Optoma EW556 User manual

Mobile, Eco+
Widescreen
Projector
EW556
DLP®Projector
www.optoma.eu
Eco+
Up to 6500h increased lamp life
+ 70% energy saving
WXGA
16:10
Widescreen presentations & HD entertainment
3200 L
3200L - Project in ambient light
13,000:1
Detailed images, crisper whites & ultra rich
blacks with 13,000:1 contrast
HDMI
HDMI – Hassle free one cable connection
5
Eco
+
HD Ready
3D-XL
Ready

EW556
ECO+MODE
Saving energy, saves money! Eco+technology reduces the power
consumption to as little as 30%. This intelligent feature also has
a positive effect on the lamp life, increasing it up to 70% while lowering
the total cost of ownership and reducing maintenance*.
100%
80%
30%
Eco mode
Bright mode
Eco+
Power Consumption
Dynamically adjusts the brightness and power consumption
Bright scene
~100% Power consumption
Dark scene
~ 30% Power consumption
AUTO POWER OFF
There may be instances when the projector is left running when not
in use. To help save energy if the projector is left running and no source
is detected, the “Auto Power Off” feature automatically turns off the
projector after a set period of time.
ECO AV MUTE
Stay in control of your presentation with the Eco AV mute feature.
Direct your audience’s attention away from the screen by blanking the
image when no longer needed. This also instantly reduces the power
consumption to 30%, further prolonging the life of your lamp.
Eco AV mute off
100% Power consumption
Eco AV mute on
30% Power consumption
ENVIRONMENTALLY FRIENDLY
To achieve the maximum 6500hrs2lamp life, the projector should
be operating in Eco+mode and the auto power off feature should
be enabled to automatically switch off the projector if it is accidentally
left on. Enabling the <0.5W standby mode ensures the minimum
energy consumption when the projector is not switched on.
We know that improving our products is the best
way to reduce our impact on the environment.
That’s why at Optoma, we design our products
to have a long usable life, use fewer materials,
ship with the minimum packaging and be free
of all possible toxic substances. Naturally, energy
efficiency and being recyclable are built in at the
design stage. With each new product, we strive
towards minimising our environmental impact.
For full details of Optoma Project Green please
visit our website.
Mobile, Eco+Widescreen Projector
The EW556 is an ultra-bright 3200L widescreen HD ready projector, with a 13,000:1 contrast allowing you to project
detailed, crystal clear images with superb colour using DLP®and BrilliantColor™ technologies. Perfectly suited for
classrooms, meeting rooms and boardrooms with ambient light. Simply connect to your projector via HDMI for a one
cable hassle free connection.
Installed or on the move, the versatile EW556 incorporates a built in speaker, 120Hz 3D Ready technology, optional
wireless capabilities and Eco+technology that brings together superb picture quality and performance with optimized
lamp life through energy saving features that are easy to use.
GREEN SOLUTIONS
ECO+TECHNOLOGY FROM OPTOMA INCREASES OUR COMMITMENT TO REDUCING THE
IMPACT WE ALL MAKE ON THE ENVIRONMENT
Eco
+

BRIGHT, CLEAR, FOCUSED IMAGES
Bright 3200 ANSI Lumens, Perfect for projecting in lights
on environments. And with DarkChip3™ technology from Texas
Instruments combined with Eco+technology produces a stunning
13,000:1 contrast ratio for pin sharp graphics and crystal clear text.
Crisper whites, ultra-rich blacks make images come alive and text
easier to read - ideal for business and education presentations.
2000:1 Contrast Ratio 13,000:1 Contrast Ratio
3D TECHNOLOGY
Using the inherent speed of DLP technology, The
Optoma EW556 can output video and images
at an astonishing rate of 120Hz, allowing you
to show full screen, full colour, stereoscopic 3D.
Typical applications include use with 3D educational or 3D design and
modelling systems. See website for updates.
TRUE WXGA RESOLUTION
The EW556 is the perfect companion for widescreen laptops. Your
presentations will appear as sharp and detailed as they do on your
widescreen laptop in WXGA (1280 x 800). WXGA resolution gives 30%
more pixels than XGA.
WIRELESS PRESENTING (OPTIONAL EXTRA)
Making presentations couldn’t be easier using the optional
wireless features of the EW556. Using the wireless VGA dongle
(Additional power required and sold separately) you can connect and
display presentations and video material wirelessly from a laptop,
PC or mobile device.
CONTROL
The extensive RS232 command set makes it simple and easy to control
the EW556 with any control system.
AMX Compatibility – Dynamic Discovery Protocol
is incorporated into the EW556. This feature allows
for easy installation with AMX control systems.
AUDIO CAPABILITY
Built-in speakers offers excellent audio support. The EW556 is easy
to set up without the need for costly external speakers.
RAPID OFF
It takes less than 10 seconds for the projector to power up and
shutdown, saving both time and energy.
QUICK RESUME
Allows you to saving time by not waiting for the projector to cool down
before it can power up again. If the projector is accidentally turned
off, this feature allows the projector to be instantly powered on again,
if selected within a period of 100 seconds.
COOLING
Instant ON
(within 100s)
N
AMAZING COLOURS
The EW556 incorporates BrilliantColor™ technology to produce
stunningly bright images with perfectly balanced life-like colours.
COLOUR GUARANTEE
We are so confident that the EW556 image colour quality will remain as
good as the day you bought it that Optoma will guarantee it for five years.
5
FEATURES
 Top cover lamp replacement
 Keypad lock
 Quick keystone correction
 Password protection for added security
 USB mouse
 Carry case
EW556
3D-XL
Ready

EW556 Projection Distance 1.2 - 12m (16:10 Aspect Ratio)
Projection Distance (m) Max. Horizontal
Image Size (m)
Min. Horizontal
Image Size (m) Max. Vertical Image Size (m) Min. Vertical Image Size (m) Max Diagonal Image Size (m) Max Diagonal Image Size (inch) Max. Image Offset (m)
1.20
2.00
2.50
3.00
4.00
5.00
6.00
7.00
8.00
9.00
10.00
11.00
12.00
0.77
1.29
1.61
1.94
2.58
3.23
3.87
4.52
5.16
5.81
6.45
7.10
7.74
0.71
1.18
1.47
1.76
2.35
2.94
3.53
4.12
4.71
5.29
5.88
6.47
7.06
0.48
0.81
1.01
1.21
1.61
2.02
2.42
2.82
3.23
3.63
4.03
4.44
4.84
0.44
0.74
0.92
1.10
1.47
1.84
2.21
2.57
2.94
3.31
3.68
4.04
4.41
0.91
1.52
1.90
2.28
3.04
3.80
4.56
5.33
6.09
6.85
7.61
8.37
9.13
35.94
59.91
74.88
89.86
119.81
149.76
179.72
209.67
239.62
269.58
299.53
329.48
359.44
0.06
0.10
0.13
0.15
0.20
0.25
0.30
0.35
0.40
0.45
0.50
0.55
0.60
For guide purposes only
EW556 is capable of 4:3 aspect ratio projection. When projecting a 4:3 image the image sizes, screen height and offset information will differ from the above.
EW556 SPECIFICATIONS
Native Resolution WXGA 1280 x 800
Max Supported Resolution UXGA (1600 x 1200)
Brightness - BRIGHT mode13200 ANSI Lumens
Contrast Ratio 13,000:1
Noise Level 28dB (ECO+mode)
Lamp Life26500/5000/4500 (Eco+/Eco/Bright mode)
Weight / Dimensions (W x D x H) 2.2 kg / 288 x 220 x 84mm
Projection Lens F/2.5 - 2.67; f=21.8 - 23.98mm, 1.1x Manual Zoom
Throw Ratio 1.55 - 1.7:1 (Projection Distance:Image Width)
Projection Distance 1.2 - 12m
Image Size 0.83 - 9.13m (32.77” - 359.44”) Diagonal 16:10
Display Technology Single 0.65” WXGA DC3 DMD chip DLP®Technology
by Texas Instruments
Remote Control Full function remote with, mouse controls and direct source
selecting
Inputs HDMI
2 x 15 Pin D-Sub VGA Component via adaptor
S-Video 4 Pin Mini Din
Composite RCA
3.5mm Audio Mini Jack
USB (remote mouse)
Control RS232 - 9 Pin D-sub
OUTPUT 15 Pin D-Sub VGA
3.5mm Audio Mini Jack
Audio 2W Speaker
Aspect Ratio 16:10 Native, 16:9/4:3 Compatible
Keystone Correction ± 40° Vertical
On Screen Display 18 Languages: English, German, French, Italian, Spanish,
Portuguese, Polish, Dutch, Russian, Finnish, Swedish,
Greek, Norwegian/Danish, Hungarian, Czech, Turkish,
Arabic & Farsi
Video Compatibility PAL SECAM 576i/p, NTSC 480i/p, HD 720p/1080i/1080p
Uniformity 85%
Displayable Colours 1.07 Billion
Horizontal Scan Rate 15.4 - 91.1kHz
Power Supply 100 - 240V, 50 - 60Hz
Power Consumption 275W BRIGHT mode < 0.5W Standby mode
220W ECO mode < 0.5W Standby mode
200W ECO+mode < 0.5W Standby mode
Operating Conditions Operating: 5 - 40˚C, 85% Humidity (Max),
3000m Altitude (Max)
Security Security Bar, Kensington Lock Port, Password Protection
Standard Accessories Soft Carry Bag, AC Power Cord, VGA Cable, Full Function
Remote, Batteries x 2, Quick Start Guide, CD User Manual,
Warranty Card
RoHS Compliant
Lamp Warranty 6 months or 1000 hours - whichever comes sooner
Warranty Warranty may vary by country. Please see
www.optomaeurope.com or ask your local
supplier for details
Colour Guarantee35 Years
3D Support 120Hz frame sequential 3D for resolutions up to 720p.
60Hz field sequential 3D for resolutions up to 480i
3D Viewing Requires Optoma DLP®Link™ active shutter glasses –
sold separately
3D Compatibility The 3D features of Optoma projectors can only be used
with compatible 3D content. Typical applications include
use with 3D educational or 3D design and modelling
systems. Support for 3D TV broadcast systems, (SKY in the
UK), Blu-ray 3D™ and 3D games from the Sony®PS3
or Microsoft®Xbox 360 will require the Optoma 3D-XL
that is available separately.
Optoma Europe Ltd.
42 Caxton Way, Watford Business Park, Watford, Hertfordshire, UK. WD18 8QZ
www.optoma.eu
*Depends on projector model and lamp.1Brightness and lamp lifetime will vary depending on selected projector mode, environmental conditions and usage. As is common with all lamp based projectors, brightness will decrease over the lamp lifetime. 2Typical lamp
life achieved through testing. Will vary according to operational use and environmental conditions. 3Optoma guarantees that in normal use, Optoma DLP®colour quality will be indistinguishable from when new. Exclusions: (a) Guarantee is voided if the projector
is subject to damage through misuse. (b) Guarantee may be void in industrial or commercial entertainment environments where dust or smoke is excessive (c) Guarantee will not apply if lamp brightness is below 50% due to wear or if the projector is not working
due to other faults.(d) Over time worn lamps within all projector types will show a slight colour variance.Copyright © 2012, Optoma Europe Ltd.All other product names and company names used herein are for identification purposes only and may be trademarks
or registered trademarks of their respective owners. Crestron®, the Crestron and RoomView®logo are registered trademarks of Crestron Electronics, Inc. Errors and omissions excepted, all specifications are subject to change without notice. DLP®, BrilliantColor™
and the DLP logo are registered trademarks of Texas Instruments.All images of products are for representation purposes only.Whilst every care is taken to provide accurate images of our products, actual products may differ slightly. Some product images may
have been digitally altered by us to add an Optoma logo to the front panel. Optoma reserves the right to amend or alter actual product or product images without notice. Some images may be simulated.
EASY TO USE REMOTE CONTROL
Exceptional Connectivity / Multiple Terminals
EW556 Remote Control
1Power
2Mouse select
3Source
4Re-sync
5Left mouse click
6Right mouse click
7Mouse control
8Display mode
9Page up/down control
10 Vertical keystone correction
11 Volume control
12 Brightness
13 Menu
14 Direct input source select
15 Eco AV mute
16 Eco+
17 3D control
EW556 Connections
18 USB (Remote mouse)
19 HDMI
20 Video
21 S-Video
22 VGA Out
23 VGA 1
24 RS232
25 Audio In
26 VGA 2
27 KensingtonTM Lock
28 Audio Out
V1- 22/06/12
EW556
2
1
3
7
6
13
15
10 11
16
5
4
9
8
12
14
17
18 20 21 22 23
26
24
27
28
19 25
