination
to overturn.
7. Wall or Ceiling Mounting - The appliance should be mounted to a
wall or ceiling only as recommended by the manufacturer.
8. Ventilation - The appliance should be situated so that its location
or position does not interfere with its proper ventilation. For example,
the appliance should not be situated on a bed, sofa, rug, or similar
surface that may block the ventilation openings; or if placed in a
built-in installation, such as a bookcase or cabinet that may impede
the flow of air through the ventilation openings, there should be free
space of at least 5 cm (2 in.) and an opening behind the appliance.
9. Heat - The appliance should be situated away from heat sources
such as radiators, heat registers, stoves, or other appliances
(including amplifiers) that produce heat.
10. Power Sources - The appliance should be connected to a power
supply only of the type described in the operating instructions or as
marked on the appliance.
11. Polarization - If the appliance is provided with a polarized plug
having one blade wider than the other, please read the following
information:
The polarization of the plug is a safety feature. The polarized plug
will only fit the outlet one way. If the plug does not fit fully into the
outlet, try reversing it. If there is still trouble, the user should seek
theservices of aqualified electrician.Under nocircumstances should
the user attempt to defeat the polarization of the plug.
12. Power-Cord Protection - Power-supply cords should be routed so
that they are not likely to be walked on or pinched by items placed
upon or against them, especially near plugs, convenience
receptacles, and the point where they exit from the appliance.
13. Cleaning - The appliance should be cleaned only as recommended
by the manufacturer.
14. Nonuse Periods - The power cord of the appliance should be
unplugged from the outlet when left unused for a long period of
time.
15. Object and Liquid Entry - Care should be taken so that objects do
notfalland liquids arenotspilled into theenclosurethrough openings.
16. Damage Requiring Service - The appliance should be serviced
by qualified service personnel when:
A. The power-supply cord or the plug has been damaged; or
B. Objects have fallen, or liquid has been spilled into the
appliance; or
C. The appliance has been exposed to rain; or
D. The appliance does not appear to operate normally or
exhibits a marked change in performance; or
E. The appliance has been dropped, or the enclosure damaged.
17. Servicing - The user should not attempt to service the appliance
beyondthat described in the operating instructions.All other servicing
should be referred to qualified service personnel.
Important Safeguards
WARNING:
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT
REMOVE COVER (OR BACK). NO USER-SERVICEABLE
PARTS INSIDE. REFER SERVICING TO QUALIFIED
SERVICE PERSONNEL.
The lightning flash with arrowhead symbol, within an equilateral
triangle, is intended to alert the user to the presence of uninsulated
“dangerous voltage” within the product’s enclosure that may be of
sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to
alert the user to the presence of important operating and maintenance
(servicing) instructions in the literature accompanying the appliance.
WARNING
RISK OF ELECTRIC SHOCK
DO NOT OPEN RISQUE DE CHOC ELECTRIQUE
NE PAS OUVRIR
AVIS
PORTABLE CART WARNING
S3125A
Declaration of Conformity
We, ONKYO EUROPE
ELECTRONICS GmbH
INDUSTRIESTRASSE 20
82110 GERMERING,
GERMANY
GERMERING, GERMANY
ONKYO EUROPE ELECTRONICS GmbH
K.OTSU
declare in own responsibility, that the ONKYO product described
in this instruction manual is in compliance with the corresponding
technical standards such as EN60065, EN55013, EN55020 and
EN61000-3-2, -3-3 (or EN60555-2, -3)

3
DANGER:
INVISIBLE LASER RADIATION WHEN OPEN AND INTER-
LOCK FAILED OR DEFEATED. AVOID DIRECT EXPOSURE
TO BEAM.
CAUTION:
THIS PRODUCT UTILIZES A LASER. USE OF CONTROLS
ORADJUSTMENTS OR PERFORMANCE OF PROCEDURES
OTHER THAN THOSE SPECIFIED HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
For European model
This unit contains a semiconductor laser system and is classified as a
“CLASS 1 LASER PRODUCT.” So, to use this model properly, read
this Instruction Manual carefully. In case of any trouble, please contact
the store where you purchased the unit. To prevent being exposed to
the laser beam, do not try to open the enclosure.
“CLASS 1 LASER
PRODUCT”
This label on the rear panel states that:
1. This unit is a CLASS 1 LASER PRODUCT and employs a laser
inside the cabinet.
2. To prevent the laser from being exposed, do not remove the cover.
Refer servicing to qualified personnel.
Precautions
For British model
Replacement and mounting of anAC plug on the power supply cord of
this unit should be performed only by qualified service personnel.
IMPORTANT
The wires in the mains lead are coloured in accordance with the
following code:
Blue : Neutral
Brown : Live
As the colours of the wires in the mains lead of this apparatus may not
correspond with the coloured markings identifying the terminals in your
plug, proceed as follows:
The wire which is coloured blue must be connected to the terminal
which is marked with the letter N or coloured black.
The wire which is coloured brown must be connected to the terminal
which is marked with the letter L or coloured red.
IMPORTANT
A 5 amp fuse is fitted in this plug. Should the fuse need to be replaced,
please ensure that the replacement fuse has a rating of 5 amps and
that it is approved by ASTA or BSI to BS1362. Check for the ASTA
mark or the BSI mark on the body of the fuse.
IF THE FITTED MOULDED PLUG IS UNSUITABLE FOR THE
SOCKET OUTLET IN YOUR HOME THEN THE FUSE SHOULD BE
REMOVEDAND THE PLUG CUT OFFAND DISPOSED OF SAFELY.
THERE IS A DANGER OF SEVERE ELECTRICAL SHOCK IF THE
CUT OFF PLUG IS INSERTED INTO ANY 13AMP SOCKET.
If in any doubt, please consult a qualified electrician.

4
1.Warranty Claim
You can find the serial number on the rear panel of this unit. In case
of warranty claim, please report this number.
2.Recording Copyright
Recording of copyrighted material for other than personal use is
illegal without permission of the copyright holder.
3.Power
WARNING
BEFORE PLUGGING IN THE UNIT FOR THE FIRSTTIME, READ
THE FOLLOWING SECTION CAREFULLY.
Thevoltage of the available power supply differs according to country
or region. Be sure that the power supply voltage of the area where
this unit will be used meets the required voltage (e.g.,AC 230 V, 50
Hz or AC 120 V, 60 Hz) written on the rear panel.
Worldwide models are equipped with a voltage selector to conform
to local power supplies. Be sure to set this switch to match the
voltage of the power supply in your area before plugging in the unit.
4.Do not touch this unit with wet hands
Do not handle this unit or power cord when your hands are wet or
damp. If water or any other liquid enters the case, take this unit to
an authorized service center for inspection.
5. Location of this unit
• Place this unit in a well-ventilated location.
Take special care to provide plenty of ventilation on all sides of this
unit especially when it is placed in an audio rack. If ventilation is
blocked, this unit may overheat and malfunction.
• Do not expose this unit to direct sunlight or heating units as this
unit's internal temperature may rise and shorten the life of the pickup.
• Avoid damp and dusty places and places directly affected by
vibrations from the speakers. In particular, avoid placing the unit on
or above one of the speakers.
• Be sure this unit is placed in a horizontal position. Never place it on
its side or on a slanted surface as it may malfunction.
• When you place this DVD Changer near a TV, radio, or VCR, the
playback picture may become poor and the sound may be distorted.
In this case, place the DVD Changer away from the TV, radio, or
VCR.
6.Care
From time to time you should wipe the front and rear panels and
the cabinet with a soft cloth. For heavier dirt, dampen a soft cloth in
a weak solution of mild detergent and water, wring it out dry, and
wipe off the dirt. Following this, dry immediately with a clean cloth.
Do not use rough material, thinners, alcohol or other chemical
solvents or cloths since these could damage the finish or remove
the panel lettering.
7.Notes on Handling
• When shipping the DVD Changer, use the original shipping carton
and packing materials. For maximum protection, repack the unit as
it was originally packed at the factory.
• Do not use volatile liquids, such as insect spray, near the DVD
Changer. Do not leave rubber or plastic products in contact with the
DVD Changer for a long time. They will leave marks on the finish.
• The top and rear panels of the DVD Changer may become warm
after a long period of use. This is not a malfunction.
• When the DVD Changer is not in use, be sure to remove the disc
and turn off the power.
• If you do not use the DVD Changer for a long period, the unit may
not function properly in the future. Turn on and use the DVD Changer
occasionally.
Precautions
8.To Obtain a Clear Picture
The DVD Changer is a high technology, precision device. If the
optical pick-up lens and disc drive parts are dirty or worn down, the
picture quality becomes poor. To obtain a clear picture, we
recommend regular inspection and maintenance (cleaning or parts
replacement) every 1,000 hours of use depending on the operating
environment. For details, contact your nearest dealer.
9.Notes on Moisture Condensation
Moisture condensation damages the DVD Changer.
Please read the following carefully.
Moisture condensation occurs, for example, when you pour a cold
drink into a glass on a warm day. Drops of water form on the outside
of the glass. In the same way, moisture may condense on the optical
pick-up lens inside this unit, one of the most crucial internal parts of
the DVD Changer.
E
x
a
m
p
l
e
s
o
f
m
o
i
s
t
u
r
e
c
o
n
d
e
n
s
a
t
i
o
n
• Moisture condensation occurs in the following cases.
- When you bring the DVD Changer directly from a cold place to a
warm place.
- When you use the DVD Changer in a room where you just turned
on the heater, or a place where the cold wind from the air conditioner
directly hits the unit.
- In summer, when you use the DVD Changer in a hot and humid
place just after you move the unit from an air conditioned room.
- When you use the DVD Changer in a humid place.
• Do not use the DVD Changer when moisture condensation may
occur.
If you use the DVD Changer in such a situation, it may damage
discs and internal parts. Remove the disc, connect the power cord
of the DVD Changer to the wall outlet, turn on the DVD Changer,
and leave it for two or three hours. After a few hours, the DVD
Changer will have warmed up and evaporated any moisture. Keep
the DVD Changer connected to the wall outlet and moisture
condensation will seldom occur.

5
Table of Contents
Important Safeguards/Precautions/Table of Contents ....................................................................................................2–5
Handling Discs .......................................................... 9
Cleaning Discs .......................................................... 9
Storing Discs ............................................................. 9
About Region Numbers .............................................9
Notes on Copyright.................................................... 9
Connecting to an Amplifier Equipped
with a DTS Decoder ................................................ 12
Connecting to an Amplifier Equipped
with a Digital Audio Input ......................................... 12
Connecting to an Amplifier Equipped
with a MPEG 2 Audio Decoder ................................ 13
Playing back Discs .......................................................14
Basic Playback ........................................................ 14
Direct Playback, Stop and Pause............................ 16
Fast Reverse and Fast Forward Playback .............. 16
Slow-Motion Playback ............................................. 17
Resuming Playback From the Desired Location ..... 17
Locating Titles, Chapters, or Tracks............................. 18
Locating a Title Using the Title Menu ...................... 18
Title Selection with the Numeric Buttons .................18
Selecting Chapters or Tracks .................................. 19
Selecting a Precise Scene or Audio Passage.............. 20
Entering the Time Location...................................... 20
Repeat Functions ......................................................... 21
Repeating a Title or Chapter/Track.......................... 21
Repeating a Given Scene or Passage .................... 21
Setting the Desired Playback Order............................. 22
Programming Memory Sequences.......................... 22
Additional Playback Functions ..................................... 24
Next Selection: Preparing the next Audio Track ...... 24
Using the DVD Changer as CD player ....................25
Random Playback ................................................... 26
DVD Video Disc Functions ...........................................27
Zooming in............................................................... 27
Changing the Camera Angle ................................... 27
Audio Playback Settings.......................................... 28
Using the Subtitle Feature....................................... 30
Using The On-Screen Display Functions.....................31
Requesting Basic Information ................................. 31
More Specific Information: Remaining Time
and Setting Status ...................................................31
Advanced Settings........................................................ 32
Setting Procedure.................................................... 32
LANGUAGE Functions ............................................ 34
PICTURE Settings................................................... 35
AUDIO Settings ....................................................... 36
Troubleshooting ............................................................ 40
Symptoms and Corrections .....................................40
Identification of Controls............................................... 41
Front Panel .............................................................. 41
Rear Panel .............................................................. 41
DISPLAY Settings.................................................... 37
OPERATION Settings.............................................. 37
Table of Languages ...................................................... 39
Table of Languages and Their Abbreviations ..........39
DVD Display ............................................................ 42
Remote Controller ................................................... 43
Specifications................................................................44
DVD Changer/Outputs ............................................ 44
Features.......................................................................... 6
Supplied Accessories ..................................................... 7
Preparing the Remote Controller ................................... 8
Installing the remote controller batteries ................... 8
Using the remote controller ....................................... 8
Notes on the Discs You Can Use with this Unit ............. 9
Discs You can Use .................................................... 9
Connecting the DV-C600 to a TV ................................. 10
Connecting the DV-C600 to a TV ............................10
Other Audio Playback Options ..................................... 11
Connecting to an Amplifier Equipped
with a Dolby Digital Decoder ................................... 11
Connecting to an Amplifier Equipped
with Dolby Pro Logic Surround ................................ 11
Getting Started
Connections
Basic Playback
Advanced Playback
Function Setup
Others

6
Getting Started
Features
■Highlights that Set the DV-C600
• Dolby®* Digital Audio Output
• 6-Disc playback (instead of the usual five)
• DTS®** Compatibility
• Full 96-kHz/24-bit resolution with 96-kHz/24-bit discs
(some players don’t play these discs, and some play them
by downsampling the signal to a lower 48-kHz sampling
rate, or reducing the resolution to 20 bits or less, or both)
• Enhanced black-level setting (another uncommon feature)
• Aluminum front panel (distinguishes the DV-C600 from
mass-market models)
■Video Features
•DTS
®Compatibility means the DV-C600 can pass a DTS-
encoded digital signal from discs with DTS soundtracks to
an external processor or receiver with a DTS decoder
• Advanced 10-Bit 27 MHz Video D/AConversion for four
times the accuracy of conventional 8-bit, 13.5 MHz
systems
• 3-Mode Picture Magnification enables you to “zoom”in and
enlarge in three steps 25 selected areas of the picture
• Enhanced Black-Level Control lets you set the reference
black threshold cutoff-especially useful for picture calibra-
tion on TVs
• Passes PLUGE Signals to make it easier for you to set the
brightness of your monitor when using DVD test discs
• High Resolution Onscreen Display
• S-Video Output
• Full-Time Active Video Outputs to make using the DVD
changer with both the main home-theater television and
the display in the bedroom much easier
• 4-Mode Search (title, DVD chapter, CD track, and time)
• Still Frame to view single frames
• Frame Advance
• Slow Motion for DVD playback without sound at 1/2, 1/4,
or 1/8th the normal speed
• Fast Forward/Reverse (x2, x8, x30)
• Last Memory Play function for both DVDs and CDs-
resumes play from where last stopped, even if the power
was turned off
• 6-Mode Repeat allows you to repeat titles, chapters,
tracks, all tracks, memory, and a user-selected A-B
section on DVDs and CDs
• Programmed Memory Playback
• Random Playback
• Multi-Aspect Ratio
• 8-Language Soundtrack Capability
• 32 Subtitle Languages
• Multi-Camera Angle
• Parental Viewing Control
• Screen Saver
■Audio Features
• Audiophile-Class Audio Performance
• Full 96-kHz/24-Bit Audio Resolution
• Digital Audio Output (coaxial)
• Optical Digital Audio Output
• 1 Pair of Analog Outputs (RCA)
■Other Features You’ll Enjoy
• 5-Disc Exchange
• CD Mode (DVD Skip) Control
• Next Selection
• Direct Disc Access
• Separate LEDs for Each Disc (1 to 6)
• Dual-Focus Optical Pickup
• Dynamic Range Control
• Large, Bright, 14-Segment Fluorescent Display
• 2-Mode Display Dimmer (normal, dim)
• Anti-Resonant, Heavy-Gauge, Reinforced-Steel Chassis
• Large Anti-Resonant Feet
• Heavy-Duty Power Cord
• Brushed Aluminum Front Panel
• 54-Key Full-Function Remote Control
* Manufactured under license from Dolby Laboratories. “Dolby” and
the double-D symbol are trademarks of Dolby Laboratories.
Confidential Unpublished Works.
©1992-1997 Dolby Laboratories, Inc. All rights reserved.
** “DTS” and “DTS Digital Surround” are trademarks of Digital
Theater Systems, Inc.
About This Manual
This manual explains the basic procedures for operating
your DVD Changer. Some DVD video discs do not
support the full potential of the DVD technology. Your DVD
Changer may therefore not respond to all operating
commands. Refer to instruction notes on discs.
A “ ” mark may appear on the TV screen during
operation. It means that the operation is not permitted by
the DVD Changer or the disc.

7
Getting Started Connections Function Setup
Advanced Playback Others
Basic Playback
SuppliedAccessories
REMOTECONTROLLERRC-
406DVby
After unpacking, check whether the box
contains all items listed below.
If anything is missing, contact the ONKYO
dealer where you bought the DVD Changer.
The number of accessories is indicated in
brackets.
Remote controller (RC-406DV) [1] Batteries for the remote controller (size AA) [2]
Audio/video connection cable [1] S video cable [1]
cable [1]

8
Installing the remote controller batteries
1Remove the battery compartment cover by pressing
and sliding it away from the remote controller unit.
2Insert two AA-size batteries into the battery compart-
ment. Carefully follow the polarity diagram (positive
(+) and negative (–) symbols) inside the battery
compartment.
3After batteries are installed and seated correctly,
replace the compartment cover.
Notes:
• Do not mix new batteries with old batteries or different
kinds of batteries.
• To avoid corrosion, remove the batteries if the remote
controller is not to be used for a long time.
• Remove dead batteries immediately to avoid damage
from corrosion. If the remote controller doesn’t operate
smoothly, replace both the batteries at the same time.
• The life of the batteries supplied is about six months but
this will vary depending on usage.
Using the remote controller
Point the remote controller toward the remote control
sensor.
Notes:
• Place the unit away from strong light such as direct
sunlight or inverted fluorescent light which can prevent
proper operation of the remote controller.
• Using another remote controller of the same type in the
same room or using the unit near equipment which uses
infrared rays may cause operational interference.
• Do not put any object such as a book on the remote
controller. The buttons of the remote controller may be
pressed by mistake and drain the batteries.
• Make sure the audio rack doors do not have colored
glass. Placing the unit behind such doors may prevent
proper remote controller operation.
• If there is any obstacle between the remote controller and
the remote control sensor, the remote controller will not
operate.
Preparing the Remote Controller
DV-C600
STANDBY indicator
Remote control sensor
30˚ 30˚ approx. 5 m
(16 feet)
3
2
1

9
Getting Started Connections Function Setup
Advanced Playback Others
Basic Playback
Notes on the DiscsYou Can Use with this Unit
Discs You can Use
Your DVD Changer can play back the following discs:
• You cannot play back discs other than those listed above.
• You cannot play back discs such as VCD (VIDEO CD) ,
CD-R, CD-RW, CD-ROM, DVD-RAM, DVD-RW, etc., even
though they may be labelled with one of the above logos.
• This DVD Changer uses the PAL/NTSC color system, and
cannot play back DVD videos recorded in any other color
system (SECAM, etc.).
• Avoid using heart-shaped or octagonal discs. Playing
irregularly shaped discs may damage the DVD Changer’s
internal mechanism.
• Do not use discs that contain adhesive tape or a disc label
(on rental discs). Otherwise, you may not be able to eject
the discs, or the DVD Changer may become inoperative.
Handling Discs
• Never touch the playback side (the “blank” side) of the
disc.
• Never attach paper or tape to discs.
Cleaning Discs
• Fingerprints and dust on the disc cause a deterioration of
the picture and sound quality. Wipe the disc from the center
outwards with a soft cloth.Always keep the discs clean.
• Stubborn dust or dirt can be removed by wiping the disc
lightly with a slightly moistened soft cloth and finishing
with a dry cloth.
• Never use solvents such as thinner, benzine, commer-
cially available cleaners, or antistatic spray for vinyl LPs.
They may damage the disc.
Storing Discs
• Do not store discs in places subject to direct sunlight or
near heat sources.
• Do not store discs in places subject to moisture and dust,
such as in a bathroom or near a humidifier.
• Store discs vertically in their case. Stacking or placing objects
on unprotected discs may cause warping and scratches.
About Region Numbers
The region number of this DVD Changer is “2”. This number
refers to the coding format of the discs that can be played
back and is only important for DVD video discs. If the region
number of the DVD video disc you are trying to play back is
different from “2”, that is, if the disc neither contains the
nor the symbol, the DV-C600 cannot play it back. (In this
case, your DVD Changer displays a warning message.)
Notes on Copyright
It is forbidden by law to copy, broadcast, show, broadcast on cable,
play in public, and rent copyrighted material without permission.
DVD video discs are copy protected, and any copy made
from these discs will be distorted.
This product incorporates copyright protection technology that is
protected by method claims of certain U.S. patents and other
intellectual property rights owned by Macrovision Corporation
and other rights owners. Use of this copyright protection
technology must be authorized by Macrovision Corporation, and
is intended for home and other limited viewing uses, unless
otherwise authorized by Macrovision Corporation. Reverse
engineering or disassembly is prohibited.
In this section, you will learn which discs can be used with your DV-C600, and how to handle, clean, and store them.
Playback side
Disc mark Contents
Audio
+
Video
(moving
pictures)
Audio
Disc
size
12 cm
8 cm
12 cm
8cm
(CD
single)
Maximum
playback time
Approx. 4 hours
(single sided disc)
Approx. 8 hours
(double-sided disc)
Approx. 80 minutes
(single-sided disc)
Approx. 160 minutes
(double-sided disc)
Approx. 74 minutes
Approx. 20 minutes
DVD
videos
Audio
CDs

10
Connecting the DV-C600 to a TV
Here is how to connect your DVD Changer to your TV set. In this case, both the video and audio signals will be played back by
your TV set.
Connecting the DV-C600 to a TV
1. Switch off the DVD Changer and the TV set.
2. Connect the DV-C600 to your TV set as shown in the illustration.
■Selecting the audio outputs
Your DV-C600 provides several options for audio playback: you can use the analog or one of the digital audio outputs. If the
audio is to be played back by your TV set, connect theANALOG OUTPUTs to the audio inputs of your TV set and activate them
(“Analog 2ch”). See “Audio Settings” on page 36 for details.
Notes:
• See also the instruction manual of the connected TV on how to select the signals transmitted by the DVD Changer.
• Before connecting the DVD Changer to your TV, be sure to turn off the power to and unplug both units from the wall outlet.
• If your TV set has one audio input (monaural), connect a Y cable adapter to the DV-C600’sANALOG OUTPUTs, and the other end of the
adapter to the TV’s audio input.
• Be sure to establish a direct video connection between the DV-C600 and your TV set. Do not route the video signal through your VCR or other
video component. Otherwise the picture may be distorted due to the DVD disc’s copy protection.
L
R
ANALOG
OUTPUT
OPTICAL
COAXIAL
REMOTE
CONTROL
D I G I TAL
OUTPUT
REGIONAL CODE 2
VIDEO OUTPUT
VIDEO
S VIDEO
"CLASS 1 LASER
PRODUCT"
2
(white)
Signal flow
To ANALOG
AUDIO OUT
To audio inputs
(white)
(red)
Audio·video cable (supplied)
To wall outlet
To
VIDEO
OUT
To S VIDEO OUT
S video cable (supplied)
If the TV has an S video input, connect the
DVD changer with the supplied S video cable.
To S video input
TV or monitor with
audio and video inputs
(red)
(yellow)
To video input
(yellow)
Power plug
