OPTIX RVC1150/T User manual

QUALITY PRODUCTS FOR THE PROFESSIONAL INSTALLER
Top/Boom Mount
Camera
MODEL : RVC1150/T

Table of Contents
INTRODUCTION 3
Contents
INSTALLATION/QUICKSTART 5
Wiring
MODEL : RVC1150/T

INTRODUCTION
 CongratulaonsonyourpurchaseoftheOpx“ToporBoomViewCamera”.Withcamerainstalled,youare
abletohaveagreatvisualofwhatisonthebehindyourvehiclewhiledrivingorgoinginreverse.
Contents:
  1-CameraBoomorTop
  1-Holesaw
  1-Hardwireplug
  1-PowerPlug
MODEL : RVC1150/T
Monitor Not Included

MODEL : RVC1150/T
1.Thesecamerasaretoporboomcamerasdependingonpartnumber.Anglescannotbe
adjusted,therefortheycanonlybemountedupsidedownorrightsideup.Mostinstallers
liketomountthisrightabovethelicenseplateorontheverytopofthevehicle.Thisisan
OEMlikecameraandmounngisuptocustomer’spreference.
2.RoutewiresintothevehicleandaachthevideowiretoyourDVR,Splier,Switcheror
directlytoyourmonitor.Makesurecablesarenotbeingpinched.Ifyoupurchasedthe
RVC1150Tyouhaveapairofwireloopsonthecamerawire.Pleaseusethenotesbellowto
assistyouwithfunconsofthoseloops.
INSTALLATION/QUICK START
AcceleElectronicswillnotberesponsiblefordamagescausedtoyourcar
duetoimproperinstallaon.Forcompleteownersmanualpleasevisit
hps://accele.com/product/t-rvc1150-t/Thankyouforbeinga
valuedcustomerofACCELEELECTRONICS
CameraSpecicaons:
• WorkswithPALandNTSC
• 120degreeviewingangle
• IP67-IP68Water-Proof
• 0.2Lux/F1.8
• CurrentCosumpon300mA
RVC1150TLOOPS:
Greencut-Lines
Greennotcut–Nolines
Whitecut–Upsidedownview/Topmount
Whitenotcut–Normalview/Boommount
Monitor Not Included
