DS330 Big projection
Bright projection – 2800 ANSI Lumens
SVGA resolution, 13,000:1 contrast ratio, HDMI input
Low ownership costs - up to 10,000 hours² lamp life
Lightweight and portable

DS330
Ideal for use in a meeting room or classroom, the DS330 has a bright 2800L and 13,000:1 contrast allowing you to project bright, crystal clear
images with superb colours using DLP® and BrilliantColor™ technologies. Incredible lamp life of up to 10,000 hours combined with Eco+
technology provides energy and money saving features. Installed or on the move, the versatile DS330 incorporates HDMI, built in speaker, Full 3D
technology and optional wireless capabilities that are easy to use.
Eco+ technology from Optoma increases our
commitment to reducing the impact we all
make on the environment
Bright Images
Project in ambient light conditions with the ultra bright 2800 ANSI
Lumens. Ideal for meeting rooms and classrooms.
Cost Saving – Long Lamp Life
Reduce the number of lamp changes with lamp life of up to 10,000
hours² using the Education Cycle.
Clear, Focused Images
Produce a stunning 13,000:1 contrast ratio for pin sharp graphics and
crystal clear text using the unique Dynamic mode feature.
Combined with DarkChip3 technology for Texas Instruments,
Dynamic mode automatically adjusts the lamp output, based on the
brightness information of each frame; to create a stunning high
contrast ratio. Bright scenes are crisp and clear, while dark scenes
remain detailed with deep blacks which gives exceptional light and
shade detail.
Green Solutions
Eco+ Mode
Saving energy saves money! Eco+ technology reduces the power
consumption to as little as 30%. This intelligent feature can more than
double your expected lamp life, lowering the total cost of ownership
and reducing maintenance.
Lamp
Mode
Bright
Dynamic
Eco+
Education Cycle
Lamp Life (Hours)
Eco AV mute off
100% power consumption
Eco AV mute on
25% power consumption
We know that improving our products is
the best way to reduce our impact on the
environment. That's why at Optoma we
design our products to have a long usable
life, use fewer materials, ship with the
minimum packaging and be free of all
possible toxic substances. Naturally,
energy efficiency and being recyclable are
built in at the design stage. With each new
product, we strive towards minimising our
environmental impact.
Auto Power Off
There may be instances when the projector is left running when not in
use. To help save energy if the projector is left running and no source
is detected, the "Auto Power Off" feature automatically turns off the
projector after a set period of time.
Eco AV Mute
Stay in control of your presentation with the Eco AV mute feature.
Direct your audience's attention away from the screen by blanking the
image when no longer needed. This also instantly reduces the power
consumption to 25%, further prolonging the life of your lamp.
Power Consumption
100% Bright mode
80%
Dynamic mode
Eco+ mode
30%

RS232 Compatibility - The DS330 comes with
an extensive RS232 command set making it
simple and easy to control with any control
system. AMX Compatibility - Dynamic
Discovery Protocol is incorporated into the
DS330. This feature allows for easy installation
with AMX control systems.
We are so confident that the DS330 image colour
quality will remain as good as the day you bought it
that we will guarantee it for five years.
The DS330 incorporates BrilliantColor™ multi-colour
processing technology to bring stunning, vibrant
colour to your screen. Using six separate primary
and secondary colours to produce a new level of
colour performance and control; BrilliantColor™
increases colour brightness by up to 50% over other
technologies to create accurate true to life images.
Cooling On
Audio Capability
Built-in 2W speaker offers excellent audio support. The DS330 is
easy to set up without the need for costly external speakers.
Control
Amazing Colours
The DS330 incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
Colour Guarantee
BrilliantColor™
Rapid Off
It takes less than 10 seconds for the projector to power up and
shutdown, saving both time and energy.
Quick Resume
Save time by not waiting for the projector to cool down before it can
power up again. If the projector is accidentally turned off, this feature
allows the projector to be instantly powered on again, if selected
within a period of 100 seconds.
instant on (within
100ms)
Using the inherent speed of DLP technology,
The Optoma DS330. Full 3D projector can
display true 3D content form any 3D display
device, such as 3D Blu-ray, PS3, Xbox and
Sky3D.
Easy Lamp Replacement
Top loading lamp cover allows easy access to replace lamps without
having to remove the projector from the mount.
Full 3D Ready
Remote Mouse
Keep your audience’s attention focussed on the right things using the
simple, yet powerful remote with USB mouse control.
Wireless Presenting (optional extra)
Making presentations couldn't be easier using the optional wireless
features of the DS330. Using the Wireless Adapter (sold separately)
you can connect and display presentations and video material
wirelessly from a laptop, PC or mobile device. (Additional power
required)

Specification Table
Display Technology Single 0.55” SVGA DC3 DMD chip DLP® Technology by Texas Instruments
Native Resolution SVGA 800 x 600
Brightness - BRIGHT mode12800 ANSI Lumens
Contrast 13,000:1
Noise Level 26dB (min)
Weight 2.21 kg
I/O Connectors Inputs: HDMI (v1.4a 3D), 2 x 15 Pin D-sub (RGB/YPbPr), S-Video, Composite, Audio In, USB (remote mouse)
Outputs: 15 Pin D-sub, Audio Out
Control: RS232 - 9 Pin
Preset Mode PC: For computer or notebook (Brightest image)
Movie: Maximum contrast and Colour accuracy
Game: Bright vivid colour
sRGB: For Standard PC Colour (Best Colour Reproductiion)
User: Memorises user's settings
Maximum Resolution UXGA 1600 x 1200
Computer Compatibility UXGA, SXGA, XGA, SVGA, VGA, Mac
Video Compatibility PAL (B, D, G, H, I, M, N, 576i/p), NTSC (M, 4.43/3.58 MHz, 480i/p), SECAM (B, D, G, K, K1, L) HD (1080i, 720p)
Displayable Colours 1073.4 Million
Projection Lens F/2.51~2.69; f=21.95~24.18mm, 1.1x Manual Zoom
Throw Ratio 1.97 - 2.17:1
Projection Screen Size 0.69m – 7.62m (27.24” - 300.04”) Diagonal 4:3
Projection Distance 1.2 - 12 metres
Horizontal Scan Rate 15.3 - 91.1kHz
Vertical Scan Rate 24 - 85Hz
Lamp Type/Lamp Life2190W, 10,000 hours² (Education Cycle) 6500/6000/4500 hours (Eco+/Dynamic/BRIGHT mode)
Keystone Correction ± 40° Vertical
Audio 2W
Dimensions (W x D x H) 316 x 224 x 124mm
Remote Control Full function remote with remote mouse and direct source selecting
Power Supply 100-240V, 50-60Hz
Power Consumption 234W BRIGHT mode < 0.5W Standby mode, 202W Eco+ mode < 0.5W Standby mode
Operating Conditions 5°C - 40°C, Max. Humidity 85%, Max. Altitude 3000m
Uniformity 85%
Security Security Bar, Kensington Lock, Password Protection
Standard Accessories AC Power Cord, VGA Cable, Infra Red Remote Control with Batteries, Quick Start Card, CD User Manual, Warranty Card
Optional Accessories Ceiling Mount Kit
RoHS Compliant
3D Support The 3D features of Optoma projectors can only be used with compatible 3D content. Typical applications include use with 3D
educational or 3D design and modelling systems. 3D TV broadcast systems, (SKY in the UK), Blu-ray 3D™ and 3D games
from the Sony® PS3 or Microsoft® Xbox 360 are now supported as part of the HDMI v1.4a specification.
3D Viewing Requires the Optoma DLP-Link shutterglasses - available separately.
3D Compatibility Side-by-Side:1080i50 / 60, 720p50 / 60
Frame-pack: 1080p24, 720p50 / 60
Over-Under: 1080p24, 720p50 / 60
Offset 115%

DS330 Remote Control
1. Power
2. Mouse select
3. Source
4. Re-sync
5. Left mouse click
6. Right mouse click
7. Mouse control
8. Display mode
9. Page up/down control
10. Vertical keystone
correction
11. Volume control
12. Brightness
13. Menu
14. Direct input source select
15. Eco AV mute
16. Eco+
17. 3D control
Easy To Use Remote
DS330 Connections
18. Audio In (VGA)
19. S-Video
20. VGA 1
21. VGA Out
22. HDMI
23. RS232
24. USB (Remote Mouse)
25. Audio In (S-Video/Video)
26. KensingtonTM Lock
27. Audio Out
28. Video
29. VGA 2
Exceptional Connectivity / Multiple Terminals
Projection Distance 1.2 - 12m (4:3 Aspect Ratio)
Projection
Distance (m)
Max. Horizontal
Image Size (m)
Min. Horizontal
Image Size (m)
Max. Vertical
Image Size (m)
Min. Vertical
Image Size (m)
Min Diagonal
Image Size (m)
Max Diagonal
Image Size (m)
Min Diagonal
Image Size (inch)
Max Diagonal
Image Size (inch)
Max. Image
Offset (m)
1.20 0.61 0.55 0.46 0.42 0.69 0.76 27.24 30.00 0.07
2.00 1.02 0.92 0.76 0.69 1.15 1.27 45.40 50.01 0.11
2.50 1.27 1.15 0.95 0.87 1.44 1.59 56.75 62.51 0.14
3.00 1.52 1.38 1.14 1.04 1.73 1.91 68.10 75.01 0.17
4.00 2.03 1.84 1.53 1.39 2.31 2.54 90.80 100.01 0.23
5.00 2.54 2.30 1.91 1.73 2.88 3.18 113.50 125.02 0.29
6.00 3.05 2.76 2.29 2.08 3.46 3.81 136.19 150.02 0.34
7.00 3.55 3.23 2.67 2.43 4.04 4.45 158.89 175.03 0.40
8.00 4.06 3.69 3.05 2.77 4.61 5.08 181.59 200.03 0.46
9.00 4.57 4.15 3.43 3.12 5.19 5.72 204.29 225.03 0.52
10.00 5.08 4.61 3.82 3.46 5.77 6.35 226.99 250.04 0.57
11.00 5.58 5.07 4.20 3.81 6.34 6.99 249.69 275.04 0.63
12.00 6.09 5.53 4.58 4.16 6.92 7.62 272.39 300.04 0.69

Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.co.uk
1Brightness and lamp lifetime will vary depending on the selected projector mode, environmental conditions and usage. As is common
with all lamp based projectors, brightness will decrease over the lamp lifetime. 2Typical lamp life achieved through testing and will vary
according to operational use and environmental conditions. 10,000 hours lamp life is based on a daily cycle that reflects projector
usage in a typical education environment. Details of this cycle are available on request. 3Optoma guarantees that in normal use,
Optoma DLP® colour quality will be indistinguishable from when new. Exclusions: (a) Guarantee is voided if the projector is subject to
damage through misuse. (b) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is
excessive (c) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working due to other faults.
(d) Over time worn lamps within all projector types will show a slight colour variance. Copyright © 2013, Optoma Europe Ltd. All other
product names and company names used herein are for identification purposes only and may be trademarks or registered trademarks
of their respective owners. Errors and omissions excepted, all specifications are subject to change without notice. DLP®,
BrilliantColor™ and the DLP logo are registered trademarks of Texas Instruments. All images of products are for representation
purposes only. Whilst every care is taken to provide accurate images of our products, actual products may differ slightly. Some product
images may have been digitally altered by us to add an Optoma logo to the front panel. Optoma reserves the right to amend or alter
actual product, product specifications or product images without notice. Some images may be simulated.
