opto engineering COE LS-X Series User manual

V 1.0 - eng
CAMERAS
USER MANUAL
COE LS-X Line Scan Camera
Line Scan Camera

V 1.0 - eng 2
COE LS-X Line Scan Camera | USER MANUAL
Legal Information
About This Manual
This manual is applicable to the COE LS-X line scan cameras.
The Manual includes instructions for using and managing the Product. Pictures, charts,
images and all other information hereinafter are for description and explanation only. The
information contained in the Manual is subject to change, without notice, due to firmware
updates or other reasons. Please findthelatest version of this Manual at the company website
Please use this Manual with the guidance and assistance of professionals trained in
supporting the Product.
Trademarks
Trademarks and logos mentioned are the properties of their respective owners.
Disclaimer
TO THE MAXIMUM EXTENT PERMITTED BY APPLICABLE LAW, THIS MANUAL AND THE
PRODUCT DESCRIBED, WITH ITS HARDWARE, SOFTWARE AND FIRMWARE, ARE
PROVIDED “AS IS” AND “WITH ALL FAULTS AND ERRORS”. OUR COMPANY MAKES NO
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING WITHOUT LIMITATION,
MERCHANTABILITY, SATISFACTORY QUALITY, OR FITNESS FOR A PARTICULAR PURPOSE.
THE USE OF THE PRODUCT BY YOU IS AT YOUR OWN RISK. IN NO EVENT WILL OUR
COMPANY BE LIABLE TO YOU FOR ANY SPECIAL, CONSEQUENTIAL, INCIDENTAL, OR
INDIRECT DAMAGES, INCLUDING, AMONG OTHERS, DAMAGES FOR LOSS OF BUSINESS
PROFITS, BUSINESS INTERRUPTION, OR LOSS OF DATA, CORRUPTION OF SYSTEMS, OR
LOSS OF DOCUMENTATION, WHETHER BASED ON BREACH OF CONTRACT, TORT
(INCLUDING NEGLIGENCE), PRODUCT LIABILITY, OR OTHERWISE, IN CONNECTION WITH
THE USE OF THE PRODUCT, EVEN IF OUR COMPANY HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES OR LOSS.
YOU ACKNOWLEDGE THAT THE NATURE OF THE INTERNET PROVIDES FOR INHERENT
SECURITY RISKS, AND OUR COMPANY SHALL NOT TAKE ANY RESPONSIBILITIES FOR
ABNORMAL OPERATION, PRIVACY LEAKAGE OR OTHER DAMAGES RESULTING FROM
CYBER-ATTACK, HACKER ATTACK, VIRUS INFECTION, OR OTHER INTERNET SECURITY
RISKS; HOWEVER, OUR COMPANY WILL PROVIDE TIMELY TECHNICAL SUPPORT IF
REQUIRED.
YOU AGREE TO USE THIS PRODUCT IN COMPLIANCE WITH ALL APPLICABLE LAWS, AND
YOU ARE SOLELY RESPONSIBLE FOR ENSURING THAT YOUR USE CONFORMS TO THE
APPLICABLE LAW. ESPECIALLY, YOU ARE RESPONSIBLE, FOR USING THIS PRODUCT IN A
MANNER THAT DOES NOT INFRINGE ON THE RIGHTS OF THIRD PARTIES, INCLUDING
WITHOUT LIMITATION, RIGHTS OF PUBLICITY, INTELLECTUAL PROPERTY RIGHTS, OR
DATA PROTECTION AND OTHER PRIVACY RIGHTS. YOU SHALL NOT USE THIS PRODUCT
FOR ANY PROHIBITED END-USES, INCLUDING THE DEVELOPMENT OR PRODUCTION OF
WEAPONS OF MASS DESTRUCTION, THE DEVELOPMENT OR PRODUCTION OF CHEMICAL
OR BIOLOGICAL WEAPONS, ANY ACTIVITIES IN THE CONTEXT RELATED TO ANY NUCLEAR
EXPLOSIVE OR UNSAFE NUCLEAR FUEL-CYCLE, OR IN SUPPORT OF HUMAN RIGHTS
ABUSES.
IN THE EVENT OF ANY CONFLICTS BETWEEN THIS MANUAL AND THE APPLICABLE LAW,
THE LATER PREVAILS.

V 1.0 - eng 3
COE LS-X Line Scan Camera | USER MANUAL
Regulatory Information
EU Conformity Statement
This product and - if applicable - the supplied accessories too are marked with "CE" and
comply therefore with the applicable harmonized European standards listed under the
EMC Directive 2014/30/EU, the LVD Directive 2014/35/EU, the RoHS Directive 2011/65/EU.
2012/19/EU (WEEE directive): Products marked with this symbol cannot be disposed of
as unsorted municipal waste in the European Union. For proper recycling, return this
product to your local supplier upon the purchase of equivalent new equipment, or dispose
of it at designated collection points.
2006/66/EC (battery directive): This product contains a battery that cannot be
disposed of as unsorted municipal waste in the European Union. See the product
documentation for specific battery information. The battery is marked with this
symbol, which may include lettering to indicate cadmium (Cd), lead (Pb), or
mercury (Hg). For proper recycling, return the battery to your supplier or to a designated
collection point.
Symbol Convention
The symbols that may be found in this document are defined as follows.
Symbol
Description
Provides additional information to emphasize or supplement important
points of the main text.
Indicates a potentially hazardous situation, which if not avoided, could
result in equipment damage, data loss, performance degradation, or
unexpected results.
Indicates a hazard with a high level of risk, which if not avoided, will result
in death or serious injury.
Safety Instructions
These instructions are intended to ensure that the user can use the device correctly to avoid
danger or property loss.
Laws and Regulations
The device should be used in compliance with local laws, electrical safety regulations, and fire
prevention regulations.
Power Supply
⚫When wiring, make sure that the device power is cut off.

V 1.0 - eng 4
COE LS-X Line Scan Camera | USER MANUAL
⚫Avoid contact with exposed circuit. When the device is powered on, avoid contact with exposed
junctions and parts.
⚫Use the power adapter provided by the regular manufacturer.
⚫Do not connect multiple devices to one power adapter, to avoid over-heating or fire hazards
caused by overload.
⚫Make sure the plug is properly connected to the power socket.
Transportation
⚫The device contains precision optical components and electronic components. During
transportation, storage and installation, incorrect operations like heavy pressure and violent
vibrations should be avoided. Otherwise, the device may be damaged.
⚫Avoid sudden collision, and pack the device with the accompanied carton and cushioning
material or similar package.
Using Environment
⚫In order to reduce the risk of fire or electric shock, do not let the device get wet or damp.
⚫Do not drop objects onto the device and avoid vigorous vibrations.
⚫Keep the device away from magnetic interference.
⚫Do not use the device in extremely heat, extremely cold, dusty environment, corrosive
environment or high humidity environment.
⚫Do not aim the device lens at objects of strong light, such as the sun and incandescent lamp.
Otherwise, the lens may be damaged.
⚫The device should be stored in dry environment without corrosive gas. Avoid placing the device
in direct sunlight and poorly ventilated locations, or near heat sources such as heaters (ignoring
this warning may lead to fire hazards).
⚫Do not operate in explosive environment.
⚫Keep the surrounding area well ventilated to avoid heat accumulation. Do not contact the
radiator directly to avoid burns.
Electrostatic Protection
⚫Remove all conductive objects (such asjewelry, watch, etc.) on the device body before touching
the device, and touch the grounding metal bracket by hand to release the static electricity.
⚫It is suggested to wear anti-static suit to prevent damage to the equipment caused by static
electricity.
⚫When installing or maintaining the device, wear anti-static wristband or anti-static gloves. Make
sure that the wristband is tightly attached to the skin and is reliably grounded.
⚫It is forbidden to touch exposed circuit boards with bare hands. Static electricity generated by
human body may damage electrostatic sensitive components on circuit boards.
⚫When touching electrostatic sensitive components or devices, proper grounding measures must
be taken.
⚫Put electrostatic sensitive components into anti-static bags for protection.
⚫It is suggested to place humidifier in dry environment to maintain suitable humidity and reduce
static electricity generation.
Maintenance
⚫If the device is not working properly, contact the manufacturer. Do not disassemble or modify
the device in any way. (The company does not bear any liability for any problem arising from
unauthorized modification or maintenance).
⚫Properly preserve all theoriginal packaging materials of the device so that when problems arise,
the device can be packed with packaging materials and sent to the manufacturer for processing.
The company does not bear any liability for accidental damage during transportation caused by
non-original packaging.
⚫This device is a precision electronic device, no components can be maintained by user, do not

V 1.0 - eng 5
COE LS-X Line Scan Camera | USER MANUAL
disassemble the device arbitrarily.
Cleaning
Do not touch the image sensor directly. If the sensor needs to be cleaned, use a clean rag and wet
it with alcohol, then gently wipe off the dirt; if the device is not in use, cover the image sensor with
dust cover for protection.
Installation
Do not install the device on vibrating surface or places that are vulnerable to impact.
Personnel Requirement
Quality requirements for installation and maintenance personnel: qualification certificate or working
experience in weak current system installation and maintenance, and relevant working experience
and qualifications. Besides, the personnel must possess the following knowledge and operation
skills:
⚫The basic knowledge and operation skills of low voltage wiring and low voltage electronic circuit
connection.
⚫The ability to comprehend the contents of this manual.

V 1.0 - eng 6
COE LS-X Line Scan Camera | USER MANUAL
INDEX
1 Overview.................................................................................................... 9
1.1 Introduction ....................................................................................................................9
1.2 Key Feature....................................................................................................................9
2 Appearance ............................................................................................. 10
3 Interface and Indicator ............................................................................11
3.1 Power and I/O Interface................................................................................................ 11
3.1.1 First Type of Pin Definitions............................Errore. Il segnalibro non è definito.
3.1.2 Second Type of Pin Definitions.......................Errore. Il segnalibro non è definito.
3.2 Indicator ....................................................................................................................... 11
4 Camera Installation................................................................................. 13
4.1 Installation Preparation.................................................................................................13
4.2 Install Camera ..............................................................................................................13
5 Camera Connection................................................................................ 13
5.1 Install Client Software...................................................................................................14
5.2 Turn off Firewall............................................................................................................15
5.3 Set PC Network............................................................................................................15
5.4 Set Camera Network ....................................................................................................16
5.5 Connect Camera to Client Software .............................................................................16
6 Client Software Layout........................................................................... 18
7 Image Acquisition................................................................................... 20
7.1 Set Line Rate................................................................................................................20
7.2 Set Frame Timeout.......................................................................................................21
7.3 Set Acquisition Mode....................................................................................................22
7.4 Set Trigger Mode..........................................................................................................22
7.5 Set Trigger Source........................................................................................................23
7.5.1 Set Software Trigger.............................................................................................24
7.5.2 Set Hardware Trigger ...........................................................................................25
7.5.3 Set Shaft Encoder Control....................................................................................26
7.5.4 Set Frequency Converter Control.........................................................................29
7.5.5 View Trigger Line Rate .........................................................................................30
7.5.6 Set Action Command Trigger................................................................................31
7.5.7 Set Free Trigger ...................................................................................................32
7.6 Trigger Related Parameters..........................................................................................33
7.6.1 Acquisition Burst Frame Count .............................................................................33

V 1.0 - eng 7
COE LS-X Line Scan Camera | USER MANUAL
7.6.2 Trigger Activation..................................................................................................34
7.6.3 Trigger Delay........................................................................................................36
7.6.4 Frame/Line Trigger Cache....................................................................................37
7.6.5 Trigger Debouncer ...............................................................................................39
8 I/O Output................................................................................................ 41
8.1 Select Output Signal.....................................................................................................41
8.2 Set Output Signal .........................................................................................................41
8.2.1 Enable Line Inverter .............................................................................................41
8.2.2 Enable Strobe Signal............................................................................................42
9 I/O Electrical Feature and Wiring........................................................... 47
9.1 I/O Introduction.............................................................................................................47
9.2 I/O Electrical Feature....................................................................................................47
9.2.1 Differential Input Circuit ........................................................................................47
9.2.2 Differential Output Circuit .....................................................................................48
9.2.3 Bi-Direction I/O Circuit..........................................................................................48
9.3 Input Wiring..................................................................................................................51
9.3.1 First Type of Input Wiring......................................................................................51
9.3.2 Seond Type of Input Wiring ..................................................................................54
9.4 Output Wiring ...............................................................................................................55
10 Image Parameter................................................................................... 58
10.1 Image Resolution........................................................................................................58
10.2 Set ROI ......................................................................................................................58
10.3 Set Image Reverse.....................................................................................................59
10.4 Set Image Compression Mode ...................................................................................59
10.5 Set Pixel Format.........................................................................................................60
10.6 Set Test Pattern..........................................................................................................62
10.7 Set Binning.................................................................................................................64
10.8 Set Exposure Auto......................................................................................................64
10.9 Set HDR.....................................................................................................................65
10.10 Set Gain ...................................................................................................................66
10.10.1 Set Analog Gain ...............................................................................................66
10.10.2 Set Digital Gain ................................................................................................67
10.11 Set Brightness ..........................................................................................................68
10.12 Set Black Level.........................................................................................................69
10.13 Set White Balance....................................................................................................69
10.14 Set Gamma Correction.............................................................................................71
10.15 Set AOI.....................................................................................................................72
10.16 Set Color Transformation Control .............................................................................72
10.17 Set Hue ....................................................................................................................74

V 1.0 - eng 8
COE LS-X Line Scan Camera | USER MANUAL
10.18 Set Saturation...........................................................................................................75
10.19 Set Color Adjustment................................................................................................75
10.20 Set LUT....................................................................................................................76
10.21 Set Flat Field Correction...........................................................................................77
10.21.1 FPNC Correction..............................................................................................77
10.21.2 PRNUC Correction...........................................................................................78
10.22 Set Space Correction ...............................................................................................80
10.22.1 Set Line Rate Ratio ..........................................................................................81
10.22.2 Set Pixel Shift and Parallax Direction ...............................................................82
11 Other Functions .................................................................................... 84
11.1 Device Control ............................................................................................................84
11.2 Embedded Information in Image.................................................................................86
11.3 TDI Function ...............................................................................................................88
11.4 Scan Direction ............................................................................................................89
11.5 File Access Control .....................................................................................................90
11.6 Event Control..............................................................................................................91
11.7 Transport Layer Control ..............................................................................................92
11.8 Transfer Control..........................................................................................................95
11.9 Save and Load User Set.............................................................................................96
11.10 Set Multicast.............................................................................................................98
11.11 Update Firmware ......................................................................................................99
12 Troubleshooting...................................................................................................................101
13 Revision History...................................................................................................................102
14 Appendix A Camera Parameter Index.................................................................................103

V 1.0 - eng 9
COE LS-X Line Scan Camera | USER MANUAL
1 Overview
1.1 Introduction
The COE LS-X line scan camera uses the GigE interface to transmit images in real time, and it
acquires images and sets parameters via the client software or SDK. The camera is applicable to
the printing, textiles, railway, logistics, metallurgy, food, pharmaceutical manufacturing, material
sorting, etc.
1.2 Key Feature
⚫Supports auto and manual adjustment for gain, exposure time and white balance, manual
adjustment for Look-Up Table (LUT), Gamma correction, etc.
⚫Adopts the image interpolation algorithm for the color reproduction.
⚫Adopts GigE interface and max. transmission distance of 100 meters without relay.
⚫Compatible with the GigE Vision Protocol, the GenlCam Standard, and the third-party
software based on the protocol and standard.
⚫The camera functions may differ by camera models.
⚫For specific camera functions, refer to the camera’s user manual.

V 1.0 - eng 10
COE LS-X Line Scan Camera | USER MANUAL
2Appearance
Appearances here are for reference only. Refer to the camera's specification for detailed
dimension information and corresponding models.
Figure 1-1 Dimensional drawings
Table 1-1 Component Description
No.
Name
Description
1
Lens Mount
It is used to install the lens.
2
Screw Hole
It is used to fix the camera to the installation position.
3
Screw Hole for GigE
Interface
It refers to the M2 screw hole for securing the network cable.
4
Gigabit Ethernet Interface
It refers to the Gigabit Ethernet interface for transmitting data.
5
LED Indicator
It indicates the camera's status.
6
Power and I/O Interface
It provides power supply, input/output signal, serial port, etc.

V 1.0 - eng 11
COE LS-X Line Scan Camera | USER MANUAL
3Interface and Indicator
3.1 Power and I/O Interface
All COE LS-X cameras have the same 12-pin power and I/O interface, as shown below.
1
2
3
4
5
678
9
10
11
12
Figure 1-2 12-Pin Interface
Refer to the pin definitions and labels attached to the power and I/O cable to wire the device.
Table 1-2 Pin Definitions
No.
Signal
I/O Signal
Source
Description
1
GND
--
Power supply ground
2
DC_PWR
--
DC power supply positive
3
LINE0_P
Line 0+
Differential input/output IO 0+
4
LINE0_N
Line 0-
Differential input/output IO 0-
5
GND
--
Power supply ground
6
LINE3_P
Line 3+
Differential input/output IO 3+
7
LINE3_N
Line 3-
Differential input/output IO 3-
8
LINE4_P
Line 4+
Differential input/output IO 4+
9
LINE1_P
Line 1+
Differential input/output IO 1+
10
LINE1_N
Line 1-
Differential input/output IO 1-
11
DC_PWR
--
DC power supply positive
12
LINE4_N
Line 4-
Differential input/output IO 4-
3.2 Indicator

V 1.0 - eng 12
COE LS-X Line Scan Camera | USER MANUAL
The camera indicator is used to display camera status.
Table 1-3 Indicator Description
No.
Indicator Color
Status
Description
1
Red
Flashing very
slowly
Cable connection error occurs.
2
Red
Solid
Major error occurs.
3
Blue
Flashing slowly
The camera is acquiring images under trigger
mode.
4
Blue
Flashing rapidly
The camera is acquiring images normally.
5
Blue
Solid
The camera is in idle status.
6
Red and blue
Flash
alternatively
The function of finding me is executed, or the
firmware is updating.
⚫When the indicator is flashing rapidly, flashing slowly, or flashing very slowly, its unlit interval is
0.2 s, 1 s, 2 s respectively.
⚫The indicator sometimes may show a purple color when red and blue colors flashing at the
same time.

V 1.0 - eng 13
COE LS-X Line Scan Camera | USER MANUAL
4Camera Installation
4.1 Installation Preparation
You need to prepare following accessories before installation.
Table 1-4 Accessories
No.
Name
Quantity
Description
1
Lens
1
You should purchase lens separately according to the
camera’s lens mount.
2
Lens Adapter
1
You should purchase lens adapter separately
according to the camera’s lens mount and lens you
use.
3
Power and I/O Cable
1
It refers to the 12-pin power and I/O cable that you
need to purchase separately.
4
Power Adapter or
Switch Power Supply
1
You should select suitable power adapter or switch
power supply according to the camera power supply
and consumption. You need to purchase it separately.
5
Network Cable
1
Use CAT-5e network cable or above. You need to
purchase it separately.
4.2 Install Camera
Before you start
Make sure all the related devices are powered off during the installation.
Steps:
2. Fix the camera to the installation position, and install lens and lens adapter to the camera.
3. Use a suitable network cable to connect the camera with a switch or a network interface card.
4. Select a power supply method.
● Direct supply: Use the 12-pin power and I/O cable to connect the camera to a power adapter.
● PoE (Power over Ethernet): For cameras supporting PoE, use a suitable network cable to
connect the camera to a switch that supports PoE or a network interface card.
5 Camera Connection
Camera connection to the client software is required for the camera’s configuration and remote
operations. This section introduces how to install the client software, set PC and camera network,
connect the camera to the client software, etc.

V 1.0 - eng 14
COE LS-X Line Scan Camera | USER MANUAL
5.1 Install Client Software
OECS client software is used to connect the camera, set its parameters, etc.
⚫The OECS client software is compatible with 32/64-bit Windows XP/7/10 operating systems.
⚫The graphic user interface may differ by different versions of the client software you use.
⚫You can contact the manufacturer to obtain the OECS client software.
Steps:
1. Double click the OECS installation package.
2. Select the language.
3. Read and check Terms of the License Agreement.
Figure 1-3 Installation Interface
4. Click Start Setup.
Figure 1-4 Default Settings
5. Keep default settings, and click Next.

V 1.0 - eng 15
COE LS-X Line Scan Camera | USER MANUAL
6. Finish the installation according to the interface prompts.
5.2 Turn off Firewall
To ensure stable client running and image transmission, you are recommended turning off
Windows firewall before using the client software.
For different Windows versions, the path name or interface may differ.
Steps:
1. Go to Windows Firewall.
⚫Windows XP system: Click Start > Control Panel > Security Center > Windows Firewall.
⚫Windows 7 system: Click Start > Control Panel > Windows Firewall.
⚫Windows 10 system: Click Start > Control Panel > System and Security > Windows
Defender Firewall.
2. Click Turn Windows Defender Firewall on or off on the left.
3. Select Turn off Windows Defender Firewall (not recommended).
Figure 1-5 Windows Defender Firewall
4. Click OK.
5.3 Set PC Network
To ensure stable image transmission and normal communication between the PC and the camera
via client software, you need to set the PC network before using the client software.
For different Windows versions, the path name or interface may differ.
Steps:
1. Go to PC network settings page: Start > Control Panel > Network and Internet > Network
and Sharing Center > Change adapter settings.
2. Select NIC and set the IP obtainment mode.
⚫Select Obtain an IP address automatically to get an IP address of the PC
automatically.
⚫Select Use the following IP address to set an IP address for the PC manually.

V 1.0 - eng 16
COE LS-X Line Scan Camera | USER MANUAL
3. Set NIC property via the PC.
1) Go to NIC settings page: Control Panel > Hardware and Sound > Device Manager >
Network Adapter.
2) Select corresponding network interface card, and click Advanced.
3) Set Jumbo Packet value to 9014 Bytes, Transmit Buffers and Receive Buffers to 2048,
Interrupt Moderation Rate to Extreme.
The max. value of receive buffers and transmit buffers may differ by network interface cards.
5.4 Set Camera Network
You can set and operate the camera in the client software only when the camera is in the same
network segment with the PC where the client software is installed.
Steps:
1. Double click the client software to run it.
2. Click in device list to search the device.
3. Select a device to be connected.
4. Right click the device, and click Modify IP.
5. Set the IP address of the device in the same network segment with the PC
6. Click OK.
Figure 1-6 Modify Device IP Address
5.5 Connect Camera to Client Software
Make sure your device IP address is in the same network segment with the PC where you installed
the client software before connecting the device to it.

V 1.0 - eng 17
COE LS-X Line Scan Camera | USER MANUAL
Double click the device name in device list, or click to connect the device to the client.

V 1.0 - eng 18
COE LS-X Line Scan Camera | USER MANUAL
6Client Software Layout
After connecting to the camera, the client software can read the camera attributes and display them.
Figure 1-7 Main Window
For specific main window of the client software, please refer to the actual one you got.
Table 1-5 Description of Main Window
No.
Area Name
Description
1
Menu Bar
The menu bar displays function modules, including File, View,
Settings, Tool, and Help.
2
Control Toolbar
The control toolbar provides quick operations for the device.
3
Device List Panel
This panel displays device list, and you can connect or
disconnect device, modify device IP address, etc.
4
Device
Information Panel
This panel displays the detailed device information.
5
Display Window
This area displays the acquisition images in real-time. You can click
different icons to capture and save image, record, etc.
6
Feature Panel
You can view and set features of the selected camera, and perform
operations such as importing, exporting, and saving features.
Click in the camera's feature panel to unfold the specific camera parameters, and set them with
the desired value.

V 1.0 - eng 19
COE LS-X Line Scan Camera | USER MANUAL
The camera’s attribute tree and parameters may differ by camera models.
Table 1-6 Attribute Description
Attribute
Description
Device Control
You can view device information, edit its name, reset the device,
etc.
Image Format Control
You can view and set the device resolution, image reverse function,
pixel format, region of interest, test pattern, etc.
Acquisition Control
You can view and set the device acquisition mode, line rate,
trigger mode, exposure mode, etc.
Analog Control
You can view and set the device gain, black level, Gamma correction,
etc.
Color Transformation
Control
You can view and set the device color transformation related
parameters like hue and saturation.
LUT Control
You can view the Look-Up Table (LUT) and set its index and value.
Encoder Control
You can set encoder control to convert source signal of external
trigger into internal signal.
Frequency Converter
Control
You can set frequency converter control to convert external signal of
different frequencies into internal signal.
Shading Correction
You can set shading correction to correct shade.
Digital IO Control
You can set the different input and output signals.
Action Control
You can view and set the device action control related parameters.
Counter And Timer
Control
You can view and set the counter related parameters.
File Access Control
You can view and set the device file access control related
parameters.
Event Control
You can view and set the device event control related parameters to
let the device generate an event and transmit a related event
message to the computer.
Chunk Data Control
You can view and set the device chunk data control related
parameters to generate supplementary image data and append that
data to every image that you acquire.
Transport Layer Control
You can view and set the parameters of the device transport layer.
Transfer Control
You can view the device transfer status.
User Set Control
You can save or load the device parameters.

V 1.0 - eng 20
COE LS-X Line Scan Camera | USER MANUAL
7Image Acquisition
7.1 Set Line Rate
Line rate refers to the image line number that is output by the camera per second. The frame rate of
the camera is proportional to the line rate, and is inversely proportional to the height of the image
area, that is, Fps = Lps (line rate)/Height (image height).
The following 4 factors determine the maximum line rate:
⚫Readout time: The shorter the readout time and the higher the line rate will be.
⚫Exposure time: The shorter the exposure time, the higher the line rate will be.
⚫Pixel format: The more bytes pixel format occupy, the lower the line rate will be.
⚫Bandwidth: The larger the bandwidth, the higher the line rate will be.
⚫Image compression mode: This function is used to compress data before transmitting
to the PC, and increase the frame rate to some extent.
In client software, click Acquisition Control >Acquisition Line Rate (Hz), and enter Acquisition
Line Rate (Hz). You can view real-time line rate and frame rate in Resulting Line Rate (Hz) and
Resulting Frame Rate (Hz) respectively.
Figure 1-8 Set Line Rate
When you enable the image compression mode (see section Set Image Compression Mode for
details), you can view Reference Line Rate (Hz) that stands for the min. line rate that is calculated
according to compression ratio.
