HD Vandal Proof IP Dome Camera User’s Manual

2
Version 3.0.0

i
Welcome
Thank you for purchasing our IP camera!
This user’s manual is designed to be a reference tool for your system.
Please read the following safeguard and warnings carefully before you use this series product!
Please keep this user’s manual well for future reference!

ii
Important Safeguards and Warnings
1．Electrical safety
All installation and operation here should conform to your local electrical safety codes.
The power shall conform to the requirement in the SELV (Safety Extra Low Voltage) and the Limited
power source is rated 12V DC or 24V AC in the IEC60950-1.
We assume no liability or responsibility for all the fires or electrical shock caused by improper handling
or installation.
We are not liable for any problems caused by unauthorized modification or attempted repair.
2．Transportation security
Heavy stress, violent vibration or water splash are not allowed during transportation, storage and
installation.
3．Installation
Do not apply power to the camera before completing installation.
Please install the proper power cut-off device during the installation connection.
Always follow the instruction guide the manufacturer recommended.
4．Qualified engineers needed
All the examination and repair work should be done by the qualified service engineers.
We are not liable for any problems caused by unauthorized modifications or attempted repair.
5．Environment
This series IP camera should be installed in a cool, dry place away from direct sunlight, inflammable,
explosive substances and etc.
Please keep it away from the electromagnetic radiation object and environment.
Please make sure the CCD (CMOS) component is out of the radiation of the laser beam device.
Otherwise it may result in CCD (CMOS) optical component damage.
Please keep the sound ventilation.
Do not allow the water and other liquid falling into the camera.
Thunder-proof device is recommended to be adopted to better prevent thunder.
The grounding holes of the product are recommended to be grounded to further enhance the reliability
of the camera.
6. Daily Maintenance
Please shut down the device and then unplug the power cable before you begin daily maintenance
work.
Do not touch the CCD (CMOS) optic component. You can use the blower to clean the dust on the lens
surface.

iii
Always use the dry soft cloth to clean the device. If there is too much dust, please use the water to
dilute the mild detergent first and then use it to clean the device. Finally use the dry cloth to clean the
device.
Please put the dustproof cap to protect the CCD (CMOS) component when you do not use the camera.
7. Accessories
Be sure to use all the accessories recommended by manufacturer.
Before installation, please open the package and check all the components are included.
Contact your local retailer ASAP if something is broken in your package.
Accessory Name
Amount
IPC Unit
1
MD9M data converter cable
1
Accessories bag
1
Quick Start Guide
1
CD
1

iv
Table of Contents
1General Introduction ..................................................................................................................1
1.1 Overview........................................................................................................................1
1.2 Features.........................................................................................................................1
1.3 Specifications................................................................................................................2
1.3.1 Performance...........................................................................................................2
1.3.2 Factory Default Setup...........................................................................................3
2Structure ....................................................................................................................................11
2.1 Multiple-function Combination Cable ......................................................................11
2.2 Framework and Dimension.......................................................................................12
2.3 Bidirectional talk..........................................................................................................13
2.3.1 Device Connection..............................................................................................13
2.3.2 Operation..............................................................................................................13
2.4 Alarm Setup.................................................................................................................13
3Installation..................................................................................................................................15
3.1 Device Installation ......................................................................................................15
3.2 SD Card Installation ...................................................................................................18
3.3 Lens Adjustment.........................................................................................................18
4 Quick Configuration .....................................................................................................20
4.1 Overview .........................................................................................................20
4.2 Operation ........................................................................................................20
5Web Operation..........................................................................................................................24
5.1 Network Connection...................................................................................................24
5.2 Login and Main Interface...........................................................................................24

v
6FAQ ............................................................................................................................................27
Appendix Toxic or Hazardous Materials or Elements ...............................................................28

1
1General Introduction
1.1 Overview
This series IP camera integrates the traditional camera and network video technology. It adopts audio
and video data collection, transmission together. It can connect to the network directly without any
auxiliary device.
This series IPC uses standard H.264 video compression technology and G.711a audio compression
technology, which maximally guarantee the audio and video quality.
This series IPC enclosure has the strong resistance capacity, which can guarantee the proper work
performance under heavy strike. It supports real-time monitor and listening at the same time. It
supports analog video output and dual-way bidirectional talk.
It can be used alone or used in a network area. When it is used lonely, you can connect it to the
network and then use a network client-end. Due to its multiple functions and various uses, this series
IPC is widely used in many environments such office, bank, road monitor and etc.
1.2 Features
User
Management
Different user rights for each group, one user belongs to one group.
The user right shall not exceed the group right.
Storage
Function
Support central server backup function in accordance with your configuration
and setup in alarm or schedule setting
Support record via Web and the recorded file are storage in the client-end
PC.
Support built-in SD card.
Support local SD card hot swap, support short-time storage when encounter
disconnection.
Alarm
Function
Real-time respond to external local alarm input and video detect as user pre-
defined activation setup and exert corresponding message in screen and
audio prompt(allow user to pre-record audio file)
Real-time video detect: motion detect, camera masking.
Can generate an alarm when network abnormal, SD card abnormal event
occurred.
Network
Monitor
IPC supports one-channel audio/video data transmit to network terminal and
then decode. Delay is within 270ms (network bandwidth support needed)
Max supports 20 connections.
Adopt the following audio and video transmission protocol: HTTP, TCP, UDP,
MULTICAST, RTP/RTCP, RTSP and etc.
Support web access, widely used in WAN.
Network
Management
Realize IPC configuration and management via Ethernet.
Support device management via web or client-end.
Support various network protocols.
Peripheral
Equipment
Support the on-off alarm device to alarm via the sound or the light.
Power
External power adapter DC12V/AC 24V
Support PoE.
Assistant
Function
Log function
Support PAL/NTSC

2
Support system resource information and running status real-time display.
Day/Night mode auto switch (ICR switch).
Built-in IR light. Support IR night vision (For HDBW Series only).
Backlight compensation: screen auto split to realize backlight compensation
to adjust the bright.
Support electronic shutter and gain setup.
Support video watermark function to avoid vicious video modification.
1.3 Specifications
1.3.1 Performance
Please refer to the following sheet for IPC performance specification.
Model
Parameter
HDD3MIA Series
System
Main
Processor
TI Davinci high performance DSP
OS
Embedded LINUX
System
Resources
Support real-time network, local record, and remote operation at the same
time.
User Interface
Remote operation interface such as WEB, DSS, PSS
System Status
SD card status, bit stream statistics, log, and software version.
Video Parameter
Image Sensor
1/2.8-inch CMOS
Pixel
2048（H）*1536（V）
Day/Night
Mode
Support day/night mode switch and IR-CUT at the same time.
Auto Iris
DC drive
Gain Control
Fixed/Auto
White Balance
Manual/Auto
BLC
Manual/Auto
Electronic
Shutter
Manual/Auto
PAL: It ranges from 1/3 to 1/10000.
NTSC: It ranges from 1/4 to 1/10000.
Video
Compression
Standard
H264/JPEG/MJPEG
Video Frame
Rate
PAL:
Main stream（2048*1536@15fps）
extra stream,（704*576@15fps）
Main stream（1920*1080@25fps）
extra stream（704*576@25fps）
NTSC:
Main stream（2048*1536@15fps）
extra stream（704×480@15fps）
Main stream（1920*1080@30fps）
extra stream（704×480@30fps）
Video Bit Rate
H.264: 56Kbps-8192Kbps.
ＭJPEG is adjustable and bit rate is adjustable.
Support customized setup.
Video Flip
Support mirror.
Support flip function.
Snapshot
Max 1f/s snapshot. File extension name is JPEG.
Privacy Mask
Supports max 4 privacy mask zones
Video Setup
Support parameter setup such as bright, contrast.

3
Video
Information
Channel title, time title, motion detect, privacy mask.
Lens
3.3~12mm@F1.4
Lens Interface
CS. Lens is the default accessories
Audio
Audio Input
1-channel，RCA audio input.
Audio Output
1-channel, RCA, audio output.
Bidirectional
Talk Input
Reuse the first audio input channel
Audio Bit Rate
16kbps 16bit
Audio
Compression
Standard
G.711a/G.711u/PCM
Video
Motion Detect
396 (18*22) detection zones；sensitivity level ranges from 1 to 6 (The 6th
level has the highest sensitivity)
Activation event, alarm device, audio/video storage, image snapshot, log,
email function and etc.
Video Loss
Activation event, alarm device, audio/video storage, image snapshot, log,
email function and etc.
Alarm Input
2-channel input，1-channel output
Record and Backup
Record
Priority
Manual>External alarm >Video detect>Schedule
Local Storage
Support Micro SD card storage
Network
Wire Network
1-channel wire Ethernet port, 10/100 Base-T Ethernet
Network
Protocol
Standard HTTP, TCP/IP, IPv4/IPv6, ARP, IGMP, ICMP, RTSP, RTP, UDP,
SMTP, FTP, DHCP, DNS, DDNS, PPPOE, UPNP, NTP, Bonjour, SNMP,
NFS.
Remote
Operation
Monitor, system setup, file download, log information, maintenance ,
upgrade and etc
AUX
Interface
Video Output
1-channel analog video output，BNC port, 9-pin port connection
Reset
6-pin port connection
IR light
35 LED, IR distance 10 to 20 meters (For HDBW series product only)
General Parameter
Power
Support AC24V/DC12V power. PoE
Power
Consumption
7W MAX
Working
Temperature
-10℃~+60℃
Working
Humidify
10%~90%
Dimensions(m
m)
¢160x118.5
Weight
1.25g
Installation
Support various installation modes（Enclosure and bracket is optional）
1.3.2 Factory Default Setup
Please refer to the following sheet for factory default setup information.
Function
Setup Type
Item
Default setup
HDD3MIA
Ca mer a Setu p
Con ditio ns
Brightness
50
Contrast
50
