TRENDnet TEG-S5g - Gigabit GREENnet Switch User manual

TEG-S5g
TEG-S8g
Quick Installation Guide

Table of Contents
Table of Contents
Version 02.26.2009
Technical Specifications .............................................................................
Troubleshooting ..........................................................................................
1
1
3
4
6
Español .......................................................................................................
1. Antes de iniciar ...................................................................................
2. Instalación del Hardware ....................................................................

1
Español
1. Antes de iniciar
Contenidos del paquete
Requisitos del sistema
•
Guía de instalación rápida
•
TEG-S5g/TEG-S8g
•
Adaptador de alimentación AC
•Un PC con adaptador de red instalado correctamente
•Cable de Red CAT 5e o 6
•La superficie debe soportar al menos 1,5 Kg para el conmutador
•La toma de corriente debe estar a 1,82 metros (6 pies) del conmutador
•Inspeccione visualmente el jack de corriente DC para comprobar que
está conectado al adaptador de corriente
•Compruebe que existe una correcta regulación de la temperatura y una
ventilación adecuada alrededor del conmutador
•No coloque objetos pesados encima del conmutador

2
60m
Full Power
60m
Delivers less power
to unused ports
1
100m
100m
20m
Regular
Switch
GREENnet
Switch
20m
Delivers less power
when devices are off
Delivers less power
with shorter
cable lengths
2
3
on on
less power
on on
off less power
Related Products
60m
Full Power
60m
Delivers less power
to unused ports
1
100m
100m
20m
Regular
Switch
GREENnet
Switch
20m
Delivers less power
when devices are off
Delivers less power
with shorter
cable lengths
2
3
on
less power
on
off less power
on
on
Español
Aplicación

3
Español
2. Instalación del Hardware
2. Conecte un cable de red RJ-45
CAT 5e o 6 del PC a un puerto
Ethernet disponible en el
TEG-S5/TEG-S8.
1. Conecte el adaptador de
alimentación AC al
TEG-S5/TEG-S8 y luego a una
toma de corriente.
La instalación ha sido completada
Registre su producto
Para asegurar los más altos niveles de servicio y apoyo al cliente, registre su producto
en línea en: www.trendnet.com/register
Gracias por elegir TRENDnet

4
Technical Specifications
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
Protocol CSMA/CD
Data Transfer Rates
Ethernet:
10Mbps (Half-Duplex), 20Mbps (Full-Duplex)
Fast Ethernet:
100Mbps (Half-Duplex), 200Mbps (Full-Duplex)
Gigabit Ethernet:
2000Mbps (full-duplex)
Network Cables
Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT-5, 5E , 6
Gigabit : UTP/STP CAT-5e, CAT-6 (Recommended)
Number of Ports
TEG-S5g:
5 x 10/100Mbps Auto-negotiation, Auto-MDIX ports
TEG-S8g:
8 x 10/100Mbps Auto-negotiation, Auto-MDIX ports
General
Topology
LEDs
Star
Per Port: LINK/ACT
Per Unit: PWR

5
DC inputs Switching Power: 5V DC, 2A
Linear Power: 9V DC, 1A
Temperature Operating: 0 ~ 50 C° °
Dimensions (L x W x H) mm150 x 105 x 33
Weight 225g
Physical and Environmental
Humidity
Certification
Operating: 10% ~ 90%
CE, FCC
Power Consumption TEG-S5g: 3W
TEG-S8g: 6W
Transmission Method Store-and-Forward
Packet Filtering/
Forwarding Rate
10Mbps Ethernet: 14,880pps (packet per second)
100Mbps Fast Ethernet: 148,800pps
1000Mbps Gigabit Ethernet: 1,488,000pps
MAC Address Learning
Switch Fabric
Filtering Address Table
Automatic update
TEG-S5g: 10Gbps Forwarding Capacity
TEG-S8g: 16Gbps Forwarding Capacity
TEG-S5g: 1K entries per device
TEG-S8g: 4K entries per device
Performance

6
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
After connecting the Switch to a power outlet, the LEDs do not turn
on.
Check the connection of the external power adapter to the
When I connect a computer to the Switch port, the PWR and
LINK/ACT LED turns on, but the 100/1000Mbps LED remains off or the
light is yellow.
When the 100/1000Mbps LED remains off or is yellow, the computer's
connection speed is 10Mbps and 100Mbps, respectively. First, check
the Ethernet Cable. Make sure you are using CAT-5e or CAT-6 Ethernet
Cables. Some CAT-5 cables are not rated to run in Gigabit. Second,
make sure that you have a Gigabit Ethernet Adapter installed on your
computer.
After I connect my PCs to the Switch, I am unable to share files.
First, check the LEDs on the Switch. Make sure the LINK/ACT LED is
on.
The Switch was not designed to share Internet between multiple
computers. You need to get an Internet router, such as the
TW100-S4W1CA.
TEG-S5g/TEG-S8g and the power outlet. Also check that the power
outlet is receiving power.
Second, check the network cable. The minimum length of the cable is
1.5 meters and the maximum length of the cable is 100 meters. Third,
disable any software firewall program. Fourth, verify that you have file
sharing enabled. Please contact your operating system support for more
information.
After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
If you still encounter problems or have any questions regarding the
TEG-S5g/TEG-S8g please contact Trendnet's Technical Support Department.
