Optim O2500 User manual

O2500 Hand Vacuum
Compact design for easy cleaning
and the convenience of an
integrated flashlight.

2
1
2
3
5
4
6
7
8

3
Features:
1. Flashlight
2. Vacuum on/off button
3. Battery indicator
4. Charger port (not shown)
5. Flashlight on/off button
6. Flashlight indicator
O2500 Hand Vacuum
Congratulations on the purchase of your new Optim Hand
Vacuum. There are many useful features built into your
hand vacuum. We recommend that you carefully read this
instruction manual for the best results.
Specifications:
Wattage: 70W
Voltage: 7. 2V
Battery lithium: 2000mAh
Dust capacity: 100mL
Runtime: Up to 12 minutes
Charging time: 2-3 Hours
Net weight: 0.6Kg
Model number: O2500
Accessories:
7. 2-In-1 cleaning tool
8. USB-C charger cord
Features
Please contact Godfreys Customer Care Australia on
1800 815 270 or New Zealand on 0800 282 288 to find
your local spare parts provider.

This cleaner must be operated in accordance with these
instructions and used only for domestic household cleaning to
remove DRY dirt and dust from household carpets, flooring, walls
and fabrics. This cleaner is not fit to be used as an industrial cleaner
and will void the manufacturer’s warranty if used inappropriately.
Please read the manual before operating cleaner
This will ensure you obtain full benefit from your new hand vacuum.
Keep this instruction manual in a handy place for future reference.
Important
This cleaner should only be used for its intended purpose as
described in these instructions. Never operate the vacuum cleaner
without filters.
Precautionary measures:
1. Do not operate the vacuum cleaner too close to heaters,
radiators or other hot surfaces.
2. Before inserting the plug into the wall, make sure your
hands
are dry.
3. Before turning on the vacuum cleaner, safely remove any
large objects from the floor or cleaning surface in order to
prevent damage to the filter.
4. When you want to remove the plug from the power
socket, do not use the power cable, gently pull the plug
from the power socket.
5. Do not use this vacuum cleaner to pick up water or
liquids.
6. Do not use this vacuum cleaner if the battery pack housing
and/or the USB charger housing is damaged.
7. Do not stare at the operating light source.
4
Before You Begin

5
Before You Begin
IMPORTANT! Always switch o the cleaner after cleaning,
when not in use or attempting any maintenance task. The
USB charger cable must only be connected to a USB supply
at the voltage shown on the rating label. This cleaner
should only be used for its intended purpose as described
in this instruction manual. Never operate the cleaner
without filters.
When using your vacuum cleaner,
basic precautions should always be
observed, including the following;
1. This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory,
mental capabilities or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
2. Children should be supervised
to ensure that they do not play
with the appliance.
3. To prevent electrical shock,
do not immerse the appliance,
battery or USB plug into water
or other liquids.
4. To prevent electrical shock, do
not use the vacuum cleaner
outdoors or on wet surfaces.
5. Always check the USB cord
before use, the USB cord
should be in a good condition
and must not be damaged.
6. The appliance is intended for
domestic indoors use only.
7. Do not handle or operate the
appliance with wet hands.
Follow electrical safety
precautions at all times.
8. Do not at tempt to change
the attachments while the
appliance is switched on.
Use only manufacturer’s
recommended accessories.
9. Do not operate the vacuum
cleaner too close to heaters ,
radiators and other hot
surfaces.
10. Do not use the appliance
to pick up flammable items
or combustible liquids (i.e.
gasoline, hot ashes, cigarettes,
matches, explosive materials
or anything burning) or use in
areas where such substances
and items may be present
11. Do not use the appliance to
pick up toxic materials (i.e.
chlorine, bleach, ammonia).
12. Never operate or use the
appliance without the filters in
place.
13. Before vacuuming, remove any
large or sharp objects from
the floor or cleaning sur face
in order to prevent damage to
the filter.
14. If the air inlet is blocked, switch
of f the cleaner straight away.
Clear the blocked object
before attempting to start the
vacuum cleaner again.
15. Before carrying out any
maintenance or cleaning the
filters , always switch off the
vacuum cleaner.
16. Keep openings away from your
face and body.
17. Do not use the vacuum cleaner
if it is damaged or broken.
If connection cables are
damaged, have them replaced
immediately.

6
18. Never clean the vacuum
cleaner or any of the electrical
parts, especially the electrical
connections with water or liquid
cleaners.
19. Never attempt to make any
modifications to the vacuum
cleaner or USB charger.
20. Always store the appliance indoors
in a cool and dry place.
21. Do not use the vacuum to pick up
water or liquids. This cleaner is for
dry household use only.
22. Damage caused by improper use or
by not observing the instructions in
this manual will void the warranty.
Battery use and care
1. The appliance is only to be used
with the USB charger c able
provided with the appliance.
2. Only charge the battery inside the
cleaner. Only use the specifically
designated rated USB charger to
charge the product.
3. When the appliance is not in use,
keep it away from other metal
objects, like paper clips, coins, keys,
nails, screws or other small metal
objects that can make a connection
from one terminal to another.
Shorting the appliance terminals
together may cause burns or a fire.
4. Under abusive conditions, liquid
may be ejected from the battery;
avoid contact. If contact occurs ,
flush with water immediately. If
liquid comes into contact with
your eyes , seek medical help
immediately.
5. Do not charge or store the
appliance outdoors or inside
the car. Only charge or store the
battery in a dry indoor area where
the temperature is more than 4°C
but less than 40°C.
6. Never attempt to open the batter y
for any reason. If the plastic housing
of the batter y casing breaks or
cracks, immediately discontinue
use and do not recharge.
7. Before disposal of your battery,
fully discharge your batter y by
running the product until it stops.
9. The cleaner contains a Lithium-
Ion battery. Do not dispose of the
appliance with your local garbage.
Contact your local council for
instruc tions on how to safely
dispose of the battery.
10. This appliance contains battery
cells that are non-replaceable.
12. Do not handle battery with wet
hands.
Charging the unit by using the
USB charging cable and a device
with a USB power port (not
supplied).
1. Insert the USB charging cable
into the USB por t on the vacuum
cleaner.
2. Insert the other end of the USB
charging cable into a device’s
func tional USB power port. The
battery charge status LED indic ator
will light or flash (as described in
the section ‘Charging the Hand
Vacuum’) to indicate the charging
status.
3. Charge until the battery charge
status LED indicator turns of f.
4. Do not switch on the vacuum
cleaner while charging.
5. When charging is complete,
disconnect the USB charging cable
from the device’s USB power por t
and the vacuum cleaner. Store the
cable in a safe place.

7
Before You Begin & Instructions For Use
Instructions For Use
Before you begin cleaning
Switching on LED flashlight
1. Insert the USB charger into the
charging port on the back of
the vacuum cleaner. When the
vacuum cleaner battery is fully
charged, the battery indicator
will switch off. When this
happens, disconnect the USB
charger.
1. Turn on LED flashlight by
pressing the flashlight on/off
button.
Warning!
Do not stare at the operating light source.
2. Remove the lid of the cleaner
and press the vacuum on/off
button to start vacuuming.
Important! Always remove the power plug from the power
supply before fitting or removing accessories.

8
Accessories
Crevice tool
Allows you to eliminate dust from hard to
reach areas.
Dusting brush
Makes cleaning blinds, bookshelves and
lampshades easy.

9
Accessories & Maintenance
Maintenance
Important! Always remove the power plug from the power
socket before performing any maintenance.
Charging the hand vacuum
1. Insert the USB charger into the
charging port on the back of
the vacuum cleaner.
Battery Indicator:
When the vacuum cleaner has run out of battery, the first
battery indicator light will flash for 5 seconds and turn off.
When the vacuum cleaner is being charged, the battery
indicator lights will flash in sequence.
When the vacuum cleaner battery is fully charged, the
battery indicator lights will continue to flash for 90 seconds
before switching off.
Attention:
1. It is recommended to charge your product after each
use to maintain maximum performance.
Note:
1. Product needs to be charged for 2-3 hours after each
use.
2. Do not try to open the battery and repair it yourself.
3. As a safety precaution, the vacuum cannot be switched
on while the vacuum is charging.

10
Emptying the dust canister
Cleaning the filter set
Important! Turn o the cleaner before conducting any maintenance
tasks. It is recommended to clean the dust canister after each use
or when dust reaches the max fill line.
1. Remove the dust canister by turning it
to the unlock position and separating it
from the main body of the machine.
1. Grasp the filter set and rotate the HEPA
filter to the unlock position.
2. Remove the HEPA filter from the mesh
filter and clean with a tissue.
2. Lift the filter set and dispose of the waste.

11
Maintenance & Troubleshooting
Troubleshooting
Problems and solutions
If you come across a problem, please use this checklist
before contacting Godfreys customer care 1800 815 270
(AUS) or 0800 282 288 (NZ).
Spare Parts
Part Part Number
Filter Set 32201746
USB Charger 33201799
Dust Canister 33156349
Fault Cause Solution
Cleaner doesn’t start Flat battery Charge the hand
vacuum
Reduced suction The dust canister is full
of dust
Empty the dust
canister
Filter is blocked Clean or replace the
filter
The airway is blocked Clear the airway
The battery indicator
light fails to flash
during charging
(“flash” indicates the
status of charging)
The USB charger is not
fully inserted into the
hand vacuum
Remove the USB
charger from the hand
vacuum and reinsert
The USB charger is
not connected to the
charger adaptor
Connect the USB
charger to the charger
adaptor
Insufficient batter y life
after charging
Insufficient charging
time
Fully charge the
battery according
to the instructions
described in the
charging section

W
A
R
R
A
N
T
Y
Y
E
A
R
1
Your cleaner, in the case of domestic use, has
a one year parts and labour warranty against
product defects and failures when the product is
used in accordance with the terms and conditions
of this warranty statement.
This warranty commences from the original date
of purchase and is not transferable; please retain
your original proof of purchase for any warranty
claims. This warranty is valid only in the country
where the cleaner is purchased.
The cleaner must be operated in accordance
with these instructions and used only for
domestic household cleaning to remove DRY
dirt and dust from household carpets, flooring
and fabrics. This cleaner is not fit to be used as
an industrial cleaner, and is not designed for the
collection of vitreous building material including
particle board, construction products and similar
products such as wood/fibres, cement, fillers,
fibre glass etc or excessive or frequent sand. The
infrequent pick-up of these materials in these
circumstances may be harmful to your cleaner
and may void the manufacturer’s warranty.
Accessories and consumables including filter and
filter mesh, unless defective in manufacture, are
not subject to this warranty. In order to prolong
the life of accessories and consumables, regular
care and maintenance is recommended.
When properly used and cared for, your
cleaner will render excellent service; refer to the
instruction manual for further details, as misuse
or failure to follow the instructions makes this
warranty void.
In the event of service or advice being needed,
please contact Electrical Home-Aids Pty. Limited,
Level 1, Building 3, Brandon Business Park, 530
Springvale Road, Glen Waverley Victoria 3150, or
on 1800 815 270 (AUS) or 0800 282 288 (NZ),
Monday-Friday 9am-5pm EST. The decision
to repair or replace the cleaner is at the sole
discretion of Electrical Home-Aids Pty. Limited. If
Electrical Home-Aids Pty. Limited decide to repair
or replace the cleaner, it will do so at its own cost.
Electrical Home-Aids Pty. Limited is unable to
accept responsibility under this warranty for any
repair work not carried out by an authorised
Service Agent or from the use of non-genuine
parts. If any part is no longer available or
manufactured, Electrical Home-Aids Pty.
Limited will replace it with a genuine functional
replacement part. This warranty does not
apply to the cost of replacing any parts of the
product due to normal wear and tear, alterations,
improper installation, physical abuse, misuse or
accidental damage. Any transportation costs
involved in the repair of defective parts shall be
borne by the claimant.
If proof of purchase cannot be provided at the
time of a warranty claim or service, any work
carried out on the cleaner is chargeable.
The repair of the cleaner under this warranty
does not extend the original period of warranty.
The benefits conferred by this warranty are
in addition to all other rights and remedies in
respect of the product as outlined under the
Competition and Consumer Act and other State
and Territory laws.
“Our goods come with guarantees that cannot
be excluded in the Australian Consumer Law.
You are entitled to a replacement or refund for
a major failure and for compensation for any
other reasonably foreseeable loss or damage.
You are also entitled to have the goods repaired
or replaced if the goods fail to be of acceptable
quality and the failure does not amount to a
major failure.”
Conditions of warranty
O2500 Hand Vacuum
V5 04/21
Call Godfreys Customer Care
with any product queries
Australia 1800 815 270
New Zealand 0800 282 288
To find out more about our range,
visit: www.godfreys.com.au
www.godfreys.co.nz
email: [e-mail]
