Optelecom-nkf XSNet 2800 SW User manual

XSNet 2800 SW
(Firmware v.3)
Field-hardened layer-2 Ethernet switch with 2 optical Gbit uplinks + 8 10/100Base-T ports
USER MANUAL
©Optelecom-NKF 2006
Version v.1.0b (060203-1b)
XSNet2800SWv3 (MW03SP2)

2
Table of Contents
Part I: description, features, hardware installation......................................................... 3
1. General description ........................................................................................................................................3
2. Front panel features .......................................................................................................................................3
3. Installation.......................................................................................................................................................4
3.1. Initial configuration notes......................................................................................................................... 4
3.2. Hardware installation ...............................................................................................................................4
3.3. Software installation.................................................................................................................................4
Part II: Configuration pages ....................................................................................................... 5
1. Logging in ........................................................................................................................................................ 5
2. XSNet 2800 Home page ..................................................................................................................................7
3. XSNet 2800 network settings .........................................................................................................................8
4. XSNet 2800 SW alarms ..................................................................................................................................9
5. 2800 SW VLANs ...........................................................................................................................................10
VLAN Control and VLAN Port Control.........................................................................................................11
Settings example ..............................................................................................................................................12
Application example ........................................................................................................................................13
6. XSNet 2800 SW Quality of Service (QoS) ..................................................................................................14
7. XSNet 2800 SNMP management by traps and/or polling ........................................................................15
Introduction .....................................................................................................................................................15
Traps.................................................................................................................................................................15
Polling ..............................................................................................................................................................16
8. XSNet 2800 SW RSTP..................................................................................................................................17
9. XSNet 2800 multicast settings .....................................................................................................................20
10. XSNet 2800 SW Port Settings....................................................................................................................21
11. XSNet 2800 SW port statistics...................................................................................................................22
12. XSNet 2800 Reboot and restore ................................................................................................................23
13. Safety, EMC, ESD.......................................................................................................................................25
14. Technical specifications..............................................................................................................................25

3
DC
P10
P9
P3
P2
P1
12
3
6
8
9
4
10
1Gb
1Gb
2800SW
P8
P7
P6
P5
P4
5
7
10/100 Mb
PLEASE READ THE DOCUMENT 'QUICK START' BEFORE INSTALLING THIS EQUIPMENT
XSNet 2800 SW v.3
Part I: description, features, hardware installation
1. General description
XSNet 2800 SW switches will handle eight electrical
(Ethernet) data streams, and also provide two
independent gigabit optical uplinks through SFP single-
mode or multimode packages using two fibres per port
(wavelengths 850 nm, 1300 nm, or CWDM) or one
fibre (SM-BiDi option, ca. 10 km). The switches are
especially suitable for use in outdoor housings.
The non-blocking, highly configurable switches support
the following protocols: ARP, LLC, IP, UDP, IGMP,
Spanning Tree (STP) and Rapid Spanning Tree
(RSTP).
Front panel status LEDs provide information about
power, port speed and port activity.
The switches come in the form of double-width (14TE)
Eurocassettes fitting in MC 11 or similar power supply
cabinets, or as stand-alone units (/SA option). Device
configuration can be performed in-band using the built-
in http server. In-band device and link management
using a GUI can be performed with the aid of
Optelecom-NKF utility programs based on the MX
protocol. In an EB-2 type power supply cabinet, the
switches can be configured and managed with the SNM
protocol [variable by name protocol not implemented].
2. Front panel features
The 2800 SW front panel, shown in figure 1, has
features as listed in table 1 below and represented in
figure 1.
Feature Function
Connectors
Optical LC (dual), 9, 10 optical Ethernet ports
RJ45, jack, 8x (1-8) 10/100TX Ethernet ports
Status LEDs
*DC green DC power OK
link speed 10 Mbit/s
blinking: data activity
link speed 100 Mbit/s
blinking: data activity
*P1-*P8
{
yellow
green
off no connection
*P9, *P10 green green: sync OK
blink: data activity
off: no sync received
Table 1. Front panel connectors and indications
Figure 1. XSNet 2800 SW front panel

4
3. Installation
3.1. Initial configuration notes
Before installing and trying to link up the switch in a network, please read the separate guide detailing
how to set the IP address and subnet mask, and if necessary the gateway address, for initial installation.
3.2. Hardware installation
A Eurocassette module will slot into an Optelecom-NKF power supply cabinet, model MC 11 or similar. A
stand-alone model may be mounted in any suitable environment that will not make it overheat or malfunction in
other respects: some natural air circulation, moisture lockout and prevention of dust or grime accumulation are
always desirable.
The switch will power up in a few seconds, performing auto-negotiation on the 100 Mbit ports. The Spanning-
Tree Protocol (if applicable) and Rapid Spanning-Tree protocol have convergence times of 10-30 and typically 4
seconds, respectively. Generally, the ports will all be up and running within a minute after powering up into a
network.
3.3. Software installation
Only the items needed for putting the switch into operation, and some auxiliary features, will be described here.
With in-band configuration using the built-in HTML pages, the main switch parameters can be set. The
following chapters contain a description of how to go about this.

5
XSNet 2800 SW
Part II: Configuration pages
1. Logging in
Logging in to the XSNet 2800 SW internal http server enables the user to configure the switch without using
separate application software. A standard Web browser will suffice to find the module by its IP address.
Activate the LOGIN button on the login screen that will appear (see figure 1 below).
After the Connect box appears (see below), a fresh module can be accessed as follows:
-login as ‘admin’
-leave the password field blank
-activate the OK button or press ‘Enter’
Figure 1. Part of the first screen: Login pane
Figure 2. Login box

6
After completing login, the Home page (see the Homepage section) will appear.
The other HTML pages can be then called up from the navigation menu appearing in the top left corner of each
page (figure 3a); each page may consist of several sections. Each section has an information button , which
can be activated to display help.
The HTML pages share the following features:
-a menu to access the pages (see figure 3a)
-a diagram (figure 3b) showing which ports are in use, i.e. connected to another active device
-panes (sections) showing parameter values, some of which are editable
-buttons, mainly SAVE, REFRESH and CANCEL, for sections with editable fields
Writing changes into the device after editing is done by activating the SAVE button.
The actual values still in the device are shown using the REFRESH button.
Activating CANCEL undoes any changes made before saving and shows the values as they were before editing.
Main operational variables and modes to be set are (see also figure 3a):
-Network addresses
-Port speed and mode
-Unicast and multicast
-RSTP (spanning tree/rapid spanning tree protocol) settings
Figures 3a,b. Page selection menu (left) and port connections

7
2. XSNet 2800 Home page
This page (see figure 4) has the following sections:
-Identification pane: administrative data, including the article code, serial number, software version, and
uptime
-Labels pane: label entries (editable)
-Status pane: an alarm status overview (alarms active or not), including the level of the highest occurring
configured alarm (Module status field).
On this page, only the 32-character labels can be edited; please activate the SAVE button if after making changes
you wish to make them definitive and active. However, if you decide to stop editing and return to view the
original values, use either the REFRESH or the CANCEL button.
The Module status will be ‘OK’ if there is no configured alarm active (see the Alarms page); otherwise it could
appear as a character from A-N, depending on the alarms configuration.
Figure 4. Home page, with Identification, Labels and status sections

8
3. XSNet 2800 network settings
For correct functioning of the 2800 SW, it is essential to set its network addressing to be compatible with the
subnet it is hooked into; see figure 5.
The Network settings pane shows the IP address. It is essential to set at least this address correctly and to
keep the value on record, otherwise management of the switch will require special software. Note that the
subnet address is also required.
The Subnet and Gateway settings show subnet mask and default gateway. Assuming the device IP address and
subnet mask are already set correctly, only the default gateway needs to be defined in order to connect the
network segment to others.
The entries in the MX alarm settings pane serve to support a video IP system using the MX protocol. The setting
shown (255.255.255.255) indicates the MX packets are being broadcast.
After filling in the addresses, use the SAVE button to set them. After saving, in-band communication with the
2800 SW will be interrupted and the user will have to contact the device again using the new IP address.
Figure 5. Network page

9
4. XSNet 2800 SW alarms
The Alarms settings page shows the Status and Alarm level settings panes. In the Status pane, the Module Status
entry shows the highest level of the occurring and configured alarms, while the other fields in that pane represent
the actual status of some alarms. These alarms are not necessarily assigned a level; this can be done in the pane
‘Alarm level settings’.
Alarm levels can be set to A-N, or to ‘_’ (equivalent to ‘O’), the latter meaning no alarm level set. In the
example screenshot, one alarm level was already set and another was in the process of being set. Setting an alarm
level A-N also means the alarm will actually go off if a certain condition is met. For the 2800 SW, these
conditions are:
Power supply alarm Indicates an active power supply alarm (2V5 or 3V3
outside 5% of their nominal value)
Temperature alarm Indicates an active temperature alarm (temperature above
the selected value, default is 70oC)
Link loss alarm (port 9) Indicates link of gigabit port 9 is down
Link loss alarm (port 10) Indicates link of gigabit port 10 is down
Bad connection alarm
(ports 9 & 10)
Indicates whether gigabit ports 9 and 10 together
experienced more than 10 000 CRC errors (value can be
changed using suitable software)
After setting an alarm level, first activate the SAVE button, then the REFRESH button to update other values
displayed.
Figure 6. Switch alarms configuration page
Table 1 XSNet 2800SW alarms

10
5. 2800 SW VLANs
XSNet 2800 switches support up to 50 virtual tagged LANs, organizing ports into separate groups. These
VLANs are to be enabled from the VLAN Control menu with at least one entry in the VLAN Port Control menu,
and a management VLAN defined. The latter is essential: without it, all in-band contact with the switch would
be lost. So: define a management VLAN first before enabling VLANs.
The 802.1q tags can contain a VLAN ID and/or a priority level. If only the latter is present, the VID is zero; the
frame is then called a ‘P-frame’ (priority-only frame) not to be confused with a pause frame.
VLAN entries: defining a 2800 SW tagged VLAN
On the VLAN Entries page, use the edit window (see figure 7) to fill in a row for each VLAN you want to
define. For each port, two entries must be considered:
-the port VLAN membership, indicating that a port should be a member of the VLAN to be defined
(membership of more than one VLAN is of course allowed)
-untag (i.e. remove Q-tags), indicating that tags holding VLAN and priority information should be
removed from the output.
For a port connected to another switch, there should be no untagging if the VLAN extends over several
switches. For edge ports, the stream should generally be untagged.
A management computer should be connected to an untagging VLAN port unless the application running on it
and the network interface card involved will handle Q-tags sensibly.
By clicking on an existing VLAN entry, it can be edited in the edit window, indicated by the arrow. Pressing
SAVE will consolidate the modified entry if the VLAN ID did not change, or add an entry if a new VLAN ID
was added.
Pressing the DELETE button while an entry is present in the edit window will irrevocably disable and remove
that VLAN.
Remember to use the SAVE button to store your VLAN definitions and settings.
Before enabling VLANs on the VLAN control page, be certain to fill in matching VLAN IDs in the VLAN Port
Control pane there.
Figure 7. 2800 SW VLAN entries. The arrow indicates the edit window

11
VLAN Control and VLAN Port Control
Before any entry on this page is made, the list on the VLAN Entries page must be filled in.
If - in the VLAN Control pane - the VLAN Enable box is checked, it is possible to add, remove or modify Q-
tags in packets, according to the ingress rules set in the VLAN Port Control pane (see figures 8 and 11).
If VLANs are enabled, the following ingress options are available:
- incoming Q-tagged frames can be modified as follows (see figure 9):
-they can be left as they are
-the VLAN ID can be changed
-both VLAN and priority can be changed.
This can be done with the ‘Q-frame’ selection box (see figure 9 below):
Figure 8. 2800 SW VLAN control and Port Control settings
Figure 9. 2800 SW VLAN Control , Q-frame menu options

12
- incoming non-Q frames can be handled as follows (see figure 10):
-a default Q-tag can be inserted
-the priority inside the tag is preserved (this if the VLAN ID is zero but a priority value is set)
-they can be dropped ( this also for tags in which the VLAN ID is zero)
This can be done with the ‘non-Q frames’ selection box, with the exception of the framesdropping, which is set
by checking the tick boxes of the ‘Drop non-Q-frames’ row in the VLAN Port Control pane (see figure 11
below).
The ingress rules are defined per port, in the VLAN Port Control pane. There, any port can be configured to drop
non-Q-frames (arrow in figure 11). If set, this has prevalence over tag insertion or modification.
Settings example
With VLANs enabled, a port connected to another switch (a non-edge port) generally would be set to:
-drop non-Q-frames (ingress, per port),
-do not untag Q-frames (egress, per port, per VLAN)
An edge device generally does not handle received Q-tags or send such tags. However, at the switch input port, a
Q-tag may be inserted holding a VLAN ID and priority assigned to the device according to the ingress rules
defined in the VLAN Port Control pane, so VLAN Control settings for an edge port would be:
-untag (egress, per port, per VLAN)
-insert default Q-tag (ingress).
The default Q-tag (per port) is defined on the VLAN Control page, under VLAN Port Control.
Figure 10. 2800 SW VLAN Control , non-Q-frame menu options
Figure 11. 2800 SW VLAN port ingress rules

13
Application example
With the switches SW 1 (137.92.254.10) and SW2 (.11) interconnected (see figure 12), traffic between the
switches should include all packets that have any business on the other switch; this includes the management
packets coming from elsewhere in the network.
Three VLANs (v1, with VLAN ID 1, v5, with VLAN ID 5, and the management VLAN, with ID 10) are
indicated; the other ports belong to other VLANs, either local to the switches or extending over other switches.
At least one port connected to the network must be a member of VLAN 10.
The four PCs (101, 102, 203, 204) connected to the VLAN 1 ports are transmitting and receiving untagged
packets. With VLANs enabled, the ports would be configured as follows:
SW1, ports 1, 2; SW2, ports 3, 4:
-port ingress: tag with VLAN ID 1, priority 0-7
-port egress: untag the VLAN packets going to the device
(for computers connected to SW1, ports 5,6 and SW2, ports 7, 8: similarly use VLAN ID 5)
Both switches, ports 9:
-ingress: Q-frames must be left as they are, non-Q-frames are to be blocked
-egress: here, both ports are member of all three VLANs indicated, so at least the packets tagged with
any of the VIDs (1, 5, 10) indicated are transmitted
SW2, port 10:
If any of the VLANs indicated span more than these two switches, at least the packets belonging to those
VLANs are to be sent out; in the drawing, this port is a member of all VLANs indicated. In any case,
management (VLAN 10) packets must be allowed to travel over the whole network, to allow switch management
from anywhere.
Internet
Router
untagged frames
SW 1
IP : 137.92.254.11
PC
101
PC
102
4
6
8
2
5
1
9
10
3
7
4
6
8
2
5
1
9
10
3
7
SW 2
v1
v5
v1
v5
Ports 9, 10 are members of
VLAN v1, v5, v10
vid 1, 5, 10
tagged frames
vid 1, 5, 10
tagged frames
PC
204
PC
203
Ports 9, 10 are members of
VLAN v1, v5, v10
untagged frames
IP : 137.92.254.10
Figure 12. 2800 SW switches with two VLANs

14
6. XSNet 2800 SW Quality of Service (QoS)
Enabling QoS on the 2800 SW instates two priority levels (high/low) and corresponding queues, used in case of
network congestion. These levels can be defined as follows:
-Port based: tagged and untagged frames entering a port marked ‘high’ go to the high-priority queue.
-Priority based: per Q-frame (only priority level 0-7 in tag is important). A TCI lo/hi threshold of 1-7
must be set. Tagged frames with a priority level equal to the TCI-threshold and up go into the high-
priority queue.
(TCI = tag control information)
Fulfilling either of these two conditions (see the arrows in figure 13) will get a frame into the high-priority
queue.
The H-weight and L-weight entries (values allowed are 0-15), defining how fast the queues are handled, must be
set. They are defined as:
-H-weight = m (default 4): after handling maximum of mhigh-priority frames, start with low-priority
frames
-L-weight = n(default 1): after a maximum of nlow-priority frames, return to handling high-priority
frames.
Figure 13. The example has QoS enabled, weights of 4 and 1, ports 1-3 set to high priority, and a TCI-threshold of 4.

15
7. XSNet 2800 SNMP management by traps and/or polling
Introduction
To prepare the XSNet 2800 switch for SNMP management, the database documenting the 2800’s variables
amenable to readout and/or modification must be registered with the program; such SNMP MIB documents are
available from our web site.
The System Information pane (on the SNMP HTML page, see figure 14) shows the network/device data
specifically made available to the SNMP manager for making the device, its location and service manager(s)
traceable.
You will always need to set the community strings (names) in the Communities pane to conform to those
configured in the SNMP manager. Often, these are ‘public’, mainly used for the read and trap communities, and
‘private’ or ‘netman’, for read-write operations. The manager software may offer additional choices.
Traps
Traps generated by the XSNet 2800 SW can be caught by any SNMP manager. Traps can be generated by
configuring an alarm level A-N on the Alarm settings page for the available events or variables to be monitored
using the SNMP manager program.
In the Traps pane (figure 14), at least the following information must be entered:
-the SNMP version used
-the IP address associated with the manager program, and the destination port (162 is a sensible default).
If desired, an alternative destination IP can be added. It is also possible to add an authentication trap to be able to
catch attempts at access using the wrong community string.
Figure 14. 2800 SW SNMP settings

16
The 2800 SW will always generate cold boot and port link up traps (if connected) while booting; this behaviour
is fixed through using the SNMP MIB group mgmt:snmp:snmp-Traps:TrapsInfo (in RFC1213-MIB). Link-
down/up traps will be sent when a port is disconnected and connected, respectively.
Polling
Depending on facilities offered by the SNMP manager, a number of variables can be read out and in a few cases
be edited and set. Many 2800 SW variables are contained in the ‘system’ and ‘interfaces’ sections of RFC1213-
MIB. Others are found in RFC1493 (bridge MIB), RFC1493 (Ethernet), and RFC1757 (RMON MOB).
The examples and drawing are taken from the Castle Rock SNMPc manager.
Figure 16. A number of devices centred around two switches connected to a management PC;
diagram drawn by hand in Castle Rock’s SNMPc.
Figure 15. Part of the 2800 SW port table called up using Castle Rock’s SNMPc. Admin status can be set by the user

17
8. XSNet 2800 SW RSTP
Introduction
Rapid Spanning Tree Protocol (RSTP) is an evolution of the Spanning Tree Protocol (802.1D standard) and
provides for faster spanning tree convergence after a topology change.
When RSTP is enabled, it ensures that only one path at a time is active between any two nodes in the network.
We recommend that you enable RSTP on all switches to ensure that only single active paths in the network exist.
The RSTP uses a distributed algorithm to select a bridging device (STP-compliant switch, but it could be a
bridge or router) that serves as the root of the spanning tree network. Then it selects a root port on each switch
(except for the root device) which incurs the lowest path cost when forwarding a packet from that device to the
root device. Thirdly, it designates a switch in each LAN which incurs the lowest path cost when forwarding a
packet from that LAN to the root device. Viewed from the root device, all ports connecting to (the root ports of)
designated switches are assigned as designated ports. After determining the lowest-cost spanning tree, the RSTP
enables all root ports and designated ports, and disables all other non-edge ports. Network packets are therefore
only forwarded between root ports and designated ports, eliminating any possible network loops.
RSTP and the 2800 SW
The XSNet 2800 SW can use the Rapid Spanning Tree Protocol, which can be enabled or disabled for the switch
as a whole, not per VLAN. Port configuration for this protocol works as follows (see the tables in figure 17):
-under General RSTP settings, specify the values for Bridge priority, Forward delay, Hello time and
Max age. Generally, the defaults shown will suffice.
-under RSTP port settings (third pane, Admin Edge column), specify for each port whether it is an edge
port (connected to an end device), or a non-edge port (such as a backbone port)
-specify path cost and priority.
-SAVE the RSTP configuration, after enabling RSTP on the General RSTP settings pane.
Figure 17. XSNet 2800 SW (R)STP settings

18
Each port 1-10 can be set to be either an edge port or a non-edge port. Edge ports should not be connected to
form loops, since rapid spanning-tree will ignore edge ports. Optical ports 9-10 are factory set to be non-edge
ports; ports 1-8 are set to edge.
RSTP related terminology is explained in table 2.
By default, RSTP is on unless another connected switch within reach of the algorithm is set to use STP.
RSTP Parameter Description
Priority (bridge) The priority value is used to identify the root bridge. The bridge with the
lowest value has the highest priority and is selected as root. Enter a value
from 1 to 61440.
Max Age The Max Age value is the number of seconds a bridge waits without
receiving Rapid Spanning Tree Protocol configuration messages before
attempting a reconfiguration. Enter a time in seconds from 6 to 40.
Hello Time The Hello time value gives the time between the transmissions of Rapid
Spanning Tree Protocol configuration messages. Enter a time in seconds
from 1 to 10.
Forward Delay time The forward delay time is the number of seconds a port waits before
changing from its Rapid Spanning Tree Protocol learning and listening
states to the forwarding status. Enter a time in seconds from 4 to 30.
Port Priority A port's priority in becoming the root port. The allowed range is between 0-
255. Its default setting is 128. The lowest number has the highest priority.
Path Cost Specifies the path cost of the port. The Switch uses this to determine which
ports are the forwarding ports. The lowest numbers assigned are the
forwarding ports. The range is between 1 and 65535 and the default values
based on IEEE802.1d are:
10Mb/s = 50-600 100Mb/s = 10-60 1000Mb/s = 3-10
EdgePort Users can enable this option if an interface is attached to a LAN segment
that is at the end of a bridged LAN or to an end node. Specifying EdgePorts
provides quicker convergence for devices such as workstations or servers,
retains the current forwarding database to reduce the amount of frame
flooding required to rebuild address tables during reconfiguration events,
does not cause the spanning tree to initiate reconfiguration when the
interface changes state, and also overcomes other STP-related timeout
p
roblems. However, remember that EdgePort should only be enabled for
ports connected to an end-node device.
Port Role, Port State This will display the ports' roles and states as per their settings. See table 3
below for an RSTP/STP state equivalence table.
Table 2. RSTP glossary
STP (802.1D)
Port State
RSTP (802.1w)
Port State
Port Included in
Active Topology?
Port Learning
MAC Addresses?
Disabled Discarding No No
Blocking Discarding No No
Listening Discarding Yes No
Learning Learning Yes Yes
Forwarding Forwarding Yes Yes
Table 3. STP and RSTP port states.

19
With RSTP not enabled, the switch is still compatible with STP switches, but will not actively partake in the
STP configuration: the ports are all forwarding (see figure 18).
To force full compatibility with STP-only equipment from the start, you will need additional MX configuration
software (set the internal variable Force Version to zero).
Figure 18. XSNet 2800 SW (R)STP with RSTP not enabled

20
9. XSNet 2800 multicast settings
The 2800 SW series switches support multicasting, each group of receivers listening to its own source. Inside a
switch, regular unicast traffic only passes through the central switch matrix, unaffected by the multicast switch
mode. Multicast streams are processed separately, but can share ports with unicast streams.
If multicasting is being used and non-backbone port output is needed, the switch mode needs to be set to 'IGMP
enabled' (see figure 19, first entry under ‘Multicast settings’).
On this page, each port can be set to one of the following modes when the switch handles multicasting:
-Transmitter mode: the switch will block all outgoing multicast traffic for this port. Multicast traffic entering
the port from outside will pass, so this is a switch entry port for a multicast transmitter.
-Receiver mode: outgoing multicast traffic will be allowed to pass, incoming multicast traffic is blocked.
-Backbone port (all multicast): all multicast traffic will internally be forwarded to and appear on the port,
irrespective of IGMP queries or IGMP memberships.
On receipt of a leave message, a port will either (1) if it is an non-edge port, ignore it because still other clients
may have subscribed themselves to that particular multicast stream, or (2) if it is an edge port (such as in an end-
node device), be disabled for this stream.
Figure 19. XSNet 2800 SW multicast settings
