Optimus Color Pocket LCD TV User manual

Features
Color Pocket LCD TV Cat. No. 16-178
©1995 Tandy Corporation.
All Rights Reserved.
Pocketvision and Radio Shack are registered trademarks used by Tandy Corporation.
Your Optimus Color Pocket LCD TV fits in
the palm of your hand! And, even though the
TV is small, it has great features like these:
2.2-Inch Super-Twisted Nematic Display
— makes the TV more compact and uses
less power than a standard picture tube.
Automatic Electronic Tuning System —
scans the VHF or UHF band and locks on to
active channels.
Earphone Jack — lets you enjoy private lis-
tening with an optional earphone.
Audio/Video Jack—lets you connect a
camcorder, VCR, laser disc player, or any
other device that has A/V outputs.
Fluorescent Backlight — illuminates the
LCD screen so you can watch the TV in the
dark or in low-light conditions.
Built-In Telescoping Antenna — provides
adequate reception in most metropolitan ar-
eas.
Features
© 1998 Tandy Corporation.
All Rights Reserved.
Optimus and RadioShack are registered trademarks used by Tandy Corporation.
AV IN
VOLUME
BRIGHT
TUNING
EAR
UHF
VHF
OFF
16-178.fm Page 1 Tuesday, July 20, 1999 10:28 AM

2
USING BATTERIES
Your TV uses three AA batteries (not sup-
plied) for power. For the best results, we rec-
ommend alkaline batteries (RadioShack
Cat. No. 23-552).
Cautions:
• Use only fresh batteries of the required
size and recommended type.
• Do not mix old and new batteries, differ-
ent types of batteries (standard, alka-
line, or rechargeable), or rechargeable
batteries of different capacities..
1. Lift up the stand, then press OPEN at
the bottom of the battery compart-
ment’s cover, on the back of the TV,
and remove the cover.
2. Insert three fresh batteries, aligning the
positive (+) poles with the positive
polarity symbols (+) marked inside.
Caution:
Installing batteries incorrectly can
damage the TV.
3. Replace the cover.
With alkaline batteries, the TV can operate
forabout 4 hours at minimum volume. When
the sound level lowers or the picture be-
comes unstable, replace the batteries.
Cautions:
• Always remove old or weak batteries.
Batteries can leak chemicals that can
destroy electronic parts.
• Dispose of old batteries promptly and
properly.
AC POWER
You can power the TV from a standard AC
outlet using an optional AC adapter (such as
Cat. No. 273-1664).
Caution: You must use an optional AC
adapter that supplies 6 volts and delivers at
least 490 mA. Its center tip must be set to
positive, and its plug must correctly fit the
TV’s DC 6V jack. The recommended adapter
meets these specifications. Using an adapt-
er that does not meet these specifications
could damage the TV or the adapter.
1. Set the adapter’s voltage switch to 6V.
2. Attach the adapter’s 3.4 mm outer
diameter/1.3 mm inner diameter barrel
plug, aligning + with TIP, and plug it into
the TV’s DC 6V jack.
3. Plug the other end of the adapter into a
standard AC outlet.
Internal batteries automatically disconnect
when you plug an adapter into the DC 6V
jack.
Cautions:
• Do not leave the adapter plugged into
the AC outlet or connected to the TV
when you are not using the TV.
• Always unplug the adapter from the AC
outlet first.
• It is normal for the adapter to become
warm after extended periods of use.
Power
–
–
–
+
++
OPTIMUS
®
LCD COLOR TV
CAT. NO. 16-178
6V DC, 490mA.
OR 3 “AA” ALKALINE
BATTERIES
CUSTOM MANUFACTURED IN CHINA FOR RADIOSHACK.
A DIV. OF TANDY CORP. FORT WORTH TEXAS 76102
CAUTION:
TO PREVENT DE-
FORMATION.DISCOLORATION OR
MALFUNCTIONS. AVOID LEAVING
THE UNIT UNDER DIRECT SUN-
LIGHT. IN A CLOSED CAR IN
SUMMER. NEAR A HEATER OR
INA BATHROOM.
SERIAL NO. 4A8-000001
Three AA
Batteries
DC 6V
273-1664
273-1815 or
270-1562
16-178.fm Page 2 Tuesday, July 20, 1999 10:28 AM

3
VEHICLE BATTERY POWER
You can use an optional DC adapter (such
as Cat. No. 270-1562 or 273-1815) to power
the TV from your vehicle’s cigarette-lighter
socket.
Caution: You must use a DC adapter that
supplies 6 volts and delivers at least 490
mA. Its center tip must be set to positive,
and its plug must correctly fit the TV’s DC 6V
jack. The recommended adapter meets
these specifications. Using an adapter that
does not meet these specifications could
damage the TV or the adapter.
1. Set the adapter’s voltage switch to 6V.
2. Attach the adapter’s 3.4 mm outer
diameter/1.3 mm inner diameter barrel
plug, aligning + with TIP, and plug it into
the TV’s DC 6V jack.
3. Unplug your vehicle’s cigarette lighter
and plug the large end of the DC
adapter cord into the cigarette-lighter
socket.
Internal batteries automatically disconnect
when you plug an adapter into the DC 6V
jack.
Cautions:
• Do not leave the adapter plugged into
the cigarette-lighter socket or con-
nected to the TV when you are not
using the TV.
• Always unplug the adapter from the cig-
arette-lighter socket first.
Note: If the TV does not operate properly
when you use DC power, be sure the ciga-
rette-lighter socket is clean and that the
adapter’s plug is pushed all the way into the
socket.
1. Extend the telescoping rod antenna.
2. Set OFF/VHF/UHF to VHF or UHF. The TV
starts scanning and stops at the first
active channel in the selected band.
3. Press TUNING <or >to tune to a differ-
ent channel. The tuning line (red for
VHF, green for UHF) on the screen
aligns with the channel number shown
below the screen.
4. Adjust VOLUME.
5. Adjust BRIGHT to the desired bright-
ness. The brightness also changes with
the screen’s angle.
Notes:
• You can fold out the stand on the back
of the TV and lean the TV on a flat sur-
face.
• If reception is poor, adjust the length,
angle, and direction of the telescoping
antenna. If you are using the TV inside
a metal or concrete building, moving
closer to a window might improve
reception.
USING AN EARPHONE
For private listening,you can connect an op-
tional earphone with a 1/8-inch (2.5mm) plug
to the TV’s EAR jack. This automatically
mutes the built-in speaker.
Listening Safely
To protect your hearing, follow these guide-
lines when you use an earphone.
• Set the volume to the lowest setting
before you begin listening. After you
begin listening, adjust the volume to a
comfortable level.
• Do not listen at extremely high volume
levels. Extended high-volume listening
can lead to permanent hearing loss.
• Once you set the volume, do not
increase it. Over time, your ears adapt
to the volume level, so a volume level
that does not cause discomfort might
still damage your hearing.
Using Your TV
16-178.fm Page 3 Tuesday, July 20, 1999 10:28 AM

4
Traffic Safety
Do not wear an earphone while operating a
motor vehicle or riding a bicycle. This can
create a traffic hazard and could be illegal in
some areas.
Even though some ‘earphones let you hear
some outside sounds when listening at nor-
mal volume levels, they still can present a
traffic hazard.
USING THE TV AS A MONITOR
You can play back the signal from an audio/
video component on your TV using a Y-
adapter cable (not supplied). We recom-
mend RadioShack Cat. No. 42-2475.
Connect the cable’s white plug to the com-
ponent’s video output jack and its red plugto
the component’s audio output jack. Then
plug the cable’s sub-mini plug into the TV’s
AV IN jack. Set OFF/VHF/UHF to either VHF or
UHF to view the signal from the component.
Note: Connecting an audio/video compo-
nent disables the TV’s antenna.
Color too light or no color
.
• Extend the antenna and adjust its angle
and direction.
•Adjust
BRIGHT.
No picture and no sound.
• Be sure the batteries are fresh and
inserted correctly.
• Be sure the adapter is correctly con-
nected.
No picture and fuzzy sound.
• Adjust the antenna.
Picture, but no sound.
•Adjust
VOLUME.
• Be sure you disconnected the ear-
phone.
Sound, but the picture is all white, dark,
or blurred.
•Adjust
BRIGHT.
• Be sure the batteries are fresh.
Picture is not clear (moves up or down,
disappears periodically, becomes fuzzy
or blurred, is doubled, etc.), but the TV
has sound.
• Be sure the antenna is fully extended.
Adjust the antenna’s angle and direc-
tion for the best reception.
• Be sure the batteries are fresh.
• Be sure the TV is away from appliances
that might cause interference.
• In locations with poor reception, it might
be impossible to get a clear picture or
any picture at all. Move the TV to a dif-
ferent location.
In low temperatures, the TV screen takes
a few seconds to light, or it is slightly red
in color.
• This is not a malfunction. Normal oper-
ation resumes after a short while.
If you are unable to identify the problem,
take the TV to your local RadioShack store
for assistance.
Troubleshooting
16-178.fm Page 4 Tuesday, July 20, 1999 10:28 AM

5
Your Optimus Color Pocket LCD TV is an example of superior design and craftsmanship.
These suggestions will help you care for it so you can enjoy it for years.
• Keep the TV dry. If it gets wet, wipe it dry immediately.
• Use only fresh batteries of the required size and recommended type. Always remove old
or weak batteries. They can leak chemicals that destroy electronic circuits.
• Handle the TVgently and carefully. Dropping it can damage circuit boards and cases and
can cause the TV to work improperly. Be particularly careful of the display screen. Avoid
putting the TV in your pocket or purse together with hard objects (coins, keys, etc.).
• Use and store the TV only in normal temperature environments.
• Keep the TV away from dust and dirt.
• Wipe the TV with a damp cloth occasionally to keep it looking new. Do not use harsh
chemicals, cleaning solvents, or strong detergents to clean the TV.
Modifying or tampering with the TV’s internal components can cause a malfunction and might
invalidate the TV’s warranty. If the TV is not performing as it should, take it to your local Ra-
dioShack store for assistance.
Channel Coverage ................................................................................. UHF: CH 14–CH 69
VHF: CH 2–CH 13
Display Element .......................................................................... High Resolution Color LCD
(Super Twisted Nematic Type)
Screen Size ........................................................................... 21/4Inches (57 mm) Diagonally
Backlight ..................................................................... High-Luminance Fluorescent Material
Antenna ....................................................................................................... Telescoping Rod
Speaker ..................................................................................... 11/8Inch (28 mm) Diagonally
Terminals ................................................................................................... DC 6V/EAR/AV IN
Power Supply ........................................................................................... Three AA Batteries
AC Adapter (Cat. No. 273-1664)
DC Adapter (270-1562 or 273-1815)
Power Consumption .................................................................. Approx. 3.0 Watts Maximum
Ambient Temperature .............................................................................. 41–104°F (5–40°C)
Dimensions (HWD) ......................................... 413/16 ×31/8×13/16 Inches (122 ×79 ×30 mm)
Weight (w/o Batteries) .................................................................... Approx. 7.4 oz. (209 gm)
Specifications are typical; individual units might vary. Specifications are subject to change
and improvement without notice.
Care and Maintenance
Specifications
16-178.fm Page 5 Tuesday, July 20, 1999 10:28 AM

RADIO SHACK
A Division of Tandy Corporation
Fort Worth, Texas 76102
#A5 Printed in (Site)
RadioShack
A Division of Tandy Corporation
Fort Worth, Texas 76102
5A8 Printed in China
Limited Ninety-Day Warranty
This product is warranted by RadioShack against manufacturing defects in material and workman-
ship under normal use for ninety (90) days from the date of purchase from RadioShack company-
owned stores and authorized RadioShack franchisees and dealers. EXCEPT AS PROVIDED
HEREIN, RadioShack MAKES NO EXPRESS WARRANTIES AND ANY IMPLIED WARRANTIES,
INCLUDING THOSE OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE,
ARE LIMITED IN DURATION TO THE DURATION OF THE WRITTEN LIMITED WARRANTIES
CONTAINED HEREIN. EXCEPT AS PROVIDED HEREIN, RadioShack SHALL HAVE NO LIABIL-
ITY OR RESPONSIBILITY TO CUSTOMER OR ANY OTHER PERSON OR ENTITY WITH RE-
SPECT TO ANY LIABILITY, LOSS OR DAMAGE CAUSED DIRECTLY OR INDIRECTLY BY USE
OR PERFORMANCE OF THE PRODUCT OR ARISING OUT OF ANY BREACH OF THIS WAR-
RANTY, INCLUDING, BUT NOT LIMITED TO, ANY DAMAGES RESULTING FROM INCONVE-
NIENCE, LOSS OF TIME, DATA, PROPERTY, REVENUE, OR PROFIT OR ANY INDIRECT,
SPECIAL, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, EVEN IF RadioShack HAS BEEN AD-
VISED OF THE POSSIBILITY OF SUCH DAMAGES.
Some states do not allow the limitations on how long an implied warranty lasts or the exclusion of in-
cidental or consequential damages, so the above limitations or exclusions may not apply to you.
In the event of a product defect during the warranty period, take the product and the RadioShack
sales receipt as proof of purchase date to any RadioShack store. RadioShack will, at its option, un-
less otherwise provided by law: (a) correct the defect by product repair without charge for parts and
labor; (b) replace the product with one of the same or similar design; or (c) refund the purchase
price. All replaced parts and products, and products on which a refund is made, become the prop-
erty of RadioShack. New or reconditioned parts and products may be used in the performance of
warranty service. Repaired or replaced parts and products are warranted for the remainder of the
original warranty period. You will be charged for repair or replacement of the product made after the
expiration of the warranty period.
This warranty does not cover: (a) damage or failure caused by or attributable to acts of God, abuse,
accident, misuse, improper or abnormal usage, failure to follow instructions, improper installation or
maintenance, alteration, lightning or other incidence of excess voltage or current; (b) any repairs
other than those provided by a RadioShack Authorized Service Facility; (c) consumables such as
fuses or batteries; (d) cosmetic damage; (e) transportation, shipping or insurance costs; or (f) costs
of product removal, installation, set-up service adjustment or reinstallation.
This warranty gives you specific legal rights, and you may also have other rights which vary from
state to state.
RadioShack Customer Relations, Dept. W, 100 Throckmorton St., Suite 600, Fort Worth, TX 76102
We Service What We Sell
3/97
16-178.fm Page 6 Tuesday, July 20, 1999 10:28 AM
