OPTICOM IPB-721 User manual

Features
Specifications
115 ft IR Day/Night Outdoor IP Camera
IPB-721
Specialty Camera
1/3” Sony Super HAD CCD
Two Way Audio
Power over Ethernet IEEE 802.3af
1 x alarm input, 1 x alarm output
IP67 Rated Weatherproof Housing
Multi-Lingual User Interface
16 Channel Surveillance Software16 Channel Surveillance Software
Image Sensor: 1/3” Sony Super HAD
Resolution: 520 TV Lines
Lens: 16mm
Digital Zoom: 10x Digital
Illumination: 0.1 Lux
IR Distance: 115 ft
IR LEDs: 35IR LEDs: 35
S/N Ratio: More than 60dB
Video Compression: Motion JPEG, MPEG-4 Part2, Profile: SP
Resolutions: Motion JPEG, MPEG-4 (704 x 480 to 176 x 120 via API)
Frame Rate: 25/30
Video Streaming: Simultaneous Motion JPEG and MPEG-4 (Dual Streaming)
Image Settings: Brightness, Contrast, Saturation, Hue, Overlay Capabilities
Video Output: 1 x Analog Composit, BNC 75 OhmVideo Output: 1 x Analog Composit, BNC 75 Ohm
Shutter Speed: 1/60 ~ 1/100,000
Audio: Two-way, External Microphone input or line input
Security: Multiple User Access Levels with Password Protection
Users: 5 Simultaneous Users, Unlimited Number of Users using Multicast
Alarm & Event: Input - Alarm Buffer, Motion Detection; Output - FTP, SMTP, HTTP Event
Connectors: RJ-45 for Ethernet (with POE), DC Power Jack, 3.5mm jack for Mic/Line, 3.5mm jack for line out, BNC
Power: 12V DC, 1A, Max 5WPower: 12V DC, 1A, Max 5W
Operating Temp: -22 ~ 122 F / -30 ~ 50 C
Requirements:

Pentium 4 2.8GHz (or equivalent
AMD)

64 MB RAM Graphic Cards (or
equivalent on-board cards)

512MB RAM
 
Windows 98, ME, 2000, 2003, XP,
Vista

Mac OS Leopard 10.5
