Onnet technologies curro User manual

w w w . o n n e t t e c h n o l o g i e s . c o m
U S E R M A N U A L

Copyright Statement
is the registered trademark of Onnet Technologies (India) Pvt. Ltd All the products and product names
mentioned herein are the trademarks or registered trademarks of their respective holders. Copyright of the whole product
as integration, including its accessories and software, belongs to Onnet Technologies (India) Pvt. Ltd Without the
express permission of Onnet Technologies (India) Pvt. Ltd, any individual or party is not allowed to copy, plagiarize,
imitate or translate it into other languages.
All the photos and product specifications mentioned in this manual are for references only. As the upgrade of software and
hardware, there will be changes. And if there are changes, Onnet Technologies is not responsible for informing in
advance. If you want to know more about our product information, please visit our website at
www.onnettechnologies.com
2

Wireless
Anywhere Anytime online
Onnet 3GR series of 3g enabled routers.
"Anywhere Anytime"
3

Table of Content
4
FCC Caution ..................................................................................................................................................................6
Chapter 1 Introduction................................................................................................................................................7
1.1 Overview ...................................................................................................................................................9
1.2 Features ....................................................................................................................................................9
1.3 Specifications ..........................................................................................................................................10
1.4 Product Appearance ................................................................................................................................11
Chapter 2 System and Network Setup.....................................................................................................................12
2.1 Build Network Connection .......................................................................................................................12
2.1.1 Router Mode ..............................................................................................................................12
2.1.2 AP Mode ....................................................................................................................................12
2.1.3 Wi-Fi AP Mode ...........................................................................................................................13
2.2 Connecting Onet 3GUSB-4SWRouter ....................................................................................................13
2.3 Network setup .........................................................................................................................................14
2.3.1 Windows 2000 ...........................................................................................................................14
2.3.2 Windows XP...............................................................................................................................15
2.3.3 Windows Vista / Windows 7.......................................................................................................15
2.4 Router IP Address Lookup ......................................................................................................................16
2.4.1 Log into Web GUI.......................................................................................................................16
Chapter 3 Internet Connection .................................................................................................................................18
3.1 Plug and Play ..........................................................................................................................................18
3.1.1 SmartPhone /iPhone Intternet sharing plug and play ................................................................18
3.2 Router Mode- Using as a broadband router............................................................................................20
3.2.1 WAN Interface- Ethernet Port ....................................................................................................20
3.2.1.1 Static IP......................................................................................................................................21
3.2.1.2 DHCP Client...............................................................................................................................22
3.2.1.3 PPPoE .......................................................................................................................................23
3.2.1.4 PPTP..........................................................................................................................................24
3.2.1.5 L2TP...........................................................................................................................................25
3.2.2 WAN Interface- 3.5G USB dongle..............................................................................................26
3.2.3 WAN Interface- Wireless............................................................................................................27
3.3 AP Mode-Using as a Access Point..........................................................................................................28
3.4 WiFi AP Mode- Using as a Network Converter .......................................................................................30
Chapter 4 Wireless Setup ........................................................................................................................................32
4.1 Wireless Setup ........................................................................................................................................32
4.1.1 Setup Wireless LAN by WPS button..........................................................................................32
4.1.2 Wireless Basic Setup from Web GUI .........................................................................................34
4.1.2.1 Multiple APs ...............................................................................................................................35
4.1.2.2 Enable Universal Repeater Mode ..............................................................................................36
4.2 Wireless Security Setup ..........................................................................................................................38
4.3 Wireless Access Control..........................................................................................................................40
Chapter 5 Router Mode Security Setup ...................................................................................................................42
5.1 NAT ...................................................................................................................................................42
5.1.1 Virtual Server...........................................................................................................................................42

5
5.1.2 Virtual DMZ ................................................................................................................................43
5.2 Firewall ...................................................................................................................................................43
5.2.1 QoS............................................................................................................................................44
5.2.2 Port Filtering...............................................................................................................................45
5.2.3 IP Filtering..................................................................................................................................46
5.2.4 MAC Filtering .............................................................................................................................46
5.2.5 URL Filtering ..............................................................................................................................47
Chapter 6 Advanced Setup ......................................................................................................................................48
6.1 Dynamic DNS Setting ............................................................................................................................48
6.2 Wireless Advanced Setup .......................................................................................................................49
6.2.1 Wireless Site Survey..................................................................................................................50
6.2.2 WDS Settings.............................................................................................................................51
6.2.3 WPS...........................................................................................................................................55
6.3 System Management ..............................................................................................................................56
6.3.1 Change Password......................................................................................................................57
6.3.2 Firmware Upgrade .....................................................................................................................57
6.3.3 Profile Save................................................................................................................................58
6.3.4 Time Zone Setting......................................................................................................................60
6.3.5 UPnP Setting..............................................................................................................................60
6.3.6 Language Setting.......................................................................................................................61
6.4 Log & Status............................................................................................................................................61
6.4.1 Network Config ..........................................................................................................................61
6.4.2 Event Log...................................................................................................................................62
6.5 Logout ...................................................................................................................................................62
Chapter 7 DDNS Service Application.......................................................................................................................63
Chapter 8 Q & A .......................................................................................................................................................66
8.1 Installation ...............................................................................................................................................66
8.2 LED .........................................................................................................................................................66
8.3 IP Address ...............................................................................................................................................66
8.4 OS Setting ...............................................................................................................................................67
8.5 Onet 3GUSB-4SWRouter Setup .............................................................................................................68
8.6 Wireless LAN...........................................................................................................................................69
8.7 Support....................................................................................................................................................71
8.8 Others......................................................................................................................................................71
8.9 USB Device .............................................................................................................................................71
Chapter 9 Appendices..............................................................................................................................................72
9.1 Operating Systems..................................................................................................................................72
9.2 Browsers .................................................................................................................................................72
9.3 Communications Regulation Information ................................................................................................72
Router
WiFi-AP
Router AP
Router AP

FCC Caution
1. The device complies with Part 15 of the FCC rules. Operation is subject to the following conditions:
2. This device may not cause harmful interference, and this device must accept any interference received, including
interference that may cause undesired operation.
3. FCC RF Radiation Exposure Statement: The equipment complies with FCC RF radiation exposure limits set forth
for an uncontrolled environment. This equipment should be installed and operated with a minimum distance of 20
centimeters between the radiator and your body.
4. This Transmitter must not be co-located or operating in conjunction with any other antenna or transmitter.
5. Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the
user authority to operate the equipment.
CE Statement of Conformity
This product has been tested in typical configuration by Ecom Sertech Corp and was found to comply with the
essential requirement of “Council Directive on the Approximation of the Laws of the Member States relating to
Electromagnetic Compatibility” (89/336/EEC; 92/31/EEC; 93/68/EEC)
6

Chapter-1 Introduction
Dear Customer,
Thank you for buying another innovative product from Onnet Technologies.
We assure you of an unparalleled and exceptional experience with our Onnet product.
This product offer the best of both worlds in terms of 3G mobility and high speed multiuser access using 802.11n Wi-
fi technology. It is yet another example of Onnet's commitment to get the latest and most innovative technologies to
you for your experience.
All Onet products come with an extensive service support and a 1 year warranty.
Each Onet product is subjected to a stringent Quality Control program at our assembly plant .
However, in the rare event that your device does not behave as it is meant to, please ensure that you log on to our
website www.onnettechnologies.com and use the “Register” tab for the first time , choose the Product
Registration tab and simply follow the tab menu to register your product and user details with us. You must enter the
serial number of your device that is printed on the box for our support team to get back to you immediately. You will
receive a confirmation mail after you have registered your product successfully.
Sincerely,
Onnet Technologies (India) Pvt. Ltd.
7

Welcome to the wonderful world of Onnet Technologies. “Anytime, Anywhere …”
You are now successfully registered with us and will now be able to access our online support center for software
upgrades,troubleshooting and receive regular updates on your email for product launches,special offers and much
more.
1.1 About Onnet
Onnet Technologies is a Green Initiative inspired company.
Our core focus is to bring together innovative energy efficient wireless network routers for the small office and
home office users as well as Energy Efficient power and switching equipments for the outdoor network in the
ICT industry .
Onnet also intends to offer Green Alternate Energy Technology for us in rural micro telecom environments .
Headquartered at Ahmedabad Gujarat, Onnet Technologies aims to make the best of one of the most
progressive business environments offered in the country.
The state of the art assembly unit for integrating the latest technology is also located at Gandhinagar.
With one of the youngest pool of entrepreneurial skills available in the country, Onnet Technologies is
revolutionizing the knowledge and technology based growth engine.
Onnet Technologies objective is to contribute to the eventual energy security of the country.
8

1.2 Product Overview
The Onet 3GUSB-4SWRouter is a solution for multiple network interfaces. Onet 3GUSBwifi4SW router with
802.11n wireless technology provides the best internet connection by auto-detecting the device connected to
Onet 3GUSB-4SWRouter such as 3G/3.5G USB Dongle and xDSL/Cable broadband.
The entire wired/wireless network can share internet connection up to 7.2Mbps when connecting with
3G/3.5G USB Dongle. The Onet 3GUSB-4SWRouter has an impressive wireless data transmission rate of up
to 150Mbps via IEEE802.11n technology. The physical WPS button also allows you to setup a secure
wireless network more effectively and securely.
Moreover, by adopting latest, state-of-the-art WLAN technology, Onet 3GUSB-4SWRouter implements
cutting-edge "Active-ECO" algorithm, which controls automatically the power consumption in accordance with
WLAN and Ethernet activities the Onet 3GUSB-4SWRouter saves up to 80% energy consumption than
legacy 802.11n products without compromising on performance.
1.3 Features
• With latest Green WLAN technology, no more setting or push-button required to save up to 80% energy no
compromise on performance.
• 3G USB external modem support
• Supports iPhone, Smartphone to create a shared Internet environment without wasting phone power; answer
calls, send e-mails, and charge the phone simultaneously.
• Auto WAN type detection brings the most convenience during installation
• Multiple SSID, Wi-Fi Protected Setup (WPS) button and WPA-PSK/WPA2-PSK support
• 150M 1T1R 802.11n WLAN, backward compatible with 802.11 b/g network
• Fail-over backup mechanism to ensure your network connectivity
• UPnP, QoS, VPN pass-through, advanced firewall security with port filter, URL blocking support
9
Renewable
Energy
Solar Power
UPS
Wind Power
UPS
Hybrid
Power UPS
1-10 KW
Wind Turbine
3G USB stick
& 3G Wi-Fi routers
Wi-Fi
(Hot Spot)
Indoor LAN
Networking
Outdoor
Wireless
Antenna
POE
Injector / Splitter/X over
Outdoor
POE Switch
Weather
Station (wireless)
RF Cable
Assemblies
IP
Surveillance
Our Solutions

1.4 Specifications
10
NETWORK
Standards
Data Rate
Frequency Range
Mobile (External): HSPA/UMTS/EVDO
WLAN: IEEE 802.11n, 802.11g, 802.11b
WAN: xDSL/Cable Modem
3.5G: Up to 7.2Mbps (Support 3G/3.5G/3.75G)
WiFi: 802.11n (Max 150Mbps), 802.11g (Max 54Mps),
802.11b (Max 11Mbps)
LAN: 802.3/802.3u (10/100Mbps)
2.412~2.484GHz
Wireless Security WEP 64 or 128 bit/WPA/WPA2/WPA2 Mixed,
WPS (PBC/PIN),
WDS, Multiple APs
Session 20,000
Firewall MAC Address Filtering, URL Filtering, IP/Port Based Filtering
UPnP, DHCP, DDNS, DNS
Operation Modes Router, AP, WiFi AP
Network Features NAT: One-to-Many NAT, Virtual Server, DMZ
HARDWARE
Antenna
LAN
Power Adapter
3 dBi x1 @2.45GHz (Internal)
4x10/100Mbps RJ45, Auto-MDI/MDI-X
DC 5V
WAN
LED Indicator
Operating Temperature
Humidity
1x10/100Mbps RJ45, Auto-MDI/MDI-X
Power, WAN, LAN (1~4), Wireless/WPS,
Operating: 0ºC ~40ºC (32ºF ~104ºF)
Storage: -20ºC ~70ºC (-4ºF ~158ºF)
Operating: 10% to 85% Non-Condensing
Storage: 5% to 90% Non-Condensing
Dimension 118 x 70 x 25 mm (4.65 x 2.75 x 0.98 inch) (Antenna not included)
Management Web GUI, Firmware upgrade via web

1.5 Product Appearance
11
• FRONT
LED Indicator Status Description:
Solid
Operation OK
Ethernet connected
Ethernet connected
Operation OK
Flashing
Green: Reset / Firmware updates in progress
Transmitting Data
Transmitting Data
Green: Transmitting Data
Orange: WPS enabled
Power
WAN
LAN (1~4)
WIRELESS & WPS
Status
LED Indicator
• REAR
RJ-45 Ethernet 10/100 Ports
RJ-45 Ethernet 10/100 Port
For 3G modem only
Press for back to factory default
DC 5V power in
Ethernet Port (LAN 1~4)
Ethernet Port (WAN)
USB Port
Reset Button
Power DC Jack
Ethernet Port (LAN)Ethernet Port (LAN)
Ethernet Port (WEthernet Port (WAN)AN)
Reset ButtonReset Button
Power DC JackPower DC Jack
USB PortUSB Port
PowerPower
WWANAN
LANLAN WPS ButtonWPS Button
AntennaAntenna

Chapter-2 System and Network Setup
12
The Onnet 3GUSB-4SWRouter is easy to setup and wireless device for various application and environment. It can be
used in conference room, hotels, even in transportation.
To begin with the Onet 3GUSB 4SW Router, you must have the following minimum system requirements. If your system
can’t correspond to the following requirements, you might have some unknown errors on your system.
• Internet Account for XDSL/Cable Modem, broadband or 3G
• One Ethernet (10 BASE-T or 10/100 BASE-TX) network interface card.
• TCP/IP and at least one web browser software installed (E.g.: Internet Explorer 5.0, Netscape Navigator 7.x, Apple
Safari 2.03 or higher version).
• At lease one 802.11g (54Mbps) or one 802.11b (11Mbps) wireless adapter for wireless mobile clients.
• Recommended OS: WinXP, Vista or Win7 / Linux.
2.1 Build Network Connection
Administrator can manage the settings for WAN, LAN, Wireless Network, NTP, password, User Accounts, Firewall,
etc. Please confirmation the network environment or the purpose before setting this product
2.1.1 Router Mode
Switch to router mode through web GUI when the first setup.
2.1.2 AP Mode
Switch to AP mode, if a router is already set up , and you want to make a wireless LAN communication.
Switch or Hub
Switch or Hub

13
2.1.3 Wi-Fi Mode
Switch to WiFi AP Mode when you connect to the internet wirelessly through PC and wireless device without
wireless LAN function equipped.
2.2 Connecting Onnet 3GUSB-4SWRouter
Prepare the followings before the connection:
• PC or Notebook for setup
• Ethernet cable or 3/3.5G modem
1. Make sure you are under “Router Mode”.
2. Connect Onet 3GUSB-4SWRouter to xDSL/ Cable modem with the Ethernet cable, WAN to LAN.
Ethernet Cable
Internet
PC
xDSL/Cable
Modem
xDSL/Cable Line
3.5 G Modem
Power Adapter
Switch or Hub

14
3. Turn ON your computer
2.3 Network setup
After the network connection is built, the next step is setup the router with proper network parameters, so it can work
properly in your network environment. Before you connect to the wireless router and start configuration procedures,
your computer must be able to get an IP address from the wireless router automatically (use dynamic IP address). If
it’s set to use static IP address, or you’re unsure, please follow the below instructions to configure your computer with
dynamic IP address:
If the operating system of your computer is….
Windows 2000 - please go to section 2.3.1
Windows XP - please go to section 2.3.2
Windows Vista/Win7 - please go to section 2.3.3
2.3.1Windows 2000
Click “Start” button (it should be located at lower-left corner of your computer), then click control panel. Double-click
Network and Dial-up Connections icon, double click Local Area Connection, and Local Area Connection Properties
window will appear. Select “Internet Protocol (TCP/IP)”, then click “Properties”.
1. Select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, then click “OK”.

15
2.3.2 Windows XP
1. Click “Start” button (it should be located at lower-left corner of your computer), then click control panel. Double-click
Network and Internet Connections icon, click Network Connections, then double-click Local Area Connection,
Local Area Connection Status window will appear, and then click “Properties”.
2. Select “Obtain an IP address automatically” and “Obtain DNS server address automatically”, then click “OK”.
2.3.3 Windows Vista / Windows 7
1. Click “Start” button (it should be located at lower-left corner of your computer), then click control panel. Click View
Network Status and Tasks, and then click Manage Network Connections. Right-click Local Area Network, then
select “Properties”. Local Area Connection Properties window will appear, select “Internet Protocol Version 4 (TCP
/ IPv4)”, and then click “Properties”.

16
2.4 Router IP Address Lookup
1. After the IP address setup is completed, please clicks “start” → “run” at the bottom-lower corner of your desktop:
2. In put "cmd" and then click "OK"
Input “ipconfig”, then press “Enter” key. Please check the IP address followed by “Default Gateway” (In this
example, the gateway IP address of router is 192.168.1.1)
2.4.1 Log into Web GUI
After your computer obtains an IP address from wireless router, please start your web browser, and input the IP
address of the wireless router in address bar, and the following message should be shown. Please click “onnet” to
login the Onet 3GUSB-4SWRouter.
Enter the User name and Password in to the blank and then Click Login. The default values for User Name and
Password are onnet (all in lowercase letters).
NOTE: If the IP address of Gateway is not displayed, or the address followed by 'IP Address' begins with
“169.x.x.x”, please recheck network connection between your computer and router, and / or go to the
beginning of this chapter, to recheck every step of network setup procedure.

17

Chapter-3 Internet Connection
18
This Chapter describes how to setup Onet 3GUSB-4SWRouter to the internet. The Onet 3GUSB-4SWRouter is
delivered with the following factory default parameters.
Default IP address: 192.168.1.1 (Router Mode)
192.168.1.254 (AP Mode)
192.168.1.254 (WiFi AP Mode)
Default IP subnet mask: 255.255.255.0
Web login user name: onnet
Web login password: onet
3.1 Plug and Play
The Onet 3GUSB-4SWRouter supports three types of Internet connection method: 3G/3.5G modem card, wire or
wireless connection via xDSL/Cable modem. Just connect the 3G/3.5G modem card or Ethernet cable to Onet
3GUSB-4SWRouter, the router will recognize it automatically.
3.1.1 SmartPhone /iPhone Intternet sharing plug and play
With Onet 3GUSB-4SWRouter, you can build an instant 802.11n wireless broadband sharing environment with
your iPhone, Windows Mobile or Google smartphone. During the time you can still answer calls, send SMS and
charge your phone.

19
Step 1. Connect iPhone/Smartphone with Onet 3GUSB-4SWRouter via USB cable.
Step 2. Select “USB Tethering” as connection type.
Step 3. Click on “Done”.
Step 4. Wait few seconds for pairing. When WAN LED on, the Internet is ready to access.
Note: 1. iPhone:
2. Google Android Phone:
(1) Due to difference in 3G service bundled in various carriers, please check your 3G service supports Internet
tethering.
(2) Enable Internet Tethering on iPhone 3GS / iPhone 4, and set up the screen lock to never to prevent the sharing is
interrupted unexpected by the iPhone screen lock feature.
please turn on "USB modem mode” when connecting router.

20
3.2 Router Mode- Using as a broadband router
1. Open a Web browser, and enter http://192.168.1.1 (Default Gateway) into the blank.
2. Enter the User name and Password in to the blank and then Click Login. The default values for User Name and
Password are onnet (all in lowercase letters).
3.2.1 WAN Interface- Ethernet Port
The WAN access type is dependent on the service that you contract with the provider. The Onet 3GUSB-
4SWRouter provides five selections for the WAN access type, Static IP, DHCP Client, PPPoE, PPTP, L2TP. Check
with your ISP if you don’t know the WAN type.
