Optimal Speaker Design BLACK TREVOCE 15 EQ DSP User manual

TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
TreVoce15 EQ DSP manual.indd 1 9/3/21 7:55 AM

TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
Installation Precautions:
Before installing
Thank you for buying the latest version of our most popular subwoofer.
The additional upgrades we have made make this the best all-round sub in our history. Incorporated in the Trevoce15 EQ DSP is the
new native EQ, and the IWoofer DSP engine. The native EQ has allowed us to extract the maximum bass extension possible from our
design. This allows the full range of musical instruments and special effects to be reproduced. The Trevoce EQ DSP Series does this all
without any increase in the size of the sub. Our Trevoce subs offer the smallest footprint you will nd in triple driver designs.
Before connecting your subwoofer, make sure all equipment is switched off and that voltage switch is set to your country’s voltage. Do
not connect the subwoofer power supply cable before completing all connections.
Features:
World Class Digital Amplier Technology
The TreVoce DSP Series powered subwoofer incorporates the latest digital amplier technology to maximize performance
while generating very little heat. In standby mode, the unit consumes less than 0.5 watts, making it one of the greenest
solutions available.
Tuned System Performance
Rear mounted volume control, low pass crossover, phase control and App controlled DSP ensure optimal system integra-
tion and built-in native EQ ensures the deepest bass frequencies.
Cabinet
An attractive furniture quality solid cabinet with ‘leather’ nish, provides the foundation for high sound quality and clarity.
TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
Connection & Controls
1. High Level Inputs
Use for Left/Right connection from speakers.
2. Line Level Input
Use for Left/Right connection from subwoofer-out,
or line-out, on amp/AVR.
3. LFE Input
Connect to the LFE output on the Receiver/Processor.
4. Balanced XLR Input
For lower noise connection if available.
5. Power LED
(Red) Standby Mode - (Blue) Power Mode ON
6. DSP Mode Switch
Set the DSP ( OFF or ON )
7. Power Mode Switch
Set the power mode ( OFF, AUTO, or ON )
8. Phase Switch
Allows you to set the phase of the woofer 0-180°
9. Crossover Control
Adjusts the subwoofers frequency output output to match
main speakers
10. Volume Control
Adjusts subwoofer volume level.
11. Voltage Switch
Select input voltage. Default: 110-120V or 220-240V
12. Master Power Switch
Controls the main power to the subwoofer
13. AC Power Cord
Connect the included AC power cord.
14. Fuse Holder
Master Power Fuse. Includes spare fuse inside holder.
3.
2.
1.
4.
5.
6.
7.
8.
9.
10.
11.
12.
13.
14.
POWER
APP DSP
POWER MODE BALANCED INPUT LFE
INPUT
LOW LEVEL
INPUT
HIGH LEVEL INPUT
PHASE
CROSSOVER
VOLUME
POWER
ON OFF
ON OFF
ON OFF
AUTO
L
L
+
-
R
R
0° 180°
40 Hz
MIN
AC110-120V
AC110-120V/60Hz
AC220-240V/50Hz
AC110-120V FUSE T15AL/250V
AC220-240V FUSE T8AL/250V
AC220-240V
1500 WATTS
MAX
160 Hz
1500W DYNAMIC POWER
TREVOCE15 EQ DSP
Settings & Controls
Setting the Power Mode
ON Mode:
If the subwoofer is set to ON mode, it will always be ready to play. However, undesired noise from interference or
connections changing may be heard. Use the standard ON mode only if needed, set the power switch to OFF when not in
use.
AUTO Mode:
Setting the switch to AUTO enables AUTO Sense. The subwoofer turns ON and OFF automatically in response to signal
input. The subwoofer will enter standby mode if no signal is sensed for longer than 15 minutes.
Set the MODE switch to the ON position for setup.
After making all the connections, setup your subwoofer using the following steps:
1. Plug the subwoofer into an electrical outlet using the included power cord. The status LED will illuminate solid blue
when power is present and the subwoofer is ON.
TreVoce15 EQ DSP manual.indd 2-3 9/3/21 7:55 AM

TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
2. Set the controls and switches to their initial setup positions:
VOLUME set the dial to 50% or 12 o’clock
CROSSOVER adjust the upper frequency limit. The purpose is to control the overlap the upper frequencies of the
subwoofer and the main speakers lower frequencies. Check your main speakers specs to determine their low-end
limit.
PHASE set to 0°
3. Play a movie scene or soundtrack and set the system volume to an average level. Listen to the bass level from your
favorite listening position and adjust the volume accordingly.
4. Continue listening to your favorite source track and experiment with the phase control until you nd the best setting
for you. Depending on the location of the subwoofer the bass may sound louder and deeper when the phase has been
optimized. In some cases adjusting the phase will have no audible difference.
5. Initial setup is now complete.
Trevoce Subwoofers are equipped with pre-programmed built-in EQ for optimal sound and great performance. You may
also use the (optional) iWoofer app to access and custom tune the DSP to suit listening preferences or room correction
for example. There is also a Pro version of the iWoofer App (IOS Only) that adds additional functions available for a small
fee.
iWoofer Setup
1. If you intend to use the custom DSP functions you must rst download the iWoofer app from the App Store or Google Play.
2. Continue reading to setup iWoofer app to access and setup the custom DSP features of the TreVoce.
TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
DSP Features Set
X-Over Control
Gain Control
SHS Control
Delay Control
Phase Control
Dynamic Bass Base Control
Dynamic Bass Detailed Control
Remote Hardware Control
Auto-On Threshold Settings
Preset Manager
Preset Import/Export Features (Pro-only)
Room Correction (Pro-only) A Group of functions For
Frequency Impulse Response Correction
SPL Meter (Pro-only)
Limiter-Compressor Bass Control (Pro-only)
Limiter-Compressor Detailed Control (Pro-only)
iWoofer App: DSP Discovery & Connect
From your listening position, using the Android or Apple App iWoofer App you can make any adjustment needed to get the
maximum out of your system.
Open the iWoofer App: Turn On Bluetooth to allow iWoofer to connect to accessories. You may tap Ok, and the app will go
into Demo Mode. Otherwise tap Settings, and turn ON Bluetooth, next tap to Home button, and open iWoofer again.
Bluetooth range is (30-65ft) the app will nd any number of subwoofers equipped iWoofer Hardware, all of them will
appear under “Devices Found:” Choose the UDID or MAC address that show up for your iWoofer equipped sub.
Main Menu
Ok, we have seen the UDID and tapping it we get the main control menu.
The app has a renaming function in Options/Name menu, and UDID number could be replaced for any name whatever
you like.
TreVoce15 EQ DSP manual.indd 4-5 9/3/21 7:55 AM

TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE TREVOCE15 EQ DSP SUBWOOFER INSTALL GUIDE
X-Over Menu
From here you will be able to ne-tune your subwoofer, carefully matching the main speakers to the sub, using variable
slopes and role offs. Whether you have ported main speakers, needing 24 or even 48dB per octave ltering, or sealed
acoustic suspension speakers needing 12dB per octave ltering, we have you covered. The innitely variable phase
correction and choice of cross-over points also provide for much better integration with the main speakers.
X-Over - control of Low Pass and High Pass Filters (LPF/HPF), double tap (or tap & hold on > 1S) on the slope to select
one, slide left/right to control a frequency (20:500Hz), and up/down to control an ‘Slope” order (2:4:8 or 12/24/48 dB/oct
Butterworth). Use this to match your main speakers with the subwoofer
The LPF/HPF frequencies limit the frequency range for Room Correction (Pro App only).
The Xover menu also controls up to 25 bands of fully Parametric Equalization
The built-in 25-band digital parametric equalization allows you to correct for frequency response dips and peaks caused
by positioning and room reections. You can do this by ear, or use a free frequency response app, or upgrade to the Pro-
App (IOS only)and simply use your phones microphone to measure the frequency response and then start making up to
25 different equalization adjustments until the response curve has been corrected. For iPhone users you can run auto-
room equalization/correction, allowing the Pro App to create the EQ lters needed to deal with Room Acoustics issues.
Equalizer (PEQ), to add a new PEQ tap to “+” icon, to delete select “Trash” icon. Slide curve right/left to set a frequency,
up/down to set a gain (db), zoom in/zoom out to control a Q factor (PEQ bandwidth), double tap (or tap&hold on > 1S) on
PEQ line to select it.
X-Over menu. Xover menu. Add new PEQ..
Options Menu
Name: By default the Name eld lled with UDID, you may rename it there. UDID shows the MAC address of the
connected iWoofer Hardware.
Restore Factory Setting: In case you want to reset all parameters to defaults. Be aware that this defaults is not exactly
the same as was preset by the manufacturer of your subwoofer. As mentioned before, the very rst connected iWoofer
hardware will offer app to import preset from DSP, this one is the manufacturer’s default preset.
Change Pairing Code: let you to set a password to you subwoofer/app. In case if the password is forgotten, please press
and hold the Pair button on the rear panel of your subwoofer during 3Sec. The subwoofer password will be reset to zero.
Preset Manager allow you to save/load and export presets. Please note that only after saving a preset the subwoofer will
memorize a new parameters. Without saving a preset, subwoofer loses a new parameters after turn Off. Export presets
carried out thru the IOS email account, but the import could work by hyperlink on website.
Preset Manager: allows you to save/load and export presets. Please note that only after saving a preset the subwoofer
will memorize a new parameter. Without saving a preset, the subwoofer loses the new parameters after turn-off. Exporting
presets is carried out thru the IOS email account, but the import could work by hyperlink.
HW Controllers (not recommended)
Hardware controller options lets you to adjust or deactivate up to four knobs or switches on the rear panel of your
subwoofer. For a full control by app please switch off all controllers, otherwise turning Off/On of the subwoofer will return
the control to the rear panel knobs.
Auto On/Off allows you to adjust auto On threshold in mVRMS units, and hold On time in minutes. 10mVRMS and 2
minutes are default values.
Gain Slider
The volume slider with Input Level indication (gray/green/red means, signal is less/more than Auto On Threshold, or input
clipped).
SHS
The ability to retore sub harmonics that have lost or not been included in early recordings. All musical notes consist of the
original note and a series of harmonics or fundamentals of that frequency, combined, they produce the note you hear. Sub
Harmonic Synthesizing (SHS) restores those lost harmonics. Sub Harmonic Synthesizer (old tracks bass restoration, a
good example is Jackson Sisters - I Believe In Miracles or Diana Krall - Temptation). Ideal for sealed subwoofers.
Delay Controls
2.5:65mS or 5:67.5mS for the FIR room correction mode (latency 2.5/5mS). Sometimes needed to match the delay with
full range speakers (if delayed).
Phase
The 1st order all pass lter F 10:10000Hz. Sometimes needed to match the phase of the main speakers in the cross-over
region.
For Pro-App features and explanations download the full digital manual from osdaudio.com
TreVoce15 EQ DSP manual.indd 6-7 9/3/21 7:55 AM

TreVoce15 EQ DSP Manual 9/21
Optimal Speaker Design | Brea, CA | osdaudio.com
Specications
Warranty Information
Spec TreVoce15 EQ DSP
Power 1500W Dynamic
Active Woofer 15”
Passive Woofer Dual 15”
Frequency 16 -160 Hz
Phase 0-180°
Voltage 100-120V AC / 220-240V AC
Inputs Hi Level / Low Level / LFE
Dimensions (WxHxD) 19.3 x 19.3 x 19.3 in
All Optimal Speaker Design powered subwoofer products have a 2 Year Limited Warranty against defects in materials and
workmanship. Proof of purchase must accompany all claims. During the warranty period Optimal Speaker Design will replace any
defective part and correct any defect in workmanship without charge for either parts or labor Optimal Speaker Design may replace
returned speakers with a product of equal value and performance. In such cases, some modication to the mounting may be necessary
and are not Optimal Speaker Designs responsibility.
For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be
performed by Optimal Speaker Design. The unit must be returned to Optimal Speaker Design at the owner’s expense and with prior
written permission. Accidental damage and shipping damage are not considered defects, nor is damaged resulting from abuse or from
servicing performed by an agency or person not specically authorized in writing by Optimal Speaker Design
Optimal Speaker Design sells products only through authorized dealers and distributors to ensure that customers obtain proper support
and service. Any Optimal Speaker Design product purchased from an unauthorized dealer or other source, including retailers, mail
over dealers and on-line sellers will not be honored or serviced under existing Optimal Speaker Design warranty policy. Any sale of
product by an unauthorized source or other manner not authorized by Optimal Speaker Design shall void the warranty on the applicable
product.
Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these cases,
repairs will be made on the basis of the retail value of the parts and labor. To return for repairs, you must email customer service at
[email protected] for a Returned Merchandise Authorization (RMA) number# then the unit must be shipped to Optimal
Speaker Design at the owner’s expense, along with a note explaining the nature of service required. Be sure to pack the speaker(s) in a
corrugated container with at least 3 inches of resilient material to protect the unit from damage in transit.
This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) • Any
products that have been altered or modied • Any product whose identifying number of decal, serial #, etc. has been altered, defaced or
removed • Normal wear and maintenance.
