ONV ONV-WR300-4G User manual

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
1
Industrial Router User Guide
ONV-WR300-4G
1. Technical specification
Product Name
4G WIFI industrial router
Antenna Direction
Omnidirectional
Installation
Wall-mounted, desktop
WIFI Frequency Band
2.4G HZ
Weight
320g
Power Supply
DC 12～24V
Material
Aluminum
Colour
Silver

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
2
Operation TEMP
-20℃-55℃
Operation Humidity
10%~95% RH Non condensing
Indicator and interface description
Power indicator
(PWR)
Green on
Power supply on
Green off
No power supply
LAN indicator
(LAN)
Green on
LAN connection is normal
Green off
LAN is not connected
4G network
indicator (LTE)
Green blink
Data transmission
Green off
3/4G failed to dial successfully
Wireless
indicator (WIFI)
Green blink
WIFI works fine
Green off
WIFI off

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
3
Reset switch
Press for one second to restart the device, press for 5 seconds to restore the
factory state.
SIM card
External standard SIM card slot
2.Installation and configuration
2.1 Device connection
Step1: Put the SIM card into the card tray and insert it into the corresponding card slot of the device
Step2: Install 3*antennas (2*2.4G WiFi antennas, 1*4G antenna) into the corresponding installation positions of
the chassis.
Step3: Connect the DC power supply that comes with the device to the DC interface of the device, and connect
the LAN port of the device to the terminal computer with a network cable to supply power to the device

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
4
2.2 Terminal settings
The PC is set to the default "Automatically obtain IP address" and "Automatically obtain DNS server address".
The device automatically assigns the P address. The device does not need to do other configuration and can
automatically access the Internet by default. As shown below.

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
5

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
6
2.3 Web login
Step1: Run the web browser, enter 192.168.10.1 in the address bar, press Enter and jump to the login page,
enter the login password admin, click login, and enter the router home page.
Step2: After entering the home page, you can view system information, device status, SIM card information and

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
7
terminal information.

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
8
2.4 Network configuration
Step1: Enter the interface configuration: You can modify the device IP address and set the DHCP related
functions. The user can set it as needed. After the setting is completed, click <Save & Apply> to complete the
setting.
Step2: Enter the wireless configuration: Set the wireless SSID (default or self-setup), the country
code/channel/power/bandwidth is recommended to be the default, the encryption type/whether it is hidden or not,

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
9
the user can set it as needed, and click <Save & Apply after the setting is completed > To complete the setting.
Step3: Enter 3/4G configuration: Select the corresponding SIM card type according to the actual situation.
Click <Save & Apply> to complete the setting.

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
10
2.5 Advanced settings
Fault diagnosis: This function is mainly for developers to locate faults, users do not need to set this.

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
11
2.6 System Settings
System time: Select <Sync local time>, the device can synchronize to the current time, click <Save & Apply>,
the setting will take effect.
Management password: You can set a new login password, click <Save & Apply>, the setting will take effect.
2.7 Backup/Upgrade
Download backup: Click <Generate Backup>, the system installation files can be backed up to a local folder.
Restore factory settings: Click <Execute reset>, the system will restore the default settings, and the previous
settings are invalid. It is recommended that users use it with caution.
System Upgrade: Upgrade the current system through the local installation package.

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
12
3. Packing List
Name
CONTENT
QTY
UNIT
Host device
4G WIFI router
1
Set
Power adapter
Power supply
1
PC
Hanging ears
Equipment fixed
1
Set
Screw pack
Fixing of equipment and hanging ears
1
Pkg
2. 4G antenna
WIFI signal amplification
2
PC
4G antenna
4G signal amplification
1
PC
User Guide
User Guide (including warranty card)
1
PC

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
13
4.Note
Keep away from hazardous materials such as flammable and explosive.
Keep away from dust or dirt.
Do not expose the device to dust, dirt, sand, food, or other inappropriate substances.
To prevent falling, the equipment should be prevented from falling from a high place.
Waterproof, this device does not have waterproof performance, please keep it dry.
5.Warranty
Dear customers:
First of all thank you for purchasing our products, and thank you again!
In order to facilitate us to provide you with high-quality and satisfactory after-sales service, but also to better

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
14
protect your rights. Please read this clause carefully.
Quality Commitment:
Adhering to the tenet of "Users are God", the company provides customers with high-quality and satisfactory
after-sales service. We promise to provide free warranty service within one year for all products sold by our
company.
The specific regulations are as follows:
1. Within one year from the date of purchase of the product, our company will provide free warranty service for
bad faults that occur during normal operation according to relevant technical data in a normal use environment;
2. For more than one year from the date of product purchase, our company provides paid maintenance services;
3. Every purchase of our products can enjoy our most professional technical service support and provide the
latest upgrade package service for free;
4. Failure and damage caused by force majeure factors (such as fire, lightning, flood, etc.) are not covered by
the warranty
5. During the warranty period, if the damage is severe and cannot be repaired or the accessories of this model

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
15
have been discontinued, our company will provide other products of equivalent value for replacement. For the
replaced products, if there is a price difference during the period, the difference will be partly The customer
makes up, and the replaced product no longer enjoys non-product failure replacement service.
If the product has the following conditions, it is not within the scope of free full warranty, replacement, and return.
Even if the product is within the warranty period, our company will charge related maintenance fees.
1. The repaired product has the following phenomena:
Burnt mark
Components are missing or destroyed
Pad defect
2. Operation negligence includes: The crystal head is connected to the wrong wire leading to damage, and the
failure to wear an anti-static wristband (the team bare board) is considered to cause product damage, such as
chip burnt, mainboard, shield cover damage, radiofrequency head damage, etc.
3. Other problems and malfunctions caused by abnormal use (mainly the power supply part or non-ONV

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
16
company standard power supply)
4. Do not follow the installation, design, and patch instructions on the manual to carry out follow-up work;
5. When the motherboard is seriously damaged and cannot be repaired, a new motherboard must be purchased
for replacement;
6. The damage caused by the user's disassembly, repair, or modification of the circuit;
7. Product information is incomplete, such as the warranty sticker/MAC address/SN code affixed to the body, the
date paper is removed, damaged, or altered, and the model sticker is torn off;
8. Change the firmware of non-ONV company without authorization

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
17
Customer Profile
Name
Contact number
Model
Postal code
MAC number
Sales name
Contact number
Sale date
Postal code
Sales address
Date
Fault description
Maintenance records
Remarks

[phone]
Optical Network Video Technologies (Shenzhen) Co., Ltd.
18
Remarks
1. The return freight will be paid by both parties.
2. For goods that are returned for repair, the customer is requested to report the abnormal quality within 7 days
after receiving the product (based on the date of the courier number), and the overdue will not be negative.
3. Please confirm and pay the cost of the repair within 7 days. Failure to deliver the repair will be regarded as
abandoned by our company and returned as it is. The customer data of our company will not be stored as a
repaired part.
The final interpretation of this clause belongs to our company.
