OPTICOM M3000 User manual

Mobile Pan/Tilt
We have teamed up with FLIR, the world leader in Thermal Imaging Technology, to offer the most cutting
edge thermal imaging technology available.
Thermal Imaging cameras are the most powerful tools available for 24-hour security coverage. When
conditions are its worst, FLIR is at its best. See clearly in total darkness, through dust, smoke, and light
fog. Thermal Imaging security cameras provide effective, economical solutions for vital areas, day and
Opticom has served the security and surveillance industry since 1973 specializes in solving the most
challenging projects with field proven products.
Fixed Camera M3000
Fever Scan Camera
M3000L
Fever Scan Camera
Product Information Bulletin

Mobile Camera
High Performance Thermal Imaging
*Includes Remote Control
Features
Specifications
Optional Accessories
TI-PT07
Thermal Imaging
High Resolution Thermal Imager
High Impact Window
Automatic Image Optimization
Automatic Window Heater
Easy to Install
1500 ft Range
Sensor Type: 320-240 Uncooled Microbolometer
Field of View: 36d H-27d V
Spectral Band: 8-14 Microns (LWIR)
System: NTSC/PAL
Weather Resistance: Hermetically Sealed
Window: High Impact Resistant with built in automatic Heating Element
Power: 12VDC or 24VACPower: 12VDC or 24VAC
Power Consumption: 2W (6W with heater on)
Operating Temperature: -40 to +176 Degrees Farenheit / -40 to +80 Degrees Celsius
Dimensions: 6” x 6” x 13” / 152 x 152 x 330 mm
Hi-Resolution, 8mm color camera to provide daytime overview image

Long Range Thermal Camera
Features
Specifications
Optional Accessories
Fixed Camera
TI-F07
Thermal Imaging
Automatic Image Optimization
Internal Heater
Superior Image Quality
Color Overview Camera
Platform for Perimeter Security
1500 ft Range
Sensor Type: 320-240 Uncooled Microbolometer
Field of View: 36d H-27d V
Spectral Band: 8-14 Microns (LWIR)
System: NTSC/PAL
Weather Resistance: Hermetically Sealed
Window: High Impact Resistant with built in automatic Heating Element
Power: 12VDC or 24VACPower: 12VDC or 24VAC
Power Consumption: 2W (6W with heater on)
Operating Temperature: -40 to +176 Degrees Farenheit / -40 to +80 Degrees Celsius
Dimensions: 6” x 6” x 13” / 152 x 152 x 330 mm
Hi-Resolution, 8mm color camera to provide daytime overview image

Fever Scan Camera
Features
Specifications
M3000
Specialty Camera
Pre-definable values for abnormal body temperatures
Grayscale image using red to indicate high temperatures
Adjustable display palette temperature range
Ability to “spot-check” with mouse for accurate crosshair temperature readings
Customizable high-temperature alarm
Log file records alarm data
Turn-key system contains thermal camera head, display software, and data acquisition/recording system.Turn-key system contains thermal camera head, display software, and data acquisition/recording system.
_

“Lite” Fever Scan Camera
Features
Specifications
M3000L
Specialty Camera
Dual Vision (thermal and visual) system for easy screening
Pre-definable values for abnormal body temperatures
Grayscale image using red to indicate high temperatures
Adjustable display palette temperature range
Ability to “spot-check: with mouse for accurate crosshair temperature readings
Customizable high-temperature alarm
Log File records alarm dataLog File records alarm data
System contains dual vision camera head, display softeare, cpu, LCD monitor
with built in speakers, keyboard, mouse and black body for continuous calibration
