Opengear ADA-8402-B User manual

ADA-8402-B
AES/EBU Distribution Amplifier (110ohm)
User Manual

ADA-8402-B User Manual
• Ross Part Number: 8402BDR-004-02
• Release Date: August 6, 2013.
The information in this manual is subject to change without notice or obligation.
Copyright
© 2013 Ross Video Limited. All rights reserved.
This work is proprietary and confidential to Ross Video Limited, its subsidiaries and its other
affiliated corporations and may not be copied, distributed, sold or otherwise used or relied upon
without the express written permission of Ross Video Limited. Reproduction or reverse
engineering of copyrighted software is prohibited.
Patents
This product is protected by the following US Patents: 4,205,346; 5,115,314; 5,280,346;
5,561,404; 7,304,886; 7,508,455; 7,602,446; 7,834,886; 7,914,332. This product is protected by
the following Canadian Patents: 2039277; 1237518; 1127289. Other patents pending.
Notice
The material in this manual is furnished for informational use only. It is subject to change without
notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited
assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
Trademarks
• is a registered trademark of Ross Video Limited.
• Ross, ROSS, ROSS®, and MLE are registered trademarks of Ross Video Limited.
• openGear® is a registered trademark of Ross Video Limited.
• DashBoard Control System™ is a trademark of Ross Video Limited.
• Dolby® is a registered trademark of Dolby Laboratories.
• All other product names and any registered and unregistered trademarks mentioned in
this manual are used for identification purposes only and remain the exclusive property of
their respective owners.

Important Regulatory and Safety Notices to Service Personnel
Before using this product and nay associated equipment, refer to the “Important Safety
Instructions” listed below to avoid personnel injury and to prevent product damage.
Product may require specific equipment, and/or installation procedures to be carried out to satisfy
certain regulatory compliance requirements. Notices have been included in this publication to call
attention to these specific requirements.
Symbol Meanings
Important Safety Instructions
This symbol on the equipment refers you to important operating and maintenance (servicing)
instructions within the Product Manual Documentation. Failure to heed this information may
present a major risk of damage to persons or equipment.
Warning — The symbol with the word “Warning” within the equipment manual indicates a
potentially hazardous situation, which, if not avoided, could result in death or serious injury.
Caution — The symbol with the word “Caution” within the equipment manual indicates a
potentially hazardous situation, which, if not avoided, may result in minor or moderate injury. It
may also be used to alert against unsafe practices.
Notice — The symbol with the word “Notice” within the equipment manual indicates a
potentially hazardous situation, which, if not avoided, may result in major or minor equipment
damage or a situation which could place the equipment in a non-compliant operating state.
ESD Susceptibility — This symbol is used to alert the user that an electrical or electronic
device or assembly is susceptible to damage from an ESD event.
Caution — This product is intended to be a component product of the DFR-8300 and
OG3-FR series frame. Refer to the DFR-8300 and OG3-FR Series Frame User Manual for
important safety instructions regarding the proper installation and safe operation of the frame
as well as its component products.
Warning — Certain parts of this equipment namely the power supply area still present a
safety hazard, with the power switch in the OFF position. To avoid electrical shock, disconnect
all A/C power cords from the chassis’ rear appliance connectors before servicing this area.
Warning — Service barriers within this product are intended to protect the operator and
service personnel from hazardous voltages. For continued safety, replace all barriers after any
servicing.
This product contains safety critical parts, which if incorrectly replaced may present a risk of
fire or electrical shock. Components contained with the product’s power supplies and power
supply area, are not intended to be customer serviced and should be returned to the factory for
repair. To reduce the risk of fire, replacement fuses must be the same time and rating. Only use
attachments/accessories specified by the manufacturer.

EMC Notices
United States of America
FCC Part 15
This equipment has been tested and found to comply with the limits for a class A Digital device,
pursant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used
in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at their own
expense.
CANADA
This Class “A” digital apparatus complies with Canadian ICES-003.
Cet appariel numerique de la classe “A” est conforme a la norme NMB-003 du Canada.
EUROPE
This equipment is in compliance with the essential requirements and other relevant provisions of
CE Directive 93/68/EEC.
INTERNATIONAL
This equipment has been tested to CISPR 22:1997 along with amendments A1:2000 and
A2:2002, and found to comply with the limits for a Class A Digital device.
Maintenance/User Serviceable Parts
Routine maintenance to this openGear product is not required. This product contains no user
servicable parts. If the module does not appear to be working properly, please contact Technical
Support using the numbers listed under the “Contact Us” section on the last page of this manual.
All openGear products are covered by a generous 5-year warranty and will be repaired without
charge for materials or labor within this period. See the “Warranty and Repair Policy” section in
this manual for details.
Notice — Changes or modifications to this equipment not expressly approved by Ross Video
Limited could void the user’s authority to operate this equipment.
Notice — This is a Class A product. In domestic environments, this product may cause radio
interference, in which case the user may have to take adequate measures.

Environmental Information
The equipment that you purchased required the extraction and use of natural
resources for its production. It may contain hazardous substances that could
impact health and the environment.
To avoid the potential release of those substances into the environment and to diminsh the need
for the extraction of natural resources, Ross Video encourages you to use the appropriate
take-back systems. These systems will reuse or recycle most of the materials from your
end-of-life equipment in an environmentally friendly and health conscious manner.
The crossed out wheelie bin symbol invites you to use these systems.
If you need more information on the collection, resuse, and recycling systems, please contact
your local or regional waste administration.
You can also contact Ross Video for more information on the environmental performance of our
products.

Company Address
Ross Video Limited Ross Video Incorporated
8 John Street P.O. Box 880
Iroquois, Ontario, K0E 1K0 Ogdensburg, New York
Canada USA 13669-0880
General Business Office: (+1) 613 • 652 • 4886
Fax: (+1) 613 • 652 • 4425
Technical Support: (+1) 613 • 652 • 4886
After Hours Emergency: (+1) 613 • 349 • 0006
E-mail (Technical Support): [email protected]
E-mail (General Information): [e-mail]
Website: http://www.rossvideo.com

ADA-8402-B User Manual (Iss. 02) Contents • i
Contents
Introduction 1
Overview.............................................................................................................................. 1-2
Features.................................................................................................................. 1-2
Functional Block Diagrams ................................................................................................. 1-3
User Interfaces ..................................................................................................................... 1-4
DashBoard Control System™ ............................................................................... 1-4
Card-edge Controls................................................................................................ 1-4
Documentation Terms and Conventions.............................................................................. 1-5
Installation 2
Before You Begin ................................................................................................................2-2
Static Discharge..................................................................................................... 2-2
Unpacking.............................................................................................................. 2-2
Installing the ADA-8402-B ................................................................................................. 2-3
Rear Modules for the ADA-8402-B...................................................................... 2-3
Installing a Rear Module ....................................................................................... 2-3
Installing the ADA-8402-B ................................................................................... 2-4
Cabling for the ADA-8402-B .............................................................................................. 2-5
DFR-8310 Series Frame Cabling Overview.......................................................... 2-5
DFR-8321 and OG3-FR Series Frame Cabling Overview.................................... 2-5
Software Upgrades...............................................................................................................2-6
User Controls 3
Card Overview..................................................................................................................... 3-2
Using the DIP Switches ....................................................................................................... 3-3
Overview ............................................................................................................... 3-3
Configuring the DIP Switches............................................................................... 3-3
Control and Monitoring Features......................................................................................... 3-6
Status and Selection LEDs on the ADA-8402-B .................................................. 3-6
DashBoard Menus 4
Status Tabs........................................................................................................................... 4-2
Status Tab .............................................................................................................. 4-2
Product Tab ........................................................................................................... 4-2
Settings Tab ......................................................................................................................... 4-3
Specifications 5
Technical Specifications ...................................................................................................... 5-2
Service Information 6
Troubleshooting Checklist................................................................................................... 6-2
Warranty and Repair Policy................................................................................................. 6-3

ii • Contents ADA-8402-B User Manual (Iss. 02)

ADA-8402-B User Manual (Iss. 02) Introduction • 1–1
Introduction
In This Chapter
This chapter contains the following sections:
• Overview
• Functional Block Diagrams
• User Interfaces
• Documentation Terms and Conventions
A Word of Thanks
Congratulations on choosing an openGear ADA-8402-B AES/EBU Distribution Amplifier
(110ohm). Your ADA-8402-B is part of a full line of products within the openGear Terminal
Equipment family of products, backed by Ross Video’s experience in engineering and design
expertise since 1974.
You will be pleased at how easily your new ADA-8402-B fits into your overall working
environment. Equally pleasing is the product quality, reliability and functionality. Thank you for
joining the group of worldwide satisfied Ross Video customers!
Should you have a question pertaining to the installation or operation of your ADA-8402-B,
please contact us at the numbers listed on the back cover of this manual. Our technical support
staff is always available for consultation, training, or service.

1–2 • Introduction ADA-8402-B User Manual (Iss. 02)
Overview
The ADA-8402-B is an AES/EBU distribution amplifier designed for broadcast use. It provides
eight copies of the incoming balanced AES3 signal when used with the 8310AR-042 or
8320AR-042 Full Rear Modules or four copies of the incoming signal when used with the
8320AR-043 Split Rear Module. The ADA-8402-B supports audio sampling frequencies from
32kHz to 96kHz. Cable equalization and reclocking techniques enable the ADA-8402-B to
recover the incoming digital audio signal reliably.
The ADA-8402-B also includes built-in loudness measurement. The card is capable of reading
the ITU1770 LKFS Audio Measurements and displaying the measurement in DashBoard.
The 8320AR-043 high density split rear module can accommodate up to 2x ADA-8402-B cards,
each configured as a 1x4 DA, accommodating up to 20 channels of distribution per 2RU frame.
Features
The following features make the ADA-8402-B the best solution for distributing digital audio
signals:
• Operates as a:
› 1x8 AES distribution amplifier (8310AR-042 or 8320AR-042 full rear modules) or
› 1x4 (high density) AES distribution amplifier (8320AR-043 split rear module)
• 110ohm balanced AES3 I/O
• Ideal for distributing Dolby® E and Dolby® Digital signals
• Reports ITU1770 LKFS Audio Measurements in DashBoard
• Cable equalization and data reclocking on the incoming AES/EBU signal
• Supports audio sampling frequencies from 32kHz to 96kHz
• Provides level matching and level control of output signals
• Higher density with up to 20 cards per frame using the 8320AR-043 Split Rear Modules
• Fits the openGear frames
• 5 year transferable warranty

ADA-8402-B User Manual (Iss. 02) Introduction • 1–3
Functional Block Diagrams
This section provides the functional block diagrams that outline the workflow of the
ADA-8402-B.
Figure 1.1 Simplified Block Diagram — 8310AR-042 and 8320AR-042 Full Rear Modules
Figure 1.2 Simplified Block Diagram — 8320AR-043 Split Rear Module

1–4 • Introduction ADA-8402-B User Manual (Iss. 02)
User Interfaces
The ADA-8402-B offers the following interfaces for control and monitoring.
DashBoard Control System™
The DashBoard Control System™ enables you to monitor and control openGear frames and cards
from a computer. DashBoard communicates with other cards in the openGear frame through the
Network Controller Card.
For More Information on...
• the menus in DashBoard, refer to the chapter “DashBoard Menus” on page 4-1.
• using DashBoard, refer to the DashBoard User Manual.
Card-edge Controls
The ADA-8402-B provides LEDs on the card-edge that display the status of the input signals.
For More Information on...
• adjusting the output levels, refer to the section “Card Overview” on page 3-2.
• monitoring the status using the card-edge LEDs, refer to the section “Control and
Monitoring Features” on page 3-6.

ADA-8402-B User Manual (Iss. 02) Introduction • 1–5
Documentation Terms and Conventions
The following terms and conventions are used throughout this manual.
Terms
The following terms are used:
•“525-line mode” refers to broadcast situations using NTSC composite (analog) signal
reference inputs.
•“625-line mode” refers to broadcast situations using PAL-B composite (analog) signal
reference inputs.
•“Board” and “Card” refer to openGear terminal devices within openGear frames,
including all components and switches.
•“DashBoard” refers to the DashBoard Control System™.
•“DFR-8300 series” refers to all versions of the DFR-8310 series and DFR-8321 series
frames and any available options unless otherwise noted.
•“OG3-FR series” refers to the OG3-FR series frames and
•“openGear frame” refers to all versions of the DFR-8300 series and OG3-FR series
frames and any available options unless otherwise noted.
•“Operator” and “User” refer to the person who uses ADA-8402-B.
•“System” and “Video system” refer to the mix of interconnected production and terminal
equipment in your environment.
Conventions
The following conventions are used:
• The “Operating Tips” and “Note” boxes are used throughout this manual to provide
additional user information.

1–6 • Introduction ADA-8402-B User Manual (Iss. 02)

ADA-8402-B User Manual (Iss. 02) Installation • 2–1
Installation
In This Chapter
This chapter provides instructions for installing the rear module(s) for the ADA-8402-B,
installing the card into the frame, cabling details, and updating the card software.
The following topics are discussed:
• Before You Begin
• Installing the ADA-8402-B
• Cabling for the ADA-8402-B
• Software Upgrades

2–2 • Installation ADA-8402-B User Manual (Iss. 02)
Before You Begin
Before proceeding with the instructions in this chapter, ensure that your openGear frame is
properly installed according to the instructions in the DFR-8300 and OG3-FR Series User
Manual.
Static Discharge
Whenever handling the ADA-8402-B and other related equipment, please observe all static
discharge precautions as described in the following note:
Unpacking
Unpack each ADA-8402-B you received from the shipping container and ensure that all items are
included. If any items are missing or damaged, contact your sales representative or Ross Video
directly.
ESD Susceptibility — Static discharge can cause serious damage to sensitive
semiconductor devices. Avoid handling circuit boards in high static environments such as
carpeted areas and when synthetic fiber clothing is worn. Always exercise proper grounding
precautions when working on circuit boards and related equipment.

ADA-8402-B User Manual (Iss. 02) Installation • 2–3
Installing the ADA-8402-B
This section outlines how to install a rear module and card in an openGear frame. The same
procedure applies regardless of the frame or card type. However, the specific rear module you
need to install depends on the frame you are using.
Rear Modules for the ADA-8402-B
The rear module for the ADA-8402-B depends on the openGear frame you are installing the card
into.
•DFR-8310 series frame — When installing the ADA-8402-B in the DFR-8310 series
frames, the 8310AR-042 rear module is required. The ADA-8402-B is not compatible
with the DFR-8310-BNC frame.
•DFR-8321 series frame — When installing the ADA-8402-B in the DFR-8321 series
frames, the 8320AR-042 Full Rear Module, or the 8320AR-043 Split Rear Module can
be used. When using a Full Rear Module, use the even numbered slots, such as 2 or 4, to
ensure that the card aligns with the rear module.
Installing a Rear Module
If the rear module is already installed, proceed to the section “Installing the ADA-8402-B” on
page 2-4.
To install a rear module in your openGear frame
1. Locate the card frame slots on the rear of the frame.
2. Remove the Blank Plate from the slot you have chosen for the ADA-8402-B installation.
3. Install the bottom of the rear module in the Module Seating Slot at the base of the
frame’s back plane. (Figure 2.1)
Figure 2.1 Rear Module Installation in an openGear Frame (ADA-8402-B not shown)
4. Align the top hole of the rear module with the screw on the top-edge of the frame back
plane.
Screw Hole
Module Seating Slots

2–4 • Installation ADA-8402-B User Manual (Iss. 02)
5. Using a Phillips screwdriver and the supplied screw, fasten the rear module to the back
plane of the frame. Do not over tighten.
6. Ensure proper frame cooling and ventilation by having all rear frame slots covered with
rear modules or Blank Plates.
Installing the ADA-8402-B
This section outlines how to install the ADA-8402-B in an openGear frame. If the ADA-8402-B
is to be installed in any compatible frame other than a Ross Video product, refer to the frame
manufacturer's manual for specific instructions.
To install the ADA-8402-B in an openGear frame
1. Locate the rear module you installed in the procedure “Installing a Rear Module” on
page 2-3.
2. Hold the ADA-8402-B by the edges and carefully align the card-edges with the slots in
the frame.
3. Fully insert the card into the frame until the rear connection plus is properly seated in the
rear module.
4. Verify whether your label is self-adhesive by checking the back of the label before
applying the label to the rear module surface.
5. Affix the supplied Rear Module Label to the BNC area of the rear module.

ADA-8402-B User Manual (Iss. 02) Installation • 2–5
Cabling for the ADA-8402-B
This section provides information for connecting cables to the installed rear modules on the
openGear frames. Connect the input and output cables according to the following sections. The
input is internally terminated in 110ohm and it is not necessary to terminate unused outputs.
DFR-8310 Series Frame Cabling Overview
The ADA-8402-B is used with the following rear modules:
•8310AR-042 Full Rear Module — Each rear module occupies one slot and
accommodates one card. This rear module provides one AES input and eight AES
outputs. (Figure 2.2)
DFR-8321 and OG3-FR Series Frame Cabling Overview
The ADA-8402-B is used with the following rear modules:
•8320AR-042 Full Rear Module — Each rear module occupies two slots and
accommodates one card. This rear module provides one AES input and eight AES
outputs. (Figure 2.2)
•8320AR-043 Split Rear Module — Each rear module occupies two slots and
accommodates two cards. This rear module provides one AES input and four outputs per
card. (Figure 2.3)
Figure 2.2 Cable Connections for the
8310AR-042 and 8320AR-042 Rear Modules
Figure 2.3 Cable Connections for the
8320AR-043 Split Rear Module

2–6 • Installation ADA-8402-B User Manual (Iss. 02)
Software Upgrades
The card can be upgraded in the field via the MFC-8300 series Network Controller card in your
frame.
To upgrade the software on a card
1. Contact Ross Technical Support for the latest software version file.
2. Display the Device View of the card by double-clicking its status indicator in the Basic
Tree View.
3. From the Device View, click Upload to display the Select file for upload dialog.
4. Navigate to the *.bin upload file you wish to upload.
5. Click Open.
6. If you are upgrading a single card, click Finish to display the Uploading to Selected
Devices dialog. Proceed to step 8.
7. If you are upgrading multiple cards:
•ClickNext > to display the Select Destination menu. This menu provides a list of
the compatible cards based on the card selected in step 2.
• Specify the card(s) to upload the file to by selecting the check box(es) for the cards
you wish to upload the file to.
• Verify that the card(s) you wish to upload the file to. The Error/Warning fields
indicate any errors, such as incompatible software or card type mismatch.
•ClickFinish to display the Uploading to Selected Devices dialog.
8. Monitor the upgrade.
• Monitor the upgrade progress bar displayed in DashBoard while the software is
upgraded on your card.
• The card(s) automatically re-boot and are temporarily taken offline during the
re-boot process. The process is complete once the status indicators for the Card
State and Connection fields return to their previous status.
Note — DashBoard version 3.0.0 or higher is required for this procedure.
