Oontz Bluetooth Adapter Gen 1 User manual

Quick Start Guide
TheOontZ.com
Designed and Engineered By

In the Package
Quick-Start Guide
Micro USB Power Adapter
3.5mm Audio Cable
Digital Audio Optical Cable

Thank you for being an OontZ Bluetooth Adapter Owner!
This User Guide rst covers the steps to connect your OontZ Bluetooth Adapter to your TV or
device (Laptop, Computer, Tablet, Mac, iPad, or Music Receiver), with the included Digital
Audio Optical Cable or the 3.5mm Audio Cable. Then the steps to connect the OontZ
Bluetooth Adapter wirelessly over Bluetooth to one or two of these Supported OontZ Speaker
Models:
SUPPORTED OONTZ SPEAKER MODELS
- OontZ Angle 3 ULTRA
- OontZ Angle 3XL ULTRA
- OontZ Angle 3 RainDance
• To connect and play to two OontZ Speakers both speakers must be the same model.
• The OontZ Bluetooth Adapter will only work with the Supported OontZ Speaker
Models, for the latest list of supported OontZ speakers please visit
TheOontZ.com/BT-Adapter
The OontZ Bluetooth Adapter is designed to transmit the audio from your TV or device to the
OontZ Speaker(s) with our Low latency Feature. The Low Latency Feature reduces delays that
occur in the Bluetooth transmission of the audio which can cause lip sync issues when playing
a video on your TV or device and playing the audio wirelessly through one or two OontZ
Speakers.

Before Getting Started with your OontZ Bluetooth Adapter please
review these important notes:
OontZ Speaker Firmware Version Requirements
Your OontZ Speaker(s) need to be on the current version of Firmware, to work with the OontZ
Bluetooth Adapter:
Current Firmware Requirements
- OontZ Angle 3 ULTRA: Version 2.15 or later (please see page 19 for instructions on how to check
Firmware Version)
- OontZ Angle 3XL ULTRA: Version 3.3.6 or later (please see page 20 for instructions on how to
check Firmware Version)
- OontZ Angle RainDance: All versions of Firmware work with the OontZ Bluetooth Adapter
If your OontZ Speaker(s) are on an earlier Firmware version, you will need to update each speaker to
the current Firmware version. If you have two OontZ Speakers, they both need to be on the same
current version of Firmware.
Volume Control
Some model TVs (and other devices) when connected to the OontZ Bluetooth Adapter are not able
to adjust the volume playing through the OontZ Speaker(s) by the TV’s remote control or physical
buttons on the TV. In this case you will need to use the volume buttons on each speaker to adjust
the volume. If your TV allows the volume playing through the OontZ Speakers(s) to be adjusted
from the TV’s remote control we would recommend that you initially set the volume on each
speaker to maximum using the volume buttons on each speaker and use the remote control to
adjust volume.

Buttons and Lights
Connectors
Connecting with Television Using Digital Audio Optical Cable
Connecting with Television Using 3.5mm Audio Cable
Connecting with Devices Using 3.5mm Audio Cable
Turning On the OontZ Bluetooth Adapter
Connecting Your OontZ Bluetooth Adapter with One Supported OontZ Speaker
Connecting Your OontZ Bluetooth Adapter with Two Supported OontZ Speaker
Play Your Audio Wirelessly in Dual Stereo
Play Your Audio Wirelessly with Left-Right Stereo Separation
Changing Between Left Channel-Right Channel and Dual Stereo
Troubleshooting
Reset Function
Checking OontZ Angle 3 ULTRA Firmware Version
Checking OontZ Angle 3XL ULTRA Firmware Version
Other Important Notes
Contacting Customer Support
Safety and Precautions
Table of Contents
1
2
3
4
5
6
7 - 9
10 - 12
13
14
15
16 - 17
18
19
20
21
22
23 - 24
Pages

SPK 2 (Speaker 2)
Blue Indicator Light
Buttons and Lights
Page 1
Bluetooth Button
L/R White Indicator Light
- Lit when connected to
two OontZ Speakers in
Left-Right Channel Mode
for stereo separation
SPK 1 (Speaker 1)
Blue Indicator Light DS Orange Indicator Light
- OontZ Speaker(s) are in
Dual Stereo Mode,
speaker(s) will play full
stereo
Speaker Mode Button
- Used when connected to
two OontZ Speakers to
change between Dual Stereo
Mode and Left - Right
Channel Mode

SPK 2 (Speaker 2)
Blue Indicator Light
Connectors
Page 2
Optical/Audio In Connector used
for 3.5mm Audio Cable or
Digital Audio Optical Cable
DC IN Power Connector
used for Micro USB Power
Adapter

Connecting with Television Using Digital Audio Optical Cable
Page 3
- Plug the longer end of the Digital Audio Optical Cable into the Optical/Audio
In Connector on the OontZ Bluetooth Adapter as shown below.
- Plug the shorter end of the Digital Audio Optical Cable into the Optical -
Digital Audio Out on your TV as shown below.
- Make sure both ends of the cable are fully inserted.
We recommend to connect to your TV using the Digital Audio Optical Out Connector. If the TV does
not have a Digital Audio Optical Out Connector, use the Analog Audio Connection as described on
Page 4.
ANALOG
AUDIO OUT
L R
DIGITAL
AUDIO OUT
OPTICAL
Digital Audio Optical Cable is included
AUDIO
OUT

Connecting with Television Using 3.5mm Audio Cable
Page 4
- Plug one end of the 3.5mm Audio Cable into the Optical/Audio In Connector on the OontZ
Bluetooth Adapter.
- Plug the other end of that 3.5mm Audio Cable into the Headphone or Audio-Out Connector on
your television.
- Make sure both ends of the cable are fully inserted.
-If your TV does not have a Headphone Connector or Audio-Out Connector but does have Left
Right Analog Audio Out you will need a 3.5mm to RCA cable as shown below.
ANALOG
AUDIO OUT
L R
3.5mm to 3.5mm Audio Cable (included)
OR
3.5mm to RCA audio cable is sold seperately
and is available at:
TheOontZ.com/accessories
AUDIO OUT
HEADPHONE
OUT
- or -
DIGITAL
AUDIO OUT
OPTICAL
L
R

Connecting with Devices Using 3.5mm Audio Cable
Page 5
- Plug one end of the 3.5mm Analog Cable into the Optical/Audio In Connector on the OontZ
Bluetooth Adapter.
- Plug the other end of that 3.5mm Audio Cable into the Headphone or Audio-Out Connector on your
device.
- Make sure both ends of the cable are fully inserted.
OR

Turning On the OontZ Bluetooth Adapter
Page 6
Step 2: Insert the small end of the Micro USB
Charging Adapter into the DC IN Micro USB
Charging Connector as shown
Step 1: Connect the wall plug end of the
Micro USB Charging Adapter into a
power outlet.
Step 3: SPK1 will be lit indicating the OontZ
Bluetooth Adapter is ON
- If the SPK1 Blue light is slowly ashing on your
OontZ Blueooth Adapter it is ready to connect to
your OontZ Speaker(s)
- If the SPK1 is solid Blue your Oontz Bluetooth
Adapter has reconnected to a supported OontZ
speaker and is ready to play.

Step 1: Turn ON your OontZ speaker.
The blue light on the OontZ Speaker will be lit:
- If the blue light on the OontZ Speaker is ashing it is ready to connect with the OontZ Bluetooth
Adapter.
- If the blue light on the OontZ Speaker is solid it has automatically reconnected with the last device it
was connected to. In order to connect with the OontZ Bluetooth Adapter you need to rst disconnect
the OontZ Speaker, from that device. Press and hold down the Bluetooth Button on the OontZ
Speaker for 5 seconds.
- The blue light will begin ashing and the OontZ Speaker is ready to connect with the OontZ
Bluetooth Adapter.
Step 2: Check that the OontZ Bluetooth Adapter is turned on, the SPK 1 blue light will be lit.
- If the SPK 1 blue light on the OontZ Bluetooth Adapter is ashing it is ready to connect with the
OontZ Speaker.
- If the SPK 1 blue light on the OontZ Bluetooth Adapter is solid it has automatically reconnected
with the last OontZ Speaker it was connected with. In order to connect with the new OontZ
Speaker you need to disconnect the current OontZ Speaker. Press and hold down the Bluetooth
Button on the OontZ Bluetooth Adapter for 5 seconds.
- The SPK 1 blue light on the Bluetooth Adapter will begin ashing and it is ready to connect with
the OontZ Speaker.
Connecting Your OontZ Bluetooth Adapter with One Supported
OontZ Speaker
(To connect with Two supported OontZ Speakers refer to Page 10)
Page 7

Step 3: Press and release the Bluetooth Button on the OontZ Bluetooth Adapter. The SPK 1 and SPK 2
blue lights will alternate ashing. *
- The SPK 1 blue light will turn solid, to indicate the OontZ Bluetooth Adapter has connected with your
OontZ speaker.
- The OontZ Bluetooth Adapter will continue to search for a second OontZ Speaker for a total of 60
seconds, then the ashing SPK2 blue light will turn o.
- The OontZ Bluetooth Adapter is now ready to transmit the audio over Bluetooth and play through the
OontZ speaker.
*Your OontZ Bluetooth Adapter needs to be within 10 unobstructed feet of the OontZ Speakers to pair and
connect. If there is an issue when connecting please move your speakers closer to the OontZ Bluetooth
Adapter, then pair and connect.
Connecting Your OontZ Bluetooth Adapter with One Supported
OontZ Speaker
Page 8

Connecting Your OontZ Bluetooth Adapter with One Supported
OontZ Speaker
Page 9
Note 1: The OontZ Bluetooth Adapter will try to automatically reconnect with last OontZ Speaker it was
connected with each time the OontZ Speaker is turned on and is within range.
Note 2: In order to pair and connect the OontZ Bluetooth Adapter with a dierent Supported OontZ
Speaker, you need to rst disconnect the currently connected OontZ Speaker.
- To disconnect the currently connected OontZ Speaker, press and hold down the Bluetooth Button
on the OontZ Bluetooth Adapter for 5 seconds.
- The SPK 1 blue light will begin ashing and the OontZ Bluetooth Adapter is ready to connect to a
dierent OontZ Speaker.
Note 3: Note: If you wish to later connect a second OontZ Speaker to the OontZ Bluetooth Adapter the
second speaker needs to be the same OontZ Speaker model and needs to be on the same level of
Firmware as the rst speaker.
- With your OontZ Bluetooth Adapter Turned On and the rst OontZ Speaker turned on and connected
to it, turn on your second OontZ Speaker.
- Press and release the Bluetooth Button on the OontZ Bluetooth Adapter. The SPK 1 and SPK 2 blue
lights will alternate ashing.
- SPK1 and SPK2 blue lights will both turn solid blue to indicate the OontZ Bluetooth Adapter has
connected with both OontZ Speakers.
. The OontZ Bluetooth Adapter is now ready to transmit the audio over Bluetooth and play through
both OontZ Speakers.

Connecting Your OontZ Bluetooth Adapter with Two Supported
OontZ Speakers
(To connect with One supported OontZ Speakers refer to Page 7)
Page 10
Step 1: Turn ON your OontZ Speakers.
The blue light on both OontZ Speakers will be lit:
- If the blue light on both OontZ Speakers are ashing they is ready to connect with the OontZ
Bluetooth Adapter.
- If the blue light on either OontZ Speaker is solid it has automatically reconnected with the last device
it was connected to. In order to connect with the OontZ Bluetooth Adapter you need to rst
disconnect the OontZ Speaker(s), from that device. Press and hold down the Bluetooth Button on
the OontZ Speaker for 5 seconds.
- The blue light will begin ashing and the OontZ Speaker is ready to connect with the OontZ
Bluetooth Adapter.
Step 2: Check that the OontZ Bluetooth Adapter is turned on, the SPK 1 blue light will be lit.
- If the SPK 1 blue light on the OontZ Bluetooth Adapter is ashing it is ready to connect with the
OontZ Speaker.
- If the SPK 1 blue light on the OontZ Bluetooth Adapter is solid it has automatically reconnected
with the last OontZ Speaker it was connected with. In order to connect with the new OontZ
Speakers you need to disconnect the current OontZ Speaker. Press and hold down the Bluetooth
Button on the OontZ Bluetooth Adapter for 5 seconds.
- The SPK 1 blue light on the Bluetooth Adapter will begin ashing and it is ready to connect with
the OontZ Speakers.

Connecting Your OontZ Bluetooth Adapter with Two Supported
OontZ Speakers
Page 11
Step 3: Press and release the Bluetooth Button on the OontZ Bluetooth Adapter. The SPK 1 and SPK 2
blue lights will alternate ashing. *
- The SPK 1 light will turn solid blue, to indicate the OontZ Bluetooth Adapter has connected with one
of your OontZ Speakers.
- The OontZ Bluetooth Adapter will continue to search for the second OontZ Speaker for up to 60
seconds.
- The SPK2 light will turn solid blue, to indicate the OontZ Bluetooth Adapter has connected with the
second OontZ Speaker.
- The OontZ Bluetooth Adapter is now ready to transmit the audio over Bluetooth and play through the
OontZ Speakers.
Step 4: If the SPK2 blue light turns o after 60 seconds, the second OontZ Speaker was not found.
- Make sure both OontZ Speakers are the same model.
- Make sure both OontZ Speakers are on the same version of rmware.
• Refer to page 19 for the OontZ Angle 3 ULTRA on how to check the version of rmware.
• Refer to page 20 for the OontZ Angle 3XL ULTRA on how to check the version of rmware.
*Your OontZ Bluetooth Adapter needs to be within 10 unobstructed feet of the OontZ Speakers to pair and
connect. If there is an issue when connecting please move your speakers closer to the OontZ Bluetooth
Adapter, then pair and connect.

Connecting Your OontZ Bluetooth Adapter with Two Supported
OontZ Speakers
Page 12
Note 1: The OontZ Bluetooth Adapter will try to automatically reconnect with last OontZ Speaker it was
connected with each time the OontZ Speaker is turned on and is within range.
Note 2: In order to pair and connect the OontZ Bluetooth Adapter with dierent Supported OontZ
Speakers, you need to rst disconnect the currently connected OontZ Speakers.
- To disconnect the currently connected OontZ Speakers, press and hold down the Bluetooth Button
on the OontZ Bluetooth Adapter for 5 seconds.
- The SPK 1 blue light will begin ashing and the OontZ Bluetooth Adapter is ready to connect to
dierent OontZ Speakers.

Page 13
Play Your Audio Wirelessly in Dual Stereo with Two OontZ Speakers
Place each speaker up to an unobstructed 66 feet
apart from the OontZ Bluetooth Adapter*
Dual Stereo
for full stereo in separate areas
Full Stereo Full Stereo
* Placing the speakers on the ground or having walls or obstructions
between the OontZ Bluetooth Adapter and the speakers will signicantly
reduce the distance the two speakers can play away from the OontZ
Bluetooth Adapter

Page 14
Play Your Audio Wirelessly with Two Oontz Speakers
Left - Right stereo separation up to an unobstructed 66 feet
apart from the OontZ Bluetooth Adapter*
* Placing the speakers on the ground or having walls or obstructions
between the OontZ Bluetooth Adapter and the speakers will signicantly
reduce the distance the two speakers can play away from the OontZ
Bluetooth Adapter
Left Channel - Right Channel
for stereo separation
Left Channel Right Channel

Page 15
Changing to Dual Stereo from Left Channel - Right Channel
Changing to Left Channel - Right Channel from Dual Stereo
Use Left Channel - Right Channel when placing the two speakers in the same area
to have stereo seperation.
- With the speakers connected together for Dual Stereo, Orange Light will be lit.
- To change to Left Channel - Right Channel, press the speaker mode button.
White Light will be lit and the Orange Light will turn o.
- SPK1
will say “Left Channel” and SPK2 will say “Right Channel” and you are ready to play.
– With the speakers connected together for Left Channel - Right Channel.
White Light will be lit.
–
To change to Dual Stereo, press the speaker mode button.
Orange Light will be lit and White Light will turn o.
– Both speakers will say “Dual Stereo” and you are ready to play.
Use Dual Stereo when placing the two speakers in dierent areas, and both
speakers will play in full stereo.
